TOYOTA LAND CRUISER 1998 Factory Repair Manual

BE0RU-04
I25046
A-bolt
BE-38
- BODY ELECTRICALFOG LIGHT SYSTEM
2411 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST FOGLIGHT AIM
A-bolt : Vertical Direction

BE0RT-04
I06374
ON
OFF
I25040
Built in relayExcept built in relay
- BODY ELECTRICALFOG LIGHT SYSTEM
BE-37
2410 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT FOG LIGHT SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
ON10 - 11Continuity
If continuity is not as specified, replace the switch.
2. INSPECT ENGINE ROOM R/B RELAY CIRCUIT(See
Pase BE-15)
HINT:
The foglight relay is built in engine room junction block. Also the
relay is constructed with a relay block that is in the junction block
as a unit. To disconnect the wire harness connecting with relay
block is impossible. If the relay has a malfunction, replace it with
junction block assembly wire harness together.

BE0H2-16
I24736
Front Fog Light
Combination Switch

Front Fog Light Switch
Engine Room R/B

FR FOG Relay

FR FOG Fuse
BE-36
- BODY ELECTRICALFOG LIGHT SYSTEM
2409 Author
: Date
:
2004 LAND CRUISER (RM1071U)
FOG LIGHT SYSTEM
LOCATION

I25809
BE2F0-01
I25810
I25811
BE-190
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
2563 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT GARAGE DOOR OPENER SWITCH
Press the switch and check that each LED (red) lights up.
Even if only one switch is found not to light up, replace it.
2. INSPECT GARAGE DOOR OPENER REGISTRATION
AND TRANSMITTING
HINT:
Use the home link tester made by KENT MORE for this test.
As it is necessary to record the code of the hand held transmit-
ter, customer's code will be erased. When the inspection com-
pletes, please register the customer's again.
(a) Check that the code of hand held transmitter for inspec-
tion can be recorded (See page BE-186).
If the code can not be registered, replace garage door opener.
(b) Press the switch which an inspection code has been reg-
istered for and check that LED (green) of the home link
tester lights up.
If the LED (green) does not light up, replace the garage door
opener.

BE0TZ-06
I25525
Grage Door Opener Switch
Cowl Side J/B RH

DOME Fuse
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
BE-189
2562 Author
: Date
:
2004 LAND CRUISER (RM1071U)
LOCATION

BE0TY-04
I25812
BE-186
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
2559 Author
: Date
:
2004 LAND CRUISER (RM1071U)
GARAGE DOOR OPENER SYSTEM
REGISTRATION PROCEDURE
1. NEW CODE REGISTRATION
NOTICE:

If pressing the switch of the original transmitter to
register the code, the system might operate.

When registering the transmitter codes such as for
garage or gate, check that there is nobody around
those places then register.
(a) Press the switch for the item to be registered for 20 se-
conds
HINT:
When transferring to registration mode, LED (red) blinks in 1 Hz
cycle.
(b) In the condition of (a), bring the original transmitter to with-
in 1-inch area around the garage door opener and press
the switch. (code transmitting).
HINT:
When code registration completes correctly, LED (red) blinks in
5.6 Hz cycle.

I03487
GARAGE DOOR
OPENER SWITCH
LEARN MODE
LED
OPERATION
ORIGINAL
TRANSMITTERPRESSED
ENTER
EXIT
ON
OFF20 sec
LED flashes
at a rate of 1 Hz
LED flashes at a
rate of 5.6 Hz PRESSED
ON
OFF
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
BE-187
2560 Author
: Date
:
2004 LAND CRUISER (RM1071U)
New code registration timing chart
If a code can not be registered, observe the following condi-
tions.
HINT:

If the battery of original transmitter is consumed.

Press the switch of the transmitter repeatedly in registra-
tion mode, as some transmitters stop transmitting for 1 to
2 seconds.

This system is not applicable to the garage door opener
which had been made before 1982.
2. CODE DELETION
(a) Press the switches at both ends of garage door opener
simultaneously for 20 seconds.
HINT:
When transferring to deletion mode, LED (red) blinks in 6 Hz
cycle.
(b) When releasing the switch within 10 seconds after trans-
ferring to deletion mode, all the registered codes will be
erased.
HINT:
Press the switch until blinking in 6 Hz cycle stops, so that the
default code for check is set.

I03488
LED
OPERATION GARAGE DOOR
OPENER SWITCH
(Switch at either end)
ON
OFF CLEAR/DEFAULT
MODEPRESSED
LOAD DEFAULT
LED flashes at a rate of 6 HZ 10 SEC
20 SEC PRESSED
ON
OFFEnter in erase mode to erase all 3 channels BE-188
- BODY ELECTRICALGARAGE DOOR OPENER SYSTEM
2561 Author
: Date
:
2004 LAND CRUISER (RM1071U)
Code deletion timing chart

BE0RS-03
I06379
Adjusting Bolt A (Vertical Direction)
BE-34
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
2407 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT

I20844
0.4 °
3 m (9.84 ft) H 20.9 mm
(0.823 in.)
7
V RH Line
90 °
V LH Line4V LH LineV Line V RH Line 65
6
V LH LineV Line
V RH Line 6
5
6
H4
O: step No.
7
H4
20.9 mm
(0.823 in.) 1,146mm (45.1 in.) Low Beam:
High Beam:20.9 mm
(0.823 in.)
20.9 mm
(0.823 in.)
1,146mm (45.1 in.)
1,146mm
(45.1 in.)H RH and
H LH lines High Beam
Low Beam
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-35
2408 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUST HEADLIGHT AIM ONLY
(a) Place the vehicle in the following conditions.

The area around the headlight is not deformed.

The vehicle is parked on a level surface.

Tire inflation pressure is the specified value.

A driver is in the driver's seat and the vehicle is in a state ready for driving (with a tank full).

The vehicle has been bounced several times.
(b) Check the headlight aiming.
(1) Prepare a thick white paper.
(2) Stand the paper perpendicular to the ground at the position 9.84 ft away from the headlights.
(3) Ensure that the center line of the vehicle and the paper face forms a 90-degree angle as shown
in the illustration.
(4) Draw a horizontal line (H line) on the paper, showing where the headlights should strike.
(5) Draw a vertical line (V line) to where the center line of the vehicle is to be.
(6) Draw 2 vertical lines (by connecting the low and high beam center marks) to where the both head-
lights should strike (V RH and V LH lines).
(7) Draw a horizontal line (by connecting the both low beam center marks) to where the headlights
should strike (H RH and H LH lines).
HINT:
The H RH and H LH line is 0.4° below the horizontal line (H line) of the light axis.
(8) Start the engine.
(9) Turn the headlights ON.
(10) Check that the headlights properly strike the position shown in the illustration.
(11) If not, adjust the lights in the vertical direction.
HINT:
As shown in the illustration, adjust each aim of the RH and LH lights.
(c) When adjusting it in the vertical direction:
Using adjusting bolt A, adjust the headlight aim to within the specified range.
