Page 121 of 588

121
iA_OM_OM99M17z_(U)
2-7. Security System
2
Before Driving
Immobilizer System
If someone attempts to start the engine with an unrecognized key, the
engine will not start, thereby helping to prevent vehicle theft.
If you have a problem with the immobilizer system or the key, consult
your Scion dealer.
● The keys carry a unique electronic code. For this reason, and to assure your
safety, obtaining a replacement key requires some waiting time. They are
only available through your Scion dealer.
● Always keep a spare key in case one is lost. If a key is lost, consult your
Scion dealer as soon as possible.
● If you lose a key, your Scion dealer will reset the electronic codes of your
remaining keys and immobilizer system. Bring all the remaining keys to your
Scion dealer to reset.
Starting the vehicle with a key that has not been reset is not possible.
The immobilizer system allows th e engine to start only with a
key the system recognizes.
NOTICE
● Radio equipment like this is governed by laws in the United States.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
● To avoid damage to the key, do not:
• Drop the key.
• Get the key wet.
• Expose the key to any kind of magnetic field.
• Expose the key to high temperatures on places such as the dashboard
or hood, under direct sunlight.
● If the engine does not start with the correct key, and the security indicator
light keeps illuminating or flashing, the system may have a malfunction.
Consult your Scion dealer.
Page 122 of 588

122
iA_OM_OM99M17z_(U)
2-7. Security System
■Arming
The system is armed when the
ignition is switched from ON to
off.
The security indicator light in
the combination meter flashes
every 2 seconds until the sys-
tem is disarmed.
■Disarming
The system is disarmed when the ignition is switched ON with the
correct programmed key. The security indicator light illuminates for
about 3 seconds and then turns off. If the engine does not start with
the correct key, and th e security indicator light remains illuminated
or flashing, try the following:
Make sure the key is within the operational range for signal trans-
mission. Switch the ignition off, and then restart the engine. If the
engine does not start after 3 or more tries, contact your Scion
dealer.
● The engine may not start and security indicator light may illuminate or flash
if the key is placed in an area where it is difficult for the system to detect the
signal, such as on the dashboard or in the glove compartment. Move the
key to a location within the signal range, switch the ignition off, and then
restart the engine.
● Signals from a TV or radio station, or from a transceiver or mobile telephone
could interfere with your immobilizer system. If you are using the proper key
and the engine fails to start, check the security indicator light.
● If the security indicator light flashes continuously while you are driving, do
not shut off the engine. Go to your Scion dealer and have it checked. If the
engine is shut off while the indicator light is flashing, you will not be able to
restart it.
● Because the electronic codes are reset when the immobilizer system is
repaired, the keys are needed. Make sure to bring all the keys to your Scion
dealer so that they can be programmed.
Operation
Page 123 of 588

123
iA_OM_OM99M17z_(U)
2-7. Security System
2
Before Driving
Theft Deterrent System
The system will not function unless it’s properly armed. So when you
leave the vehicle, follow the arming procedure correctly.
■System triggering conditions
The horn sounds intermittently and the hazard warning lights flash
for about 30 seconds when the system is triggered by any one of
the following: • Unlocking a door with the key, door lock switch, or an inside door-lock knob.
• Forcing open a door, the hood or the trunk lid.
• Opening the hood by operating the hood release handle.
• Switching the ignition ON without using the push button start.
If the system is triggered again, the lights and horn will activate until
the driver’s door or the trunk lid is unlocked with the smart key.
● The trunk lid does not open while the theft deterrent system is operating.
● If the battery goes dead while the theft deterrent system is armed, the horn
will activate and the hazard warning lights will flash when the battery is
charged or replaced.
: If equipped
If the theft deterrent system detects an inappropriate entry into
the vehicle, which could result in the vehicle or its contents
being stolen, the alarm alerts the surrounding area of an abnor-
mality by sounding the horn and flashing the hazard warning
lights.
Operation
Page 124 of 588

124
iA_OM_OM99M17z_(U)
2-7. Security System
Close the windows securely.
Switch the ignition OFF.
Make sure the hood, the doors, and the trunk lid are closed.
Press the lock button on the smart key or lock the driver’s door from
the outside with the auxiliary key.
The hazard warning lights will flash once.
The following method will also arm the theft deterrent system:
Press the door-lock switch “ ” while any door is open and then
close all of the doors.
The security indicator light in
the instrument panel flashes
twice per second for 20 sec-
onds.
After 20 seconds, the system is fully armed.
● The theft deterrent system can also be armed by activating the auto relock
function with all the doors, the trunk lid and the hood closed. Refer to Smart
Key on P. 89.
● The system will disarm if one of the following operations takes place within
20 seconds after pressing the lock button:
• Unlocking any door.
• Opening any door or the trunk lid.
• Opening the hood.
• Switching the ignition ON.
To rearm the system, do the arming procedure again.
● When the doors are locked by pressing the lock button on the smart key or
using the auxiliary key while the theft deterrent system is armed, the hazard
warning lights will flash once to indicate that the system is armed.
How to Arm the System
1
2
3
4
5
Page 125 of 588

