TOYOTA LAND CRUISER 2003 J100 Navigation Manual

143
2003 Land Cruiser 100 Navigation (OM60A00U)
If you touch the part where switches are not
located while you are watching video on the
video CD, video CD operation switches will
appear.
“Second Page” switch: Use this switch to
display the operation switches on the sec-
ond page.
“Top Page” switch:Use this switch to dis-
play the operation switches on the top page.
“Hide Keys” switch: Use this switch to turn
off the operation switches from the display.
If “
” appears on the display when you
touch the switch, the operation is not per-
mitted. (iii) Description of each switch
 Switches on top page
“Sel. Number” switch: The track or num-
ber search screen appears. (See “Searching
by track” on the next page.)
“D. Menu Prev.” switch: When you touch
this switch while the disc menu is displayed,
the previous page appears on the screen. If
you touch this switch while the player is play-
ing video, the previous track is searched and
played.
“D. Menu Next” switch: When you touch
this switch while the disc menu is displayed,
the next page appears on the display. If you
touch this switch while the player is playing
video, the next track is searched and played.
“Main/Sub” switch: A multiplex transmis-
sion changing switch. The mode changes
from Main/Sub to Main, to Sub and back to
Main/Sub by touching this switch.
Switches on second page
“
” switch: Use this switch to pause the
video screen. When you touch this switch
again, the video screen advances by frame
by frame.
“ \b\b ” switch: Touch this switch to fast re-
verse during playback.
“  ” switch: Touch this switch during pause
to resume playing.
“  ” switch: Touch this switch to fast for-
ward during the playback and start playing
slowly during pause.

144
2003 Land Cruiser 100 Navigation (OM60A00U)
(iv) Searching by track
unx626
Enter the track numbers using “”, “+”
and “+10” switches and touch “Enter”.
The player starts playing video for that
title number.
You can select a track number by pushing
“
” or “” on the “TRACK” button.
Touch “Back”, the previous screen returns.
(g) If the player malfunctions
If the player or another unit equipped with the
player malfunction, your audio system will
display one of the six following messages.
If “DISC CHECK” appears on the display:
It indicates that the disc dirty, damaged, or it
was inserted up −side down. Clean the disc
or insert it correctly.
If “NO DISC” appears on the display: It in-
dicates that there is no disc in the DVD play-
er.
If “REGION CODE ERROR” appears on
the display: It indicates that the DVD region
code is not set properly.
If “DVD DOOR OPEN” appears on the dis-
play: It indicates that the door of the DVD
player is open.
If “DVD ERROR” appears on the display:
It indicates that the inside of the player unit
may be too hot due to the very high ambient
temperature. Remove the magazine from
the player and allow the player to cool down.
If “NO DVD MAGAZINE” appears on the
display: It indicates that the magazine is not
inserted into the DVD player.
If the malfunction is not rectified:Take
your vehicle to your Toyota dealer. (i) DVD video discs
This DVD player conforms to NTSC color
TV formats. The DVD video disc conform-
ing to another formats such as PAL or SE-
CAM cannot be used.
Region codes: Some DVD video discs
have a region code indicating a country
where you can use the DVD video disc on
this DVD player. If the DVD video disc is not
labeled as “ALL” or “1”, you cannot use it on
this DVD player. If you attempt to play an in-
appropriate DVD video disc on this player,
“REGION CODE ERROR” appears on the
screen. Even if the DVD video disc does not
have a region code, there is a case that you
cannot use it.
(h) DVD player and DVD video
disc information

