TOYOTA LAND CRUISER 2021 (in English) Repair Manual

611-2. Child safety
LC200_OM_OM60T03U_(U)
1
For safety and security
WARNING
■When a child is riding
Observe the following precautions.
Failure to do so may result in death or serious injury.
● For effective protection in automobile accidents and sudden sto ps, a child
must be properly restrained, using a seat belt or child restrai nt system
which is correctly installed. For installation details, refer t o the operation
manual enclosed with the child restraint system. General instal lation
instructions are provided in this manual.
● Toyota strongly urges the use of a proper child restraint syste m that con-
forms to the weight and size of the child, installed on the rea r seat. Accord-
ing to accident statistics, the child is safer when properly restrained in the
rear seat than in the front seat.
● Holding a child in your or someone else’s arms is not a substit ute for a
child restraint system. In an accident, the child can be crushed against the
windshield or between the holder and the interior of the vehicle.
■ Handling the child restraint system
If the child restraint system is not properly fixed in place, t he child or other
passengers may be seriously injured or even killed in the event of sudden
braking, sudden swerving, or an accident.
● If the vehicle were to receive a strong impact from an accident, etc., it is
possible that the child restraint system has damage that is not readily visi-
ble. In such cases, do not reuse the restraint system.
● Make sure you have complied with all installation instructions provided
with the child restraint system manufacturer and that the syste m is prop-
erly secured.
● Keep the child restraint system properly secured on the seat ev en if it is
not in use. Do not store the child restraint system unsecured in the pas-
senger compartment.
● If it is necessary to detach the child restraint system, remove it from the
vehicle or store it securely in the luggage compartment.

621-2. Child safety
LC200_OM_OM60T03U_(U)■
Types of child restraint s
ystem installation methods
Confirm with the operation manual enclosed with the child restr aint
system about the installation of the child restraint system.
Child restraint system
Installation methodPage
Seat belt
attachment P. 66
Child
restraint
LATCH
anchors
attachment P. 72
Anchor
brackets (for
top tether
strap) attach-
ment
P. 75

631-2. Child safety
LC200_OM_OM60T03U_(U)
1
For safety and security
■When installing a child restraint system to a front passenger
seat
For the safety of a child, install a child restraint system to a rear
seat. When installing child restraint system to the front passe nger
seat is unavoidable, adj ust the seat as follows and install the child
restraint system.
● Raise the seatback as much
as possible
● Move the seat to the rear-
most position
● Raise the seat to the upper
most position
● Lower the seat belt height to
the lowest position
● If the head restraint interferes
with the child restraint sys-
tem installation and the head
restraint can be removed,
remove the head restraint
When using a child restraint system

641-2. Child safety
LC200_OM_OM60T03U_(U)
WARNING
■When using a child restraint system
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Never install a rear-facing child restraint system on the front passenger
seat even if the “AIR BAG OFF” indicator light is illuminated. In the event
of an accident, the force of the rapid inflation of the front p assenger airbag
can cause death or serious injury to the child if the rear-facing child
restraint system is installed on the front passenger seat.
● A forward-facing child restraint system may be installed on the front pas-
senger seat only when it is unavoidable. A child restraint system that
requires a top tether strap should not be used in the front passenger seat
since there is no top tether strap anchor for the front passenger seat.
● When a booster seat is installed, always ensure that the should er belt is
positioned across the center of the child’s shoulder. The belt should be
kept away from the child’s neck, but not so that it could fall off the child’s
shoulder.
● A forward-facing child restraint system
may be installed on the front passenger
seat only when it is unavoidable. When
installing a forward-facing child restraint
system on the front passenger seat,
move the seat as far back as possible,
even if the “AIR BAG OFF” indicator
light is illuminated.
If the head restraint interferes with the
child restraint system installation and
the head restraint can be removed,
remove the head restraint.
● Do not allow the child to lean his/her
head or any part of his/her body against
the door or the area of the seat, front,
side and rear pillars, or roof side rails
from which the SRS side airbags or
SRS curtain shield airbags deploy even
if the child is seated in the child restraint
system. It is dangerous if the SRS side
airbags and curtain shield airbags
inflate, and the impact could cause
death or serious injury to the child.

