If following another vehicle on a dusty
road, or driving in windy and dusty
conditions, it is recommended that the
air intake selector be temporarily set to
RECIRCULATE, which will close off the
outside passage and prevent outside
air and dust from entering the vehicle
interior.Heating
For best results, set controls to:
Fan speed— Any setting except “OFF”
Temperature— To w a r d s WARM
(red zone)
Air intake—FRESH (outside air)
Air flow—FLOOR
Air conditioning—OFF
For quick heating, select recirculated
air for a few minutes. To keep the
windows from fogging. select fresh af-
ter the vehicle interior has been
warmed.
Press the “A/C” button on for dehumidi-
fied heating.
Choose floor/windshield air flow to heat
the vehicle interior while defrosting or
defogging the windshield. Air conditioning
For best results, set controls to:
Fan speed— Any setting except “OFF”
Temperature— To w a r d s COLD
(blue zone)
Air intake—FRESH (outside air)
Air flow—PANEL
Air conditioning—ON
For quick cooling, move the air intake
selector to recirculate for a few min-
utes.
Ventilation
For best results, set controls to:
Fan speed— Any setting except “OFF”
Temperature— To w a r d s COLD
(blue zone)
Air intake—FRESH (outside air)
Air flow—PANEL
Air conditioning—OFF

02 MY MR2 SMT(U) L/O 0108
11 3
01 06 12
2002 MR2 (OM17493U)
Defogging
The inside of the windshield
For best results, set controls to:Fan speed— Any setting except “OFF”
Temperature— To w a r d s WARM
(red zone) to heat;
COLD (blue zone) to-
cool
Air intake—FRESH (outside air)
Air flow—WINDSHIELD
Turning the air flow control knob to wind-
shield position turns on the defroster
linked air conditioning. At this time, the
“A/C” button indicator comes on regard-
less of whether or not the “A/C” button is
pressed in. This is to clean up the front
view more quickly.
When the “A/C” button is not pressed in,
turning the air flow control knob to a posi-
tion other than windshield or floor/wind-
shield turns off the air conditioning.
On humid days, do not blow cold air
on the windshield—the difference be-
tween the outside and inside tempera-
tures could make the fogging worse. Defrosting
The outside of the windshield
For best results, set controls to:
Fan speed— Any setting except “OFF”
Temperature— To w a r d s WARM
(red zone)
Air intake—FRESH (outside air)
Air flow—WINDSHIELD
Turning the air flow control knob to wind-
shield position turns on the defroster
linked air conditioning. At this time, the
“A/C” button indicator comes on regard-
less of whether or not the “A/C” button is
pressed in. This is to clean up the front
view more quickly.
When the “A/C” button is not pressed in,
turning the air flow control knob to a posi-
tion other than windshield or floor/wind-
shield turns off the air conditioning.
To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.
Side vents
SB18005
Open
Close
If air flow control is not satisfactory, check
the side vents. The side vents may be
opened or closed as shown.

02 MY MR2 SMT(U) L/O 0108
11 4
01 06 12
2002 MR2 (OM17493U)

02 MY MR2 SMT(U) L/O 0108
11 5
01 06 12
2002 MR2 (OM17493U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Clock116
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 116
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 117
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Front box 117
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Auxiliary box 118
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Luggage space 119
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Cup holders 121
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Floor mat 121
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
SECTION 1 9

02 MY MR2 SMT(U) L/O 0108
11 6
01 06 12
2002 MR2 (OM17493U)
Clock
SB19015
The digital clock indicates the time.
The key must be in the “ACC” or “ON”
position.
To reset the hour: Push the “H” button.
To reset the minutes: Push the “M” button.
If quick adjustment to a full hour is de-
sired, push the “:00” button.
For example, if the “:00” button is de-
pressed when the time is between
1:01—1:29, the time will change to 1:00.
If the time is between 1:30—1:59, the
time will change to 2:00.If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o’clock).
When the instrument panel lights are
turned on, the brightness of the time indi-
cation will be reduced.
Cigarette lighter and ashtray
SB19016
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
After it finishes heating up, it automati-
cally pops out ready for use.
If the engine is not running, the key must
be in the “ACC” position to use the light-
er.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.

