- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA-1 15
2065 Author
: Date
:
2004 LAND CRUISER (RM1071U)
If the preload is less than the specified value, retighten the nut
with a force of 13 N´m (130 kgf´cm, 9 ft´lbf) at a time until the spe-
cified preload is reached.
SST 09330-00021
Torque: 441 N´m (4,500 kgf´cm, 326 ft´lbf) or less
If the maximum torque is exceeded while retightening the nut,
replace the bearing spacer and repeat the preload procedure.
Do not loosen the pinion nut to reduce the preload.
24. RECHECK RING GEAR BACKLASH
(See page SA-107)
25. RECHECK TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION (See step 14)
26. CHECK RUNOUT OF COMPANION FLANGE (See
page SA-107)
27. STAKE DRIVE PINION NUT
28. INSTALL ADJUSTING NUT LOCKS
(a) Install 2 new nut locks on the bearing caps.
(b) Tightening 2 bolts, bend the nut locks.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
29. REMOVE DIFFERENTIAL CARRIER FROM OVER-
HAUL STAND ETC.

SA15N-04
F04386
SST
F05217
F05080
Matchmarks
SA-100
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
2050 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE 2 REAR WHEELS
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. DRAIN HYPOID GEAR OIL
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
3. DISCONNECT BRAKE LINES
(a) Using SST, disconnect the brake line and remove the clip.
SST 09023-00100
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
(b) Employ the same manner described above to the other
side.
4. DISCONNECT PARKING BRAKE CABLES
(a) Remove the 2 clips, pin and disconnect the parking brake
cable from the bellcrank.
(b) Employ the same manner described above to the other
side.
5. REMOVE AXLE SHAFTS
(a) Remove the 4 nuts.
Torque: 123 N´m (1,250 kgf´cm, 90 ft´lbf)
(b) Pull out the axle shaft and remove the O-ring.
NOTICE:
Be careful not to damage the oil seal.
(c) Employ the same manner described above to the other
side.
6. DISCONNECT REAR PROPELLER SHAFT
(a) Place matchmarks on the propeller shaft and differential
flange.
(b) Remove the 4 nuts, bolts, washers and disconnect the
propeller shaft.
Torque: 106 N´m (1,080 kgf´cm, 78 ft´lbf)
(c) Support the propeller shaft securely.

F05932
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA-101
2051 Author
: Date
:
2004 LAND CRUISER (RM1071U)
7. REMOVE DIFFERENTIAL CARRIER ASSEMBLY
(a) Remove the 10 nuts, washers and differential carrier as-
sembly.
NOTICE:
Be careful not to damage the installation surface.
Torque: 72 N´m (740 kgf´cm, 53 ft´lbf)
(b) Remove the gasket.

SA15P-04
SA2419SST
Steel Plate
SA2418SST
Steel Plate SA-106
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
2056 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. REMOVE COMPANION FLANGE DUST DEFLECTOR
Using SST, a steel plate and press, remove the dust deflector.
SST 09950-00020
2. INSTALL DUST DEFLECTOR
Using SST, a steel plate and press, install a new dust deflector.
SST 09726-40010

SA15S-04
F05171
49 (500, 36)
 GasketFiller PlugPin
Clip
Clip
 Gasket
Drain Plug
49 (500, 36)
15 (150, 11)
Clip
 O-Ring
123 (1,250, 91)
 Gasket
106 (1,080, 78)
Axle Shaft (RH)
No. 1
Actuator
ProtectorDifferential
Carrier
Axle Shaft (LH)
72 (740, 53)
x10
N´m (kgf´cm, ft´lbf) : Specified torque
 Non-reusable partPropeller Shaft
15 (150, 11)
15 (150, 11)
36 (367, 27)

No. 2
Actuator
Protector
Parking Brake Cable
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-1 17
2067 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
COMPONENTS

F05444
Pinion Shaft
Holder
Pinion Gear
Pinion Gear Thrust Washer
Side Gear
Side Gear Thrust
Washer
Ring Gear
 Bearing Spacer
Bearing
Plate Washer
Drive Pinionx3
x5
Differential Cover
Differential Case
137 (1,400, 101)

x12
Bearing
Plate Washer
Actuator
Shift Fork
Sleeve
24 (240, 18)
20 (200, 15)

Rear Diff. Lock
Position Switch
 Gasket
18 (185, 13)
Cover
N´m (kgf´cm, ft´lbf) : Specified torque
 Non-reusable part

Precoated part
See page SA-127
Companion Flange
 Dust Deflector
 Oil Seal
Oil Slinger
Bearing
Differential Carrier
113 (1,150, 83)
Bearing Cap
58 (590, 43)
58 (590, 43)



40 (410, 30)
SA-1 18
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2068 Author
: Date
:
2004 LAND CRUISER (RM1071U)

