TOYOTA iA 2016 Owners Manual (in English)

iA_OM_OM99M17z_(U)
4715-4. Appearance Care
5
Maintenance and Care
●Do not use abrasive cleansers or wax that contain abrasives.
Pay special attention to removing salt, dirt, mud, and other foreign
material from the underside of the fenders, and make sure the drain
holes in the lower edges of the doors and rocker panels are clean.
Insects, tar, tree sap, bird droppings, industrial fallout, and similar
deposits can damage the finish if not removed immediately. When
prompt washing with plain water is ineffective, use a mild soap made
for use on vehicles.
Thoroughly rinse off all soap with lukewarm or cold water. Do not
allow soap to dry on the finish.
After washing the vehicle, dry it wi th a clean chamois to prevent water
spots from forming.
● When using an automatic car wash
• Retract the door mirrors.
• The automatic car wash brushes could reduce the paint luster or hasten paint deterioration.
● When using a high water pressure car wash
High water temperature and high water pressure car washers are
available depending on the type of car wash machine. If the car
washer nozzle is put too close to the vehicle, the force of the spray
could damage or deform the molding, affect the sealability of parts,
and allow water to penetrate the in terior. Keep a sufficient space
(12 in. (300 mm) or more) between the nozzle and the vehicle. In
addition, do not spend too much time spraying the same area of the
vehicle, and be very careful when spraying between gaps in doors
and around windows.
■Waxing
Your vehicle needs to be waxed when water no longer beads on the
finish. Always wash and dry the vehicle before waxing it. In addition
to the vehicle body, wax the metal trim to maintain its luster.
Use wax which contains no abrasives. Waxes containing abra-
sive will remove paint and co uld damage bright metal parts.
Use a good grade of natural wax for metallic, mica, and solid col-
ors.
When waxing, coat evenly with the sponge supplied or a soft
cloth.
Wipe off the wax with a soft cloth.
1
2
3
4

4725-4. Appearance Care
iA_OM_OM99M17z_(U)
■Maintaining the Finish
●Scion is not responsible for scratches caused by automatic car washes or
improper washing.
● Scratches are more noticeable on vehicles with darker paint finishes.
● A spot remover to remove oil, tar, and similar materials will usually also take
off the wax. Rewax these areas even if the rest of the vehicle does not need
it.
WARNING
■Dry off brakes that have become wet by driving slowly, releasing the
accelerator pedal and lightly applyi ng the brakes several times until
the brake performance returns to normal
Driving with wet brakes is dangerous . Increased stopping distance or the
vehicle pulling to one side when braking could result in a serious accident.
Light braking will indicate whether the brakes have been affected.
NOTICE
● Do not spray water in the engine compartment. Otherwise, it could result in
engine-starting problems or damage to electrical parts.
● When washing and waxing the vehicle, be careful not to apply excessive
force to any single area of the vehicle.
● Do not use steel wool, abrasive cleaners, or strong detergents containing
highly alkaline or caustic agents on chrome- plated or anodized aluminum
parts. This may damage the protective coating; also, cleaners and deter-
gents may discolor or deteriorate the paint.

iA_OM_OM99M17z_(U)
4735-4. Appearance Care
5
Maintenance and Care
Deep scratches or chips on the finish should be repaired promptly.
Exposed metal quickly rusts and can lead to major repairs.
●Use tar remover to remove road tar and insects. Never do this with
a knife or similar tool.
● To prevent corrosion on bright- metal surfaces, apply wax or
chrome preservative and rub it to a high luster.
● During cold weather or in coastal areas, cover bright-metal parts
with a coating of wax or preservati ve heavier than usual. It would
also help to coat them with nonc orrosive petroleum jelly or some
other protective compound.
Repairing Damage to the Finish
NOTICE
If your Scion is damaged and needs metal parts repaired or replaced, make
sure the body shop applies anti- corrosion materials to all parts, both
repaired and new. This will prevent them from rusting.
Bright-Metal Maintenance
NOTICE
Do not use steel wool, abrasive cleaners, or strong detergents containing
highly alkaline or caustic agents on chrome-plated or anodized aluminum
parts. This may result in damage to the protective coating and cause discol-
oration or paint deterioration.

