TOYOTA PRIUS C 2019 Owners Manual (in English)

3715-12. Using the voice command system (Multimedia system)
5
Audio system
PRIUS c_U
The Mobile Assistant feature will activate Apple’s Siri® Eyes Free
mode via the steering wheel switches. To operate the Mobile Ass is-
tant, a compatible cellular phone must be registered and connec ted to
this system via Bluetooth
®. (  P. 3 1 5 )
Press and hold the until
you hear the beeps.
The Mobile Assistant can be
used only when the following
screen is displayed.
To cancel the Mobile Assistant,
select “Cancel”, or press and hold
the on the steering wheel.
To restart the Mobile Assistant for
additional commands, press the on the steering wheel.
• Mobile Assistant can only be restarted after the system responds to a voice command.
• After some phone and music commands, the Mobile Assistant feat ure will
automatically end to complete the requested action.
■
Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR/VOL” knob or steering wheel volume switches. The Mobile
Assistant and phone call vo lumes are synchronized.
Mobile Assistant
1
2

3725-12. Using the voice command system (Multimedia system)
PRIUS c_U
■Notes about Mobile Assistant
● The available features and functions may vary based on the iOS version
installed on the connected device.
● Some Siri features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri will inform you that the function is not available.
● If Siri is not enabled on the cellular phone connected via Bluetooth
®, an
error message will be displayed on the screen.
● While a phone call is active, the Mobile Assistant cannot be us ed.
● If using the navigation feature of the cellular phone, ensure t he active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

373
6Interior features
PRIUS c_U6-1. U
sing the air
c onditioning system
and defogger
Automatic air conditioning system ........ 374
Seat heaters...................... 382
6-2. Using the interior lights Interior lights list ................ 383
• Interior lights ................. 384
• Personal lights .............. 384
6-3. U sing the storage
features
List of storage fea tures ..... 386
• Glove box...................... 387
• Console box .................. 387
• Auxiliary boxes.............. 388
• Cup holders .................. 389
• Bottle holders ................ 390
6-4. Other interior features Other interior features ....... 391
• Sun visors ..................... 391
• Vanity mirrors................ 391
• Power outlet .................. 392
• Coat hooks.................... 393
• Assist grips ................... 394
• Luggage cover .............. 395

374
PRIUS c_U
6-1. Using the air conditioning system and defogger
■Adjusting the temperature setting
To adjust the temperature setting, turn clockwise to
increase the temperature and turn counterclockwise to
decrease the temperature.
If is not pressed, the system will blow ambient temperature ai r or
heated air.
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls

3756-1. Using the air conditioning system and defogger
6
Interior features
PRIUS c_U■
Fan speed setting
To adjust the fan speed, press on to increase the fan
speed and to decr
ease the fan speed.
Press to turn the fan off.
■
Changing airflow modes
To change the airflow mode,
press .
The air outlets used are
switched each time the button is
pressed.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.
Press .
The air conditioning system begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature s et-
ting.
Adjust the temperature setting.
To stop the operation, press .
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
1
2
3
4
Using automatic mode
1
2
3

3766-1. Using the air conditioning system and defogger
PRIUS c_U■
Switching between outside air
and recirculated air modes
Press .
The mode switches between outside air mode (the indicator is of f) and
recirculated air mode (the indicator is on) each time the butto n is
pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically .)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the wind-
shield is defogged.
■
Defogging the rear window and outside rear view mirrors (if
equipped)
Defogger(s) are used to defog the rear window, and to remove ra in-
drops, dew and frost from the outside rear view mirrors (if
equipped).
Press .
The defogger(s) will automatically turn off after a period of t ime.
Other functions

3776-1. Using the air conditioning system and defogger
6
Interior features
PRIUS c_U■
Location of a
ir outlets
The air outlets and air volume
change according to the
selected airflow mode.
: Some models
■
Adjusting the position of and opening and closing the air out-
lets
Center outlets
Direct air flow to the left or right,
up or down.
Right and left side outlets (type A)
Direct air flow to the left or right,
up or down.
Air outlets

3786-1. Using the air conditioning system and defogger
PRIUS c_U
Open the vent
Close the vent
Right and left side outlets (type B)
Direct air flow to the left or right,
up or down.
Open the vent
Close the vent
1
2
1
2

3796-1. Using the air conditioning system and defogger
6
Interior features
PRIUS c_U
■Operation of the air conditioning system in Eco drive mode
In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:
● Engine speed and compressor operation controlled to restrict heating/cool-
ing capacity
● Fan speed restricted when automatic mode is selected
To improve air conditioning perf ormance, perform the following operations:
● Adjust the fan speed
● Turn off Eco drive mode
■ Using automatic mode
Fan speed is adjusted automatically according to the temperatur e setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the wind-
shield effectively.
● If you turn off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.

3806-1. Using the air conditioning system and defogger
PRIUS c_U■
Outside/recirculated air mode
●When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effec-
tive in preventing outside air from entering the vehicle interi or. During
cooling operation, setting the recirculated air mode will also cool the vehicle
interior effectively.
● Outside/recirculated air mode may automatically switch dependin g on the
temperature setting or the inside temperature.
■ When the outside temperature exceeds 75 F (24 C) and the air condition-
ing system is on
● In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
● Recirculated air mode is selected as a default mode when the power switch
is turned to the “ON” position (vehicles without a smart key system) or the
power switch is turned to ON mode (vehicles with a smart key system).
● It is possible to switch to outside air mode at any time by pre ssing .
■ When the outside tempera ture falls to nearly 32F (0 C)
The dehumidification function may not operate even when is pre ssed.
■ Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the out side air mode.
● During use, various odors from inside and outside the vehicle m ay enter into
and accumulate in the air conditioning system. This may then ca use odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to o utside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short peri od of time
immediately after the air conditioning system is started in aut omatic
mode.
■ Air conditioning filter
P. 447
■ Customization
Settings (e.g. A/C auto switch operation) can be changed.
(Customizable features: P. 559)
