I25241
ºTUNE DOWNº Switch
ºTUNE UPº Switch
- BODY ELECTRICALAUDIO SYSTEM
BE-135
2508 Author: Date:
2004 LAND CRUISER (RM1071U)
2. DIAGNOSIS FUNCTION (Sub AVC-LAN)
HINT:
As starting Main AVC-LAN to operate the diagnosis mode, Sub AVC-LAN is automatically to the mode. Per-
form the diagnosis mode operation on the RSA panel.
(a) Element check mode
After the diagnosis start-up, the system enters the element check mode. Check that the all elements
light up.
HINT:
By pressing the ºTUNE UPº switch, the system enters the ºService Check Modeº.
(b) Switch check mode
(1) Element check mode is started at the same time with the switch check mode.
(2) Check that there is a beep sound when any switch is pressed.
HINT:
By pressing ºTUNE UPº switch, the system enters the ºService Check Modeº.
Page 172 of 3115
I25241
ºTUNE DOWNº Switch
ºTUNE UPº Switch
BE-136
- BODY ELECTRICALAUDIO SYSTEM
2509 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Service check mode
(1) After the element check and switch check is completed, the system enters service check mode
when ºTUNE UPº switch is pressed.
(2) Error codes over the tuner and connected equipments are displayed on the screen of the tuner.
Results for each check are displayed as follows:
good:
No DTC is detected for both ºSystem Check Confirmationº and ºDiagnosis Memory Re-
sponseº.
nCon:
The component does not respond to the ºDiagnosis On Instructionº command.
Applicable to only the system where connected components are limited to be used.
ECHn:
Application of new version has been confirmed by the ºDiagnosis On Checkº, and there
is one or more DTC which indicates ºReplacementº in the ºSystem Check Result Re-
sponseº or ºDiagnosis Memory Responseº.
CHEC:
Application of new version has been confirmed by the ºDiagnosis On Checkº, and there
is no DTC which indicates ºReplacementº in the ºSystem Check Result Responseº or
ºDiagnosis Memory Responseº, but one or more DTC which indicates ºCheckº is identified.
Old:
Application of old version is confirmed by the ºDiagnosis On Checkº, and DTC is identified
in the ºSystem Check Result Responseº or ºDiagnosis Memory Responseº.
nrES:
No response is identified to the ºSystem Check Start Instructionº and ºRequest for System
Check Resultº commands.
HINT:
Check the present and past condition of components by performing the System Check and collecting
stored DTC memories.
Check results are displayed as one of the following six indications: ºgoodº, ºECHnº, ºCHECº,ºnConº,
ºOldº or ºnrESº.
Page 173 of 3115
Normal Mode
Service Check ModePhysical Address (When checking,
P1F4 is blinking)
A long beep (3 sec.) 3 beeps
Memory Clear ModeAfter 3 sec.
P1F4
ECHn
CLr Example:
Connection parts ( physical address): Radio receiver (P190), RSA ECU (P1F4), DVD player (P1A0)
Diagnosis of main AVC- LAN
start up.
HINT:
To exit diagnosis mode, press
the ºDISCº switch for 1.7 sec. or
turn ignition switch to ACC or
OFF
ºECHnº Detail
Display Mode
(Refer to (e))
CHEC
ºCHECº Detail
Display Mode
(Refer to (f))
Physical AddressP190
Physical AddressP1A0
Old
ºOldº Detail
Display Mode
(Refer to (g))
Result (Replacing)
Result (Check)
Result (Old)
After the memory is cleared, only the physical address is displayed cyclically.OFF (1.7 sec.)
: Indicates a switch operation
When re-checking (ch1 switch is pressed) in that condition, the result is also
displayed as shown above.
Element check mode
Switch Check Mode
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VDISC/CH/PROG
VDISC/CH/PROG
VDISC/CH/PROG
VDISC/CH/PROG
VDISC/CH/PROG
VDISC/CH/PROG
- BODY ELECTRICALAUDIO SYSTEM
BE-137
2510 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Display Screen for Service Check.
Page 174 of 3115
Service Check Mode
ºECHnº Detail Display Mode
Physical Address of Component
Logical Address
Number of Occurrence (*2)
DTC (Refer to diagnostic
trouble code chart)
Logical Address
Connection Check Code (*2)
Continued if more than one DTC is identified.Details for 1st
Component
Details for 2nd
Component ECHn
P1F4
P1F4
SyS
COdE
DTC (Refer to diagnostic
trouble code chart)
Auxiliary Code (*1)
OFF (Along)
CLr
: Indicates a switch operation
Detail code is displayed
cyclically.
