TOYOTA LAND CRUISER 1998 Factory Repair Manual

SA15K-04
F05115
Normal: See page SA-107
w/ Diff. Lock: See page SA-127
w/ LSD: See page SA-150

106 (1,080, 78)

Oil Seal
Oil Slinger
Bearing

Bearing Spacer
N´m (kgf´cm, ft´lbf) : Specified torque

Non-reusable partCompanion Flange
SA-94
- SUSPENSION AND AXLEREAR DIFFERENTIAL FRONT OIL SEAL
2044 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR DIFFERENTIAL FRONT OIL SEAL
COMPONENTS

F05080
Matchmarks
SA15L-08
Z15218
SST
R13239
SST
Z06901
SST
Z06902
SST
- SUSPENSION AND AXLEREAR DIFFERENTIAL FRONT OIL SEAL
SA-95
2045 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. DISCONNECT REAR PROPELLER SHAFT
(a) Place matchmarks on the propeller shaft and companion
flange.
(b) Remove the 4 nuts, bolts, washers and disconnect the
propeller shaft.
(c) Support the propeller shaft securely.
2. DRAIN HYPOID GEAR OIL
3. REMOVE COMPANION FLANGE
(a) Using a chisel and hammer, unstake the nut.
(b) Using SST to hold the flange, remove the nut.
SST 09330-00021
(c) Using SST, remove the companion flange.
SST 09950- 30012 (09951- 03010, 09953- 03010,
09954-03010, 09955-03030, 09956-03040)
4. REMOVE OIL SEAL AND OIL SLINGER
(a) Using SST, remove the oil seal.
SST 09308-10010
(b) Remove the oil slinger.
5. REMOVE FRONT BEARING
Using SST, remove the front bearing from the drive pinion.
SST 09556-22010

SA2395
SST
Z06903
SST
Z06904
SST
R13238
SST
SA1966
SST SA-96
- SUSPENSION AND AXLEREAR DIFFERENTIAL FRONT OIL SEAL
2046 Author
: Date
:
2004 LAND CRUISER (RM1071U)
6. REMOVE BEARING OUTER RACE
Using SST, remove the bearing outer race.
SST 09308-00010
NOTICE:
Do not scratch the taper surface of the outer race.
7. REMOVE BEARING SPACER
8. INSTALL NEW BEARING SPACER
9. INSTALL BEARING OUTER RACE
Using SST and a hammer, install the bearing outer race.
SST 09316-6001 1 (09316-00011, 09316-00021)
10. INSTALL FRONT BEARING
11. INSTALL OIL SLINGER AND OIL SEAL
(a) Install the oil slinger.
(b) Coat the hypoid gear oil to a new oil seal periphery.
(c) Using SST and a hammer, install the new oil seal.
SST 09214-7601 1
Oil seal drive in depth: 0.5 mm (0.020 in.)
(d) Coat MP grease to the oil seal lip.
12. INSTALL COMPANION FLANGE
(a) Using SST, install the companion flange on the drive pin-
ion.
SST 09950- 30012 (09951- 03010, 09953- 03010,
09954-03010, 09955-03030, 09956-03040)
(b) Coat the threads of a new companion flange nut with gear
oil.
(c) Using SST to hold the flange, install a new nut.
SST 09330-00021
Torque: 245 N´m (2,500 kgf´cm, 181 ft´lbf)
13. ADJUST DRIVE PINION PRELOAD
(See page SA-107, SA-127 or SA-150)
14. STAKE DRIVE PINION NUT
15. CONNECT REAR PROPELLER SHAFT
(a) Align the matchmarks on the propeller shaft and flange.
(b) Install the 4 bolts, washers and nuts.
Torque: 106 N´m (1,080 kgf´cm, 78 ft´lbf)

Z06905
Less than 5 mm
(0.20 in.)
- SUSPENSION AND AXLEREAR DIFFERENTIAL FRONT OIL SEAL
SA-97
2047 Author
: Date
:
2004 LAND CRUISER (RM1071U)
16. FILL DIFFERENTIAL WITH HYPOID GEAR OIL
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
Oil type:
w/o LSD: Hypoid gear oil API GL-5
w/ LSD: Hypoid gear oil LSD API GL-5
Recommended oil viscosity:
Above -18°C (0°F) SAE 90
Below -18°C (0°F) SAE 80W-90 or 80W
Capacity:
w/ Diff. Lock: 3.20 liters (3.38 US qts, 2.82 lmp.qts)
Others: 3.30 liters (3.49 US qts, 2.90 lmp.qts)

SA16F-02
F05238
Lateral Control Rod
N´m (kgf´cm, ft´lbf) : Specified torque
150 (1,530, 111)
149 (1,520, 110)



Non-reusable part
SA-178
- SUSPENSION AND AXLEREAR LATERAL CONTROL ROD
2128 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR LATERAL CONTROL ROD
COMPONENTS

SA16H-01
SA-180
- SUSPENSION AND AXLEREAR LATERAL CONTROL ROD
2130 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-179).

SA16G-02
F04399
A
B
- SUSPENSION AND AXLEREAR LATERAL CONTROL ROD
SA-179
2129 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. SUPPORT REAR AXLE HOUSING WITH JACK
2. REMOVE LATERAL CONTROL ROD
Remove the 2 bolts, nut, washer and lateral control rod.
Torque:
A: 149 N´m (1,520 kgf´cm, 110 ft´lbf)
B: 150 N´m (1,530 kgf´cm, 111 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nut and bolt.

SA16L-02
F05239
Retainer
Cushion
Stabilizer Bar Bracket
Retainer
Cushion
Retainer
Collar
CushionStabilizer BarBushing
Bracket


Non-reusable part
15 (150, 11)
18 (185, 13)
26 (270, 19)
18 (185, 13)
18 (185, 13)
N´m (kgf´cm, ft´lbf) : Specified torqueStabilizer Bar Link


SA-184
- SUSPENSION AND AXLEREAR STABILIZER BAR
2134 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR STABILIZER BAR
COMPONENTS

SA16M-02
F04393
F04400
- SUSPENSION AND AXLEREAR STABILIZER BAR
SA-185
2135 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE REAR WHEELS
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. SUPPORT REAR AXLE HOUSING WITH JACK
3. DISCONNECT LH AND RH STABILIZER BAR BRACK-
ETS
Remove the 4 bolts and disconnect the LH and RH stabilizer bar
brackets.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
4. REMOVE STABILIZER BAR
(a) Remove the 4 bolts and stabilizer bar with the bushings
and brackets.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(b) Remove the 2 brackets and 2 bushings from the stabilizer
bar.
5. REMOVE BOTH STABILIZER BAR LINKS FROM STA-
BILIZER BAR
(a) Remove the nut, 3 retainers, 2 cushions and disconnect
the stabilizer bar link from the bracket.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
(b) Employ the same manner described above to the other
side.
(c) Remove the 2 nuts, bolts and stabilizer bar links.
Torque: 26 N´m (270 kgf´cm, 19 ft´lbf)
(d) Remove the 2 collars and cushions.

SA16I-02
F05240
ABS Speed Sensor
Wire Harness
Lower Control Arm
N´m (kgf´cm, ft´lbf) : Specified torque
18 (185, 13)
150 (1,530, 111)
150 (1,530, 111)
150 (1,530, 111)
150 (1,530, 111)
Upper Control Arm
Heat Insulator
150 (1,530, 111)









Non-reusable part
- SUSPENSION AND AXLEREAR UPPER AND LOWER CONTROL ARM
SA-181
2131 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR UPPER AND LOWER CONTROL ARM
COMPONENTS
