1414-3. Media operation
4
Audio/visual system
• random (1 folder/album random)  folder/album random (all
folder/album random)  off
The iPod/iPhone operation
screen can be reached by the
following methods: P.126
 Connecting an iPod/iPhone
( P.127)
 When an Android Auto con-
nection is established, this
function will be unavailable.
An Apple CarPlay connection
is not established
An Apple CarPlay connection
is established
Select to display the audio
source selection screen.
Select to return to the top
WA R N I N G
●Do not operate the player’s con-
trols or connect the USB mem-
ory while driving.
NOTICE
●Do not leave your portable
player in the car. In particular,
high temperatures inside the
vehicle may damage the porta-
ble player.
●Do not push down on or apply
unnecessary pressure to the
portable player while it is con-
nected as this may damage the
portable player or its terminal.
●Do not insert foreign objects into
the port as this may damage the
portable player or its terminal.
iPod/iPhone (Apple
CarPlay)
Overview
Control screen
A
B

1444-3. Media operation
The Android Auto operation
screen can be reached by the
following methods: P. 1 2 6
 Connecting an Android Auto
device ( P.127)
 When an Apple CarPlay con-
nection is established, this
function will be unavailable.
Select to display the audio
source selection screen.
Select to return to the top
screen.
Select to display the sound
setting screen. ( P.127)
Select to display the audio
control screen of Android
Auto.
Select to change the track.
Select to play/pause.
Select to change the track.
Displays cover art
8-inch display model
12.3-inch display model
Press to change the track.
Turn to change the track.
Android Auto
Overview
Control screen
A
B
C
D
E
F
G
H
&RQWUROSDQHO
:$ 5 1 , 1 *
●Do not connect smartphone or
operate the cont rols while driv-
ing.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.
NOTICE
●Do not push down on or apply
unnecessary pressure to the
smartphone while it is con-
nected as this may damage the
smartphone or its terminal.
A
B

1454-3. Media operation
4
Audio/visual system
The Bluetooth® audio operation
screen can be reached by the
following methods: P.126
 Connecting a Bluetooth
®
audio device ( P.149)
 Depending on the type of por-
table player connected, some
functions may not be avail-
able and/or the screen may
look differently than shown in
this manual.
 When an Apple Car-
Play/Android Auto connec-
tion is established, Bluetooth
®
audio will be suspended and
become unavailable.
●Do not insert foreign objects into
the port as this may damage the
smartphone or its terminal.Bluetooth® audio
The Bluetooth® audio sys-
tem enables users to enjoy
listening to music that is
played on a portable player
on the vehicle speakers via
wireless communication.
This audio/visual system
supports Bluetooth
®, a
wireless data system capa-
ble of playing portable
audio music without cables.
If your device does not sup-
port Bluetooth
®, the Blue-
tooth
® audio system will not
function.
Overview

1494-4. Audio/visual remote controls
4
Audio/visual system
4-4.Audio/visual remote controls
Some parts of the audio/visual
system can be adjusted using
the switches on the steering
wheel.Volume control switch
“MODE” switch
Seek switch
■Volume control switch
• Press: Volume up/down
• Press and hold (0.8 sec. or more): Volume up/down con-
tinuously
■“MODE” switch
AM/FM/SXM
• Press: Change audio modes
• Press and hold (0.8 sec. or more): Mute/pause (Press
and hold again to resume.)
USB, iPod/iPhone, Blue-
tooth
® audio, Android Auto,
Toyota apps
• Press: Change audio modes
• Press and hold (0.8 sec. or more): Pause (Press and hold again to resume the play
mode.)
■Seek switch
AM/FM
• Press: Preset channel up/down
• Press and hold (0.8 sec. or more): Seek up/down
• Press and hold (1.5 sec. or more): Seek up/down continu-
ously while the switch is being
pressed
SXM
• Press: Preset channel up/down
• Press and hold (0.8 sec. or more): Seek for stations in the
relevant program type/chan-
nel category
• Press and hold (1.5 sec. or more): Fast channel up/down
USB, iPod/iPhone, Blue-
tooth
® audio
• Press: Track/file up/down
• Press and hold (0.8 sec. or more): Fast forward/rewind
Android Auto
• Press: Track up/down
Steering switches
Steering switch operation
A
B
C

1514-4. Audio/visual remote controls
4
Audio/visual system
■ button
• Press: Turn the rear seat audio control buttons on and off
■“CH FLD” button
AM/FM/SXM
• Select: Preset channel up/down
USB/Bluetooth® audio
• Select: Folder/album up/down
■“TUNE TRACK” button
AM/FM
• Select: Tune the frequency up/down
• Select and hold (0.8 sec. or more): Seek up/down
• Select and hold (1.5 sec. or mo re): Seek up/down continuously
while the switch is being pressed
SXM
• Select: Select a channel
• Select and hold (0.8 sec. or more): Seek for stations in the r ele-
vant program type/channel category
• Select and hold (1.5 sec. or more): Fast channel up/down
USB, iPod/iPhone, Bluetooth® audio
• Select: Track/file up/down
• Select and hold (0.8 sec. or more): Fast forward/rewind
Android Auto
• Select: Track up/down
■“VOL” button
• Select: Volume up/down
• Select and hold (0.8 sec. or more): Volume up/down continuousl y
●Rear seat audio control buttons turn off after a while without operation.
Press the button to turn the buttons back on.
●For operation buttons except for audio control buttons, Refer to the
“OWNER’S MANUAL”.

