Page 40 of 51

38
Dealer Service verification:
D
ate: Mileage:
Dealer Service verification:
D
ate: Mileage:
95,000 miles or 114 months
■ Check installation of driver’s floor mat
■ Inspect and adjust all fluid levels1
■Inspect FC HV battery cooling intake filter2
■Inspect wiper blades
■Rotate tires
■ Visually inspect brake linings/drums
and brake pads/discs
Additional Maintenance Items for
Special Operating Conditions3
Driving on dirt roads or dusty roads: ■Inspect ball joints and dust covers
■Inspect drive shaft boots
■Inspect fuel cell air filter
■Inspect steering linkage and boots
■ Tighten nuts and bolts on chassis
and body
Extensive idling and/or low speed driving
for a long distance such as police, taxi
or door-to-door delivery use:
■ Inspect hydrogen supply system for
leaks and damage
■ Inspect hydrogen tank (with valve)
for leaks and damage
■Inspect hydrogen tank band for damage
Driving while towing, using a car-top
carrier, or heavy vehicle loading:
4
■ Tighten nuts and bolts on chassis
and body
Operating on rough or muddy roads, or
roads with melted snow:
■ Inspect hydrogen supply system for
leaks and damage
■ Inspect hydrogen tank (with valve) for
leaks and damage
■Inspect hydrogen tank band for damage
100,000 miles or 120 months
■Check installation of driver’s floor mat
■Clean FC HV battery cooling intake filter2
■Inspect and adjust all fluid levels1
■Inspect wiper blades
■Replace cabin air filter
■Rotate tires
■ Visually inspect brake linings/drums
and brake pads/discs
Inspect the following:
■Fuel cell air filter
■Fuel cell cooling system for leaks
■Hydrogen sensor
■ Hydrogen supply system for leaks
and damage
■ Hydrogen tank (with valve) for leaks
and damage
■ Hydrogen tank band for looseness
and damage
Additional Maintenance Items for
Special Operating Conditions3
Driving on dirt roads or dusty roads: ■Inspect ball joints and dust covers
■Inspect drive shaft boots
■Inspect steering linkage and boots
■ Tighten nuts and bolts on chassis
and body
Driving while towing, using a car-top
carrier, or heavy vehicle loading:
4
■ Tighten nuts and bolts on chassis
and body
Maintenance Log
MAINTENANCE LOG
MAINTENANCE
Page 42 of 51

40
Dealer Service verification:
D
ate: Mileage:
Dealer Service verification:
D
ate: Mileage:
110,000 miles or 132 months
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■Inspect FC HV battery cooling intake filter2
■Inspect wiper blades
■Replace cabin air filter
■Rotate tires
■ Visually inspect brake linings/drums
and brake pads/discs
Inspect the following: ■Fuel cell air filter
■ Fuel cell cooling system for leaks
■Hydrogen sensor
■ Hydrogen supply system for leaks
and damage
■ Hydrogen tank (with valve) for leaks
and damage
■ Hydrogen tank band for looseness
and damage
■Additional MainteAdditional Maintenance Items for
Special Operating Conditions3
Driving on dirt roads or dusty roads: ■Inspect ball joints and dust covers
■Inspect drive shaft boots
■Inspect steering linkage and boots
■ Tighten nuts and bolts on chassis
and body
Driving while towing, using a car-top
carrier, or heavy vehicle loading:
4
■ Tighten nuts and bolts on chassis
and body
115,000 miles or 138 months
■Check installation of driver’s floor mat
■Inspect and adjust all fluid levels1
■Inspect FC HV battery cooling intake filter2
■Inspect wiper blades
■Rotate tires
■ Visually inspect brake linings/drums
and brake pads/discs
Additional Maintenance Items for
Special Operating Conditions3
Driving on dirt roads or dusty roads: ■Inspect ball joints and dust covers
■Inspect drive shaft boots
■Inspect fuel cell air filter
■Inspect steering linkage and boots
■ Tighten nuts and bolts on chassis
and body
Extensive idling and/or low speed driving
for a long distance such as police, taxi
or door-to-door delivery use:
■ Inspect hydrogen supply system for
leaks and damage
■ Inspect hydrogen tank (with valve)
for leaks and damage
■Inspect hydrogen tank band for damage
Driving while towing, using a car-top
carrier, or heavy vehicle loading:
4
■ Tighten nuts and bolts on chassis
and body
Operating on rough or muddy roads, or
roads with melted snow:
■ Inspect hydrogen supply system for
leaks and damage
■ Inspect hydrogen tank (with valve) for
leaks and damage
■Inspect hydrogen tank band for damage
Maintenance Log
MAINTENANCE LOG
MAINTENANCE
Page 43 of 51

