TOYOTA LAND CRUISER 2020 Accessories, Audio & Navigation (in English)

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
Information
6
2111. Information display
1Display the “Weather” screen.
(P.210)
2Select “Current Weather”.
3Select the desired ta b to be displayed. 
When the “Current” tab is selected
 When the “3 Day” tab is selected
When a specific day is selected, weather
information for that day will be displayed.
When the “6/12 Hour” tab is selected
Displaying the weather of the
current location
INFORMATION
●If weather is set to the home screen, the
weather screen of the current location
will be displayed.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2121. Information display
1Press the “SETUP” button.
2Select “Data Services Settings” .
3Select the desired item to be set.
Select a checkbox on the right to set.
Data services settings
Setting download methods
Data service information, which is
comprised of traffic information and
weather information, can be received
via the HD Radio and by the Entune
App Suite application on a Bluetooth
®
phone. The receiving method can be
set to both or only via the HD Radio.
For details about the Entune App Suite
application: P.249
No.Function
Select to receive data service infor-
mation via both the HD Radio and
the Entune App Suite application on
a Bluetooth
® phone. When both
methods are available, the HD Ra-
dio will be selected.
Select to receive data only via the
HD Radio.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
213
7
1. Phone operation(Hands-free systemfor cellular phones)
Quick reference ... .................... 214
Some basics .......... ................. 214
Registering/connecting a
Bluetooth® phone.................... 215
Using the phone switch/ microphone ............................. 215
Voice command system ............ 216
About the contacts in the contact list ............................... 216
When selling or disposing of the vehicle ..................................... 216
Calling on the Bluetooth®
phone .................................... 217
By favorites list .......................... 218
By call history ............................ 218
By contacts list .......................... 219
By dial pad................................. 220
By off hook switch ..................... 221
Receiving on the Bluetooth®
phone .......... .......................... 221
Incoming calls ........................... 221
Talking on the Bluetooth®
phone .......... .......................... 222
Incoming call waiting ................. 223
Bluetooth® phone message
function ................................. 224
Receiving a message................ 224
Checking messages.................. 225
Replying to a message
(Quick reply) ........................... 226
Calling the message sender ..... 227
2. Setup
Phone/message settings ......... 228
Phone/message settings screen .................................... 228
“Sound Settings” screen .......... 229
“Contact/Call History Settings” screen ..................................... 230
“Messaging Settings” screen .... 237
“Phone Display Settings” screen ..................................... 238
3. What to do if...
Troubleshooting...... ................. 239
Phone

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2141. Phone operation (Hands-free system for cellular phones)
Quick reference
The phone top screen can be used to
make a phone call. To display the
hands-free operation screen, press the button or the switch on the
steering wheel.
Several functions are available to op-
erate on each screen that is displayed
by selecting the 4 tabs.
FunctionPage
Phone operation
Registering/connecting
Bluetooth® device32
Calling on the Bluetooth® phone217
Receiving on the Bluetooth®
phone221
Talking on the Bluetooth® phone222
Message function
Using the Bluetooth® phone mes-
sage function224
Setting up a phone
Phone settings228
Bluetooth® settings36
Some basics
The hands-free system enables calls
to be made and received without hav-
ing to take your hands off the steering
wheel.
This system supports Bluetooth
®.
Bluetooth
® is a wireless data system
that enables cellular phones to be used
without being connected by a cable or
placed in a cradle.
The operating procedure of the phone
is explained here.
WARNING
● While driving, do not use a cellular
phone or connect the Bluetooth® phone.
● Your audio unit is fitted with Bluetooth
®
antennas. People with implantable car-
diac pacemakers, cardiac resynchroni-
zation therapy-pacemakers or
implantable cardioverter defibrillators
should maintain a reasonable distance
between themselves and the Bluetooth
®
antennas. The radio waves may affect
the operation of such devices.
