Page 97 of 556

973-1. Instrument cluster
Owners Manual_USA_M62084_en
3
Vehicle status information and indicators
The units used on the meter and display may differ depending on the target
region.
Fuel gauge/Driving range ( P. 9 9 )
Multi-information display
Presents the driver with a variety of driving-related data ( P.100)
Displays warning messages if a malfunction occurs (P.451)
Speedometer
Displays the vehicle speed
Clock ( P. 9 8 )
Time displayed is linked to the multimedia system. For details, refer to
“NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
Shift position indicator
Displays the selected shift position ( P.178)
Odometer and trip meter ( P.98)
Outside temperature ( P. 9 8 )
■The meters and display illumi-
nate when The power switch is in ON.
Gauges and meters
The meters display various drive information.
Meter display
Page 98 of 556

983-1. Instrument cluster
Owners Manual_USA_M62084_en
■When changing driving mode
Background color of the multi-infor-
mation display is changed following
the selected driving mode. ( P.313,
314)
■Clock settings screen
If “Clock :00” is displayed when
is selected on the multi-information
display, the system may be malfunc-
tioning. Have the vehicle inspected
by your Toyota dealer.
■Outside temperature display
●In the following si tuations, the cor-
rect outside tempe rature may not
be displayed, or the display may
take longer than normal to
change.
• When stopped, or driving at low
speeds (less than 12 mph [20
km/h])
• When the outside temperature
has changed su ddenly (at the
entrance/exit of a garage, tunnel,
etc.)
●When “--” or “E” is displayed, the
system may be malfunctioning.
Take your vehicle to your Toyota
dealer.
●Displays the outside temperature
within the range of -40°F (-40°C)
to 122°F (50°C).
●When the outside temperature is
approximately 37°F (3°C) or
lower, the indicator will flash
for approximately 10 seconds,
then stay on.
■Liquid crystal display
P. 1 0 0
■Customization
Settings (e. g. meter display) can be
changed on screen of the multi-
information display. ( P.498)
■Display items
Odometer
Displays the total distance the vehi-
cle has been driven.
Trip meter A/Trip meter B
Displays the distance the vehicle
has been driven since the meter
was last reset. Trip meters A and B
can be used to record and display
different distances independently.
■Changing the display
Each time the “ODO/TRIP”
switch is pressed, the displayed
item will be changed. When the
trip meter is displayed, pressing
and holding the switch will reset
the trip meter.
The brightness of the instrument
panel lights can be adjusted.
Odometer and trip meter
display
Instrument panel light
control
Page 458 of 556

4588-2. Steps to take in an emergency
Owners Manual_USA_M62084_en
1Remove the luggage mat.
( P.352)
2 Remove the band.
3 Take out the emergency tire
puncture repair kit. ( P.456)1
Take out the repair kit from
the plastic bag.
2 Remove the valve cap from
the valve of the punctured
tire.
3 Extend the hose. Remove
the air release cap from the
hose.
Attach the sticker enclosed with the
bottle on the spec ified locations.
(See step 10.)
You will use the air release cap
again. Therefore keep it in a safe
place.
4 Connect the hose to the
valve.
Screw the end of the hose clock-
WARNING
■Precautions for use of the
sealant
●Ingesting the sealant is hazard-
ous to your health. If you ingest
sealant, consume as much
water as possible, and then
immediately consult a doctor.
●If sealant gets in eyes or
adheres to skin, immediately
wash it off with water. If discom-
fort persists, consult a doctor.
Taking out the emer-
gency tire puncture repair
kit
Emergency repair method
Page 469 of 556

4698-2. Steps to take in an emergency
Owners Manual_USA_M62084_en
8
When trouble arises
■Locking and unlocking the
door
Use the mechanical key
( P.120) in order to perform the
following operations:
1 Locks all the doors
2 Unlocks all the doors
■Locking the door
1 With the door open, push
down the inside lock button.
2 Close the door.
■Trunk
Turn the mechanical key clock-
wise to open. ( P.71)
■Key linked functions
1 Closes the windows (turn and
hold)
2 Opens the windows (turn and
hold)
These settings mus t be customized
at your Toyota dealer.
Locking and unlocking
the doors, unlocking the
trunk
WARNING
■When using the mechanical
key and operating the power
windows
Operate the power window after
checking to make sure that there
is no possibility of any passenger
having any of their body parts
caught in the window.
Also, do not allo w children to
operate the mechanical key. It is
possible for children and other
passengers to get caught in the
power window.
Page 529 of 556