02 MY MR2 SMT(U) L/O 0108
11 7
01 06 12
2002 MR2 (OM17493U)
ASHTRAY
To use the ashtray, pull out the lid.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, close the lid
completely.
To remove the ashtray, pull the lid and
pull it out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always completely close
the ashtray after use.
Glove box
SB19026
To use the glove box, do this.
To open: Compress the lock release but-
tons.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Front box
SB41047
To use the front box in the trunk, do
this.1. Open the trunk lid, and pull the lock release lever.

02 MY MR2 SMT(U) L/O 0108
11 8
01 06 12
2002 MR2 (OM17493U)
SC19031
2. Fix the cover by hitching the inside clipon the hood.
NOTICE
Do not place valuables in the front
box to prevent robbery.
 Do not place anything which weighs
over 5 kg (11 lb.) in the front box.
If something weighs over 5 kg (11
lb.) is placed in the front box while
driving, the front box may be dam-
aged.
 Be sure to lock the cover securely
when you close the trunk lid. If the
cover is not securely locked, it may
cause damage to the trunk lid.
SB19018
Front of vehicle
DRAINAGE OF THE FRONT BOX
In case that the water is pooled inside the
front box, remove the grommet on the
bottom of the box to drain the water.
NOTICE
Since the front box is not waterproof
completely, it is possible for the
things stored in the box to the
drenched.
Auxiliary box
SB19019
Instrument panel
To use the box, open it as shown in
the illustration.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the auxiliary box closed
while driving.

02 MY MR2 SMT(U) L/O 0108
11 9
01 06 12
2002 MR2 (OM17493U)
Luggage space
SB19027
Lean the seatback forward to use the
luggage space.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
SB12059
\b

\fflare
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the luggage space door
closed while driving.
NOTICE
Do not place valuables in the lug-
gage space to prevent robbery.
 Do not lower the soft top while
placing a luggage which is higher
than the bottom edge of the flare
inside the luggage space.
The luggage may be damaged by
hitting the folding board or the im-
properly folded soft top may flap in
the wind and cause an accident.

02 MY MR2 SMT(U) L/O 0108
120
01 06 12
2002 MR2 (OM17493U)
SB19030
When you load a long luggage
Remove the side trims on the both sides
in the luggage space when you need to
load a long luggage (except tapered
things) such as a golf bag.
The side trims can be removed by pulling
the clips (at two places).
SB19029
Removing the side trims
SB19028
Installing the side trims
NOTICE
Do not place tapered things or a
long luggage into the luggage
space. That may damage the water
receiving bag installed behind the
side trims.
 Do not lower the soft top with a
long luggage loaded. The luggage
may touch the lower portion of the
soft top side rails and may be dam-
aged.
 Never remove the side trims except
when loading a long luggage. Other-
wise, the luggage may move while
driving and damage the water re-
ceiving bag or the luggage may be
damaged when the soft top is
opened.

02 MY MR2 SMT(U) L/O 0108
121
01 06 12
2002 MR2 (OM17493U)
Cup holders
SB19013
Front
SB19014
Center console
The cup holders are designed for hold-
ing cups or drinkcans securely in its
holes.
Front: To use the cup holders, pull them
out.
CAUTION
Do not place anything else other
than cups or drinkcans in the cup
holders, as such items may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or an
accident.
Front only: To reduce the chance of
injury in case of an accident or a
sudden stop while driving, keep the
cup holder closed when it is not in
use.
Floor mat
SB19023
Use a floor mat of the correct size.
If the floor carpet and floor mat have a
hole, then it is designed for use with a
locking clip. Fix the floor mat with locking
clip into the hole in the floor carpet.