● Before using Bluetooth
® devices, users
of any electrical medical device other
than implantable cardiac pacemakers,
cardiac resynchronization therapy-pace-
makers or implantable cardioverter
defibrillators should consult the manu-
facturer of the device for information
about its operation under the influence
of radio waves. Radio waves could have
unexpected effects on the operation of
such medical devices.
NOTICE
● Do not leave your cellular phone in the
vehicle. The temperature inside may rise
to a level that could damage the phone.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2151. Phone operation (Hands-free system for cellular phones)
Phone
7
Steering switch
Volume control switch
 Press the “+” side to increase the volume.
 Press the “-” side to decrease the vol-
ume.
Off hook switch
On hook switch
 Microphone
INFORMATION
● This system is not guaranteed to oper-
ate with all Bluetooth® devices.
● If your cellular phone does not support
Bluetooth
®, this system cannot function.
● In the following conditions, the system
may not function:
• The cellular phone is turned off.
• The current position is outside the
communication area.
• The cellular phone is not connected.
• The cellular phone has a low battery.
● When using Bluetooth
® audio and
hands-free system at the same time, the
following problems may occur:
• The Bluetooth
® connection may be
cut.
• Noise may be heard on the Bluetooth
®
audio playback.
Registering/connecting a
Bluetooth® phone
To use the hands-free system for cellu-
lar phones, it is necessary to register a
cellular phone with the system.
( P.32)
Bluetooth® phone condition
display
The condition of the Bluetooth
® phone
appears on the upper right side of the
screen. ( P.11)
Using the phone switch/
microphone
By pressing the phone switch, a call
can be received or ended without tak-
ing your hands off the steering wheel.
The microphone is used when talking
on the phone.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2161. Phone operation (Hands-free system for cellular phones)
The following data is stored for every reg-
istered phone. When another phone is
connected, the following registered data
cannot be read:
• Contact data
• Call history data
• Favorites data
• Image data
• All phone settings
• Message settings
 The following data in the system can be
initialized:
• Contact data
• Call history data
• Favorites data
• Image data
• All phone settings
• Message settings
Voice command system
Press this switch to operate the voice
command system.
 The voice command system and its list
of commands can be operated.
( P.194)
INFORMATION
●The other party’s voice will be heard
from the front speakers. The audio/
visual system will be muted during
phone calls or when hands-free voice
commands are used.
● Talk alternately with the other party on
the phone. If both parties speak at the
same time, the other party may not hear
what has been said. (This is not a mal-
function.)
● Keep call volume down. Otherwise, the
other party’s voice may be audible out-
side the vehicle and voice echo may
increase. When talking on the phone,
speak clearly towards the microphone.
● The other party may not hear you clearly
when:
• Driving on an unpaved road. (Making
excessive traffic noise.)
• Driving at high speeds.
• The roof or windows are open.
• The air conditioning vents are pointed towards the microphone.
• The sound of the air conditioning fan is loud.
• There is a negative effect on sound quality due to the phone and/or net-
work being used.
About the contacts in the contact
list
INFORMATION
● When a phone’s registration is deleted,
the above-mentioned data is also
deleted.
When selling or disposing of the
vehicle
A lot of personal data is registered
when the hands-free system is used.
When selling or disposing of the vehi-
cle, initialize the data. ( P.48)
INFORMATION
● Once initialized, the data and settings
will be erased. Pay much attention when
initializing the data.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2171. Phone operation (Hands-free system for cellular phones)
Phone
7
1Press the button.
2Select the desired tab to call from.
The phone top screen can be displayed by
pressing the
switch on the steering
wheel.Calling on the Bluetooth®
phone
After a Bluetooth® phone has been
registered, a call can be made using
the hands-free system. There are sev-
eral methods by which a call can be
made, as described below.How to make a callPage
By favorites list218
By call history218
By contacts list*219
By dial pad*220
By e-mail/SMS/MMS227
By POI call63
By off hook switch221
By Entune App Suite*255
By voice command system199
*: The operation cannot be performed
while driving.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2181. Phone operation (Hands-free system for cellular phones)
1Display the phone top screen.