iA_OM_OM99M17z_(U)
1252-7. Security System
2
Before Driving
An armed system can be turned off using any one of the following
methods:
● Pressing the unlock button on the smart key.
● Starting the engine with the push button start.
The hazard warning lights will flash twice.
When the doors are unlocked by pressing the unlock button on the smart key
while the theft deterrent system is turned off, the hazard warning lights will
flash twice to indicate that the system is turned off.
A triggered alarm can be turned off using any one of the following
methods:
● Pressing the unlock button on the smart key.
● Starting the engine with the push button start.
The hazard warning lights will flash twice.
A label indicating that your vehicle
is equipped with a Theft Deterrent
System is in the glove compart-
ment.
Scion recommends that you affix
it to the lower rear corner of a front
door window.
To Turn Off an Armed System
To Stop the Alarm
Theft Deterrent Labels
Page 126 of 588

126
iA_OM_OM99M17z_(U)
2-8. Driving Tips
Break-In Period
No special break-in is necessary, but a few precautions in the first 600
miles (1,000 km) may add to the performance, economy, and life of
the vehicle.
● Do not race the engine.
● Do not maintain one constant speed, either slow or fast, for a long
period of time.
● Do not drive constantly at full-throttle or high engine rpm for
extended periods of time.
● Avoid unnecessary hard stops.
● Avoid full-throttle starts.
Page 127 of 588

127
iA_OM_OM99M17z_(U)
2-8. Driving Tips
2
Before Driving
Saving Fuel and Protection of the Environment
How you operate your Scion determines how far it will travel on a tank
of fuel. Use these su ggestions to help save fuel and reduce CO2.
● Avoid long warm-ups. Once the engine runs smoothly, begin driv-
ing.
● Avoid fast starts.
● Drive at lower speeds.
● Anticipate when to apply the brakes (avoid sudden braking).
● Follow the maintenance schedule and have your Scion dealer per-
form inspections and servicing.
● Use the air conditioner only when necessary.
● Slow down on rough roads.
● Keep the tires properly inflated.
● Do not carry unnecessary weight.
● Do not rest your foot on the brake pedal while driving.
● Keep the wheels in correct alignment.
● Keep windows closed at high speeds.
● Slow down when driving in crosswinds and headwinds.
WARNING
■Never stop the engine when going down a hill
Stopping the engine when going down a hill is dangerous. This causes the
loss of power steering and power brake control, and may cause damage to
the drivetrain. Any loss of steering or braking control could cause an acci-
dent.
Page 128 of 588

128
iA_OM_OM99M17z_(U)
2-8. Driving Tips
Hazardous Driving
When driving on ice or in water, snow, mud, sand, or similar hazards:
●Be cautious and allow extra distance for braking.
● Avoid sudden braking and sudden maneuvering.
● Do not pump the brakes. Continue to press down on the brake
pedal. Refer to Antilock Brake System (ABS) on P. 193.
● If you get stuck, select a lower g ear and accelerate slowly. Do not
spin the front wheels.
● For more traction in starting on slippery surfaces such as ice or
packed snow, use sand, rock salt, chains, carpeting, or other non-
slip material under the front wheels.
Use snow chains only on the front wheels.
WARNING
■ Be extremely careful if it is necessary to downshift on slippery sur-
faces
Downshifting into lower gear while driving on slippery surfaces is danger-
ous. The sudden change in tire speed could cause the tires to skid. This
could lead to loss of vehicle control and an accident.
Page 129 of 588

129
iA_OM_OM99M17z_(U)
2-8. Driving Tips
2
Before Driving
Floor Mat
When setting a floor mat, position
the floor mat so that its grommets
are inserted over the pointed end
of the retention posts.
WARNING
■Make sure the floor mats are hooked on the retention pins to prevent
them from bunching up under the foot pedals
Using a floor mat that is not secured is dangerous as it will interfere with the
accelerator and brake pedal operation, which could result in an accident.
■ Do not install two floor mats, one on top of the other, on the driver’s
side
Installing two floor mats, one on top of the other, on the driver’s side is dan-
gerous as the retention pins can only keep one floor mat from sliding for-
ward.
If using a heavy duty floor mat for winter use always remove the original
floor mat.
Loose floor mat(s) will interfere with the foot pedal and could result in an
accident.
Page 130 of 588

130
iA_OM_OM99M17z_(U)
2-8. Driving Tips
Rocking the Vehicle
If you must rock the vehicle to free it from snow, sand or mud, depress
the accelerator slightly and slowly move the shift lever from 1 (D) to R.
WARNING
■Do not spin the wheels at more th an 35 mph (56 km/h), and do not
allow anyone to stand behind a wheel when pushing the vehicle
When the vehicle is stuck, spinning the wheels at high speed is dangerous.
The spinning tire could overheat and explode. This could cause serious
injuries.
NOTICE
Too much rocking may cause engine overheating, transaxle failure, and tire
damage.