651-2. Child safety
LC200_OM_OM60T03U_(U)
1
For safety and security
WARNING
■When using a child restraint system
● Use a child restraint system suitable to the age and size of the child and
install it to the rear seat.
● Vehicles with third seats: Child restraint system installed on the third seat
should not contact the second seatbacks.
● When installing a child restraint system on the second center s eat, adjust
both seat cushions to the same position and align both seatback s at the
same angle. The seatbacks must be adjusted to the same angle. O ther-
wise, the child restraint system cannot be securely restrained and this may
cause death or serious injuries in the event of sudden braking, sudden
swerving or an accident.
● If the driver’s seat interferes with the
child restraint system and prevents it
from being attached correctly, attach the
child restraint system to the right-hand
rear seat.
● Adjust the front passenger seat so that
it does not interfere with the child
restraint system.

661-2. Child safety
LC200_OM_OM60T03U_(U)
A child restraint system for a small child or baby must itself be prop-
erly restrained on the seat with the lap portion of the lap/shoulder belt.
◆Installing child restraint system using a seat belt (child
restraint lock function belt)
Install the child restraint system in accordance to the operati on
manual enclosed with the child restraint system.
■Rear-facing — Infant seat/convertible seat
Adjust the second seat or the th ird outboard seat (if equipped)
If there is a gap between the child seat and the seatback, adjust the
seatback angle until good contact is achieved.
Place the child restraint sys-
tem on the second seat or
the third outboard seat (if
equipped) facing the rear of
the vehicle.
Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.
Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.
Child restraint system fixed with a seat belt
1
2
3
4

671-2. Child safety
LC200_OM_OM60T03U_(U)
1
For safety and security
While pushing the child
restraint system down into
the second seat or the third
outboard seat (if equipped),
allow the shoulder belt to
retract until the child restraint
system is securely in place.
After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.
After installing the child restraint system, rock it back and forth to
ensure that it is in stalled securely. ( P. 71)
■Forward-facing — Convertible seat
Adjust the seat
When using the front passenger seat
If installing the child restraint system to the front passenger seat is
unavoidable, refer to P. 63 for front passenger seat adjustment.
When using the second seat or the third outboard seat (if equip ped)
If there is a gap between the child seat and the seatback, adjust the
seatback angle until good contact is achieved.
If the head restraint interferes with the child restraint syste m
installation and the head restraint can be removed, remove the
head restraint. ( P. 158)
Place the child restraint sys-
tem on the seat facing the
front of the vehicle.
5
6
1
2
3

681-2. Child safety
LC200_OM_OM60T03U_(U)
Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.
Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.
While pushing the child
restraint system into the sec-
ond seat or the third out-
board seat (if equipped),
allow the shoulder belt to
retract until the child restraint
system is securely in place.
After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.
If the child restraint has a top tether strap, follow the child
restraint manufacturer’s operation manual regarding the installa-
tion, using the top tether strap to latch onto the top tether s trap
anchor. ( P. 7 5 )
After installing the child restrai nt system, rock it back and forth to
ensure that it is in stalled securely. ( P. 71)
4
5
6
7
8

691-2. Child safety
LC200_OM_OM60T03U_(U)
1
For safety and security
■Booster seatIf installing the child restraint system to the front passenger seat
is unavoidable, refer to P. 63 for front passenger seat adjustm ent.
High back type: If the head restra int interferes with your child
restraint system, and the head restraint can be removed, remove
the head restraint. ( P. 158)
Place the child restraint system on the seat facing the front of the
vehicle.
Sit the child in the child
restraint system. Fit the seat
belt to the child restraint sys-
tem according to the manu-
facturer’s instructions and
insert the plate into the
buckle. Make sure that the
belt is not twisted.
Check that the shoulder belt is correctly positioned over the c hild’s
shoulder and that the lap belt is as low as possible. ( P. 60)
1
2
3
Booster typeHigh back type
4

701-2. Child safety
LC200_OM_OM60T03U_(U)
◆Removing a child restraint system installed with a seat belt
Press the buckle release button
and fully retract the seat belt.
When releasing the buckle, the
child restraint system may
spring up due to the rebound of
the seat cushion. Release the
buckle while holding down the
child restraint system.
Since the seat belt automatically
reels itself, slowly return it to the
stowing position.
