TOYOTA PRIUS C 2012 NHP10 / 1.G Owners Manual

5
When trouble arises
451
5-2. Steps to take in an emergency
OnceContinuous
(For 5 seconds)
(Displayed alter- nately)
(Flashes) An attempt was
made to lock
the doors using
the entry func-
tion after the
electronic key
was carried out-
side the vehicle
without turning
off the
“POWER”
switch.
Turn the
“POWER”
switch off and
lock the doors
again.
9 times
(Flashes)An attempt was
made to start
the hybrid sys-
tem without the
electronic key
being present,
or the elec-
tronic key was
not functioning
normally.
An attempt was
made to drive
when the regu-
lar key was not
inside the vehi-
cle.
Confirm that the
electronic key is
inside the vehi-
cle.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

452 5-2. Steps to take in an emergency
Continuous(Flashes)The driver’s
door was
opened while a
shift lever posi-
tion other than
P was selected
without turning
off the
“POWER”
switch.
Shift the shift
lever to P.
ContinuousContinuous
(Displayed alter-
nately)
(Flashes) The electronic
key was carried
outside the
vehicle and the
driver’s door
was opened
and closed
while a shift
lever position
other than P
was selected
without turning
off the
“POWER”
switch.
• Shift the shift
lever to P.
• Bring the elec- tronic key back
into the vehicle.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

5
When trouble arises
453
5-2. Steps to take in an emergency
OnceContinuous
(Flashes)
An attempt was
made to lock
the doors using
the smart key
system while
the electronic
key was still
inside the vehi-
cle.
Retrieve the
electronic key
from the vehi-
cle and lock the
doors again.
An attempt was
made to lock
either front door
by opening a
door and putting
the inside door
lock button into
the lock posi-
tion, and then
closing the door
while pulling on
the outside door
handle with the
electronic key
still inside the
vehicle.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

454 5-2. Steps to take in an emergency
Once(Flashes)• The electronic
key could not be
detected when
the “POWER”
switch was
pressed after
the doors were
unlocked with
the mechanical
key.
• The electronic key could not be
detected two
consecutive
times when the
“POWER”
switch was
pressed. Touch the elec-
tronic key to the
“POWER”
switch while
depressing the
brake pedal.
Once
(Flashes)An attempt was
made to start
the hybrid sys-
tem with the
shift lever in a
position other
than P.
Shift the shift
lever to P and
start the hybrid
system.
 Power was
turned off due to
the automatic
power off func-
tion.Next time when
starting the
hybrid system,
increase the
engine speed
slightly and
maintain that
level for approx-
imately 5 min-
utes to recharge
the 12-volt-bat-
tery.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

5
When trouble arises
455
5-2. Steps to take in an emergency
Once
The electronic
key has a low
battery.Replace the
electronic key
battery.
(
P. 397)
Once
(Flashes)The driver's
door was
opened and
closed with the
“POWER”
switch turned off
and then the
“POWER”
switch was put
in ACCES-
SORY mode
twice without
the hybrid sys-
tem being
started.
Press the
“POWER”
switch while
depressing the
brake pedal.
During a hybrid
system starting
procedure in the
event that the
electronic key
was not func-
tioning properly
( P. 473), the
“POWER”
switch was
touched with
the electronic
key. Press the
“POWER”
switch within 10
seconds of the
buzzer sound-
ing.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

456 5-2. Steps to take in an emergency
Once(Flashes)The steering
lock could not
be released
within 3 sec-
onds of the
“POWER”
switch being
pressed. Press the
“POWER”
switch while
depressing the
brake pedal and
moving the
steering wheel
left and right.
Once
(Flashes)The “POWER”
switch has been
turned off with
the shift lever in
a position other
than P.
Shift the shift
lever to P.
Once
(Flashes)After the
“POWER”
switch has been
turned off with
the shift lever in
a position other
than P, the shift
lever has been
shifted to P.
Turn the
“POWER”
switch off.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

5
When trouble arises
457
5-2. Steps to take in an emergency
If you have a flat tire
Remove the flat tire and replace it with the spare tire provided.
■Before jacking up the vehicle
●Stop the vehicle on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P.
● Stop the hybrid system.
● Turn on the emergency flashers.
■ Location of the spare tire, jack and tools
*: Jack handle, wheel nut wrench and towing eyelet
Jack
Spare tire
Tool bag*
Spare wheel
cushions
Luggage floor
cover

458 5-2. Steps to take in an emergency
Taking out the jackMove the driver seat to the front
most position.
Push the tabs in and remove the
cover by pulling it towards you.
For tightening
For loosening
STEP1
STEP2
STEP3

5
When trouble arises
459
5-2. Steps to take in an emergency
Taking out the compact spare tire
Remove the luggage floor cover
by lifting up the points indicated
by the arrows.
Remove the spare wheel cush-
ions, then loosen the center fas-
tener that secures the spare tire.
STEP1
STEP2

460 5-2. Steps to take in an emergency
Replacing a flat tireChock the tires.
For vehicles with steel wheels,
remove the wheel ornament
using the wrench.
To protect the wheel ornament,
place a rag between the wrench
and the wheel ornament.
STEP1
Flat tireWheel chock positions
Front
Left-
hand
sideBehind the
rear right-
hand side
tire
Right-
hand
sideBehind the
rear left-
hand side
tire
Rear
Left-
hand
sideIn front of
the front
right-hand
side tire
Right-
hand
sideIn front of
the front
left-hand
side tire
STEP2
