TOYOTA LAND CRUISER 1998 Factory Repair Manual

BE2EI-01
I24733
Engine Room R/B
Cowl Side J/B LHCowl Side J/B RH
Fusible Link Block
- BODY ELECTRICALPOWER SOURCE
BE-1 1
2384 Author
: Date
:
2004 LAND CRUISER (RM1071U)
POWER SOURCE
LOCATION

I24921
Fuses:
1. TOWING
2. MIR HTR
3. RR HTR
4. HAZ-TEN
5. ALT-S
6. NV-IR
7. FR FOG
8. TOWING BRK
9. HEAD CLNER
10. FR-IG
11. PANEL
12. TOWING TAIL
13. TAIL
14. -
15. BAT
16. TEL
17. AMP
18. EFI or ECD NO.1
19. AM2
20. ETCS
21. HORN
22. HEAD RH-LWR
23. HEAD LH-LWR
24. HEAD RH-UPR
25. HEAD LH-UPR
26.STARTER
27. GLOW
28. ST1
29. AHC
30. ABS NO.1
31. ABS NO.2
Relays:
A. AHC
B. ABS SOL
C. ABS MTR1
D. ABS MTR2
E. STARTER
F. EFI or ECD
G. C/OPN
H. F/PUMP
I. HTR
J. IG1 NO.1
K. MIR HTR
L. RR HTR
M. FR FOG
N. TAIL
O. PANEL
P. CDS FAN
Q. MG CLT
R. W/TEMP CUT
S. HEAD
T. HEAD HI
U. HORN
A
1
B CD
E F
G
H I
J
KL
MN O
P
RST
U Q
2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25 26
2728 29 30 31
Engine Room R/B BE-12
- BODY ELECTRICALPOWER SOURCE
2385 Author
: Date
:
2004 LAND CRUISER (RM1071U)

I24922
Cowl Side J/B LH
ABCD
Relays:
A. DEFOG
B. IG1 No.2
C. ACC
D. DOME Fuses:
1. AHC-IG
2. POWER HTR
3. FUEL HTR
4. AHC-B
5. DEFOG
6. AM1
7. ACC
8. CIG
9. PWR OUTLET
10. OBD-2
11. STOP
12. A/C
13. BATT CHARGE
14. DBL LOCK
15. ECU-B1
16. ECU-IG1
17. GAUGE1
18. EFI or ECD NO.2
19. RR WIPER
20. SUN ROOF
21. DOOR
22. LH SEAT
23. IDLE UP
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
19 20 21 22 23
- BODY ELECTRICALPOWER SOURCE
BE-13
2386 Author
: Date
:
2004 LAND CRUISER (RM1071U)

I24923
Cowl Side J/B RH
Relays:
A. ACC CUT
B. IG1 NO.3
C. POWER MAIN Fuses:
1. P/W (RL)
2. P/W (FL)
3. VGRS
4. DOME
5. RADIO
6. WASHER
7. DIFF
8. ECU-B2
9. P/W(FR)
10.P/W(RR)
11. SECURITY
12. IGN
13. MET
14. GAUGE 2
15. SEAT HTR
16. ECU-IG2
17. WIPER
18. RH SEAT
19. RR A/C
20. TIL&TEL
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 17
18 19 20 21 22
BA
BE-14
- BODY ELECTRICALPOWER SOURCE
2387 Author
: Date
:
2004 LAND CRUISER (RM1071U)

BE0S5-05
I06114
I07503
OPEN
I06238
CLOSE
I07504
OPEN
- BODY ELECTRICALPOWER REAR QUARTER WINDOW SYSTEM
BE-85
2458 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT POWER QUARTER WINDOW SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
CLOSE3 - 6
4 - 5Continuity
OFF-Continuity
OPEN3 - 4
5 - 6Continuity
Illumination Circuit1 - 2Continuity
If continuity is not as specified, replace the switch.
2. Left side:
INSPECT POWER VENT WINDOW MOTOR OPERA-
TION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2, and check that
the window link moves to OPEN position.
(b) Remove the polarity and check that the window link
moves to CLOSE position.
If operation is not as specified, replace the window motor.
3. Right side:
INSPECT POWER VENT WINDOW MOTOR OPERA-
TION
(a) Connect the positive (+) lead from the battery to terminal
2 and the negative (-) lead to terminal 1, and check that
the window link moves to OPEN position.

I07505
CLOSE BE-86
- BODY ELECTRICALPOWER REAR QUARTER WINDOW SYSTEM
2459 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(b) Remove the polarity and check that the window link
moves to CLOSE position.

BE0S4-06
I24747
Ignition Switch
Cowl Side J/B LH

GAUGE1 FuseRear Quarter Window Switch
Rear Quarter Window Motor
BE-84
- BODY ELECTRICALPOWER REAR QUARTER WINDOW SYSTEM
2457 Author
: Date
:
2004 LAND CRUISER (RM1071U)
POWER REAR QUARTER WINDOW SYSTEM
LOCATION

BE0S5-05
I06114
I07503
OPEN
I06238
CLOSE
I07504
OPEN
- BODY ELECTRICALPOWER REAR QUARTER WINDOW SYSTEM
BE-85
2458 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT POWER QUARTER WINDOW SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
CLOSE3 - 6
4 - 5Continuity
OFF-Continuity
OPEN3 - 4
5 - 6Continuity
Illumination Circuit1 - 2Continuity
If continuity is not as specified, replace the switch.
2. Left side:
INSPECT POWER VENT WINDOW MOTOR OPERA-
TION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2, and check that
the window link moves to OPEN position.
(b) Remove the polarity and check that the window link
moves to CLOSE position.
If operation is not as specified, replace the window motor.
3. Right side:
INSPECT POWER VENT WINDOW MOTOR OPERA-
TION
(a) Connect the positive (+) lead from the battery to terminal
2 and the negative (-) lead to terminal 1, and check that
the window link moves to OPEN position.

I07505
CLOSE BE-86
- BODY ELECTRICALPOWER REAR QUARTER WINDOW SYSTEM
2459 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(b) Remove the polarity and check that the window link
moves to CLOSE position.

BE0S4-06
I24747
Ignition Switch
Cowl Side J/B LH

GAUGE1 FuseRear Quarter Window Switch
Rear Quarter Window Motor
BE-84
- BODY ELECTRICALPOWER REAR QUARTER WINDOW SYSTEM
2457 Author
: Date
:
2004 LAND CRUISER (RM1071U)
POWER REAR QUARTER WINDOW SYSTEM
LOCATION
