TOYOTA PRIUS 2021 Accessories, Audio & Navigation (in English)

512-4. Other settings
2
Basic function
2Select “Delete Personal
Data”.
3 Select “Delete”.
4 Select “Yes” when the confir-
mation screen appears.
Examples of settings that can be
returned to their default conditions:
Audio settings
 Phone settings
etc.
*1: This function is not made avail-
able in some countries or areas.
*2: Vehicles with DCM
When the automatic update
check function is enabled, if a
software update is available
from the Cloud, a message will
be displayed.
1 Display the general settings
screen. ( P.49)
2 Select “Software Update Set-
ting”.
3 Select “Automatic Update
Check” to enable/disable the
automatic update check func-
tion.
●When software update information
is displayed, contact your Toyota
dealer.
Software update set-
tings
*1, 2

522-4. Other settings
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Voice”.
4 Select the desired items to
be set.
Select to adjust the volume of
voice guidance.
*1
Select to set the voice recog-
nition prompts.
Select to train voice recogni- tion.
The voice command system
adapts the user accent.
Select to start the voice rec-
ognition tutorial.
Select to set the voice
prompt interrupt on/off.
*2, 3
Select to reset all setup
items.
*1: When an Apple CarPlay/Android
Auto connection is established,
speech command system
(Siri/Google Assistant) and map
application voice guidance vol-
ume can be changed.
*2: Audio Plus only
*3: Audio with DCM only
Voice settings
Voice volume, etc. can be
set.
Displaying the voice set-
tings screen
Voice settings screen
A
B
C
D
E
F

532-4. Other settings
2
Basic function
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Vehicle”.
4 Select the desired items to
be set.
Select to set vehicle customi-
zation.
*1
Select to set valet mode.
( P.54)
Select to set dealer informa- tion.
*2
*1: Refer to the “OWNER’S MAN-
UAL”
*2: Audio Plus with DCM only
The security system can be set
to on by entering a security code
(4-digit number).
When set to on, the system will
become inoperative once the
electrical power source is dis-
connected until the security
code is entered.
1 Display the vehicle settings
screen. ( P.54)
2 Select “Valet Mode”.
3 Enter the 4-digit personal
code and select “OK”.
4 Enter the same 4-digit per-
sonal code again and select
“OK”.
 The system will request that
you input the security code
again to confirm that you
remember it correctly.
 When valet mode activates,
the system stops and a secu-
rity code (4-digit number)
standby screen is displayed.
●If the 4-digit personal code is for-
gotten, please contact your
Toyota dealer.
Vehicle settings
Settings are available for
vehicle customization, etc.
Displaying the vehicle
settings screen
Vehicle settings screen
A
B
C
6HWWLQJWKHY\
DOHWPRGH

542-4. Other settings
1Enter the 4-digit personal
code and select “OK”.
●If an incorrect security code (4-
digit number) is entered 6 times,
the system will not accept another
security code (4-digit number) for
10 minutes.
*: Audio Plus with DCM only
Dealer information can be regis-
tered in the system. If the vehi-
cle alert screen is displayed,
selecting the call dealer button
on the screen will call the phone
number registered in the dealer
information.
1Display the vehicle settings
screen. ( P.54)
2 Select “Dealer Info”.
3 Select the desired items to
be edited.
Select to enter the name of a
dealer. ( P.55)
Select to enter the name of a
dealer member. ( P.55)Select to enter the phone
number. (
P.55)
Select to delete the dealer
information displayed on the
screen.
1 Select “Edit” next to “Dealer”
or “Contact”.
2 Enter the name and select
“OK”.
1 Select “Edit” next to “Phone
#”.
2 Enter the phone number and
select “OK”.
If the valet mode has been
activated
Setting dealer informa-
tion*
A
B
(GLWLQJGHDOHURUFRQWDFW
QDPH
(GLWLQJSKRQHQXPEHU
C
D

57
3
3
Audio/visual system
Audio/visual system
3-1. Basic operationQuick reference.............. 58
Some basics .................. 60
3-2. Radio operation AM/FM/SiriusXM (SXM) radio ............................. 65
3-3. Media operation CD .................................. 73
USB memory.................. 75
iPod/iPhone (Apple Car- Play) ............................. 77
Android Auto .................. 80
Bluetooth
® audio ............ 81
3-4. Audio/visual remote con- trols
Steering switches ........... 85
3-5. Setup Audio settings ................ 87
3-6. Tips for operating the audio/visual system
Operating information .... 89