41
Dealer Service verification:
D
ate: Mileage:
120,000 miles or 144 months
■Check installation of driver’s floor mat
■Clean FC HV battery cooling intake filter2
■Inspect and adjust all fluid levels1
■Inspect wiper blades
■Replace breather pipe tip part (Gore film)
■Replace cabin air filter
■Replace fuel cell air filter
■Replace ion exchanger element
■Rotate tires
Inspect the following:
_ B
all joints and dust covers
_ B
rake lines and hoses
_ B
rake linings/drums and
brake pads/discs
5
_ Dr ive shaft boots
_F
uel cell coolant level
_ F
uel cell cooling system for leaks
_ H
ybrid transaxle for signs of leakage
_H
ydrogen sensor
Additional Maintenance Items for Special Operating Conditions3
Driving on dirt roads or dusty roads: ■Tighten nuts and bolts on chassis and body
Driving while towing, using a car-top carrier, or heavy vehicle loading:4
■Replace hybrid transaxle fluid
■Tighten nuts and bolts on chassis and body
1 Inspect sealed transmissions, transfer cases and differentials for signs of leakage. If any leakage from a sealed
component is suspected, it is recommended that you have the sealed component inspected by a Toyota dealer. Inspect
power steering fluid (if equipped) and brake fluid level/condition. Inspect engine and inverter (if equipped) coolant
level/condition/freezing point. Your dealer may recommend services (Dealer-Recommended Maintenance) based on
inspection results.
2 Visually check the FC HV battery cooling intake filter for dirt or dust every 5,000 miles and clean if necessary. Clean every
20,000 miles.
3 Perform these service items only if you drive primarily under the conditions indicated.4 N ot all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.5 Inspect thickness measurement and disc runout.6 Replace tank (with valve) every 15 years or 180 months whichever comes first.7 Replace inverter coolant at 150,000 miles and every 50,000 miles thereafter.
_
H ydrogen supply system for leaks
and damag
e
_ H ydrogen tank (with valve) for leaks
and damage6
_ H ydrogen tank band for looseness
and damage
_ I
nverter coolant level
7
_ S teering gear
_S
teering linkage and boots
Maintenance Log
MAINTENANCE LOG
MAINTENANCE
Page 45 of 51

43
Fuel Cell Air Filter
Inspect or replace at specified intervals.
When performing inspections, check for
dama
ge, excessive wear and oiliness,
and replace if necessary.
Fuel Cell Coolant
Inspect at specified intervals. When performing
inspections, check that the coolant level is
between the “FULL” and “LOW” lines on the
see-through reservoir tank.
Notice: A qualified technician should perform
this operation.
Use the following product:
“Toyota Genuine FC Stack Coolant.”
• In order to safely cool the fuel cell
stack, which is at high voltages, the
fuel cell stack coolant is an exclusive
high insulation product.
• Never use water or other kinds of coolant s
as they will cause damage.
• Coolant changes are unnecessary .
• Do not reuse coolant that has been removed
from the radiator.
• Coolant is colorless.
• Consult your Toyota dealer about
replenishing the fuel cell stack coolant.
Fuel Cell HV Battery
Cooling Intake Filter
Inspect and clean at specified intervals.
Refer to “Cleaning the traction battery air
intake vents and filters”
in the “Maintenance
and Care” section of the Owner’s Manual
for cleaning procedures.
Hybrid Transaxle Fluid
Inspect level and replace at specified intervals.
When performing inspections, check each
component for signs of leakage. If you
discover any leakage, have it repaired by a
qualified technician immediately.
Hydrogen Sensors
Inspect both hydrogen sensors at specified
intervals. This inspection should be performed
using calibration gas at a concentration of
1.3% hydrogen.
Notice: A qualified technician should perform
this operation.
Hydrogen Tank (with Valve)
NOTE: Replace every 15 years or
180 months, whichever comes first.
Notice: A qualified technician should
perform this opera
tion.
EXPLANATION OF MAINTENANCE ITEMS
Maintenance Log
MAINTENANCE
