H20953SST
R13455
10 m (33 ft) or more
SSTBattery
R06753
RS-22
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2297 Author: Date:
2004 LAND CRUISER (RM1071U)
(7) Connect the connector of SST to the airbag con-
nector of the spiral cable.
SST 09082-00700, 09082-00780
NOTICE:
To avoid damaging the connector of the SST and wire har-
ness, do not lock the secondary lock of the twin lock.
(8) Move the SST at least 10 m (33 ft) away from the
front of the vehicle.
(9) Close all the doors and windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(10) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the negative (-) termi-
nal.
(c) Deploy the airbag.
(1) Confirm that no one is inside the vehicle nor within
10 m (33 ft) area around the vehicle.
(2) Press the SST activation switch and deploy the air-
bag.
CAUTION:
The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.
When moving a vehicle for scrapping which has a
steering wheel pad with deployed airbag, use gloves
and safety glasses.
Use gloves and safety glasses when handling a steer-
ing wheel pad with the deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a steering wheel pad with
the deployed airbag.
HINT:
The airbag deploys as the LED of the SST activation switch
comes on.
2. DEPLOYMENT WHEN DISPOSING OF STEERING
WHEEL PAD ONLY
NOTICE:
When disposing of the steering wheel pad (with air-
bag) only, never use the customer's vehicle to deploy
the airbag.
Be sure to follow the procedure given below when de-
ploying the airbag.
Page 2782 of 3115
AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
H20646
L
M
H20057
SST
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-23
2298 Author: Date:
2004 LAND CRUISER (RM1071U)
HINT:
Have a battery ready as the power source to deploy the airbag.
(a) Remove the steering wheel pad (See page SR-14).
CAUTION:
When storing the steering wheel pad, keep the upper
surface of the pad facing upward.
When removing the steering wheel pad, work must be
started 90 seconds after the ignition switch is turned
to the ºLOCKº position and the negative (-) terminal
cable is disconnected from the battery.
(b) Using a service-purpose wire harness for the vehicle, tie
down the steering wheel pad to the disc wheel.
Wire harness: Stripped wire harness section
1.25 mm
2
or more (0.0019 in2. or more).
CAUTION:
If a wire harness which is too thin or some other thing is
used to tie down the steering wheel pad, it may be snapped
by the shock when the airbag is deployed. This is highly
dangerous. Always use a wire harness for vehicle use
which is at least 1.25 mm
2
(0.0019 in2).
HINT:
To calculate the square of the stripped wire harness section:
Square = 3.14 x (Diameter)
2
divided by 4
(1) Install the 2 bolts with washers in the 2 bolt holes in
the steering wheel pad.
Bolt:
L: 35.0 mm (1.387 in.)
M: 6.0 mm (0.236 in.)
Pitch: 1.0 mm (0.039 in.)
NOTICE:
Tighten the bolts by hand until the bolts become diffi-
cult to turn.
Do not tighten the bolts excessively.
(2) Connect the connectors of the SST to the steering
wheel pad connectors.
SST 09082-00802 (09082-10801, 09082-30801)
Page 2783 of 3115
H20060
2 Times or more
H20058
AB0158
SSTBattery RS-24
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2299 Author: Date:
2004 LAND CRUISER (RM1071U)
(3) Using 3 wire harness, wind the wire harness at least
2 times each around the bolts installed on the left
and right sides of the steering wheel pad.
CAUTION:
Tightly wind the wire harness around the bolts so that
there is no slack.
If there is slackness in the wire harness, the steering
wheel pad may come loose due to the shock when the
airbag is deployed. This is highly dangerous.
(4) Face the upper surface of the steering wheel pad
upward. Separately tie the left and right sides of the
steering wheel pad to the disc wheel through the
hub nut holes. Position the steering wheel pad con-
nector so that it hangs downward through a hub
hole in the disc wheel.
CAUTION:
Make sure that the wire harness is tight. It is very dan-
gerous when looseness in the wire harness results in
the steering wheel pad coming free through the shock
from the airbag deploying.
Always tie down the steering wheel pad with the pad
side facing upward. It is very dangerous if the steer-
ing wheel pad is tied down with the metal surface fac-
ing upward as the wire harness will be cut by the
shock caused by the airbag is deployment and the
steering wheel pad will be thrown into the air.
NOTICE:
The disc wheel will be marked by airbag deployment, so
when disposing of the airbag, use a redundant disc wheel.
(c) Check the function of the SST (See step 1-(a)).
SST 09082-00700
Page 2784 of 3115
H20059
SST
R13763
10 m (33 ft) or more SSTBattery
H00401Weight
X Y
Y
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-25
2300 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Install the SST.
CAUTION:
Place the disc wheel on the level ground.
(1) Connect the connector of the SST.
SST 09082-00700
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the disc
wheel.
(2) Move the SST at least 10 m (33 ft) away from the
steering wheel pad tied down on the disc wheel.
(e) Cover the steering wheel pad with a cardboard box or
tires.
Covering method using a cardboard box:
Cover the steering wheel pad with the cardboard
box and weight the cardboard box down in 4 places
with at least 190 N (20 kg, 44 lb).
Size of cardboard box:
Must exceed the following dimensions:
X = 460 mm (18.11 in.)
Y = 650 mm (25.59 in.)
NOTICE:
When dimension Y of the cardboard box exceeds the
diameter of the disc wheel with tire to which the steer-
ing wheel pad is tied, X should be the following size.
