Ye s
Ye sNo
No
Is there battery positive voltage between terminal IG and
body ground?
Is there battery positive voltage between terminal +B and
body ground?
Replace multi display.IG wire harness faulty.
Ye sNo
Is there battery positive voltage between terminal GND and
body ground?Ground wire harness faulty. +B wire harness faulty.
Ye sNo
Is there battery positive voltage between terminal ACC and
body ground?ACC wire harness faulty.
2 CLOCK LOSES OR GAINS TIME
Ye s
Is there battery positive voltage between terminal +B and
body ground?
Adjust clock or replace multi display.Bellow 10 V
Locate cause and repair, or recharge battery.
Ye s
Is there battery positive voltage between terminal ACC and
body ground?Bellow 10 V
Locate cause and repair, or recharge battery.
- BODY ELECTRICALMULTI DISPLAY
BE-179
2552 Author: Date:
2004 LAND CRUISER (RM1071U)
2. TROUBLESHOOTING NO.2
(a) Check that the battery positive voltage is 10 - 16 V.
If voltage is not as specified, replace the battery.
(b) Inspect the error of the clock.
Allowable error (per day): ± 1.5 seconds
If the error exceeds the allowable error, replace the multi display.
(c) Check that the clock adjusting button is sticking in position and has failed to return.
If the error exceeds the allowable error, replace the multi display.
(d) Troubleshoot the clock as follows.
HINT:
Inspect the connector on the wire harness side.
Page 272 of 3115
3 DRIVE MONITOR FUNCTION MALFUNCTION
Ye s
Does cotinuity exists waire harness between combination meter and
multi display?
Replace multi display.No Repair or replace wire harness.
Ye s
Is combination meter operation normaly?Go to Combination Meter No
4 OUTER TEMPERATURE DISPLAY MALFUNCTION
Ye s
Does cotinuity exists waire harness between A/C control Assy and
multi display?
Replace multi display.No Repair or replace wire harness.
Ye s
Is A/C operation normaly?Go to Air Conditioner System No
BE-180
- BODY ELECTRICALMULTI DISPLAY
2553 Author: Date:
2004 LAND CRUISER (RM1071U)
3. TROUBLESHOOTING NO.3
(a) Check that the battery positive voltage is 10 - 16 V.
If voltage is not as specified, replace the battery.
(b) Troubleshoot the drive monitor function as follows.
HINT:
Inspect the connector on the wire harness side.
4. TROUBLESHOOTING NO.4
(a) Check that the battery positive voltage is 10 - 16 V.
If voltage is not as specified, replace the battery.
(b) Troubleshoot the outer temperature display as follows.
HINT:
Inspect the connector on the wire harness side.
Page 273 of 3115
BE2E5-01
I25537
Connector ºAº
Connector ºBº
To Tail Light
Microphone
Connector ºDº
Garage Door
Opener
Connector ºCºIllumination LED
DOME Fuse
Combination
Switch
TA I L
Relay
Connector ºEº
SW1
SW2
SW3
Circuit
Plate
(Garage
Door
Opener)
Connector ºEºConnector ºFº
Connector ºGº
MIC
AMP
BE-182
- BODY ELECTRICALOVERHEAD JUNCTION BLOCK
2555 Author: Date:
2004 LAND CRUISER (RM1071U)
CIRCUIT
Page 274 of 3115
BE2E6-01
I24661
Main Circuit Plate
Circuit Plate
(Garage Door Opener Switch)
- BODY ELECTRICALOVERHEAD JUNCTION BLOCK
BE-183
2556 Author: Date:
2004 LAND CRUISER (RM1071U)
COMPONENTS
Page 275 of 3115
I24662
1 2
34A
Circuit Plate
(Garage Door Opener Switch)Main Circuit Plate
CB
G
E
D
BE-184
- BODY ELECTRICALOVERHEAD JUNCTION BLOCK
2557 Author: Date:
2004 LAND CRUISER (RM1071U)Parts No.
Connector nameRelated to systems
A, BVehicle wire harness connector-
COverhead console illumination connector (Unbar)Overhead junction block illumination
DGarage door opener ECU connectorGarage door opener system
EGarage door opener ECU connectorGarage door opener system
GVoice recognition connectorNavigation system
1Garage door opener substrate flat harness connectorGarage door opener system
2Garage door opener switchGarage door opener system
3Garage door opener LED (Green)Garage door opener system
4Garage door opener operate indicator LED (Red)Garage door opener system
Page 276 of 3115
I20746
Wire Harness Side:
BE2E7-01
I24663
- BODY ELECTRICALOVERHEAD JUNCTION BLOCK
BE-185
2558 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT OVERHEAD JUNCTION BLOCK ASSEMBLY
Disconnect the connector from the overhead J/B and inspect
the connector on the wire harness side, as shown.