(*1): Some diagnostic codes
may not be displayed. In this
case, º- - -º displayed.
(*2): Some diagnostic codes
may not be displayed. In this
case, º- -º displayed.1L
**
1d21
2L**
2dD7
2P***
2n**
2c**
VTUNE/TRACK VTUNE/TRACK
VDISC/CH/PROG VDISC/CH/PROG
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK VTUNE/TRACK
BE-138
- BODY ELECTRICALAUDIO SYSTEM
2511 Author: Date:
2004 LAND CRUISER (RM1071U)
(e) ºECHnº Detail Display Mode Screen
Page 175 of 3115
Service Check Mode
ºCHECº Detail Display Mode
Physical Address of Component
Logical Address
Number of Occurrence (*2)
DTC (Refer to diagnostic
trouble code chart)
Continued if more than one DTC is identified.Details for 1st
Component
Details for 2nd
Component CHEC
P190
P190
COde
DTC (Refer to diagnostic
trouble code chart)
CLr
: Indicates a switch operationAuxiliary Code (*1)
Connection Check Code (*2)
Logical Address
Connection Check Code (*2)
Detail code is displayed
cyclically.
Auxiliary Code (*1)
Number of Occurrence (*2)
1L**
1dE4
2L**
2d43
2P***
2n**
1P***
1n**
2c**
1c**
(*1): Some diagnostic codes
may not be displayed. In this
case, º- - -º displayed.
(*2): Some diagnostic codes
may not be displayed. In this
case, º- -º displayed.
VTUNE/TRACK
VTUNE/TRACK
VDISC/CH/PROG VDISC/CH/PROG
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
OFF (Along)
- BODY ELECTRICALAUDIO SYSTEM
BE-139
2512 Author: Date:
2004 LAND CRUISER (RM1071U)
(f) ºCHECº Detail Display Mode Screen
Page 176 of 3115
Service Check Mode
ºOldº Detail Display Mode
Physical Address of Component
Logical Address
Number of Occurrence (*2)
DTC (Refer to diagnostic
trouble code chart)
Continued if more than one DTC is identified.Details for 1st
Component
Details for 2nd
Component Old
P1A0
P1A0
COdE
DTC (Refer to diagnostic
trouble code chart)
CLr
: Indicates a switch operationAuxiliary Code (*1)
Connection Check Code (*2)
Logical Address
Connection Check Code (*2)
Detail code is displayed
cyclically.
Auxiliary Code (*1)
Number of Occurrence (*2)
1L**
1dd4
2L**
2d43
2P***
2n**
1P***
1n**
2c
1c- -
- - (*1): Some diagnostic codes
may not be displayed. In this
case, º- - -º displayed.
(*2): Some diagnostic codes
may not be displayed. In this
case, º- -º displayed.
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK
OFF (Along) VDISC/CH/PROG VDISC/CH/PROG
VTUNE/TRACK
VTUNE/TRACK
VTUNE/TRACK VTUNE/TRACK
VTUNE/TRACK VTUNE/TRACK
BE-140
- BODY ELECTRICALAUDIO SYSTEM
2513 Author: Date:
2004 LAND CRUISER (RM1071U)
(g) ºOldº Detail Display Mode Screen
Page 177 of 3115
Physical address: 190 Radio receiver assembly
Diagnosis item
ROM Error
Absence of
MasterDiagnosis contentCountermeasure and
inspected parts
Error is detected in internal ROM. Logical address
01
(Communication
Control)
01 *2
(Communication
Control)Component in which this code is re-
corded has been disconnected from
system with ignition in ACC or ON.
Or, when this code was recorded, ra-
dio receiver assembly was discon-
nected. Check harness for power supply
system of radio receiver assembly.
Check harness for communica-
tion system of radio receiver as-
sembly.
DTC
21
D6Replace radio receiver assembly.
RAM Error Error is detected in internal RAM. 01
(Communication
Control)22Replace radio receiver assembly.
No Response
to Connection
Check 01 *3
(Communication
Control)Component shown by auxiliary code
is or had been disconnected from
system after engine start.
D9 Check harness for power supply
system of component shown by
auxiliary code.
Check harness for communica-
tion system of component shown by
auxiliary code. D8
Last Mode Error 01 *2
(Communication
Control)Component operated (sounds and/
or images were provided) before en-
gine stop is or has been discon-
nected with ignition switch in ACC or
ON. Check harness for power supply
system of component shown by
auxiliary code.
