EM-80
- ENGINE MECHANICALENGINE UNIT
1653 Author
: Date
:
2004 LAND CRUISER (RM1071U)
22. REMOVE TORQUE CONVERTER CLUTCH BOLTS
(a) Remove the bolt and the flywheel housing under cover.
(b) Turn the crankshaft pulley bolt to gain access to each bolt.
(c) Hold the crankshaft pulley bolt with a wrench, and remove
the 6 bolts.
23. REMOVE TRANSMISSION
(a) Remove the 10 bolts.
(b) Remove the transmission together with the torque con-
verter clutch from the engine.
24. REMOVE DRIVE PLATE
Hold the crankshaft pulley bolt with a wrench, and remove the
8 bolts, the front spacer, the drive plate and the rear spacer.

EM0EE-18
A19478
N´m (kgf´cm, ft´lbf) : Specified torque
 Non-reusable partHeat
Insulator
Ring
Heat
Insulator
 Gasket Center Exhaust PipeRing
 Gasket
Heat
Insulator
40 (408, 30)
40 (408, 30)
Heated Oxygen Sensor
(Bank 2 Sensor 2)



Ring


Heated Oxygen Sensor
(Bank 1 Sensor 2)Clamp
Ring
Ring

20 (200, 14)
 Gasket
 Gasket
No.2 Front
Exhaust Pipe
Ring
 Heat Insulator
Tailpipe
 Gasket
 Gasket
Heat
Insulator62 (632, 46)
TWC Front Exhaust Pipe
Front
Exhaust
Pipe
TWC
 Gasket







85 (867, 63)
- ENGINE MECHANICALEXHAUST SYSTEM
EM-1 15
1688 Author
: Date
:
2004 LAND CRUISER (RM1071U)
EXHAUST SYSTEM
COMPONENTS

EM0KU-10
- ENGINE MECHANICALIDLE SPEED
EM-1 1
1584 Author
: Date
:
2004 LAND CRUISER (RM1071U)
IDLE SPEED
INSPECTION
1. INITIAL CONDITIONS
(a) Engine is at normal operating temperature
(b) Air cleaner is installed
(c) All pipes and hoses of air induction systems are connected
(d) All accessories are switched OFF
(e) All vacuum lines are properly connected
HINT:
All vacuum hoses should be properly connected.
(f) SFI system wiring connectors are fully plugged
(g) Ignition timing is set correctly
(h) Transmission is in neutral position
(i) Air conditioning switches are OFF
2. CONNECT TOYOTA HAND-HELD TESTER OR OBD II SCAN TOOL
(See page EM-9)
3. INSPECT IDLE SPEED
(a) Race the engine speed at 2,500 rpm for approx. 90 seconds.
(b) Check the idle speed.
Idle speed: 700 ± 50 rpm
If the idle speed is not as specified, check the air intake system.
4. DISCONNECT TOYOTA HAND-HELD TESTER OR OBD II SCAN TOOL

EM0KT-10
A07061
TOYOTA Hand-Held Tester
DLC3
A05511
A05512
SSTTC
E1
A04459
- ENGINE MECHANICALIGNITION TIMING
EM-9
1582 Author
: Date
:
2004 LAND CRUISER (RM1071U)
IGNITION TIMING
INSPECTION
1. REMOVE BATTERY CLAMP COVER
2. REMOVE INTAKE AIR CONNECTOR
3. REMOVE V-BANK COVER
4. WARM UP ENGINE
Allow the engine to warm up to the normal operating tempera-
ture.
5. CONNECT TOYOTA HAND-HELD TESTER OR OBD II
SCAN TOOL
(a) Connect the TOYOTA hand-held tester or OBD II scan
tool to the DLC3.
(b) Please refer to the TOYOTA hand-held tester or OBD II
scan tool operator's manual for further details.
6. CONNECT TIMING LIGHT TO ENGINE
Connect the tester probe of a timing light to the wire of the igni-
tion coil connector for No.1 cylinder.
7. CHECK IDLE SPEED
(a) Race the engine speed at 2,500 rpm for approx. 90 se-
conds.
(b) Check the idle speed.
Idle speed:
700 ± 50 rpm
8. INSPECT IGNITION TIMING
(a) Using SST, connect terminal TC and E1 of the DLC1.
SST 09843-18020
(b) Using a timing light, check the ignition timing.
Ignition timing:
5 - 15° BTDC @ idle
(Transmission in neutral position)
(c) Remove SST from the DLC1.
SST 09843-18020
9. DISCONNECT TIMING LIGHT FROM ENGINE
10. DISCONNECT TOYOTA HAND-HELD TESTER OR
OBD II SCAN TOOL

EM-10
- ENGINE MECHANICALIGNITION TIMING
1583 Author
: Date
:
2004 LAND CRUISER (RM1071U)
11. REINSTALL V-BANK COVER
12. REINSTALL INTAKE AIR CONNECTOR
13. REINSTALL BATTERY CLAMP COVER