Owners Manual_USA_M62084_en
Alphabetical Index529
Roof film ............................... 381
Seat belts ............................. 384
Clock ......................................... 97
Coat hooks .............................. 362
Condenser .............................. 398
Console box ............................ 351
Consumption screen.............. 111
Coolant .................................... 397 Capacity ............................... 484
Checking .............................. 397
Preparing and c hecking before
winter.................................. 320
Cooling system ...................... 397 Fuel cell system overheating 477
Overheating.......................... 477
Cruise control Dynamic radar cruise control with full-speed range .......... 237
Cup holders ............................ 350
Current fuel economy ............ 101
Curtain shield airbags ............. 34
Customizable features ........... 498
D
Daytime running light system191
Defogger Outside rear view mirrors ... 327, 334
Rear window ................ 327, 334
Windshield.................... 326, 334
Digital Rearview Mirror .......... 144
Dimension ............................... 482
Dinghy towing ........................ 171
Display Dynamic radar cruise control with full-speed range .......... 237
Head-up display ................... 107
Intuitive parking assist .......... 254
LTA (Lane Tracing Assist) ..... 229
Multi-information display ...... 100
Parking Support Brake function (rear pedestrians) ............... 282 RCD (Rear Camera Detection)
...........................................269
Rear Camera Detection (RCD) ...........................................269
Toyota multi-operation touch 353
Toyota Teammate Advanced Park ....................................287
Warning message.................451
Display change button .............98
Do-it-yourself maintenance ...387
Door courtesy lights...............346
Door lock Doors ....................................121
Smart key system .................130
Wireless remote control........ 119
Doors .......................................121 Automatic door locking and unlocking system ................125
Door glasses ........................156
Door lock ..............................121
Open door warning buzzer .122, 124
Outside rear view mirrors .....154
Rear door child-protectors ....124
Drive distance .........................104
Drive information ....................104
Driver’s seat position memory ...............................................136Driving position memory .......136
Memory recall function .........138
Power easy access system ..136
Driving .....................................161 Break-in tips .........................162
Correct driving posture ...........27
Driving mode select switch ...313
Fuel cell vehicle driving tips ....89
Procedures ...........................161
Winter drive tips....................320
Driving informatio n display ...101
Driving position memory .......136 Memory recall function .........138
Power easy access system ..136
Page 533 of 556

Owners Manual_USA_M62084_en
Alphabetical Index533
K
Keyless entrySmart key system................. 130
Wireless remote control ....... 119
Keys ......................................... 118 Battery-saving function......... 131
Electronic key ....................... 118
If the electronic key does not operate properly ................. 468
If you lose your keys ............ 467
Key number plate ................. 118
Keyless entry................ 121, 130
Mechanical key .................... 118
Power switch ........................ 172
Replacing the battery ........... 423
Warning buzzer .................... 130
Wireless remote control ....... 119
Knee airbags ............................. 34
L
Lane Tracing Assist (LTA)...... 223 Operation ............................. 223
Warning lights....................... 444
Warning messages............... 233
Language (multi-information dis- play) ....................................... 105
LATCH anchors ........................ 60
Lever Auxiliary catch lever ............. 393
Hood lock release lever........ 393
Internal trunk release lever... 128
Shift lever ............................. 177
Turn signal lever ................... 182
Wiper lever ........................... 197
License plate lights Light switch .......................... 191
Replacing light bulbs ............ 429
Light bulbs Replacing ............................. 429
Lights Automatic High Beam system ...........................................193
Front personal lights .............347
Headlight switch ...................191
Interior lights .................346, 347
Interior lights list ...................346
Rear personal lights .............347
Replacing light bulbs ............429
Trunk light .............................128
Turn signal lever ...................182
Vanity lights ..........................369
Lock steering column ............173
LTA (Lane Tracing Assist) ......223 Operation..............................223
Warning lights .......................444
Warning messages ...............233
Luggage mats .........................352
M
Maintenance Do-it-yourself maintenance ..391
General maintenance ...........388
Maintenance data .................482
Maintenance requirements ...387
Menu icons ..............................101
Meter Clock ......................................97
Driving range ..........................97
Indicators ................................94
Instrument panel light control .98
Meter control switches..........100
Meters ....................................97
Multi-information display.......100
Settings ................................105
Warning lights .................93, 441
Warning message.................451
Meter control switches...........100
Mirrors Digital Rearview Mirror .........144
Inside rear view mirror ..........143
Outside rear view mirror defog-gers ............................327, 334
Outside rear view mirrors .....154
