TOYOTA MIRAI 2016 1.G Owners Manual

2716-2. Using the interior lights
6
Interior features
MIRAI_OM_USA_OM62004U
■Illuminated entry system
The lights automatically turn on/off according to power switch mode, the pres-
ence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are opened/closed.
■ To prevent 12-volt battery discharge
If the following lights remain on when the power switch is turned off, the lights
will go off automatically after 20 minutes:
●Front interior lights
● Rear interior lights
● Personal lights
● Door courtesy lights
● Vanity lights
● Trunk light
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 438)
NOTICE
■To prevent 12-volt battery discharge
Do not leave the lights on longer than necessary when the fuel cell system
is off.

2726-3. Using the storage features
MIRAI_OM_USA_OM62004U
List of storage features
Auxiliary boxes ( P. 276)
Glove box ( P. 273)
Bottle holders ( P. 276) Console box (
P. 273)
Cup holders ( P. 274)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this
may result in the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
5

2736-3. Using the storage features
6
Interior features
MIRAI_OM_USA_OM62004U
Open (press the button)
Lock with the mechanical key
Unlock with the mechanical key
The glove box light turns on when the tail lights are on.
Front
Slide the armrest to the rear
most position.
Lift the lid while pulling up the
lever to release the lock.
Glove box
1
2
3
Console box
1
2

2746-3. Using the storage features
MIRAI_OM_USA_OM62004U
Rear
Lift the lid while pushing the but-
ton to release the lock.
Front
Push in the lid.
Rear
Push in and release the cup
holder.
Cup holders

2756-3. Using the storage features
6
Interior features
MIRAI_OM_USA_OM62004U
■When stowing bottles (front cup holder)
When bottles are stowed in the cup holder
of the armrest side, when sliding the
armrest, the bottles interfere and may
prevent movement of the armrest.
WARNING
■Items unsuitable for the cup holders
●Do not place anything other than cups or aluminum cans in the cup hold-
ers.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury.
● To prevent burns, cover hot drinks when placed in the cup holders.

2766-3. Using the storage features
MIRAI_OM_USA_OM62004U
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Push the lid.
Bottle holders
WARNING
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glass or paper cups containing liquid. The contents may spill
and glass cups may break.
Auxiliary box

2776-3. Using the storage features
6
Interior features
MIRAI_OM_USA_OM62004U
Trunk features
The warning reflector can be
stowed underneath the luggage
mat.
■Stowing the warning reflector
Due to the size and shape of the warning reflector case, it may not be able to
be stowed.
Grocery bag hooks
NOTICE
To prevent damage to the hooks, do not apply too much load to the hooks.
Warning reflector storage space

2786-3. Using the storage features
MIRAI_OM_USA_OM62004U
Loosen the belt
Tighten the belt
First-aid kit storage belt
1
2

2796-4. Other interior features
6
Interior features
MIRAI_OM_USA_OM62004U
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Slide the cover to open.
The light turns on when the cover
is opened.
Sun visors
1
2
3
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity lights on for
extended periods while the fuel cell system is off.

2806-4. Other interior features
MIRAI_OM_USA_OM62004U
The time can be adjusted through the [settings display] for the
multi-information display (P. 107)
◆Round to the nearest hour
Press or of the meter control switches ( P. 108), select
and press .
The minute section of the clock goes to 00.*
*
: e.g.1:00 to 1:29  1:00
1:30 to 1:59  2:00
◆Time adjustment
Press or of the meter control switches ( P. 108), select
and press .
Press or on the meter control switches, select hours, min-
utes, or 12/24-hour clock, pres s or of the meter operation
switches to adjust.
When the adjustments are finis hed, press and check the time.
The clock is displayed when the power switch is in ON mode.
Clock
1
2
3
