Page 111 of 620

LC200_OM_OM60Q26U_(U)
1113-2. Opening, closing and locking the doors
3
Operation of each component
■Setting and canceling the functions
To switch between setting and canceling, follow the procedure
below:Close all the doors and turn the engine switch to IGNITION ON
mode. (Perform step within 20 seconds.)
Shift the shift lever to P or N,
and press and hold the door
lock switch ( or ) for
approximately 5 seconds and
then release.
The shift lever and switch posi-
tions corresponding to the
desired function to be set are
shown in the following table.
Use the same procedure to cancel the function.
When the setting or canceling ope ration is complete, all the doors
are locked and then unlocked.
1
2
2
FunctionShift lever positionDoor lock switch position
Shift position linked door locking
function
PShift position linked door unlock-
ing function
Speed linked door locking func-
tion
NDriver’s door linked door unlocking
function
Page 112 of 620

112
LC200_OM_OM60Q26U_(U)
3-2. Opening, closing and locking the doors
■Changing the door unlock function setting
It is possible to set which doors the entry function unlocks using the wireless
remote control.
Turn the engine switch off.
When the indicator light on the key surface is not on, press and hold
or for approximately 5 seconds while pressing and holding .
The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat step .)
To prevent unintended triggering of the alarm, unlock the doors using the
wireless remote control and open and close a door once after the settings
have been changed. (If a door is not opened within 60 seconds after is
pressed, the doors will be locked again and the alarm will automatically be
set.)
In a case that the alarm is triggered, immediately stop the alarm. ( →P. 75)
1
2
2
Multi-information
displayUnlocking functionBeep
Holding the driver’s door
handle unlocks only the
driver’s door.
Exterior: Beeps 3
times
Interior: Pings once
Holding a passenger’s door
handle unlocks all the
doors.
Holding a door handle
unlocks all the doors.Exterior: Beeps twice
Interior: Pings once
Page 113 of 620

LC200_OM_OM60Q26U_(U)
1133-2. Opening, closing and locking the doors
3
Operation of each component
■Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are
unlocked. Depending on the force of the impact or the type of accident, how-
ever, the system may not operate.
■ Using the mechanical key
The doors can also be locked and unlocked with the mechanical key.
(→P. 548)
■ Conditions affecting the operation of the smart key system or wireless
remote control
→P. 128
■ Customization
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features: →P. 582)
WARNING
■To prevent an accident
Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant being thrown
out of the vehicle, resulting in death or serious injury.
● Ensure that all doors are properly closed and locked.
● Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened even
if the inside lock buttons are in locked position.
● Set the rear door child-protector locks when children are seated in the rear
seats.
Page 114 of 620

114
LC200_OM_OM60Q26U_(U)
3-2. Opening, closing and locking the doors
Back door
◆Smart key system
Carry the electronic key to enable this function.Locks all the doors
Check that the door is securely
locked.
Unlocks all the doors
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
◆Wireless remote control
→P. 1 0 6
◆Door lock switches
→P. 1 0 8
Press and hold the switch.
The power back door can be oper-
ated even when the back door is
locked.
*
*
: This setting can be customized so
that the power back door can be
operated only when the back door
is unlocked. ( →P. 582)
The back door can be locked/unl ocked and opened by the fol-
lowing procedures.
Locking and unlocking the back door
1
2
Opening/closing the back door with the wireless remote control
(vehicles with power back door)
Page 115 of 620

LC200_OM_OM60Q26U_(U)
1153-2. Opening, closing and locking the doors
3
Operation of each component
The power back door can be
opened/closed using the power
back door switch or wireless
remote control. (→P. 1 1 4 )
Push and hold the switch to close
or open.
(A buzzer sounds.)
Open the upper back door
Vehicles without power back
door
When the back door is
unlocked: Raise the back
door while pressing up the
back door opener switch.
When the back door is
locked: While carrying an
electronic key, raise the back
door while pressing up the
back door opener switch.
Vehicles with power back door
When the power back door is unlocked: Press the back door
opener switch.
When the power back door is locked: While carrying an elec-
tronic key, press and hold the back door opener switch.
The upper back door will automatically* open.
*: Using the customization function, the upper back door can be set to not automatically open, even when the back door opener switch is
pressed. ( →P. 582)
When the automatic open function is disabled, the upper back door
can be opened by lifting it up with the back door opener switch
pressed and held.
Opening the back door from the inside (vehicles with power
back door)
Opening the back door from the outside
1
Page 116 of 620

