TOYOTA PRIUS 2004 2.G Owner's Guide

31
INFORMATION
When changing the mode, be sure
to push both “ ” (lock) and “ ”
(panic) buttons firmly, or panic
alarm may be activated.
 This operation will not change the
wireless remote control unlocking
function.
 In the single or driver’s door un-
locking mode, if you get into the
vehicle from the driver’s door carry-
ing the smart key, all the smart un-
locking controls activated by the
smart key will be stopped for secu-
rity. If you get out of the vehicle
from the driver’s door carrying the
smart key and get out of the effec-
tive range of the smart function,
unlocking control by the smart key
will be possible. However, unlocking
control may not be carried out for
5 seconds after you get out from
the vehicle. In this case, operate
unlock control again after 5 sec-
onds.
BATTERY POWER SAVING
When doors are locked, the smart entry
and start system transmits electromagnetic
waves to the outside of the vehicle at
regular intervals. For this reason, the ve-
hicle battery will be discharged if the ve-
hicle is left for a long time. If the key is
left within the effective range of the smart
function outside of the vehicle, the key
and the vehicle transmit electromagnetic
waves periodically. If these conditions con-
tinue for a long time, the battery in the
key and vehicle will be discharged.
To prevent the batteries from being dis-
charged, the smart function is automatical-
ly deactivated in the following conditions:
If there is no response from the key
for more than 14 days
If the key is left within the effective
range of the smart function outside of
the vehicle for more than 10 minutes To reactivate the smart function, perform
any of the following:
(a) Press the lock button on the outside front door handle or back door while
carrying the smart key.
(b) Perform a wireless remote control op- eration.
(c) Insert and turn the mechanical key in the keyhole of the driver’s door.

32
INFORMATION
To maintain communication with the
vehicle, smart keys use builtin bat-
tery power. The battery service life
is about 1 to 3 years on average. If
battery power becomes insufficient,
replace the battery with a new one.
The smart key continually receives
electromagnetic waves, and if it re-
ceives strong electromagnetic waves
over a period of time, the battery
can be drastically run down. There-
fore, avoid storing smart keys near
any electrical appliances.Here is a list of electrical ap-
pliances which may have adverse
effects on the smart key perfor-
mance: TVs, personal computers,
cellular phone or cordless phone
recharger units, electric light stands
and fluorescent desk lights
Note that you should always keep
such electrical appliances at least 1
m (3 ft.) away from the smart key.
21p138a
1. Smart function is on.
2. Smart function is off.
DEACTIVATING THE SMART FUNCTION
The cancel switch for this function is
located at the bottom of the instrument
panel on the driver side. When you
push the switch, the smart function will
be deactivated. Pushing the switch
again will reactivate the function.
When the smart function is deactivated,
use a mechanical key or wireless remote
control function key to lock and unlock the
doors. To start the hybrid system, insert
a smart key into the key slot. If you do not intend to drive your vehicle
for a long time, push the cancel switch to
deactivate the smart function.
INFORMATION
The smart function will be deactivated
in the following cases:
The cancel switch is turned on.
The smart key is inserted into the
key slot.
The battery of the smart key is dis-
charged.

33
For vehicles sold in U.S.A.
FCC ID: MOZB31EG
MADE IN JAPAN
FCC ID: MOZB31UG
MADE IN JAPAN
FCC ID: MOZRO2TY1
MADE IN JAPAN
FCC ID: PENASAT2
MADE IN JAPAN
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
For vehicles sold in Canada
This device complies with RSS −210 of
industry Canada. Operation is subject to
the following two conditions:
(1) This device may not cause interfer-
ence, and (2) this device must accept
any interference, including interference
that may cause undesired operation of
the device.
21p013f
Locking operation
21p014f
Unlocking operation
Wireless remote control