Tester connectionConditionSpecified condition
1 - GroundConstantContinuity
8 - GroundConstantBattery positive voltage
11 - GroundIgnition switch OFF or ACCNo voltage11 Ground
Ignition switch ONBattery positive voltage
If continuity is not as specified, repair or replace the wire har-
ness.
2. Overhead J/B side:
INSPECT OVERHEAD JUNCTION BLOCK ASSEMBLY
Circuit nameTester connectionSpecified condition
Power source circuitA8 - B6 - E6Continuity
Ground circuitA1 - B2 - E8 - D3Continuity
Microphone circuitB10 - G4Continuity
Microphone circuitB9 - G2Continuity
If continuity is not as specified, replace the overhead J/B as-
sembly.
Page 277 of 3115
BE2E4-01
I25538
Cowl Side J/B RH
SECURITY Fuse
Overhead Junction Block
Sliding Roof Switch
Garage Door Opener Switch
- BODY ELECTRICALOVERHEAD JUNCTION BLOCK
BE-181
2554 Author: Date:
2004 LAND CRUISER (RM1071U)
OVERHEAD JUNCTION BLOCK
LOCATION
Page 278 of 3115
BE2EK-01
I25784
I09912
I06229
Front door:
UNLOCK
I06228
Rear door:
UNLOCK
I06227
Back door:
UNLOCK BE-88
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
2461 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. Master switch:
INSPECT DRIVER'S DOOR LOCK CONTROL SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK3 - 4Continuity
OFF-No continuity
UNLOCK3 - 14Continuity
If continuity is not as specified, replace the switch.
2. INSPECT PASSENGER'S DOOR LOCK CONTROL
SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
LOCK3 - 2Continuity
OFF-No continuity
UNLOCK1 - 2Continuity
If continuity is not as specified, replace the switch.
3. Front door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)1 - 4Continuity
If continuity is not as specified, replace the switch.
4. Rear door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)1 - 4Continuity
If continuity is not as specified, replace the switch.
5. Back door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)-No continuity
ON (Door Lock set to
UNLOCK)1 - 4Continuity
If continuity is not as specified, replace the switch.
Page 279 of 3115
I06225
2 3
UNLOCK
I06226
2 3
LOCK
I06223
2 3
UNLOCK
I06224
2 3
LOCK
I06221
UNLOCK
2 3
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE-89
2462 Author: Date:
2004 LAND CRUISER (RM1071U)
6. Front door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
7. Rear door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
8. Back door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
Page 280 of 3115
I06222
2 3
LOCK
I06242
UNLOCK
2
3
I06226
2 3
LOCK
I06244
2 3
UNLOCK
I06245
2 3
LOCK BE-90
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
2463 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
9. Front door:
INSPECT PTC THERMISTOR OPERATION (Using an
ammeter)
(a) Connect the negative (-) lead from the battery to terminal
2.
(b) Connect the positive (+) lead from the ammeter to termi-
nal 3 and the negative (-) lead to battery negative (-) ter-
minal, and check that the current changes from approxi-
mately 3.2 A to less than 0.5 A within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, connect the positive (+)
lead from the battery to terminal 2 and the negative (-)
lead to terminal 3, and check that the door lock moves to
the LOCK position.
If operation is not as specified, replace the door lock assembly.
10. Rear door:
INSPECT PTC THERMISTOR OPERATION (Using an
ammeter)
(a) Connect the negative (-) lead from the battery to terminal
2.
(b) Connect the positive (+) lead from the ammeter to termi-
nal 3 and the negative (-) lead to battery negative (-) ter-
minal, and check that the current changes from approxi-
mately 3.2 A to less than 0.5 A within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, connect the positive (+)
lead from the battery to terminal 2 and the negative (-)
lead to terminal 3, and check that the door lock moves to
the LOCK position.
If operation is not as specified, replace the door lock assembly.