X = 460 mm (18.11 in.) + width of tire
If a cardboard box smaller than the specified size is
used, the cardboard box will be broken by the shock
from the airbag deployment.
Page 2785 of 3115
R04211
Inner Diam.
Tires
(3 or More)Width
R13763
10 m (33 ft) or more SSTBattery
AB0166
RS-26
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2301 Author: Date:
2004 LAND CRUISER (RM1071U)
Covering method using tires:
Place at least 3 tires with no disc wheels on top of
the tire with disc wheel to which the steering wheel
pad is tied.
Tire size: Must exceed the following dimensions-
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels.
NOTICE:
The tires may be marked by the airbag deployment, so use
the redundant tires.
(f) Deploy the airbag.
(1) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip to the battery neg-
ative (-) terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air-
bag.
HINT:
The airbag deploys as the LED of the SST activation switch
comes on.
(g) Dispose of the steering wheel pad (with airbag).
CAUTION:
The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.
Use gloves and safety glasses when handling a steer-
ing wheel pad with deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a steering wheel pad with
deployed airbag.
(1) Remove the steering wheel pad from the disc
wheel.
(2) Place the steering wheel pad in a plastic bag, tie the
end tightly and dispose of it as the other general
parts disposal.
Page 2786 of 3115
AB0166
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-27
2302 Author: Date:
2004 LAND CRUISER (RM1071U)
3. DEPLOYMENT WHEN DISPOSING OF STEERING
WHEEL PAD WITH AN AIRBAG DEPLOYED IN A COL-
LISION
Dispose of the steering wheel pad (with airbag).
CAUTION:
The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.
When moving a vehicle for scrapping which has a
steering wheel pad with the deployed airbag, use
gloves and safety glasses.
Use gloves and safety glasses when handling a steer-
ing wheel pad with the deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a steering wheel pad with
the deployed airbag.
(1) Remove the steering wheel pad from the steering
wheel (See page SR-14).
(2) Place the steering wheel pad in a plastic bag, tie the
end tightly and dispose of it as the other general
parts disposal.
Page 2787 of 3115
RS0VI-01
H20912
H20642
H20056
Horn Button
Contact Plate
H20912
RS-18
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
2293 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. Vehicle not involved in collision:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
(a) Do a diagnostic system check (See page DI-692).
(b) Do a visual check which includes the following item with
the steering wheel pad (with airbag) installed in the ve-
hicle.
Check cuts, minute cracks or marked discoloration on the
steering wheel pad top surface and in the grooved por-
tion.
2. Vehicle involved in collision and airbag is not
deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
(a) Do a diagnostic system check (See page DI-692).
(b) Do a visual check which includes the following items with
the steering wheel pad (with airbag) removed from the ve-
hicle.
Check cuts, minute cracks or marked discoloration
on the steering wheel pad top surface and in the
grooved portion.
Check cuts and cracks in wire harness, and chip-
ping in connectors.
Check the deformation of the horn button contact
plate on the steering wheel pad (with airbag).
CAUTION:
For removal and installation of the steering wheel pad, see
page SR-14 and SR-24, and be sure to follow the correct
procedure.
HINT:
If the horn button contact plate of the steering wheel pad
(with airbag) is deformed, never repair it. Always replace
the steering wheel assembly with a new one.
There should be no interference between the steering
wheel pad and steering wheel, and the clearance should
be uniform all the way around when the new steering
wheel pad is installed on the steering wheel.
Page 2788 of 3115
H20912
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-19
2294 Author: Date:
2004 LAND CRUISER (RM1071U)
3. Vehicle involved in collision and airbag is deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
(a) Do a diagnostic system check (See page DI-692).
(b) Do a visual check which includes the following items with
the steering wheel pad (with airbag) removed from the ve-
hicle.
Check that the metal part where the steering wheel
pad is to be installed is not deformed.
Check the damage on the spiral cable connector
and wire harness.
HINT:
Do not repair the metal part where the steering wheel pad
is to be installed even if any deformation is found. Always
replace the steering wheel assembly with a new one.
There should be no interference between the steering
wheel pad and steering wheel, and the clearance should
be uniform all the way around when the new steering
wheel pad is installed on the steering wheel.
Page 2789 of 3115
RS0BD-08
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-29
2304 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
HINT:
For step 1 to 9, refer to page SR-24.
1. INSTALL SPIRAL CABLE
2. INSTALL COLUMN UPPER AND LOWER COVERS
3. INSTALL LOWER NO. 1 PANEL
4. INSTALL INSTRUMENT CLUSTER FINISH PANEL
5. INSTALL FRONT DOOR OPENING TRIM LH
6. INSTALL COWL SIDE TRIM LH
7. INSTALL FRONT DOOR SCUFF PLATE LH
8. INSTALL STEERING WHEEL
9. INSTALL STEERING WHEEL PAD
10. INSPECT SRS WARNING LIGHT (See page DI-692)
Page 2790 of 3115
RS0B9-10
- SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS-17
2292 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
HINT:
For step 1 to 9, refer to page SR-14.
1. REMOVE STEERING WHEEL PAD
2. REMOVE STEERING WHEEL
3. REMOVE FRONT DOOR SCUFF PLATE LH
4. REMOVE COWL SIDE TRIM LH
5. REMOVE FRONT DOOR OPENING TRIM LH
6. REMOVE INSTRUMENT CLUSTER FINISH PANEL
7. REMOVE LOWER NO. 1 PANEL
8. REMOVE COLUMN UPPER AND LOWER COVERS
9. REMOVE SPIRAL CABLE
