3915-1. Using the air conditioning system and defogger
5
Interior features
■Changing the air flow mode
Press .
The air flow mode switches
each time the button is pressed.
Air flows to the upper body
Air flows to the upper body
and feet
Air flows to the feet
Air flows to the feet and the
windshield defogger oper-
ates
Select the air flow mode
* (left-
hand side)
Air flows to the feet and the
windshield defogger operates
Select the air flow mode
* (right-
hand side)
Display the option control
screen ( P. 392)
Adjust the fan speed setting
Display the rear air conditioning control screen ( P. 3 9 4 )
To adjust or select settings, touch the screen button.
*: Air flows to the upper body
 Air flows to the upper body and feet
 Air flows to the feet
1
2
3
4
Control screen
1
2
3
4
5
6

3925-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
Select to set cooling and dehu-
midification function on/off
Adjust the temperature for
driver, front passenger and rear
seats separately (Individual
mode) (P. 3 9 3 )
Prevent ice from building up on
the windshield and wiper
blades (if equipped) ( P. 396)
Remove pollen from the air (Mi cro dust and pollen filter) (P. 396)
■Using the automatic mode
Press .
Adjust the temperature setting.
To stop the operation, press .
■
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
Option control screen
1
2
3
Air conditioning controls
4
1
2

LC200_OM_OM60R53U_(U)
3935-1. Using the air conditioning system and defogger
5
Interior features
To turn on the individual mode, perform any of the following pr oce-
dures:
● Press “4-ZONE” on the option control screen.
● Adjust the passenger’s side temperature setting.
● Change the rear air conditioning setting
The indicator comes on when the individual mode is on.
To return to the simultaneous mode, press “4-ZONE”.
In the simultaneous mode, only or on the driver’s side can
be used to adjust the temperature for all seats.
Adjusting the temperature for driver and passenger seats sepa-
rately (Individual mode)

3945-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
Press on the control
screen to display the rear air con-
ditioning control screen.
Adjust the temperature set-
ting (left-hand rear seat)
Adjust the fan speed setting
Adjust the temperature set-
ting (right-hand rear seat)
Select to set automatic mode
Turn the fan off
■Using the automatic modePress “REAR AUTO”.
The air conditioning system will operate, and air outlets and s peed will
be set automatically.
Press “ ” to increase the temperature and “ ” to decrease the
temperature.
Air outlets for the right-hand and left-hand may be set separat ely
depending on the temperature setting.
■
Adjusting the temperature setting
Press “ ” (increase) “ ” or (decrease).
Operating the switch will enter the individual mode. ( P. 393)
■
Adjusting the fan speed setting
Press (increase) or (decrease).
The fan speed is shown on the display. (7 levels)
Press “REAR OFF” to turn the fan off.
■
Turning the rear air conditioning system off
Press “REAR OFF”.
Changing the rear seat settings
1
2
3
4
5
1
2

LC200_OM_OM60R53U_(U)
3955-1. Using the air conditioning system and defogger
5
Interior features
■Switching between outside air and recirculated air modes
Press .
The mode switches between (recirculated air mode) and
(outside air mode) modes each time the button is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
Set the outside/recirculated air mode button to outside air mod e if the
recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the wind-
shield is defogged.
Other functions

3965-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)■
Defogging the rear window and
outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain -
drops, dew and frost from the outside rear view mirrors.
Press .
Press the switch again to turn the defogger off.
■
Micro dust and pollen filter
Press on the control screen.
Press .
Outside air mode switches to recirculated air mode. Pollen is removed
from the air and the air flows to the upper part of the body.
Usually the system will turn off automatically approximately 1 to 3 min-
utes.
To stop the operation, press again.
■
Windshield wiper de -icer (if equipped)
This feature is used to prevent ice from building up on the win d-
shield and wiper blades.
Press on the control screen.
Press .
Press again to turn the de-icer off.
1
2
1
2

LC200_OM_OM60R53U_(U)
3975-1. Using the air conditioning system and defogger
5
Interior features
■Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
■Adjusting the air flow direction and opening/closing the air
outlets
Direct air flow to the le ft or right, up or down.
Turn the knob to open o r close the vent.
Air outlets
Front outletsRear outlets
1
2

3985-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
■Using automatic mode
Fan speed is adjusted automatically according to the temperatur e setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning “A/C” on will dehumidify the air from the outlets and d efog the wind-
shield effectively.
● If you turn “A/C” off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
■ When driving on dusty roads
Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.
■ Outside/recirculated air mode
●Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.
● Outside/recirculated air mode may automatically switch dependin g on the
temperature setting or the inside temperature.
■ When outside air temperature is low
The dehumidification function may not operate even when “A/C” i s pressed.
■ When the outside temperature exceeds 75°F (24°C) and the air co ndition-
ing system is on
● In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
● Recirculated air mode is selected as a default mode when the en gine switch
is turned to IGNITION ON mode.
● It is possible to switch to outside air mode at any time by pressing
.

LC200_OM_OM60R53U_(U)
3995-1. Using the air conditioning system and defogger
5
Interior features
■Micro dust and pollen filter
●In order to prevent the windows from fogging up when the outsid e air is cold,
the following may occur.
• Outside air mode does not switch to recirculated air mode.
• The dehumidification function operates.
• The operation cancels after approximately 1 minute.
● In rainy weather, the windows may fog up. Press .
● In extremely humid weather, the windows may fog up.
● The pollens are filtered out even if the micro dust and pollen filter is turned
off.
■ Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the out side air mode.
● During use, various odors from inside and outside the vehicle m ay enter into
and accumulate in the air conditioning system. This may then ca use odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to o utside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short peri od of time
immediately after the air conditioning system is started in aut omatic
mode.
■ The rear window defogger and windshield wiper de-icer (if equip ped)
can be operated when
The engine switch is in IGNITION ON mode.
■ When the windshield wiper de-icer (if equipped) is on
The windshield wiper de-icer will automatically turn off after approximately 15
minutes.
■ Using the voice command system
Air conditioning system can be operated using voice commands. F or details,
refer to the “NAVIGATION S YSTEM OWNER’S MANUAL”.
■ While the cool box is on (if equipped)
The front air conditioning system cannot be turned off.
■ Air conditioning filter
P. 492
■ Customization
Settings (e.g. A/C automatic mode switch operation) can be chan ged.
(Customizable features: P. 590)

4005-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
WARNING
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid
weather. The difference between the temperature of the outside air and
that of the windshield can cause the outer surface of the winds hield to fog
up, blocking your vision.
■ To prevent burns
● Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.
● Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicle s with wind-
shield wiper de-icer)
NOTICE
■ To prevent battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
engine is not running.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