Check harness for communica-
tion system of component shown by
auxiliary code. D9
No Response
to ON/OFF
InstructionNo response is identified when
changing mode (audio and visual
mode change). Detected when
sound and picture does not change
by button operation. DA 01
(Communication
Control) Check harness for power supply
of component shown by auxiliary
code.
Check harness for communica-
tion system of component shown by
auxiliary code.
If error occurs again, replace
component shown by auxiliary
code.
HINT:
*1: Even if no failure is detected, it may be stored depending on the battery condition or voltage for starting an engine.
*2: It may be stored when the engine key is turned 1 min. angain after engine start.
*3: It may be stored when the engine key is turned again after engine start.
*4: When 210 sec. has passed after pulling out the power supply connector of the master component with the ignition
switch in ACC or ON, this code is stored.
Mode Status
Error DB 01 *2
(Communication
Control)Dual alarm is detected. Check harness for power supply
of component shown by auxiliary
code.
Check harness for communica-
tion system of component shown by
auxiliary code.
- BODY ELECTRICALAUDIO SYSTEM
BE-141
2514 Author: Date:
2004 LAND CRUISER (RM1071U)
3. DIAGNOSIS CODE LIST
w/ Navigation system (See page)
Page 178 of 3115
Transmission
Error DC 01 *4
(Communication
Control)Transmission to component shown
by auxiliary code has been failed.
(Detecting this DTC does not nec-
essary mean actual failure.) If same auxiliary code is recorded
in other component, check harness
for power supply and communica-
tion system of components shown
sub code.
Master Reset
(Momentary
Interruption) DD 01 *3
(Communication
Control)After engine is started, radio receiv-
er assembly assembly was discon-
nected from system. If this error occurs frequently, re-
place radio receiver assembly.
Slave Reset
(Momentary
Interruption) DE 01 *3
(Communication
Control)After engine is started, slave com-
ponent was disconnected from sys-
tem. Check harness for power supply
of component shown by auxiliary
code.
Check harness for communica-
tion system of component shown by
auxiliary code.
Master Error DF 01 *4
(Communication
Control)Due to defective condition of radio
receiver assembly, master function
is switched to audio equipment.
Error occurs in communication be-
tween sub-master (audio) and ra-
dio receiver assembly. Check harness for power supply
of radio receiver assembly.
Check harness for communica-
tion system of radio receiver as-
sembly .
Check harness for communica-
tion system between radio receiver
assembly and sub-master compo-
nent.
Registration
Completion
Instruction
Error E0 01
(Communication
Control)ºRegistration Completion Instruc-
tionº command from radio receiver
assembly cannot be received. Since this DTC is provided for en-
gineering purpose, it may be de-
tected when no actual failure exists.
Audio
processor ON
error E1
01 *2
(Communication
Control)While source equipment is operat-
ing, AMP output is stopped. Check harness for power supply
of radio receiver assembly.
Check harness for communica-
tion system of radio receiver as-
sembly.
ON/OFF
Instruction
Parameter
Error E2 01
(Communication
Control)Error occurs in ON/OFF controlling
command from radio receiver as-
sembly assembly. Replace radio receiver assembly
.
Registration
Request
Transmission E3 01
(Communication
Control)Registration Request command is
output from slave component.
Receiving Connection Check
Instruction, Registration Request
command is output from sub-mas-
ter component. Since this DTC is provided for en-
gineering purpose, it may be de-
tected when no actual failure exists.
Plural Frame
Abort E4 01
(Communication
Control) Since this DTC is provided for en-
gineering purpose, it may be de-
tected when no actual failure exists. Plural frame transmission is
aborted.
AM Tuner Error 43 60
(Radio receiver
assembly)Replace radio receiver assembly. Abnormal condition is detected in
AM tuner.
Inspect radio receiver assembly.
FM Tuner Error 44
60
(Radio receiver
assembly)Replace radio receiver assembly. Abnormal condition is detected in
FM tuner.
BE-142
- BODY ELECTRICALAUDIO SYSTEM
2515 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 179 of 3115
EJECT
Malfunction 41 61
(Cassette
switch)Malfunction due to mechanical fail-
ure.Replace radio receiver assembly.
63 (In-dash CD
auto changer)42 No Disc
ReadoutDisc cannot be read. Inspect CD.
63 (In-dash CD
auto changer)44
CD Error
Error is detected in CD auto
changer.Replace radio receiver assembly.