1665-1. Voice command system operation
5-1.Voice command system operation
■Steering switchTa l k s w i t c h
Voice command system:
• Press the talk switch to start the voice command system. To can-
cel voice command, press and
hold the talk switch.
When an Apple CarPlay/Android
Auto connection is established:
• Press and hold the talk switch to start Siri/Google Assistant. To
cancel Siri/Google Assistant,
press the talk switch.
• Press the talk switch to start the voice command system.
■Microphone
 It is unnecessary to speak
directly into the microphone
when giving a command.
●Voice commands may not be rec-
ognized if:
• Spoken too quickly.
• Spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while voice commands are spoken.
• The fan speed of the air condition-
ing system is set at high.
• The air conditioning vents are turned towards the microphone.
●In the following c onditions, the
system may not recognize the
command properly and using
voice commands may not be pos-
sible:
• The command is incorrect or unclear. Note that certain words,
accents or speech patterns may
be difficult for the system to recog-
nize.
• There is excessive background
noise, such as wind noise.
●Normally, it is necessary to wait
for a beep before saying a com-
mand. To enable th e ability to talk
over prompts and say commands
before the beep, enable the voice
prompt interrupt function. ( P. 6 6 )
●This system may not operate
immediately after the power
switch is in ACC or ON.
Voice command sys-
tem
The voice command system
enables the radio, phone
dialing, etc. to be operated
using voice commands.
Refer to the command list
for samples of voice com-
mands. ( P.188)
Using the voice command
system
A

1705-1. Voice command system operation
Recognizable voice commands
and their actions are shown
below.
Frequently used commands
are listed in the following
tables.
 For devices that are not
installed to the vehicle, com-
mands relating to that device
may not be displayed on the
screen. Also, depending on
other conditions, such as
compatibility, some com-
mands may not be displayed
on the screen.
 The functions available may
vary according to the system
installed.
 Voice recognition language
can be changed. ( P.62)
 When an Apple Car-
Play/Android Auto connec-
tion is established, some
commands will become
unavailable.
■Common
■Top menu
*: Vehicle must be parked
Command list
Command list overview
Command list
CommandAction
“Help”
Displays exam-
ples of some of
the available
commands
“Go back”Returns to the
previous screen
“Cancel”
Cancels the
voice command
system
“Start over”Returns to top
menu screen
“Pause”
Temporarily
pauses a voice
session until it is
resumed by
pressing the talk
switch again.
CommandAction
“Show com-
mand examples
for

2978-2. Setup
8
Phone
matically.
2 Check that a confirmation
screen is displayed when the
operation is complete.
 This operation may be unnec-
essary depending on the type
of Bluetooth
® phone.
 If another Bluetooth
® device
is connected when transfer-
ring contact data, depending
on the phone, the connected
Bluetooth
® device may need
to be disconnected.
 Depending on the type of
Bluetooth
® phone being con-
nected, it may be necessary
to perform additional steps on
the phone.
■Updating the contacts in a
different way (from the call
history screen)
*
1 Display the phone top
screen. ( P.276)
2 Select “History” and select a
contact not yet registered in
the contact list.
3 Select “Update Contact”.
4 Select the desired contact.
5 Select a phone type for the
phone number.
*: For PBAP compatible Bluetooth®
phones, this function is available
when “Automatic Transfer” is set
to off. ( P.296)
●When an Android Auto connection
is established, this function will be
unavailable.
When the contact is not regis-
tered
1 Select “Transfer Contacts
from Device”.
2 Select “From Phone (Blue-
tooth)”.
3 Transfer the contact data to
the system using a Blue-
tooth
® phone.
 This operation may be unnec-
essary depending on the type
of Bluetooth
® phone.
 To cancel this function, select
“Cancel”.
4 Check that a confirmation
screen is displayed when the
operation is complete.
When the contact is regis-
tered
1 Select “Transfer Contacts
from Device”.
2 Select “From Phone (Blue-
tooth)”.
3 Select “Replace Contacts” or
“Add Contact”.
“Replace Contacts”: Select to trans-
fer the contact fr om the connected
Transfer contacts from
device
From phone (OPP compati-
ble Bluetooth
® phones only)

326Alphabetical Index
Alphabetical Index
A
AM/FM/SiriusXM® Satellite Radio
............................................... 131 Available HD Radio™ technol- ogy ..................................... 135
Caching a radio program...... 132
Displaying the radio ID ......... 137
How to Subscribe to SiriusXM Satellite Radio .................... 136
Overview .............................. 131
Presetting a station .............. 132
Radio broadcast data system134
Radio options ....................... 134
Refer to the table below to iden- tify the problem and take the
suggested corrective action 138
Selecting a station from the list ........................................... 133
Smart favorites ..................... 138
Troubleshooting guide .......... 135
Using HD Radio™ technology ........................................... 134 “Android Auto” button (“Menu”
screen) ...............................15, 55
“Apple CarPlay” button (“Menu” screen) ...............................15, 55
Apple CarPlay/Android Auto ...55 Establishing an Android Auto connection ............................56
Establishing an Apple CarPlay connection ............................55
“Apps” button (“Menu” screen) .........................................15, 318
“Apps” button (“Setup” screen) .........................................18, 323
“APPS” button ...... ............12, 318
“Audio” button (“Menu” screen) .........................................15, 124
“Audio” button (“Setup” screen) .........................................18, 153
“AUDIO” button ........12, 124, 126
Audio settings.........................153 Audio settings screen ...........153
Displaying the audio settings screen.................................153
Audio/visual remote controls 150