116
LC200_OM_OM60Q26U_(U)
3-2. Opening, closing and locking the doors
Open the lower back door
Pull the handle.
Pressing the switch closes upper
back door automatically. (A
buzzer sounds.)
Pressing the switch while the
upper back door is closing opens it
again.
Turn the main switch off to disable
the power back door system. On
Orange mark on the switch should
be visible when the switch is on.
Off
The back door cannot be operated
even with the wireless remote con-
trol or power back door switch.
2
Power back door switch (if equipped)
Canceling the power back door system (if equipped)
1
2
Page 117 of 620

LC200_OM_OM60Q26U_(U)
1173-2. Opening, closing and locking the doors
3
Operation of each component
●Make sure that the lower side of
the back door is closed before
closing the upper side of the
back door.
● Lower the back door using the
back door handle, and make
sure to push the back door
down from the outside to close
it.
The rear step bumper is for rear
end protection and easier step-up
loading.
When closing the back door
Rear step bumper
Page 118 of 620

118
LC200_OM_OM60Q26U_(U)
3-2. Opening, closing and locking the doors
■Power back door operati ng conditions (vehicles with power back door)
● When the engine switch is off or in accessory mode, the power back door
can be opened and closed if the power back door main switch is on and all
of the following conditions are met.
• The lower back door is closed (only when closing)
*1
●When the engine switch is in IGNITION ON mode, the power back door can
be opened and closed if the power back door main switch is on and all of the
following conditions are met.
*2
• The power back door is unlocked (except when closing)
• The lower back door is closed (only when closing)
*1
• The vehicle speed is below 1 mph (3 km/h) and the shift lever is in P
*1: If the lower back door is opened while the upper back door is in a closing
operation, it automatically opens again.
*2: The back door cannot be operated using the wireless remote control.
■ If the back door open er is inoperative
The back door can be operated from the inside.
Remove the cover on the back door
trim.
Use a cloth to prevent scratches.
Remove the screw and cover.
(Vehicle without power back door)
1
2
Page 119 of 620

LC200_OM_OM60Q26U_(U)
1193-2. Opening, closing and locking the doors
3
Operation of each component
Push the lever for the back door motor, open the back door.
Vehicles without power back door
Vehicles with power back door
■ Jam protection function (veh icles with power back door)
If anything obstructs the power back door while it is closing/opening, the back
door will automatically operate in the opposite direction.
■ When re-connecting the battery (vehicles with power back door)
To enable the power back door to operate properly, perform the following:
● Unlock the back door using the door lock switch
● Close the back door manually
■ Back door closer (vehicl es with power back door)
In the event that the upper side and lower side of the back door are left
slightly open, the back door closer will automatically close them to the fully
closed position.
■ Fall-down protection function (vehicles with power back door)
While the power back door is opening automatically, applying excessive force
to it will stop the opening operation to prevent the power back door from rap-
idly falling down.
3
IY32LA068
Page 120 of 620

120
LC200_OM_OM60Q26U_(U)
3-2. Opening, closing and locking the doors
■Back door reserve lock function ( vehicles with power back door)
This function is a function which re serves locking of all doors, beforehand,
when the back door is open. When the following procedure is performed, all
the doors except the back door are locked and then back door will also b\
e
locked at the same time it is closed.
Close all doors, except the back door.
Perform any of the following during the automatic closing operation of the
back door.
• Press the lock button on the wireless remote control. ( →P. 102)
• Touch the lock sensor on the side door handle with carrying the electronic key on your person. ( →P. 106)
Also, if the back door does not fully close due to the operation of the jam
protection function, etc., while the back door is automatically closing after a
reserve lock operation is performed, the reserve lock function is canceled
and all the doors will unlock.
■ Customization
Settings (e.g. switch operation) can be changed.
(Customizable features →P. 582)
WARNING
■While driving
● Keep the back door closed while driving.
If the back door is left open, it may hit near-by objects while driving or lug-
gage may be unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a seri-
ous health hazard. Make sure to close the back door before driving.
● Before driving the vehicle, make sure that the back door is fully closed. If
the back door is not fully closed, it may open unexpectedly while driving,
causing an accident.
● Never let anyone sit in the luggage compartment. In the event of sudden
braking, sudden swerving or a collision, they are susceptible to death o\
r
serious injury.
■ When children are in the vehicle
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not allow children to play in the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could
have heat exhaustion or other injuries.
● Do not allow a child to open or close the back door.
Doing so may cause the back door to move unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door.
1
2