34
The wireless remote control system is
designed to lock or unlock all the side
doors and back door, or activate the
theft deterrent system from a distance
within approximately 1 m (3 ft.) of the
vehicle.
LOCKING AND UNLOCKING THE
DOORS
To lock and unlock all the doors, push
the switches slowly and securely. At
this time, the indicator light on the key
flashes once.
To lock: Push the “
” (lock) switch. All
the side doors and back door are locked
simultaneously. At this time, the turn sig-
nal lights will flash once.
Check to see that the doors are securely
locked.
If any of the doors is not securely closed
or if the key is in the key slot, locking
cannot be performed by the “
” (lock)
switch. At this time, a beep will sound for
10 seconds on the vehicle with smart
entry and smart system. However, if the
key is in the key slot, a beep will not
sound. To stop the beep, close all the
side doors and back door securely or
push the “
” (unlock) switch. The buzzer can be disabled. For details,
contact your Toyota dealer.
To unlock: Push the “
” (unlock) switch
once to unlock the driver ’s door alone.
Pushing the switch twice within 3 seconds
unlocks all the doors simultaneously. Each
time the “
” (unlock) switch is pushed,
the turn signal lights will flash twice.
This double switch operation to unlock all
the side doors and back door can be
changed to a single switch operation. For
details, contact your Toyota dealer.
When the “
” (unlock) switch is pressed
the interior light comes on. The light re-
mains on for about 15 seconds unless any
of the doors is opened and then closed.
(For further information, see “Interior light”
on page 107.)
You have 30 seconds to open a door after
using the wireless remote unlock feature.
If a door is not opened by then, all the
doors will be automatically locked again.
The timing for the automatic door lock
function can be changed. For details, con-
tact your Toyota dealer. If the “
” (lock) or “” (unlock) switch
is kept pressed in, the locking or unlock-
ing operation is not repeated. Release the
switch and then push it again.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer:
Cancelling the wireless door locking or
unlocking function
Cancelling the flash of the turn signal
lights

35
21p015a
ACTIVATING PANIC MODE
Pushing the “
” (panic) switch for 1
second blows the horn intermittently
and flashes the headlights, tail lights
and emergency flashers and turns on
the interior light.
The “
” (panic) switch is used to deter
vehicle theft when you witness anyone at-
tempting to break into or damage your
vehicle.
The alarm will last for one minute. To stop
the alarm midway, do the follows:
Push any switch on the key.
Put the hybrid system in the “IG −ON”
mode. The panic mode does not work in “IG
−ON”
mode.
The alarm function can be activated or
deactivated. For details, contact your
Toyota dealer.
WIRELESS REMOTE CONTROL KEY
The wireless remote control key is an
electronic component. Observe the follow-
ing instructions in order not to cause dam-
age to the key.
Do not leave the key in places where
the temperature becomes high such as
on the dashboard.
Do not disassemble it.
Avoid knocking it hard against other
objects or dropping it.
Avoid putting it in water.
If your vehicle is equipped with smart
entry and start system, you can use up
to 5 master keys for the same vehicle. In
case of the vehicle not equipped with
smart entry and start system, up to 4
master keys are avairable. Contact your
Toyota dealer for detailed information.
If the wireless remote control key does
not actuate the doors or alarm or operate
from a normal distance, or indicator light
on the key is dimmed or does not come
on:
Check for closeness to a radio trans-
mitter such as a radio station or an
airport which can interfere with normal
operation of the key.
The battery may have been consumed.
Check the battery in the key. To re-
place the battery, see “REPLACING
THE BATTERY” on page 36.
If you lose your key, contact your Toyota
dealer as soon as possible to avoid the
possibility of theft, or an accident. (See “If
you lose your keys” on page 257.)
For vehicles sold in U.S.A.
FCC ID: MOZB21TG
MADE IN JAPAN
FCC ID: MOZB21RG
MADE IN JAPAN
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.

36
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
For vehicles sold in Canada
This device complies with RSS−210 of
industry Canada. Operation is subject to
the following two conditions:
(1) This device may not cause interfer-
ence, and (2) this device must accept
any interference, including interference
that may cause undesired operation of
the device.
REPLACING THE BATTERY
For replacement, use a CR2032 lithium
battery or equivalent and a special screw-
driver.
CAUTION
Special care should be taken that
small children do not swallow the re-
moved battery or components.
NOTICE
 When replacing the battery, be care-
ful not to lose the components.
 Replace only with the same or
equivalent type recommended by a
Toyota dealer.
 Dispose of used batteries according
to the local laws.
Replace the battery by following proce-
dures.
21p016c
1. Remove the mechanical key and cover
with slide the lock knob in the arrow
direction.

