302-1. Basic information before operation
Select to display the seat
heater/ventilation control
screen, etc.
*1, 2
Select to display the audio
control screen. (P. 3 0 )
Select to display the energy
monitor/fuel consumption
screen, etc.
*1
Select to display the settings
screen and software informa-
tion. ( P. 3 0 )
*1: Refer to the “OWNER’S MAN-
UAL”.
*2: If equipped
Selecting or to change its
displayed position of the side
display to the left or right side of
the screen.
The screen position can also be
changed by perform a left or
right flick operation on a screen.
Selecting or on the
energy monitor/consumption
screen or vehicle information screen will display that screen in
full screen.
Select or to return to the
split-screen display.
Select on the side display to
display the setting screen.
Select to change the interior
illumination light color.
*
Select to turn flick operation
on the side display on/off.
Display the software informa-
tion
*: If equipped
■Software license
©1982-2013, QNX Software
Systems Limited. All rights
reserved.
The selected audio source
screen is displayed.
Toyota multi-operation
touch operation
Moving screens on the
Toyota multi-operation
touch
Displaying a screen in full
screen
B
C
D
E
6HWWLQJVDQGVRIWZDUH
LQIRUPDWLRQ
2SHUDWLQJWKHDXGLRYLVXDO
V\VWHP
A
B
C

312-1. Basic information before operation
2
Basic function
■Searching for radio stations
1 Select “Option”.
2 Select or to change
stations in the relevant pro-
gram type/channel category. 1
Press the “HOME” button.
8-inch display model
12.3-inch display model
Home screen
On the home screen, multi-
ple screens, such as the
audio/visual system screen,
hands-free screen and
clock screen, can be dis-
played simultaneously.
Home screen operation

322-1. Basic information before operation
2Check that the home screen
is displayed.
 Selecting a screen will display
it full screen.
●The display information and area
on the home screen can be cus-
tomized.
●The home screen can be set to
several types of split layouts.
The display information/area on
the home screen and the home
screen layout can be changed.
1 Press the “MENU” button.
2 Select “Setup”.
 If the general settings screen
is not displayed, select “Gen-
eral”.
3 Select “Customize Home
Screen”. 4
Select the items to be set.
Select to change the display
information and area on the
home screen.
Select to change the home
screen layout.
Customizing the home
screen
A
B

332-1. Basic information before operation
2
Basic function
When searching by an address,
name, etc., or entering data, let-
ters and numbers can be
entered via the screen.When this icon is displayed,
select to enable the dictation
function.
* (English only)
( P.168)
Text field. Entered charac-
ter(s) will be displayed.
Select to erase one charac-
ter.
Select and hold to continue
erasing characters.
Select to move the cursor.
Select to choose predictive
text candidate for entered
text. ( P. 3 4 )
Select to display a list of pre-
dictive text candidates when
there is more than one.
( P. 3 4 ) Select to enter desired char-
acters.
Select to enter characters in
lower case or in upper case.
Select to change character
types. (
P. 3 3 )
Select to make a space on
cursor.
*: 12.3-inch display model. This function is not made available in
some countries or areas.
●Keyboard layout can be changed.
( P. 6 2 )
1 Select “Change Type”.
2 Select the desired character.
●Depending on the screen being
displayed, it may not be possible
to change keyboard characters.
Entering letters and
numbers/list screen
operation
Entering letters and num-
bers
A
B
C
D
E
F
&KDQJLQJFKDUDFWHUW\SH
G
H
I
J

342-1. Basic information before operation
When text is input, the system
predicts the text that may com-
plete the currently unconfirmed
text and displays predictive
replacement candidates that
match the beginning of the text.
1Input text.
2 Select the desired candidate.
 To select a candidate that is
not displayed, select , and
then select the desired predic-
tive replacement candidate.
The list screen may be dis-
played after entering characters.
When a list is displayed, use the
appropriate screen button to
scroll through the list. To scroll up/down the list,
flick the list up/down.
Select to skip to the next or
previous page. Select and
hold or to scroll
through the displayed list.
Indicates the position of the
displayed entries in the entire
list.
To scroll up/down pages,
drag the bar.
●If appears to the right of an
item name, the complete name is
too long to display.
• Select to scroll to the end of the name.
• Select to move to the begin- ning of the name.
●Matching items from the data-
base are listed even if the entered
address or name is incomplete.
●The list will be displayed automati-
cally if the maximum number of
characters is entered or matching
items can be displayed on a single
list screen.
●The number of matching items is
shown on the right side of the
screen. If the num ber of matching
items is more than 999, the sys-
Displaying predictive text
candidates
List screen
Scrolling list screen
A
B
C