4745-4. Appearance Care
iA_OM_OM99M17z_(U)
Road chemicals and salt used for ice and snow removal and solvents
used for dust control may collect on the underbody. If not removed,
they will speed up rusting and deterioration of such underbody parts
as fuel lines, frame, floor pan, and exhaust system, even though these
parts may be coated with anti-corrosive material.
Thoroughly flush the underbody and wheel housings with lukewarm or
cold water at the end of each winter. Try also to do this every month.
Pay special attention to these areas because they easily hide mud
and dirt. It will do more harm than good to wet down the road grime
without removing it.
The lower edges of doors, rocker panels, and frame members have
drain holes that should not be clogged. Water tr apped there will cause
rusting.
A protective coating is provided over the aluminum wheels. Special
care is needed to protect this coating.
● Do not use a wire brush or any abrasive cleaner, polishing compound, or
solvent on aluminum wheels. They may damage the coating.
● Always use a sponge or soft cloth to clean the wheels.
Rinse the wheels thoroughly with lukewarm or cold water. Also, be sure to
clean the wheels after driving on dusty or salted roads to help prevent corro-
sion.
● Avoid washing your vehicle in an automatic car wash that uses high- speed
or hard brushes.
Underbody Maintenance
WARNING
■Dry off brakes that have become wet by driving slowly, releasing the
accelerator pedal and lightly applyi ng the brakes several times until
the brake performance returns to normal
Driving with wet brakes is dangerous . Increased stopping distance or the
vehicle pulling to one side when braking could result in a serious accident.
Light braking will indicate whether the brakes have been affected.
Aluminum Wheel Main tenance (if equipped)

iA_OM_OM99M17z_(U)
4755-4. Appearance Care
5
Maintenance and Care
●When cleaning the plastic lenses of the lights, do not use gasoline,
kerosene, rectified spirit, paint, thinner, highly acidic detergents, or
strongly alkaline detergents. Otherwise, these chemical agents can
discolor or damage the surfaces resulting in a significant loss in
functionality. If plastic parts beco me inadvertently exposed to any of
these chemical agents, flus h with water immediately.
● If plastic parts such as the bum pers become inadvertently exposed
to chemical agents or fluids such as gasoline, oil, engine coolant, or
battery fluid, it could cause discoloration, stai ning, or paint peeling.
Wipe off any such chemical agents or fluids using a soft cloth imme-
diately.
● High water temperature and high water pressure car washers are
available depending on the type of high pressure car washer
device. If the car washer nozzle is put too close to the vehicle or
aimed at one area for an extended period of time, it could deform
plastic parts or damage the paint.
● Do not use wax containing compounds (polish). Otherwise, it could
result in paint damage.
● In addition, do not use an electrical or air tool to apply wax. Other-
wise, the frictional heat generat ed could result in deformation of
plastic parts or paint damage.
NOTICE
Do not use any detergent other than mild detergent. Before using any deter-
gent, verify the ingredients.
Otherwise, the product could discolor or stain the aluminum wheels.
Plastic Part Maintenance

476
iA_OM_OM99M17z_(U)
5-4. Appearance Care
Interior Care
Prevent caustic solutions such as perfume and cosmetic oils from
contacting the dashboard. They will damage and discolor the dash-
board. If these solutions get on t he dashboard, wipe them off immedi-
ately.
■Instrument panel top
● When cleaning, it is recommende d that you use a clean towel
dampened in a mild detergent to remove soiling.
● If the surface is rubbed harshly, it could result in the surface
being damaged leaving white scratch marks.
WARNING
■Do not spray water in the cabin
Splashing water on electrical parts such as the audio unit and switches is
dangerous as it could cause a malfunction or a fire.
Dashboard Precautions
NOTICE
Do not use glazing agents.
Glazing agents contain ingredients which may cause discoloration, wrin-
kling, cracks and peeling.