37
21p017c
2. Remove the 4 screws to take out thelid of the module.
NOTICE
Do not bend the terminals.
3. Remove the discharged battery and put
in a new battery with positive (+) side
up.
NOTICE
Make sure the positive side and
negative side of the battery are
faced correctly.
 Do not replace the battery with wet
hands. Water may cause unexpected
rust.
 Do not touch or move any compo-
nents inside the transmitter, or it
may interfere with proper operation.
 Be careful not to bend the electrode
when inserting the battery and that
dust or oils do not adhere to the
case.
4. Install the lid with the 4 screws.
NOTICE
Take care not to damage or bend the
Oring when installing.
5. Replace the mechanical key and cover
with slide the lock knob.
After replacing the battery, check that the
key operates properly. If the key still does
not operate properly, contact your Toyota
dealer.
21p008a
LOCKING AND UNLOCKING THE DRIV-
ER’S DOOR WITH MECHANICAL KEY
Insert the mechanical key into the key-
hole and turn it.
To lock: Turn the knob forward.
To unlock: Turn the knob backward.
The alarm sounds when you unlock the
door using a key with the theft deterrent
system set. For details, see “Theft deter-
rent system” on page 44.
Side doors

38
21p009a
LOCKING AND UNLOCKING WITH IN-
SIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
The driver ’s door can be opened by pull-
ing the inside door handle even if the lock
knob is depressed.
Closing the door with the lock knob in the
lock position will also lock the door. Be
careful not to lock your keys in the ve-
hicle.
The driver ’s door cannot be locked if you
leave the key in the key slot.
21p010a
Driver’s side
21p011a
Front passenger’s side
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
To lock: Push the switch down on the
front side.
To unlock: Push the switch down on the
rear side.
All the doors lock or unlock simultaneous-
ly.

39
21p012b
REAR DOOR CHILDPROTECTORS
Move the lock lever to the “LOCK”
position as shown on the label.
When the child−protector is locked, you
cannot open the rear door by the inside
door handle. We recommend using this
feature whenever small children are in the
vehicle.
CAUTION
Before driving, be sure that the doors
are closed and locked, especially
when small children are in the ve-
hicle. Along with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also helps
prevent the doors from being opened
unintentionally.
12p032
To open the back door, push the back
door opener and raise the back door.
If the back door opener does not operate,
see “If you cannot operate back door
opener” on page 258.
Back door

40
12p033
When closing the back door, the inside
handle can be used to make the reach
easier.
See “Cargo and luggage” on page 224 for
precautions to observe when loading lug-
gage.
To close the back door, lower it and press
down on it. After closing the back door,
try pulling it up to make sure it is secure-
ly closed.
CAUTION
Keep the back door closed while driv-
ing. This not only keeps the luggage
from being thrown out, but also pre-
vents exhaust gases from entering
the vehicle.
If the auxiliary battery is disconnected
or run down, the back door will be auto-
matically locked and the back door system
may not work after you reconnect, replace
or recharge the auxiliary battery. In any of
these cases, normalize the back door sys-
tem by following procedure.
1. Unlock the back door with the remote control key or power door lock switch.
2. Close the back door completely by hand.
If the back door system does not operate
properly after the above procedure, there
may be a problem in the system. Contact
your Toyota dealer.
21p019a
The windows can be operated with the
switch on each door.
The power windows work when the “IG −
ON” mode is enabled.
Key off operation : If both front doors are
closed, they work for 45 seconds even
after the hybrid system is stopped. They
stop working when either front door is
opened.
OPERATING THE DRIVER’S WINDOW
Use the switch on the driver’s door.
Normal operation : The window moves as
long as you hold the switch.
To open: Lightly push down the switch.
To close: Lightly pull up the switch.
Power windows