145
2003 Land Cruiser 100 Navigation (OM60A00U)
Marks shown on DVD video discs:
Indicates NTSC format
of color TV.
Indicates the number
of audio tracks.
Indicates the number
of language subtitles.
Indicates the number
of angles.
Indicates the screen
to be selected.
Wide screen: 16:9
Standard: 4:3
Indicates a region code
by which this video disc
can be played.
ALL: in all countries
Number: region code
(ii) DVD video disc glossary
DVD video discs: Digital versatile Disc that
holds video. DVD video discs have adopted
“MPEG2”, one of the world standards of digi-
tal compression technologies. The picture
data is compressed by 1/40 on average and
stored. V ariable rate encoded technology in
which the volume of data assigned to the pic-
ture is changed depending on the picture for-
mat has also been adopted. Audio data is
stored using PCM and Dolby digital, which
enables higher quality of sound. Further-
more, multi−angle and multi −language fea-
tures will also help you enjoy the more ad-
vanced technology of DVD video.
Viewer restrictions: This feature limits what
can be viewed in conformity with a level of re-
strictions of the country. The level of restric-
tions varies depending on the DVD video
disc. Some DVD video discs cannot be
played at all, or violent scenes are skipped or
replaced with other scenes.
Level 1: DVD video discs for children can be
played.
Level 2 − 7: DVD video discs for children and
G−rated movie can be played.
Level 8: All types of t he DVD video discs can
be played. Multiangle feature: You can enjoy the
same scene at different angles.
Multilanguage feature: You can select a
language of the subtitle and audio.
Region codes:
The region codes are pro-
vided on DVD players and DVD discs. If the
DVD video disc does not have the same re-
gion code as the DVD player, you cannot
play the disc on the DVD player. For region
codes, see page 144.
Audio: This DVD player can play liner PCM
and Dolby digital and MPEG audio format
DVD. Other decoded type cannot be played.
Title and chapter: Video and audio pro-
grams stored in DVD video disc are divided
in parts by title and chapter.
Title: The largest unit of the video and audio
programs stored on DVD video discs. Usual-
ly, one piece of movie, one album, or one au-
dio program is assigned as a title.
Chapter: The unit smaller than that of title.
A title comprises plural chapters.

146
2003 Land Cruiser 100 Navigation (OM60A00U)
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic”, and
the doubleD symbol are trademarks of
Dolby Laboratories. Confidential unpub-
lished works.
19921997 Dolby Laboratories. All
rights reserved.
This product incorporates copyright
protection technology that is protected
by method claims of certain U.S. patents
and other intellectual property rights
owned by Macrovision Corporation and
other rights owners. Use of this copyright
protection technology must be autho-
rized by Macrovision Corporation, and is
intended for home and other limited view-
ing uses only unless otherwise autho-
rized by Macrovision Corporation. Re-
verse engineering or disassembly is
prohibited.
“DTS” is a trademark of Digital Theater
Systems, Inc.
NOTICE
To ensure correct audio/video system
operation:
 Be careful not to spill beverages
over the audio system.
 Do not put anything other than a cas-
sette tape or magazine into the cas-
sette tape slot or DVD player.
 The use of a cellular phone inside or
near the vehicle may cause a noise
from the speakers of the audio
system which you are listening to.
However, this does not indicate a
malfunction.
Radio reception
Usually, the problem with radio reception
does not mean there is a problem with your
radio − it is just the normal result of conditions
outside the vehicle. For example, nearby buildings and terrain
can interfere with FM reception.
Power lines
or telephone wires can interfere with AM sig-
nals. And of course, radio signals have a lim-
ited range, and the farther you are from a sta-
tion, the weaker its signal will be. In addition,
reception conditions change constantly as
your vehicle moves.
Here are some common reception problems
that probably do not indicate a problem with
your radio:
FM
Fading and drifting stations − Generally,
the effective range of FM is about 40 km (25
miles). Once outside this range, you may no-
tice fading and drifting, which increase with
the distance from the radio transmitter. They
are often accompanied by distortion.
Multipath − FM signals are reflective, mak-
ing it possible for two signals to reach your
antenna at the same time. If this happens,
the signals will cancel each other out, caus-
ing a momentary flutter or loss of reception.
Static and fluttering − These occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass lev-
el may reduce static and fluttering.
Car audio/video system
o
perating hints