EM0KV-1 1
A09750
P/S Air HoseRadiator
Reservoir Tank
Intake Air
Connector
Radiator Assembly
EVAP HoseV-Bank Cover
Engine Under Cover No.1
N´m (kgf´cm, ft´lbf) : Specified torque Generator
Drive Belt
A/C CompressorA/C Compressor
Connector
A/T Oil Cooler Hose
Fan w/ Fluid
Coupling
Fan Pulley
49 (500, 36)
5.0 (50, 43 in.´lbf)
18 (185, 13)
Air Hose
x 8Fan Shroud Fuel Return
Hose
20 (200, 15)
A/T Oil Cooler
Hose
A/C Discharge
Tube
Clamp
BracketWireClamp
Clamp
Lower Radiator Hose
Bracket
EM-12
- ENGINE MECHANICALTIMING BELT
1585 Author
: Date
:
2004 LAND CRUISER (RM1071U)
TIMING BELT
COMPONENTS

A04326
RH No. 3 Timing Belt Cover
No. 2 Timing
Belt Cover
LH No. 3 Timing Belt Cover Drive Belt Idler Pulley
Camshaft Position
Sensor ConnectorCover Plate
Engine Wire
16 (160, 12)
7.5 (80, 16 in.´lbf)
N´m (kgf´cm, ft´lbf) : Specified torque
Oil Cooler PipeWire Grommet
39 (400, 29)
7.5 (80, 66 in.´lbf)
A04327
Timing BeltRH Camshaft Timing Pulley
LH Camshaft Timing Belt Pulley
Timing belt Tensioner
Fan BracketDust Boot
108 (1,100, 80)
245 (2,500, 181)
16 (160, 12)
32 (330, 24)
26 (270, 19)N´m (kgf´cm, ft´lbf) : Specified torque
- ENGINE MECHANICALTIMING BELT
EM-13
1586 Author
: Date
:
2004 LAND CRUISER (RM1071U)

A19486
Generator Wire
Drive Belt Tensioner
No.1 Timing Belt Cover
Generator
Crankshaft Pulley
No.1 Idler Pulley
Timing Belt
Plate Washer
Crankshaft Timing Pulley
Timing Belt Cover Spacer No.2 Idler Pulley Timing Belt Guide
(Crankshaft Angle Sensor Plate)
Gasket
34.5 (350, 25)


N´m (kgf´cm, ft´lbf) : Specified torque

Precoated part
34.5 (350, 25)
39 (400, 29)
39 (400, 29)
15.5 (158, 11)
EM-14
- ENGINE MECHANICALTIMING BELT
1587 Author
: Date
:
2004 LAND CRUISER (RM1071U)

EM0KX-06
EM3336
NO !
P20079
P20633
EM-20
- ENGINE MECHANICALTIMING BELT
1593 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT TIMING BELT
NOTICE:

Do not bend, twist or turn the timing belt inside out.

Do not allow the timing belt to contact with oil, water
or steam.

Do not utilize timing belt tension when installing or re-
moving the mount bolt of the camshaft timing pulley.
If there any defects as shown in the illustrations, check these
points:
(a) Premature parting

Check for proper installation.

Check the timing cover gasket for damage and
proper installation.
(b) If the belt teeth are cracked or damaged, check if either
camshaft is locked.
(c) If there is noticeable wear or cracks on the belt face,
check if there are nicks on the side of the idler pulley lock
and the water pump.
(d) Even if there is wear or damage on only one side of the
belt, check the belt guide and the alignment of each
pulley.
(e) If there is noticeable wear on the belt teeth, check timing
cover for damage and for foreign materials on the pulley
teeth.
If necessary, replace the timing belt.
2. INSPECT IDLER PULLEYS
(a) Visually check the seal portion of the idler pulley for oil
leakage.
If leakage is found, replace the idler pulley.
(b) Check that the idler pulley turns smoothly.
If necessary, replace the idler pulley.
3. INSPECT TIMING BELT TENSIONER
(a) Visually check the seal portion of the tensioner for oil leak-
age.
HINT:
If there is only the faintest trace of oil on the seal on the push
rod side, the tensioner is all right.
If leakage is found, replace the tensioner.

P20634
P20635
Protrusion
- ENGINE MECHANICALTIMING BELT
EM-21
1594 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(b) Hold the tensioner with both hands, and push the push
rod strongly to check that it doesn't move.
If the push rod moves, replace the tensioner.
NOTICE:
Never hold the tensioner push rod facing downward.
(c) Measure the protrusion of the push rod from the housing
end.
Protrusion:
10.5 - 11.5 mm (0.413 - 0.453 in.)
If the protrusion is not as specified, replace the tensioner.
4. INSPECT WATER PUMP
(See page CO-7)
