TELEPHONE AND INFORMATION
126
Connecting a Bluetooth phone
AUTOMATICALLY
When you register your phone, auto
connection will be turned on. Always
set it to this mode and leave the
Bluetooth  phone in a condition where
connection can be established.
When the “ENGINE START STOP”
switch is in ACCESSORY or IGNITION
ON mode, a nearby cellular phone you
have registered is searched for.
Next, the system automatically con-
nects with the latest of the phones con-
nected to in the past.
Then, the connection result is dis-
played.
This screen appears when the Bluetooth
phone is first connected after the “ENGINE
START STOP” switch is in ACCESSORY
or IGNITION ON mode.
INFORMATION
It may take time, the phone connec-
tion is carried out during Bluetooth
audio play.

TELEPHONE AND INFORMATION
127
MANUALLY
When the auto connection has failed or
“Handsfree power” is turned off, you
have to connect Bluetooth manually.
1. Push the “INFO/PHONE” button.
2. Touch “Phone”.
3. Touch “Connect Phone”.
4. Touch “Handsfree Power”, or select
the phone to connect.
5. The “Connect Bluetooth*” screen is
displayed.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
6. When the connection is completed,
this screen is displayed.
Now you can use the Bluetooth phone.

TELEPHONE AND INFORMATION
128
When you connect the phone while
Bluetooth audio is playing
This screen is displayed, and the
Bluetooth  audio will stop temporarily.
Reconnecting the Bluetooth
phone
If the Bluetooth phone is
disconnected with a poor reception
from the Bluetooth network when the
“ENGINE START STOP” switch is in
ACCESSORY or IGNITION ON mode,
the system automatically reconnects
the Bluetooth  phone. In this case, the
connection result is not displayed.
If the Bluetooth is disconnected on pur-
pose such as you turned your cellular
phone off, this does not happen. Recon-
nect it by the following methods.
Select the Bluetooth phone again.
Enter the Bluetooth phone.

TELEPHONE AND INFORMATION
129
After you enter the Bluetooth phone,
you can call by using handsfree sys-
tem. You can call using the 6 methods
described below.
By dial
You can call by inputting the phone
number.
This cannot be operated while driving.
1. Push the “INFO/PHONE” button.
You can also push
of the steering
wheel to display the “Phone” screen.
2. Touch “Phone”.
3. Touch the desired key to input the
phone number.
Each time you touch
, an inputted
digit is deleted.
When you touch “Redial” , the number you
called last is inputted.
Touch
or push of the steering
wheel.
— Call on the Bluetooth
phone

TELEPHONE AND INFORMATION
136
When a call is received, this screen is
displayed with a sound. Touch
or
push
of the steering wheel to talk on
the phone.
To refuse to receive the call:
Touch
or push of the steering
wheel.
To adjust the volume of received call: Touch “
–” or “+” or use the volume
switch of the steering wheel.
On the international phone call, the other
party’s name may not be displayed cor-
rectly depending on the cellular phone
which you have.
While you are talking on the phone, this
screen is displayed. Y ou can do the op-
eration below on the screen.
To adjust the volume of the other party’s
voice: Touch “
–” or “+” or use the volume
switch of the steering wheel.
To hang up the phone:
Touch
or push of the steering
wheel.
To mute your voice: Touch “Mute” .
To input a Key: Touch “09” .
To transfer the call: Touch “Call Transfer” .
You cannot change from Hands −free call
to cellular phone call while driving.
When you change from cellular phone call
to Hands −free call, the Hands −free screen
will be displayed and you can operate it on
the screen.
Transferring met hod and behavior are dif-
ferent depending on the cellular phone
which you have.
For the operation of the phone, see the
manual that comes with your cellular
phone.
— Receive on the
Bluetooth  phone
— Talk on the Bluetooth
phone

SECTION 6
AUDIO/VIDEO SYSTEM
141
AUDIO/VIDEO SYSTEM
Audio/video system
Quick reference 142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 Using your audio/video system 143
. . . . . . . . . . . . . . . . . . . . . . .
Some basics 143 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Radio operation 151 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

DVD changer operation 162 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  audio operation 195 . . . . . . . . . . . . . . . . . . . . . . . . . . .
USB memory/iPod operation 203 . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video remote controls (steering switches) 211 . . . . . . . . . . .
 Rear seat entertainment system features 213
. . . . . . . . . . . . . .
Using the radio 220 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Using the DVD changer 220 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Playing an audio CD/CD text 221 . . . . . . . . . . . . . . . . . . . . . . . . .
Playing WMA/MP3 discs 221 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Playing DVD video/audio 222 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Playing a video CD 232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the video mode 235 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing other settings 237 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video system operating hints 239 . . . . . . . . . . . . . . . . . . . . . .