147
2003 Land Cruiser 100 Navigation (OM60A00U)
Station swapping − If the FM signal you are
listening to is interrupted or weakened, and
there is another strong station nearby on the
FM band, your radio may tune in the second
station until the original signal can be picked
up again.
AM
Fading − AM broadcasts are reflected by the
upper atmosphere − especially at night.
These reflected signals can interfere with
those received directly from the radio station,
causing the radio station to sound alternately
strong and weak.
Station interference − When a reflected sig-
nal and a signal received directly from a radio
station are very nearly the same frequency,
they can interfere with each other, making it
difficult to hear the broadcast.
Static − AM is easily affected by external
sources of electrical noise, such as high ten-
sion power lines, lightening, or electrical mo-
tors. This results in static.
Caring for your cassette player and tapes
For high performance from your cassette
player and tapes:
Clean the tape head and other parts regular-
ly.
A dirty tape head or tape path can de-
crease sound quality and tangle your cas-
sette tapes. The easiest way to clean
them is by using a cleaning tape. (A wet
type is recommended.)
Use high −quality cassettes:
 Low−quality cassette tapes can cause
many problems, including poor sound, in-
consistent playing speed, and constant
auto−reversing. They can also get stuck
or tangled in the cassette player.
 Do not use a cassette if it has been dam-
aged or tangled or if its label is peeling off.
 Do not leave a cassette in the player if you
are not listening to it, especially if it is hot
outside.
 Store cassettes in their cases and out of
direct sunlight.
 Avoid using cassettes with a total playing
time longer than 100 minutes (50 minutes
per side). The tape used in these cas-
settes is thin and could get stuck or
tangled in the cassette player. Caring for your DVD player and discs

The player is intended for use with 12 cm
(4.7 in.) discs only.
 Extremely high temperature can keep
your DVD player from working. On hot
days, use air conditioning to cool the ve-
hicle interior before you listen to a disc.
 Bumpy roads or other vibrations may
make your multi
−disc player skip.
 I

f moisture gets into your DVD player, you
may not hear any sound even though your
DVD player appears to be working. Re-
move the magazine from the player and
wait until it dries.
CAUTION
DVD players use an invisible laser
beam which could cause hazardous
radiation exposure if directed outside
the unit. Be sure to operate the player
correctly.

148
2003 Land Cruiser 100 Navigation (OM60A00U)
Audio CDs
DVD video discs
Video CDs
DVD player
Use only compact discs marked as shown
above. The following products may not be
playable on your compact disc player.
SACD dts− CD
Copy −protected CD
CD−R(CD−Recordable)
CD−RW(CD−Re−writable)
CD−ROM
DVD−R
DVD+R
DVD−RW
DVD+RW
DVD−ROM
DVD−RAM
I17003
 Special shaped discs
I17003
Low quality disc
I17003
Labeled discs
NOTICE
To prevent damage to the player or
changer, do not use special shaped,
low quality or labeled discs such as
those shown in the illustrations.

149
2003 Land Cruiser 100 Navigation (OM60A00U)
I17003
Handle discs carefully, especially when
you set them into the magazine. Hold
them on the edge and do not bend them.
Avoid getting fingerprints on them, partic-
ularly on the shiny side.
 Dirt, scrapes, warping, pin holes, or other
disc damage could cause the player to
skip or to repeat a section of a track. (To
see a pin hole, hold the disc up to the
light.)
 Remove discs from the DVD player when
you are not listening to them. Store them
in their plastic cases away from moisture,
heat, and direct sunlight. To clean a disc: Wipe it with a soft, lint
−free
cloth that has been dampened with water.
Wipe in a straight line from the center to the
edge of the disc (not in a circle). Do not use
a conventional record cleaner or anti−static
device.

150
2003 Land Cruiser 100 Navigation (OM60A00U)

SECTION VII
151
2003 Land Cruiser 100 Navigation (OM60A00U)
APPENDIX
Speech command list 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .

152
2003 Land Cruiser 100 Navigation (OM60A00U)
Speech command list
Map Operation1Command
Action
Current Position
Current Location
Map
Shows current position map.
Zoom INZooms in.
Zoom OUTZooms out.
Maximum ScaleShows maximum scale.
Minimum ScaleShows minimum scale.
Right Map Zoom InZooms right map in.
Right Map Zoom OutZooms right map out.
Right Map Minimum ScaleShows right map minimum scale.
Right Map Maximum ScaleShows right map maximum
scale.
North Up
Change to North UpChanges map bearing to north
up.
Heading Up
Change to Heading UpChanges map bearing to heading
up.
Map Direction
Change Map DirectionChanges map bearing to another
direction.
Right Map North UpChanges right map bearing to
north up.
Right Map Heading UpChanges right map bearing to
heading up.
Right Map DirectionChanges right map bearing to
another direction.
Dual Map
Change to Dual MapChanges map to dual mode.
Single Map
Change to Single MapChanges map to single mode.
Map Operation 2–––To register a point
Command
Action
Mark This Point
MarkRegisters this point as a marked
point.
Map Operation 3–––To change the guidance mode
