TOYOTA LAND CRUISER 2020 Owners Manual (in English)

LC200_OM_OM60R53U_(U)
4215-3. Using the storage features
5
Interior features
Remove the cover. Hold the first-
aid kit with a band.
The first-aid kit itself is not included
as an original equipment.
■
Using the luggage cover
Pull out the luggage cover and
hook it on the anchors.
■Removing the luggage cover
Retract the cover and release
both ends, then lift it out.
After removing the luggage
cover, place it somewhere other
than the passenger compart-
ment.
First-aid kit holder
Luggage cover (if equipped)

422
LC200_OM_OM60R53U_(U)
5-3. Using the storage features
■When installing the luggage cover (if equipped)
Keep the “TOP” mark on the luggage
cover ends upward.
WARNING
●To avoid injury, always return the cargo hooks to their positions when not
in use.
● Keep the auxiliary box closed. In the event of sudden braking o r sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.
● Do not allow children to climb on the luggage cover. Climbing o n the lug-
gage cover could result in damage to the luggage cover, possibl y causing
death or serious injury to the child.
NOTICE
■ To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.

423
LC200_OM_OM60R53U_(U)
5-4. Using the other interior features
5
Interior features
Other interior features
While the engine is running, the cool box, which is cooled by the air
conditioning , can be used.
Lift the lid while pulling up the
lower lever to release the lock.
Turns the cool box on/off
When on, the indicator light comes
on.
If the front air conditioning system
is not in use, the front air condition-
ing system is automatically turned
on when the cool box is turned on.
■ While the cool box is on
The front air conditioning system cannot be turned off.
■ When the outside temperature is 32 F (0 C) or below
The cool box may not operate.
Cool box (if equipped)
1
2

424
LC200_OM_OM60R53U_(U)
5-4. Using the other interior features
WARNING
Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swer ving or an
accident.
NOTICE
To prevent battery discharge, do not leave the cool box on long er than nec-
essary when the engine is not running.

LC200_OM_OM60R53U_(U)
4255-4. Using the other interior features
5
Interior features
Main sun visor
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Sub sun visor
Flip down with the main sun visor
in position or .
Slide the cover to open.
The light turns on when the cover
is opened.
If the vanity lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.
Sun visors
1
2
3
23
Vanity mirror
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended
periods when the engine is not running.

426
LC200_OM_OM60R53U_(U)
5-4. Using the other interior features
Refer to “NAVIGATION SYSTEM
OWNER’S MANUAL” for adjust-
ment.
■The clock is displayed when
The engine switch is in ACCESSORY or IGNITION ON mode.
The displayed temperature
ranges from -22 F (-30C) up to
122 F (50 C).
■The outside temperature is displayed when
The engine switch is in IGNITION ON mode.
■ When --- is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
■ Display
In the following situations, the correct outside temperature ma y not be dis-
played, or the display may take longer than normal to change.
● When stopped, or driving at low speeds (less than 12 mph [20 km/h])
● When the outside temperature has changed suddenly (at the entra nce/exit
of a garage, tunnel, etc.)
Clock
Outside temperature display

LC200_OM_OM60R53U_(U)
4275-4. Using the other interior features
5
Interior features
The power outlet can be used for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories t hat use less than 100 W
■Center of console
Front (12 V DC)
Press the lid to open.
Rear (12 V DC)
Power outlets

428
LC200_OM_OM60R53U_(U)
5-4. Using the other interior features
■Luggage compartment (120 V AC)
■The power outlet can be used when
12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode.
120 V AC: The engine switch is in IGNITION ON mode.
■ When turning the engine switch off
Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the engine switch may not be turned off
normally.
NOTICE
■ To avoid damaging the power outlets
Close the power outlet lid when not in use.
Foreign objects or liquids that enter the power outlet may caus e a short cir-
cuit.
■ To prevent the fuse from being blown
12 V DC: Do not use an accessory that uses more than 12 V 10 A.
120 V AC: Do not use a 120 V AC appliance that requires more than 100 W.
If a 120 V AC appliance that consumes more than 100 W is used, th e pro-
tection circuit will cut the power supply.
■ To prevent the battery from being discharged
Do not use the power outlet longer than necessary when the engi ne is not
running.
■ Appliances that may not operate properly (120 V AC)
The following 120 V AC appliances may not operate even if their power
consumption is under 100 W.
● Appliances with high initial peak wattage
● Measuring devices that process precise data
● Other appliances that require an extremely stable power supply

LC200_OM_OM60R53U_(U)
4295-4. Using the other interior features
5
Interior features
A portable device can be charged by just placing Qi standard wireless
charge compatible portable devices according to the Wireless Po wer
Consortium, such as smart phones and mobile batteries, etc., on the
charge area.
This function cannot be used with portable devices that are lar ger
than the charging area. Also, depending on the portable device, it may
not operate as normal. Please read the operation manual for por table
devices to be used.
■The “Qi” symbol
The “Qi” symbol is a trademark of the Wireless Power Consortium .
■Name for all parts
Power supply switch
Operation indicator light
Charge area
Wireless charger (if equipped)
1
2
3

430
LC200_OM_OM60R53U_(U)
5-4. Using the other interior features
■Using the wireless charger
Press the lid to open.
Press the power supply
switch of the wireless char-
ger.
Switches on and off with each
press of the power supply
switch.
When turned on, the operation
indicator light (green) comes on.
Even with the engine off, the on/
off state of the power supply
switch is memorized.
Place the charging side of
the portable device down.
When charging, the operation
indicator light (orange) comes
on.
If charging is not occurring, try
placing the portable device as
close to the center of the
charging area as possible.
When charging is complete, the operation indicator light (green ) comes
on.
● Recharging function
• When charging is complete and after a fixed time in the charge suspension state, c harging restarts.
• When the portable device is moved, charging is stopped for a moment and then it restarts.
1
2
3
