TOYOTA LAND CRUISER 2018 (in English) User Guide

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
9
Engine oil level dipstick
Engine coolant reservoirWindshield washer fluid tank
Engine oil filler cap
NOTE: Regularly scheduled maintenance, including oil changes, will help
extend the life of your vehicle and maintain performance. Please refer to the
“Warranty & Maintenance Guide.”
Brightness
control
-
+
Instrument panel light control
Engine maintenance

10
Auto lock/unlock
Automatic transmission
Automatic door locks can be programmed to operate in four different mode\
s, or
turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed is approximately 12 mph or higher.
-Doors unlock when shifting into Park.
-Doors unlock when the driver’s door is opened within 45 seconds after\
turning the “ENGINE START STOP” switch OFF. (Vehicles with a Smart Key system\
)
-Doors unlock when the driver’s door is opened within 45 seconds afte\
r turning the ignition switch to the “ACC” or “LOCK” position. (Vehic\
les without a Smart Key
system)
Refer to the Owner’s Manual for more details.
* The “ENGINE START STOP” switch/ignition switch must be “ON”\
and the brake pedal depressed to shift from Park.
Shift the shift lever to “S” position from “D” position.
+ : Upshift (push and release)
- : Downshift (pull and release)
Downshifting increases power going uphill, or provides engine braking do\
wnhill. For
best fuel economy during normal driving conditions, always drive with th\
e shift lever
in the “D” position.
Park*
Reverse
Neutral
Drive
P
R
N
D
S“S” mode
For powerful acceleration and driving in
mountainous regions.For starting on slippery surfaces, such as snowy
roads. Press “2nd” to return to normal mode.
POWER MODE SECOND GEAR START MODE
FEATURES & OPERATIONS
“S” (SEQUENTIAL) MODE

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
11
Four-wheel drive
High speed
Low speed
Shift to “N” position when stopped, then push and turn to “L4.”\
H4
L4
Lock the center differential when your vehicle’s wheels get stuck in \
a ditch or when
driving on a slippery or bumpy surface.
Push
Turn
FOUR-WHEEL DRIVE CONTROL SWITCH
CENTER DIFFERENTIAL LOCK/UNLOCK SWITCH

12
Seat adjustments-Front
Seat adjustments-Rear
Seats-Head restraints
FEATURES & OPERATIONS
Seat positionSeatback angleLumbar support
(driver’s side only)
Seat position, cushion
angle and height Seatback angle
Refer to the Owner’s Manual for more details.
Second row
Third row (fold down)
Front Second rowThird row
Lock release button
Height
Angle
(if equipped)Lock release button
Height
Fold down
Lock release lever
Seatback angle

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
13
Seats-Tumbling 2nd row seats
(1)
(5)
(3)
(2)
(4)
Pull Seat hook cover
Pull
Stow the seat belt buckles and
lower the head restraints.
Hook the seat belt to the seat
belt hangers.
Hook the holding strap to the assist
grip and secure the seat. Install the seat hook covers on the
seat hooks.
Fold down the seatback and swing the whole seat up and forward.

14
Seats-Tumbling 3rd row seats
FEATURES & OPERATIONS
Stow the seat belt buckles.Stow the center head restraint.
Hook the seat belt to the seat belt
hangers. Fold down the outer head restraints.
Fold the seats. Lift the seats sideward.
Lock the seats. Install the seat hook covers on the
seat hooks.
Install the seat hook covers into
the back of the seat cushions. Lower the seats to their
original
position.
(1)
(5)
(3)
(2)
(4)
Push
(6)
Pull
(7)(8)
Seat hook cover
Pull
Pull
Returning seats
(1)(2)

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
15
Steering lock release
Turn
Push
Tilt and telescopic steering wheel
Up
Toward driver
Down
NOTE: Do not attempt to adjust while the vehicle is in motion.
Away from
driver
Control switch

16
FEATURES & OPERATIONSBack door
Pull
Unlock
The back door can be locked and unlocked using the entry function, wirel\
ess
remote control or door lock switch.
Raise
Upper back door Lower back door
Door locks
LockUnlock
Power back door (if equipped)
Upper back door
Open: Push and hold
Close: Push and hold again
NOTE: If battery is disconnected, the power back door needs to be reinitialized.
Refer to the
Owner’s Manual for more details.
Instrument panel
NOTE: Door will stop closing if obstructed, or to
manually stop door closing, push button again.
Push and holdPush
Upper back door

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
17
Daytime Running Light system (DRL) Automatically turns on the headlights at a
reduced intensity. Automatic light cut off system Automatically turns lights off after a delay of 30
seconds.
Right turn
Lane change
Lane change Left turn
Auto
OFF
Parking lights
Headlights
TurnOFF
ON
Front fog lights come on only when the headlights are on low beam.
Low beam
High beam flasher
High beam
Lights & turn signals
HEADLIGHTS
FRONT FOG LIGHTS
TURN SIGNALS

18
FEATURES & OPERATIONS
Intermittent
Normal
Adjust sensor sensitivity2
Pull to wash and wipe
Push to wash
and wipe
Single wipe
Auto wipe
Slow
Fast
1 Intermittent windshield wiper frequency adjustment Rotate to increase/
decrease wipe frequency.
2 Rain-sensing windshield wiper Rotate to increase/decrease sensor sensitivity.
With intermittent wiper
With AUTO rain-sensing wiper
Pull to wash
and wipe
Single wipe
Interval wipe
Slow
Fast
Adjust
frequency1
Turn end to activate
FRONT
REAR
Up
Down
Driver sideWindow lock switch
Automatic operation Push the switch completely down or pull it completely up and
release to fully open or close. To stop window midway, lightly push the \
switch in the
opposite direction.
Window lock switch Deactivates all passenger windows. Driver’s window remains
operable.
Windows-Power
Windshield wipers & washers
