TOYOTA iM 2016 Owners Manual (in English)

Scion iM_U (12J49U)
Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3
Operation of
each
componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advice which are necessary for
driving
5Interior featuresUsage of the interior features, etc.
6Maintenance
and careCaring for your vehicle and maintenance
procedures
7When trouble
arisesWhat to do in case of malfunction or emergency
8Vehicle
specificationsVehicle specifications, customizable features, etc.
9For ownersReporting safety defects for U.S. owners, and seat
belt and SRS airbag instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically

TABLE OF CONTENTS2
Scion iM_U (12J49U)For your information....................... 6
Reading this manual .................... 10
How to search .............................. 11
Pictorial index .............................. 12
1-1. For safe use
Before driving ...................... 22
For safety drive ................... 24
Seat belts ............................ 26
SRS airbags ........................ 32
Front passenger occupant classification system ......... 45
Safety information for children ........................ 51
Child restraint systems ........ 52
Installing child restraints ...... 56
Exhaust gas precautions ..... 65
1-2. Theft deterrent system Engine immobilizer system............................... 66
Theft prevention labels (U.S.A.) ............................. 68
2. Instrument cluster Warning lights and indicators........................... 70
Gauges and meters............. 74
Multi-information display ..... 76 3-1. Key information
Keys..................................... 84
3-2. Opening, closing and locking the doors
Side doors ........................... 88
Back door ............................ 91
3-3. Adjusting the seats Front seats........................... 95
Rear seats ........................... 96
Head restraints .................... 98
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................... 101
Inside rear view mirror ....... 103
Outside rear view mirrors ............................. 104
3-5. Opening and closing the windows
Power windows.................. 106
1For safety and security
2Instrument cluster
3Operation of each
component

3
1
8 7
6
5
4
3
2
9
Scion iM_U (12J49U)4-1. Before driving
Driving the vehicle ............. 110
Cargo and luggage............ 120
Vehicle load limits ............. 123
Trailer towing..................... 124
Dinghy towing (vehicles with a
continuously variable
transmission)................... 125
Dinghy towing (vehicles with a
manual transmission) ...... 126
4-2. Driving procedures Engine (ignition) switch ..... 128
Continuously variable transmission .................... 131
Manual transmission ......... 135
Turn signal lever................ 137
Parking brake .................... 138
4-3. Operating the lights and wipers
Headlight switch ................ 139
Windshield wipers and washer ............................ 143
Rear window wiper and washer ............................ 145
4-4. Refueling Opening the fuel tank cap .................................. 147
4-5. Using the driving support systems
Cruise control .................... 151
Driving assist systems....... 156
4-6. Driving tips Winter driving tips.............. 162 5-1. Using the air conditioning
system and defogger
Automatic air conditioning system ......... 166
5-2. Using the interior lights Interior lights list................. 173
• Front interior light/ front personal lights ....... 174
• Rear interior light ........... 175
• Vanity lights ................... 175
5-3. Using the storage features
List of storage features ...... 176
• Glove box ...................... 177
• Console box .................. 177
• Bottle holders ................ 178
• Cup holders ................... 179
• Auxiliary boxes .............. 180
Luggage compartment features ........................... 181
5-4. Other interior features Other interior features........ 185
• Sun visors ..................... 185
• Vanity mirrors ................ 185
• Clock ............................. 185
• Power outlet .................. 186
• Armrest.......................... 186
• Assist grips .................... 187
• Using the AUX port/ USB port........................ 187
• Steering wheel audio switches ........................ 188
• Using the microphone ................... 188
4Driving5Interior features