352-1. Basic information before operation
2
Basic function
tem displays “***” on the screen.
The order of a list displayed on
the screen can be sorted in the
order of distance from the cur-
rent location, date, category,
etc.
1Select “Sort”.
2 Select the desired sorting cri-
teria.
Items are displayed in the list
with the most similar results of
the search at the top.
1 Select . 2
Input text.
3 Select “Search”.
4 The list is displayed.
Sorting
Searching a list

362-1. Basic information before operation
1Press the “MENU” button.
8-inch display model
12.3-inch display model
2 Select “Display”. 3
Select the desired items to
be set.
Select to turn the screen off.
To turn it on, press any but-
ton.
Select to turn day mode
on/off. ( P.36)
Select to adjust the screen
display. ( P. 3 7 )
Select to adjust the camera
display.
●When the screen is viewed
through polarized sunglasses, a
rainbow pattern may appear on
the screen due to optical charac-
teristics of the screen. If this is dis-
turbing, please operate the screen
without polarized sunglasses.
Depending on the position of the
headlight switch, the screen
changes to day or night mode.
This feature is available when
the headlight is switched on.
1 Select “Day Mode”.
●If the screen is set to day mode
with the headlight switch turned
on, this conditio n is memorized
Screen adjustment
The contrast and brightness
of the screen display and
the image of the camera dis-
play can be adjusted. The
screen can also be turned
off, and/or changed to
either day or night mode.
(For information regarding
audio/visual screen adjust-
ment: P.129)
Displaying the screen
adjustment screen
Changing between day
and night mode
A
B
C
D

372-1. Basic information before operation
2
Basic function
even with the fuel cell system off.
The contrast and brightness of
the screen can be adjusted
according to the brightness of
your surroundings.
1Select “General” or “Cam-
era”.
2 Select the desired item.
 “Display (General)” screen
only: Select “<” or “>” to select
the desired display.
• “Contrast”
“+”: Select to strengthen the con-
trast of the screen.
“-”: Select to weaken the contrast of
the screen.
• “Brightness”
“+”: Select to brighten the screen.
“-”: Select to darken the screen.
Adjusting the con-
trast/brightness
Linking multi-informa-
tion display and the
system
The following functions of
the system are linked with
the multi-information dis-
play in the instrument clus-
ter:
Navigation
 Audio
 Phone
*
etc.
These functions can be
operated using the multi-
information display control
switches on the steering
wheel. For details, refer to
“OWNER’S MANUAL”.
*: When an Apple CarPlay con-
nection is esta blished, this
function will be unavailable.

382-2. Connectivity settings
2-2.Connectivity settings
■Registering from the sys-
tem
1 Turn the Bluetooth
® connec-
tion setting of your cellular
phone on.
 This function is not available
when Bluetooth
® connection
setting of your cellular phone
is set to off.
2 Press the “MENU” button.
8-inch display model
12.3-inch display model
3 Select “Phone”.
 8-inch display model: Opera-
tions up to this point can also
be performed by pressing the
“PHONE” button on the instru-
ment panel.
Registering/Connect-
ing a Bluetooth®
device
To use the hands-free sys-
tem, it is necessary to regis-
ter a Bluetooth
® phone with
the system.
Once the phone has been
registered, it is possible to
use the hands-free system.
This operation cannot be
performed while driving.
When an Apple CarPlay
connection is established,
Bluetooth
® functions of the
system will become unavail-
able and any connected
Bluetooth
® devices will be
disconnected.
When connecting to
Android Auto, a Bluetooth
®
connection will be made
automatically.
When an Android Auto con-
nection is established,
some Bluetooth
® functions
other than hands-free sys-
tem cannot be used.
Registering a Bluetooth®
phone for the first time

392-2. Connectivity settings
2
Basic function
4Select “Yes” to register a
phone.
5 Select the desired Bluetooth
®
device.
 If the desired Bluetooth
®
phone is not on the list, select
“If you cannot find...” and fol-
low the guidance on the
screen. ( P. 4 0 )
6 Register the Bluetooth
®
device using your Blue-
tooth
® device.
 For details about operating
the Bluetooth
® device, see
the manual that comes with it. 
A PIN code is not required for
SSP (Secure Simple Pairing)
compatible Bluetooth
®
devices. Depending on the
type of Bluetooth
® device
being connected, a message
confirming registration may
be displayed on the Blue-
tooth
® device’s screen.
Respond and operate the
Bluetooth
® device according
to the confirmation message.
7 Check that the following
screen is displayed, indicat-
ing pairing was successful (a
Bluetooth
® link has been
established but registration is
not yet complete).
 The system is connecting to
the registered device.
 At this stage, the Bluetooth
®
functions are not yet avail-
able.