AUDIO/VIDEO SYSTEM
142
Operations such as selecting a preset station and adjusting the sound balance are c\
ar-
ried out on the screen. To display the audio screen, push the “AUDIO” button.
1Function menu tab
To control the radio, DVD changer,
Bluetooth audio player, AUX or USB
memory/iPod, touch the touch −
screen tabs. For details, see page
145.
2Function menu display screen
To control the radio, DVD changer,
Bluetooth  audio player, AUX or USB
memory/iPod, touch the touch −
screen buttons. For details, see page
145.
3“DISC” button
Push this button to play a DVD. For
details, see pages 145 and 167.
4“AUX·USB” button
Push this button to turn the
Bluetooth  audio player, AUX or USB
memory/iPod on. For details, see
pages 145, 151, 195 and 203.
5“LOAD” button
Push this button to insert the discs.
For details, see pages 150, 163 and
164.
6“TUNE·FILE” knob
Turn this knob to move the station
band and files up or down. For de-
tails, see pages 151, 157, 172 and
207.
Quick reference

AUDIO/VIDEO SYSTEM
147

The touchscreen buttons for radio,
DVD changer, Bluetooth audio player,
AUX and USB memory/iPod operation
are displayed on the screen when the
audio control mode is selected. Touch
them lightly and directly on the screen.
Touch the tab to select the desired mode
when the audio control mode is selected.
The selected switch is highlighted.
INFORMATION
If the system does not respond to a
touch of a touchscreen button,
move your finger away from the
screen and then touch it again.
You cannot operate dimmed
touchscreen buttons.
Wipe off fingerprints using a glass
cleaning cloth. Do not use chemi-
cal cleaners to clean the touch
screen.

AUDIO/VIDEO SYSTEM
195
Audio: This DVD player can play liner
PCM, Dolby Digital and MPEG audio for-
mat DVD. Other decoded type cannot be
played.
Title and chapter: Video and audio pro-
grams stored in DVD video disc are divid-
ed in parts by title and chapter.
Title: The largest unit of the video and au-
dio programs stored on DVD video discs.
Usually, one piece of movie, one album, or
one audio program is assigned as a title.
Chapter: The unit smaller than that of title.
A title comprises plural chapters.
Manufactured under license from
Dolby Laboratories. “Dolby”, and the
doubleD symbol are trademarks of
Dolby Laboratories.
This product incorporates copyright
protection technology that is protected
by method claims of certain U.S. pat-
ents and other intellectual property
rights owned by Macrovision Corpora-
tion and other rights owners. Use of
this copyright protection technology
must be authorized by Macrovision
Corporation, and is intended for home
and other limited viewing uses only un-
less otherwise authorized by Macrovi-
sion Corporation. Reverse engineering
or disassembly is prohibited.
“DTS” and “DTS Digital Surround” are
registered trademarks of Digital The-
ater Systems, Inc.
Manufactured under license under
U.S. Patent #’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,487,535 & oth-
er U.S. and worldwide patents issued
& pending. DTS and the Symbol are
registered trademarks & DTS Digital
Surround and the DTS logos are trade-
marks of DTS, Inc. Product includes
software. DTS, Inc. All Rights Re-
served. The Bluetooth
audio system enables
users to enjoy music played on a porta-
ble player from the vehicle speaker via
wireless communication.
This audio system supports
Bluetooth , a wireless data system
capable of playing portable audio
music without cables. If your portable
player does not support Bluetooth ,
the Bluetooth audio system will not
function.
— Bluetooth audio
operation

AUDIO/VIDEO SYSTEM
196
INFORMATION
Portable players must correspond to
the following specifications in order
to be connected to the Bluetooth au-
dio system. However, please note
that some functions may be limited
depending on the type of portable
player.
 Bluetooth  Specification
Ver.1.1 or higher
(Recommended: Ver.2.0+EDR or
higher)
 Profile
 A2DP (Advanced Audio Dis-
tribution Profile) Ver.1.0 or high-
er
 AVRCP (Audio/Video Remote
Control Profile) Ver.1.0 or higher
(Recommended: Ver .1.3 or high-
er)
Please go to “http://www.toyota.
letstalk.com/” to find approved
Bluetooth  phones for this system.
Bluetooth is a trademark owned by
Bluetooth SIG. Inc.
CAUTION
Do not operate the player’s controls
or connect to the Bluetooth  audio
system while driving.
NOTICE
Do not leave your portable player in
the car. In particular, high tempera-
tures inside the vehicle may damage
the portable player.
INFORMATION
In the following conditions, the
system may not function.
 The portable player is turned off.
 The portable player is not con-
nected.
 The portable player has a low bat-
tery.
It may take time, the phone connec-
tion is carried out during
Bluetooth  audio play.
