Page 147 of 1399
−
BODY ELECTRICAL BODY ELECTRICAL SYSTEM
BE−3
1996 LAND CRUISER (RM451U)
Only one side taillight does not light.
1. Taillight Bulb
2. Wire Harness−
−
Taillight does not light.
(Headlight is normal.)
1. Taillight Bulb
2. TAIL Fuse (No.2 R/B)
3. Taillight Control Relay (No.2 R/B)
4. Light Control Switch
5. Wire Harness−
BE−14
BE−14
BE−14 −
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
”Hazard” and ”Turn” do not light up.
1. Hazard Warning Switch
2. Turn Signal Flasher (No.1 R/B)
3. Wire HarnessBE−19
BE−19
−
None of blinks for hazard. (Turn is normal.)
1. Bulb
2. Turn Signal Flasher (No.1 R/B)
3. Wire Harness−
BE−19 −
Hazard warning light does not light up. (Turn is normal.)1. HAZ − HORN Fuse (No.2 R/B)
2. Wire HarnessBE−19 −
Hazard warning light does not light up in one direction.1. Hazard Warning Switch
2. Wire HarnessBE−19−
The flashing frequency is abnormal.
1. Bulb
2. Turn Signal Flasher (No.1 R/B)
3. Wire Harness−
BE−19 −
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE−19−
Only one bulb does not light up for hazard turn.1. Bulb
2. Wire Harness−
−
Turn signal does not light up.
(Combination meter, wiper and washer do not operate.)
1. Ignition Switch
2. TURN Fuse (I/P F/B)
3. Turn Signal Switch
4. Wire HarnessBE−11
BE−19
BE−19 −
Turn signal does not light up.
(Combination meter, wiper and washer are normal.)1. TURN Fuse (I/P F/B)
2. Turn Signal Switch
3. Wire HarnessBE−19
BE−19−
INTERIOR LIGHT SYSTEM
SymptomSuspect AreaSee page
Room light does not light up.
1. DOME Fuse (No.2 R/B)
2. Door Courtesy Switch
3. Front Personal Light
4. Room Light Assembly
5. Bulb
6. Wire Harness−
BE−21
BE−21
BE−21 −
−
Room light remains always on.1. Door Courtesy Switch
2. Wire HarnessBE−21
−
BACK −UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back−Up light does not light up.
1. GAUGE Fuse (I/P F/B)
2. Ignition Switch
3. Park/Neutral Position Switch (A/T)
4. Bulb
5. Wire Harness−
BE−11 −
−
−
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 163 of 1399
BE27G−01
BE1843
−
BODY ELECTRICAL TURN SIGNAL AND HAZARD WARNING SYSTEM
BE−19
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT HAZARD WARNING SWITCH CONTINUITY
ConditionTester connectionSpecified condition
Switch OFF7 − 10Continuity
Switch ON7 − 8
4 − 5 − 6 − 9Continuity
Illumination circuit2 − 3Continuity
If continuity is not as specified, replace the switch.
2. INSPECT TURN SIGNAL FLASHER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
2 and the negative ( −) lead to terminal 3.
(b) Connect the 2 turn signal light bulbs parallel to each other
to terminals 1 and 3, and check that the bulbs flash.
HINT:
The turn signal lights should flash 60 to 120 times per minute.
If one of the front or rear turn signal lights has an open circuit,
the number of flashes will be more than 140 per minute.
If operation is not as specified, replace the flasher.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 1007 of 1399
PP2YT−01
PP−66
−
PREPARATION BODY ELECTRICAL
1996 LAND CRUISER (RM451U)
EQUIPMENT
Bulb (3.4 W)Fuel sender gauge
Seat belt warning relay
Bulb (21 W)Turn signal flasher relay
Clip removerFor removing cowl louver
Dry cell batteryFuel sender gauge
Masking tapeRear window defogger wire
Oil bathEngine oil level warning switch
Test lead
ThermometerEngine coolant temperature sender gauge
Engine oil level warning switch
Tin foilRear window defogger wire
Torque wrench