iA_OM_OM99M17z_(U)
4775-4. Appearance Care
5
Maintenance and Care
■Vinyl
Remove dust and loose dirt from vinyl with a whisk broom or vac-
uum cleaner. Clean vinyl with a leather-and-vinyl cleaner.
■Leather (if equipped)
Remove dust and sand first using a vacuum cleaner or other
means, then wipe dirt off using a so ft cloth with a leather cleaner or
a soft cloth soaked in mild soap. Wipe off the remaining cleaner or
soap using a cloth soaked in clean water and wrung out well.
Remove moisture with a dry, soft cloth and allow the leather to fur-
ther dry in a well-ventilated, sh aded area. If the leather gets wet
such as from rain, also remove moisture and dry it as soon as pos-
sible.
■Fabric
Remove dust and loose dirt from fabric with a whisk broom or vac-
uum cleaner. Clean it with a mild soap solution good for upholstery
and carpets. Remove fresh spots immediately with a fabric spot
cleaner.
To keep the fabric looking clean and fresh, take care of it. Other-
wise its color will be affected, it can be stained easily, and its fire-
resistance may be reduced.
■Panel
When the interior panels need to be cleaned, use soft material such
as a soft cloth soaked in clean water and wrung out well and lightly
wipe off dirt from the surface. If a panel requires further cleaning,
use the following procedure.
Wipe dirt off using a soft cloth soaked in mild detergent (about
5% solution).
Wipe off any remaining detergent using a cloth soaked in clean
water and wrung out well.
Cleaning the Upholstery and Interior Trim
1
2

4785-4. Appearance Care
iA_OM_OM99M17z_(U)
■Cleaning the Upholstery and Interior Trim
●Because genuine leather is a natural material, its surface is not uniform and
it may have natural scars, scratches, and wrinkles.
● To maintain the quality for as long as possible, periodical maintenance,
about twice a year, is recommended.
● Sand and dust on the seat surface may damage the overcoat of the genuine
leather surfaces and accelerate wear.
● Greasy soiling on genuine leather may cause molding and stains.
● Rubbing hard with a stiff brush or cloth may cause damage.
● Do not wipe the leather using alcohol, chlorine bleach, or organic solvents
such as thinner, benzene, or gasoline. Otherwise, it may cause discoloration
or stains.
● If the seats get wet, promptly remove moisture with a dry cloth. Remaining
moisture on the surface may cause deterioration such as hardening and
shrinkage.
● Exposure to direct sunlight for long periods may cause deterioration and
shrinkage. When parking the car under direct sunlight for long periods,
shade the interior using sunshades.
● Do not leave vinyl products on the seats for long periods as they may affect
the leather quality and coloring. If the cabin temperature becomes hot, the
vinyl may deteriorate and adhere to the genuine leather.
● Do not wipe leather parts using alcohol, chlorine bleach, or organic solvents
such as thinner, benzene, or gasoline. Otherwise, it may cause discoloration
or stains.
• Scratches or nicks on the panels and metallic trim resulting from the use
of a hard brush or cloth may not be repairable. Be particularly careful
when cleaning high lustre panels and metallic trim as they can be easily
scratched.
NOTICE
Use only recommended cleaners and procedures. Others may affect
appearance and fire-resistance.

iA_OM_OM99M17z_(U)
4795-4. Appearance Care
5
Maintenance and Care
Clean the webbing with a mild soap solution recommended for uphol-
stery or carpets. Follow instructions. Do not bleach or dye the web-
bing; this may weaken it.
After cleaning the belts, thoroughly dry the belt webbing and make
sure there is no remaining moisture before retracting them.
If the windows become covered with an oily, greasy, or waxy film,
clean them with glass cleaner. Follow the directions on the container.
Rubber floor mats should be cleaned with mild soap and water only.
After removing the floor mats for cleaning, always reinstall them
securely. ( P. 129)
Cleaning the Lap/Shoulder Belt Webbing
WARNING
■Have your Scion dealer replace damaged seat belts immediately
Using damaged seat belts is dangerous. In a collision, damaged belts can-
not provide adequate protection.
Cleaning the Window Interiors
NOTICE
● Do not scrape or scratch the inside of the window glass. It could damage
the thermal filaments.
● When washing the inside of the window glass, use a soft cloth dampened
in lukewarm water, gently wiping the thermal filaments.
Use of glass cleaning products could damage the thermal filaments.
Cleaning the Floor Mats
WARNING
■Do not use rubber cleaners, such as tire cleaner or tire shine, when
cleaning rubber floor mats
Cleaning the rubber floor mats with rubber cleaning products makes the
floor mats slippery.
This may cause an accident when depressing the accelerator, brake, or
clutch (Manual transaxle) pedal or when getting in or out of the vehicle\
.

4805-4. Appearance Care
iA_OM_OM99M17z_(U)