TABLE OF CONTENTS4
Scion iM_U (12J49U)6-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 190
Cleaning and protecting the vehicle interior ........... 193
6-2. Maintenance Maintenance requirements ................... 196
General maintenance ........ 198
Emission inspection and maintenance (I/M)
programs ......................... 202
6-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 203
Hood.................................. 205
Positioning a floor jack ...... 207
Engine compartment ......... 208
Tires .................................. 220
Tire inflation pressure........ 230
Wheels .............................. 233
Air conditioning filter .......... 235
Wireless remote control battery ............................. 237
Checking and replacing fuses ............................... 239
Light bulbs ......................... 242 7-1. Essential information
Emergency flashers ........... 252
If your vehicle has to be stopped in an
emergency....................... 253
7-2. Steps to take in an emergency
If your vehicle needs to be towed ...................... 254
If you think something is wrong............................... 260
Fuel pump shut off system ............................. 261
If a warning light turns on or a warning buzzer
sounds ............................. 262
If a warning message is displayed ......................... 269
If you have a flat tire .......... 272
If the engine will not start ................................. 283
If the shift lever cannot be shifted from P .................. 284
If the vehicle battery is discharged ....................... 285
If your vehicle overheats......................... 288
If the vehicle becomes stuck ................................ 291
6Maintenance and care7When trouble arises

5
1
8 7
6
5
4
3
2
9
Scion iM_U (12J49U)8-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 294
Fuel information ................ 303
Tire information ................. 306
8-2. Customization Customizable features ...... 319
8-3. Items to initialize Items to initialize................ 324
Reporting safety defects for U.S. owners ........................ 326
Seat belt instructions for Canadian owners
(in French) ............................... 327
SRS airbag instructions for Canadian owners
(in French) ............................... 329 What to do if...
(Troubleshooting) ..................... 340
Alphabetical index ...................... 343
8Vehicle specifications
9For owners
Index

6
Scion iM_U (12J49U)Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Scion policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Approximately five hours after the engine is turned off, you may hear a sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and it does not indicate a malfunction.
A wide variety of non-genuine spare parts and accessories for Scion vehicles
are currently available in the market. You should know that Scion does not
warrant these products and is not responsible for their performance, repair, or
replacement, or for any damage they may cause to, or adverse effect they
may have on, your Scion vehicle.
This vehicle should not be modified with non-genuine Scion products. Modifi-
cation with non-genuine Scion products could affect its performance, safety
or durability, and may even violate governmental regulations. In addition,
damage or performance problems resulting from the modification may not be
covered under warranty.
For your infor mation
Main Owner’s Manual
Noise from under the vehicle after turning off the engine
Accessories, spare parts and modification of your Scion

7
Scion iM_U (12J49U)The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
l
Multiport fuel injection system/sequential multiport fuel injection system
l Cruise control system
l Anti-lock brake system
l SRS airbag system
l Seat belt pretensioner system
Be sure to check with your Scion dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.
Your Scion is equipped with several sophisticated computers that will rec\
ord
certain data, such as: • Engine speed
• Accelerator status
• Brake status
• Vehicle speed
• Shift position (vehicles with a continuously variable transmission)
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
lData usage
Scion may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Scion will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Scion in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
Installation of a mobile two-way radio system
Vehicle data recordings

8
Scion iM_U (12J49U)This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed to
record data related to vehicle dynamics and safety systems for a short period
of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fas- tened;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ-
ation occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
lDisclosure of the EDR data
Scion will not disclose the data recorded in an EDR to a third party except
when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Scion in a lawsuit
However, if necessary, Scion may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner
Event data recorder

9
Scion iM_U (12J49U)The SRS airbag and seat belt pretensioner devices in your Scion contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as a fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Scion dealer
before you scrap your vehicle.
Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
Scrapping of your Scion
Perchlorate Material
WARNING
n
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
n General precaution regard ing children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, or other features of the vehicle. In addition, heat build-up or
extremely cold temperatures inside the vehicle can be fatal to children.

10
Scion iM_U (12J49U)
WARNING:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to
or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps
in numerical order.
Indicates the action (push-
ing, turning, etc.) used to
operate switches and other
devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not do
this”, or “Do not let this hap-
pen”.
Reading this manual
123
