TOYOTA PRIUS 2010 3.G Owners Manual

291
3
Interior features
PRIUS_U (OM47668U) U.S.A.
3-2. Using the audio system
Audio system type
With navigation system
Owners of models equipped with a navigation system should
refer to the “Navigation System Owner’s Manual”.
Without navig ation system
Type A: CD player with changer and AM/FM radio
ITO32P102

292 3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
■Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio syste\
m is
operating.
Type B: CD player and AM/FM radio (with CD changer control-
ler)
ITO32P101
TitlePage
Using the radioP. 294
Using the CD playerP. 303
Playing back MP3 and WMA discs P. 3 11
Optimal use of the audio systemP. 319
Using the AUX adapter P. 322
Using the steering switchesP. 323

293
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
CAUTION
■
For vehicles sold in the U.S.A.
● Part 15 of the FCC Rules
FCC Warning: 
Any unauthorized changes or modifications to this equipment will void the
user’s authority to operate this device.
● Laser products
• Do not take this unit apart or attempt to make any changes yourself. 
This is an intricate unit that uses a laser pickup to retrieve information
from the surface of compact discs. The laser is carefully shielded so
that its rays remain inside the cabinet. Therefore, never try to disas-
semble the player or alter any of its parts since you may be exposed to
laser rays and dangerous voltages.
• This product utilizes a laser. 
Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation expo-
sure.
NOTICE
■ To prevent 12 volt battery discharge
Do not leave the audio system on longer than necessary with the hybrid sys-
tem is not operating.
■ To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.

294
3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
Using the radio
Press , or to choose either an AM or
FM band.
Station selectorMute (type B only)
Adjusting the
frequency
Changing the
program type
Scanning for
receivable
stations
AM
SAT/FM mode buttons
Seeking the
frequency Volume
Power

295
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
Setting station presets (excluding XM® Satellite Radio)
Search for desired stations by turning or pressing “ ” or
“  ” on .
Press and hold the button (fro m to ) the station is
to be set to, and you hear a beep.
Scanning radio stations (excluding XM® Satellite Radio)
■ Scanning the preset radio stations
Press and hold until you hear a beep.
Preset stations will be played for a few seconds each.
When the desired station is reached, press once
again.
■ Scanning all radio stations within range
Press . 
“SCAN” appears on the display and all stations with reception
will be played for a few seconds each.
When the desired station is reached, press once
again.
STEP1
STEP2
STEP1
STEP2
STEP1
STEP2

296 3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
XM® Satellite Radio (if equipped)
■ Receiving XM
® Satellite Radio
Press until “SAT” shows in the display.
The display changes as follows each time the button is pressed.
“AM”  “SAT1”  “SAT2”  “SAT3”
Turn to select a desired channel from all the categories
or press “ ” or “ ” on to select a desired channel in
the current category.
■ Presetting XM
® Satellite Radio channels
Select the desired channel. Press and hold the button (from
to ) until you hear a beep.
■ Changing the channel category
Press “ ” or “ ” on .
STEP1
STEP2

297
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
■
Scanning XM
® Satellite Radio channels
● Scanning channels in the current category
Press .
When the desired channel is reached, press the button again.
● Scanning preset channels
Press and hold until you hear a beep.
When the desired channel is reached, press the button again.
■ Displaying text information
Press .
The display will show up to 10 characters.
The display changes as follows each time the button is pressed.
● CH NAME
● TITLE (SONG/PROGRAM TITLE)
● NAME (ARTIST NAME/FEATURE)
● CH NUMBER
STEP1
STEP2
STEP1
STEP2

298 3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
Silencing the sound (type B only)Press .
Push the button again to turn the
system back on.
ITO32P122
■When the 12 volt battery is disconnected
All preset stations are erased.
■ Reception sensitivity
● Maintaining perfect radio reception at all times is difficult due to the con-
tinually changing position of the antenna, differences in signal strength
and surrounding objects, such as trains, transmitters, etc.
● The radio antenna is mounted on the rear roof. The antenna can be
removed from the base by turning.

299
3-2. Using the audio system
3
Interior features
PRIUS_U (OM47668U) U.S.A.
■
Receiving XM® Satellite Radio
An XM
® Satellite Radio is a tuner designed exclusively to receive broadcasts
provided under a separate subscription. Availability is limited to the 48 con-
tiguous states and 10 Canadian provinces.
● XM
® subscriptions
For detailed information about XM® Satellite Radio or to subscribe: 
U.S.A– 
Visit on the web at www.xmradio.com
or call 1-800-967-2346. 
Canada– 
Visit on the web at www.xmradio.ca
or call 1-877-438-9677.
● Radio ID 
You will need the radio ID when activating XM
® service or reporting a
problem. Select “CH000” using , and the receiver’s 8-character ID
number will appear.
● Satellite tuner 
The tuner supports only Audio Services (Music and Talk) and the accom-
panying Text Information of XM
® Satellite Radio.

300 3-2. Using the audio system
PRIUS_U (OM47668U) U.S.A.
■If the satellite radio does not operate normally
If a problem occurs with the XM
® tuner, a message will appear on the dis-
play. Refer to the table below to identify the problem, and take the suggested
corrective action.
ANTENNA
The XM® antenna is not connected. Check
whether the XM® antenna cable is attached
securely.
There is a short-circuit in the antenna or the sur-
rounding antenna cable. See a Toyota certified
dealer.
UPDATING You have not subscribed to XM
® Satellite Radio.
The radio is being updated with the latest encryp-
tion code. Contact XM
® Satellite Radio for sub-
scription information. When a contract is canceled,
you can choose “CH000” and all free-to-air chan-
nels.
The premium channel you selected is not autho-
rized. Wait for about 2 seconds until the radio
returns to the previous channel or “CH001”. If it
does not change automatically, select another
channel. If you want to listen to the premium chan-
nel, contact XM
® Satellite Radio.
NO SIGNAL The XM
® signal is too weak at the current location.
Wait until your vehicle reaches a location with a
stronger signal.
LOADING The unit is acquiring audio or program information.
Wait until the unit has received the information.
OFF AIRThe channel you selected is not broadcasting any
programming. Select another channel.
