Page 3001 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual F05185
SA2475
Matchmarks
F05443SST
SST
F05187
SST
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-125
2075 Author: Date:
2004 LAND CRUISER   (RM1071U)
(f) Using a dial indicator, m

Page 3002 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual SA15X-09
SA-138
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2088 Author: Date:
2004 LAND CRUISER   (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page

Page 3003 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual SA15W-1 1
SA0510
R08274
R08276
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-127
2077 Author: Date:
2004 LAND CRUISER   (RM1071U)
REASSEMBLY
HINT:
Using a shop rag, clean off an

Page 3004 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual R13246MatchmarksAdhesive
F05178
SST
F05179
SST
SA1143
Boiling Water SA-128
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2078 Author: Date:
2004 LAND CRUISER   (RM1071U)
2. ASSEMBLE

Page 3005 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual F05188
F05182
F05804
SST
SST Front: Rear:
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-129
2079 Author: Date:
2004 LAND CRUISER   (RM1071U)
(g) Temporarily install the 12 set bo

Page 3006 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual SA3102
SST
R13414
SST
SA2450
SST
SA2446
SA-130
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2080 Author: Date:
2004 LAND CRUISER   (RM1071U)
7. INSTALL DRIVE PINION REAR BEARING
(a

Page 3007 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual R08261
R08262
R08263
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-131
2081 Author: Date:
2004 LAND CRUISER   (RM1071U)
9. INSTALL DIFFERENTIAL CASE IN CARRIER
(a) Place the 2 be

Page 3008 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual R08264
R08265
R08263
RA0090
SA-132
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
2082 Author: Date:
2004 LAND CRUISER   (RM1071U)
(c) Select a ring gear side plate washer so that th

Page 3009 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual R08269
SST
F05183
SA2446
F05170
- SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER (w/ Diff. Lock)
SA-133
2083 Author: Date:
2004 LAND CRUISER   (RM1071U)
(d) Using SST, tap in the plate washer.
SST 095

Page 3010 of 3115

TOYOTA LAND CRUISER 1998  Factory Repair Manual FA2013
Proper ContactHeel ContactFace Contact
Select an adjusting washer that will bring the drive
pinion closer to the ring gear.
Toe ContactFlank Contact
Select an adjusting washer that will shift t