SA15U-1 1
W00493
30 mm
(1.18 in.)
F05182
F05183
SA2446
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-121
2071 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. SET DIFFERENTIAL CARRIER TO OVERHAUL STAND
ETC.
2. CHECK RUNOUT OF COMPANION FLANGE
Using a dial indicator, measure the vertical and lateral runout of
the companion flange.
Maximum runout: 0.10 mm (0.0039 in.)
If the runout is greater than the maximum, replace the compan-
ion flange.
3. CHECK RING GEAR RUNOUT
Using a dial indicator, measure the ring gear runout.
Maximum runout: 0.05 mm (0.0020 in.)
If the runout is greater than the maximum, replace the ring gear.
4. CHECK RING GEAR BACKLASH
Using a dial indicator, while holding the drive pinion flange,
measure the ring gear backlash.
Backlash: 0.13 - 0.18 mm (0.0051 - 0.0071 in.)
HINT:
Perform the measurements at 3 or more positions around the
circumference of the ring gear.
If the backlash is not within the specified value, adjust the side
bearing preload or repair as necessary.
5. MEASURE DRIVE PINION PRELOAD
Using a torque wrench, measure the drive pinion preload using
the backlash of the drive pinion and ring gear.
Preload (at starting):
0.64 - 0.92 N´m (6.5 - 9.4 kgf´cm, 5.7 - 8.1 in.´lbf)

F05801
F05802
SA2448
SST SA-122
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2072 Author
: Date
:
2004 LAND CRUISER (RM1071U)
6. CHECK TOTAL PRELOAD
Using a torque wrench, measure the preload with the teeth of
the drive pinion and ring gear in contact.
Total preload (at starting):
Drive pinion preload plus
0.3 - 0.5 N´m (3 - 5 kgf´cm, 2.7 - 4.4 in.´lbf)
If necessary, disassemble and inspect the differential.
7. CHECK TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION (See page SA-127)
8. REMOVE REAR DIFF. LOCK POSITION SWITCH
Remove the rear diff. lock position switch and gasket.
9. REMOVE COVER
(a) Remove the 3 bolts.
(b) Using a brass bar and hammer, tap on the cover to re-
move it.
10. REMOVE ACTUATOR, SHIFT FORK AND SLEEVE
(a) Remove the 4 bolts.
(b) Remove the shift fork shaft bolt.
(c) Using a screwdriver, pull out the actuator and remove the
sleeve and shift fork.
11. REMOVE COMPANION FLANGE
(a) Using a chisel and hammer, unstake the nut.
(b) Using SST to hold the flange, remove the nut.
SST 09330-00021

R13166
SST
SA2348
SST
Z00641
SST
SA2437
Matchmarks
R08254
SST
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-123
2073 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(c) Using SST, remove the companion flange.
SST 09950- 30012 (09951- 03010, 09953- 03010,
09954-03010, 09955-03030, 09956-03040)
12. REMOVE OIL SEAL AND OIL SLINGER
(a) Using SST, remove the oil seal from the differential carrier.
SST 09308-10010
(b) Remove the oil slinger.
13. REMOVE FRONT BEARING
Using SST, remove the front bearing from the drive pinion.
SST 09556-22010
If the front bearing is damaged or worn, replace the bearing.
14. REMOVE DIFFERENTIAL CASE ASSEMBLY
(a) Place matchmarks on the bearing cap and differential car-
rier.
(b) Remove the 4 bolts and 2 bearing caps.
(c) Using SST and a hammer, remove the plate washers.
SST 09504-22012
HINT:
Measure the plate thickness and note down it.
(d) Remove the differential case with the side bearing outer
races from the differential carrier.
HINT:
Tag the bearing outer races to show the location for reassem-
bling.

Z06911
SST
F05439
Front: Rear:
F05184
Matchmarks
SA-124
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2074 Author
: Date
:
2004 LAND CRUISER (RM1071U)
15. REMOVE DRIVE PINION AND BEARING SPACER
FROM DIFFERENTIAL CARRIER
(a) Remove the drive pinion with the rear bearing.
(b) Remove the bearing spacer.
16. REMOVE DRIVE PINION REAR BEARING
(a) Using SST and a press, remove the rear bearing from the
drive pinion.
SST 09950-00020
HINT:
If the drive pinion or ring gear is damaged, replace them as a
set.
(b) Remove the plate washer from the drive pinion.
17. REMOVE FRONT AND REAR BEARING OUTER
RACES
Using a brass bar and hammer, remove the outer races.
18. REMOVE RING GEAR
(a) Place matchmarks on the ring gear and differential case.
(b) Remove the 12 ring gear set bolts.
(c) Using a plastic hammer, tap on the ring gear to remove it
from the differential case.
19. CHECK DIFFERENTIAL CASE RUNOUT
(a) Place the bearing outer races on their respective bear-
ings. Check that the right and left outer races are not inter-
changed.
(b) Install the assembled plate washers onto the side bear-
ing.
(c) Install the differential case in the differential carrier.
HINT:
If it is difficult to install the differential case into the carrier, re-
place the plate washer with a thinner one.
However, select a plate washer that allows no clearance be-
tween it and the carrier.
(d) Align the matchmarks on the bearing cap and differential
carrier.
(e) Install and uniformly tighten the 4 bolts a little at a time.
