1715-1. Using the air conditioning system and defogger
5
Interior features
Scion iM_U (12J49U)
Open the vent
Close the vent
nUsing automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
n Fogging up of the windows
lThe windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the wind-
shield effectively.
l If you turn off, the windows may fog up more easily.
l The windows may fog up if the recirculated air mode is used.
n Outside/recirculated air mode
lWhen driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effec-
tive in preventing outside air from entering the vehicle interior. During
cooling operation, setting the recirculated air mode will also cool the vehicle
interior effectively.
l Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
n When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on
lIn order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
l Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position.
l It is possible to switch to outside air mode at any time by pressing .
1
2

1725-1. Using the air conditioning system and defogger
Scion iM_U (12J49U)n
Ventilation and air conditioning odors
lTo let fresh air in, set the air conditioning system to the outside air mode.
l During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
l To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
n Air conditioning filter
P. 235
n Customization
Settings (e.g. air conditioning setting) can be changed.
(Customizable features P. 319)
WARNING
nTo prevent the windshield from fogging up
lDo not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
n To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
NOTICE
nTo prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.
lDo not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

173
5
Interior features
Scion iM_U (12J49U)
5-2. Using the interior lights
Vanity lights (P. 175)
Front interior/front personal lights ( P. 174)
Rear interior light ( P. 175)
Interior li ghts list
1
2
3

1745-2. Using the interior lights
Scion iM_U (12J49U)n
Front interior light
Door position on
Off
nFront personal lights
On/off
When the lights are on due to
the door link switch, a light will
not turn off even if its lens is
pressed.
Front interior light/front personal lights
1
2

1755-2. Using the interior lights
5
Interior features
Scion iM_U (12J49U)
On
Door position
Off
On
Off
nIlluminated entry system
When the interior light switch is in the door position, the interior lights auto-
matically turn on/off according to the engine switch position, whether the
doors are locked/unlocked and whether the doors are open/closed.
n To prevent battery discharge
The following lights will turn off automatically after 20 minutes:
lFront interior/front personal lights
l Rear interior light
l Luggage compartment light
l Vanity lights
n Customization
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 319)
Rear interior light
1
2
3
Vanity lights
1
2

176
Scion iM_U (12J49U)
5-3. Using the storage features
List of storage features
Auxiliary boxes ( P. 180)
Glove box ( P. 177)
Bottle holders ( P. 178) Cup holders (
P. 179)
Console box ( P. 177)
WARNING
lDo not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
l When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
5

1775-3. Using the storage features
5
Interior features
Scion iM_U (12J49U)
Pull up the lever to open the glove
box.
Glove box
Console box
Console boxUpper level box
Lift the lid while pulling up the
knob on the right seat side. Lift the lid while pulling up the
knob on the left seat side.

1785-3. Using the storage features
Scion iM_U (12J49U)
lWhen storing a bottle, close the cap.
l The bottle may not be stored depending on its size or shape.
Bottle holders
FrontRear
WARNING
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glass or paper cups containing liquid. The contents may spill
and glass cups may break.

1795-3. Using the storage features
5
Interior features
Scion iM_U (12J49U)
Cup holders
FrontRear
lThe insert for the front cup holders can
be removed for cleaning.
l The front cup holders can be adjusted to
the appropriate size for a cup or drink
can by changing the insert position.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.

1805-3. Using the storage features
Scion iM_U (12J49U)
Auxiliary boxes
Ty p e AType B
Push the lid to open. Pull the lid to open.
Type B only: The tray can be removed.
WARNING
l Keep the auxiliary boxes closed. In the event of sudden braking, an acci-
dent may occur due to an occupant being struck by an open auxiliary box
or the items stored inside.
l Type A only: Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.