583-1. Basic operation
3-1.Basic operation
The audio control screen can be reached by the following methods:
From the “AUDIO” button
1 Press the “AUDIO” button.
From the “MENU” button
1 Press the “MENU” button, then select “Audio”.
Audio
Audio Plus
 Using the radio ( P.65)
Quick reference
Functional overview

593-1. Basic operation
3
Audio/visual system
Playing an audio CD or MP3/WMA/AAC disc*1 ( P.73)
 Playing a USB memory ( P.75)
 Playing an iPod/iPhone (Apple CarPlay
*2) ( P.77)
 Using the Android Auto
*2 ( P.80)
 Playing a Bluetooth
® device ( P.81)
 Using the steering wheel audio switches ( P.85)
 Audio system settings ( P.87)
*1: Audio Plus only
*2: This function is not made available in some countries or areas .

603-1. Basic operation
“POWER VOLUME” knob:
Press to turn the audio/visual
system on and off. The system
turns on in the last mode used.
Turn this knob to adjust the vol-
ume.1
Press the “AUDIO” button.
2 Select “Source” or press
“AUDIO” button again.
3 Select the desired source.
●Dimmed screen buttons cannot be
operated.
●When there are tw o pages, select
or to change the page.
●When an Apple CarPlay/Android
Auto connection is established,
some system functions, such as
the following, will be replaced by
similar Apple CarPlay/Android
Auto function or will become
unavailable
*:
• iPod (Audio Playback)
• USB audio/USB video
• Bluetooth
® audio
• Toyota apps
*: This function is not made avail-
able in some countries or areas.
Some basics
This section describes
some of the basic features
of the audio/visual system.
Some information may not
pertain to your system.
Your audio/visual system
works when the power
switch is in ACCESSORY or
ON mode.
NOTICE
●To prevent the 12-volt battery
from being discharged, do not
leave the audio/visual system
on longer than necessary when
the hybrid system is not operat-
ing.
Turning the system on
and off
Selecting an audio source

613-1. Basic operation
3
Audio/visual system
1Display the audio source
selection screen. ( P.60)
2 Select “Reorder”.
3 Select the desired audio
source then or to reor-
der.
4 Select “OK”.
■Inserting a disc
1 Insert a disc into the disc slot.
 After insertion, the disc is
automatically loaded.
*: Audio Plus only
■Ejecting the disc
1 Press the button and
remove the disc.
●The player is intended for use with
12 cm discs only.
●When inserting a disc, gently
insert the disc with the label facing
up.
1Open the cover and connect
a device to the USB port.
 Turn on the power of the
device if it is not turned on.
●If a USB hub is plugged-in, two
Reordering the audio
source
Disc slot*
NOTICE
●Never try to dis assemble or oil
any part of the CD player. Do
not insert anything other than a
disc into the slot.
USB port

623-1. Basic operation
devices can be connected at a
time.
●Even if a USB hub is used to con-
nect more than two USB devices,
only the first two connected
devices will be recognized.
●If a USB hub that has more than
two ports is connected to the USB
port, devices connected to the
USB hub may not charge or be
inoperable, as the supply of cur-
rent may be insufficient.
●When an Apple CarPlay/Android
Auto connection is established,
the other USB port can be used
only for device battery charger.
1 Display the audio control
screen. ( P.60)
2 Select “Sound”.
3 Select the desired item to be
set.
Select to set the tre-
ble/mid/bass. ( P.62)
Select to set the fader/bal-
ance. ( P.62)
Select to set the automatic
sound leveliser. ( P.63)
■Treble/Mid/Bass
How good an audio program
sounds is largely determined by the mix of the treble, mid and
bass levels. In fact, different
kinds of music and vocal pro-
grams usually sound better with
different mixes of treble, mid
and bass.
1
Select “Treble/Mid/Bass”.
2 Select the desired screen
button.
Select “+” or “-” to adjust
high-pitched tones.
Select “+” or “-” to adjust mid-
pitched tones.
Select “+” or “-” to adjust low-
pitched tones.
■Fader/Balance
A good balance of the left and
right stereo channels and of the
front and rear sound levels is
also important.
Keep in mind that when listening
to a stereo recording or broad-
cast, changing the right/left bal-
ance will increase the volume of
1 group of sounds while
decreasing the volume of
another.
1 Select “Fader/Balance”.
Sound settings
A
B
C
A
B
C