(P.217)
2Select the “Favorites” tab and select
the desired contact.
3Select the desired number.
4Check that the “Call” screen is dis-
played.
1Display the phone top screen.
( P.217)
2Select the “Call History” tab and se-
lect or the desired contact.
 The icons of call type are displayed.
: Missed call
: Incoming call
: Outgoing call
 When is selected
3Check that the “Call” screen is dis-
played.
 When the desired c ontact is selected
3Select the desired number.
4Check that the “Call” screen is dis-
played.
By favorites list
Calls can be made using registered
contacts which can be selected from a
contact list. ( P.235)By call history
Up to 30 of the latest call history items
(missed, incoming and outgoing) can
be selected from the “Call History” tab.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2191. Phone operation (Hands-free system for cellular phones)
Phone
7
1Display the phone top screen.
(P.217)
2Select the “Contacts” tab and select
the desired contact.
3Select the desired number.
4Check that the “Call” screen is dis-
played.
■For PBAP compatible Bluetooth®
phones
 When “Automatic Contact/History
Transfer” is set to on ( P.230)
1Select the “Contacts” tab.
Contacts are transferred automatically.
2Check that a confirmation screen is
displayed when the operation is com-
plete.
 When “Automatic Contact/History
Transfer” is set to off ( P.230)
1Select the “Contacts” tab.
2Select the desired item.
INFORMATION
●When making a call to the same number
continuously, only the most recent call is
listed in call history.
● When a phone number registered in the
contact list is received, the name is dis-
played.
● Number-withheld calls are also memo-
rized in the system.
● International phone calls may not be
made depending on the type of cellular
phone you have.
● The list should group together consecu-
tive entries with the same phone number
and same call type. For example, two
calls from John’s mobile would be dis-
played as follows: John (2)
● By pressing the
switch on the
steering wheel, a call to the latest history
item can be made.
By contacts list
Calls can be made by using contact
data which is transferred from a regis-
tered cellular phone. ( P.219)
Up to 2500 contacts (maximum of 4
phone numbers and e-mail addresses
per contact) can be registered in the
contact list.
When the contact is empty
No.Function
Select to always transfer all the con-
tacts from a connected cellular
phone automatically.
Select to transfer all the contacts
from a connected cellular phone
only once.
Select to cancel transferring.

LC200_Navi_OM60R69U_(U)
19.03.06 15:36
2201. Phone operation (Hands-free system for cellular phones)
3Check that a confirmation screen is
displayed when the operation is com-
plete.
■For PBAP incompatible but OPP
compatible Bluetooth
® phones
1Select the “Contacts” tab.
2Select the desired item.
 When “Transfer” is selected
3Follow the steps in “For PBAP
incompatible but OPP compatible
Bluetooth
® phones” from step 3.
(P.231)
 When “Add” is selected
3Follow the steps in “Registering a new
contact to the contact list” from step 2.
(P.232)
1Display the phone top screen.
( P.217)
2Select the “Dial Pad” tab and enter the
phone number.
3Select or press the switch
on the steering wheel.
4Check that the “Call” screen is dis-
played.
No.Function
Select to transfer the contacts from
the connected cellular phone.
Select to add a new contact manual-
ly.
Select to cancel transferring.
INFORMATION
● Manual transfer operation cannot be
performed while driving.
● If your cellular phone is neither PBAP
nor OPP compatible, the contacts can-
not be transferred.
● Depending on the type of Bluetooth
®
phone:
• It may be necessary to perform addi-
tional steps on the phone when trans-
ferring contact data.
• The registered image in the contact list may not transfer depending on the
type of Bluetooth
® phone connected.
By dial pad
INFORMATION
● Depending on the type of Bluetooth®
phone being connected, it may be nec-
essary to perform additional steps on
the phone.