Physical address: 440 Strereo component amplifier
01
(Communica-
tion Control)22 RAM Error
01
(Communica-
tion Control)D6
*1Absence of
MasterComponent in which this code is re-
corded has been disconnected from
system with ignition in ACC or ON.
Or, when this code was recorded, ra-
dio receiver assembly was discon-
nected. Check harness for power supply of
radio receiver assembly.
Check harness for communication
system of radio receiver assembly.
Check harness for power supply of
stereo component amplifier.
Check harness for communication
system of stereo component ampli-
fier. HINT:
*1: Even if no failure is detected, it may be stored depending on the battery condition or voltage for starting an engine.
*2: It may be stored when the engine key is turned 1 min. angain after engine start.
*3: It may be stored when the engine key is turned again after engine start.
*4: When 210 sec. has passed after pulling out the power supply connector of the master component with the ignition
switch in ACC or ON, this code is stored.
Logical addressDTC
Diagnosis itemDiagnosis content
Countermeasure and inspeced parts
01
(Communica-
tion Control)21 ROM Error Abnormal condition of ROM is
detected.Replace stereo component
amplifier.
Abnormal condition of RAM is
detected.Replace stereo component
amplifier.
63
(In-dash CD auto
Changer)45EJECT Error
CD cannot be ejected.
Replace radio receiver assembly.
63
(In-dash CD auto
Changer)47 CD High Temp.
High temperature is detected in
CD auto changer.Replace radio receiver assembly.
63
(In-dash CD auto
Changer)48CD Excess
CurrentExcess current is applied to CD
auto changer.Replace radio receiver assembly.
Mechanical or
Media Error 40 61
(Cassette
switch)Inspect cassette tape. Malfunction due to mechanical fail-
ure is identified. Or, cassette tape is
cut or entangled.
- BODY ELECTRICALAUDIO SYSTEM
BE-143
2516 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 180 of 3115
01*6
(Communica-
tion Control)D7 Connection
Check ErrorComponent in which this code is re-
corded has been disconnected from
system after engine start.
Or, when this code was recorded,
radio receiver assembly was dis-
connected. Check harness for power supply of
radio receiver assembly.
Check harness for communication
system of radio receiver assembly.
Check harness for power supply of
stereo component amplifier.
Check harness for communication
system of stereo component ampli-
fier.
Transmission
Error DC
*2 01
(Communication
Control)Transmission to component shown
by auxiliary code has bee failed.
(This code does not necessarily
mean actual failure.)If same auxiliary code is recorded in
other component(s), check harness
for power supply and communica-
tion system of components shown
sub code.
Master Reset
(Momentary
Interruption) DD
*3 01
(Communication
Control) Check harness for power supply
of radio receiver assembly.
Check harness for communica-
tion system of radio receiver as-
sembly.
If error occurs frequently, replace
radio receiver assembly.
Registration
Completion
Instruction
Error E0
*1 01
(Communication
Control)ºRegistration Completion Instruc-
tionº command fromradio receiver
assembly cannot be received.Since this DTC is provided for engi-
neering, it may be detected when
no actual failure exists.
ON/OFF
Instruction
Parameter
Error E2 01
(Communication
Control)Error is detected in ON/OFF control
command from radio receiver as-
sembly.Replace radio receiver assembly.
Registration
Request
Transmission E3 01
(Communication
Control)Since this DTC is provided for engi-
neering, it may be detected when
no actual failure exists. Registration Request command
is output from slave component.
By reception of connection check
Instruction, Registration Request
command is output from sub-mas-
ter component.After engine is started, radio receiv-
er assembly assembly was discon-
nected from system.
Master Error DF
*4 01
(Communication
Control)Due to defective condition of com-
ponent with a display, master func-
tion is switched to audio equip-
ment . Error occurs in communica-
tion between sub-master (audio)
and master component. Check harness for power supply
of radio receiver assembly.
Check harness for communica-
tion system of radio receiver as-
sembly.
Check harness for communica-
tion system between radio receiver
assembly and sub-master compo-
nent.
Audio proces-
sor ON error E1
*1 01
(Communication
Control)While source equipment is operat-
ing, AMP output is stopped. Check harness for power supply of
radio receiver assembly
Check harness for communication
system of radio receiver assembly.
Plural Frame
Abort E4 01
(Communication
Control)Plural frame transmission is
aborted.Since this DTC is provided for engi-
neering purpose, it may be detected
when no actual failure exists. BE-144
- BODY ELECTRICALAUDIO SYSTEM
2517 Author: Date:
2004 LAND CRUISER (RM1071U)
