TOYOTA PRIUS C 2019 Owners Manual (in English)

391
6
Interior features
PRIUS c_U
6-4. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
Slide the cover to open.
Other interior features
Sun visors
1
2
Vanity mirrors

3926-4. Other interior features
PRIUS c_U
Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power c onsumption of 120 W).
Open the lid.
■ The power outlet can be used when
Vehicles without a smart key system
The power switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The power switch is in ACCESSORY or ON mode.
Power outlet
NOTICE
● To avoid damaging the power outlet, close the power outlet lid when the
power outlet is not in use. Foreign objects or liquids that ent er the power
outlet may cause a short circuit.
● To prevent 12-volt battery discharge, do not use the power outl et longer
than necessary when the hybrid system is off.

3936-4. Other interior features
6
Interior features
PRIUS c_U
Coat hooks
WARNING
Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy , these items may become projectiles,
causing death or serious injury.

3946-4. Other interior features
PRIUS c_U
An assist grip installed on the ceil-
ing can be used to support your
body while sitting on the seat.
Assist grips
WARNING
Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.
NOTICE
Do not hang any heavy object or put a heavy load on the assist grip.

3956-4. Other interior features
6
Interior features
PRIUS c_U■
Removing the luggage cover
Unhook the cords.
Pull the luggage cover back-
ward to disengage the
anchors.
Remove the luggage cover.
Luggage cover (if equipped)
1
2
3

3966-4. Other interior features
PRIUS c_U■
Installing the luggage cover
Place the luggage cover on
the anchors.
Push the luggage cover until
a click sound is heard.
Hook the cords.
1
2
3

397
7Maintenance and care
PRIUS c_U7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 398
Cleaning and protecting the vehicle interior ........... 401
7-2. Maintenance Maintenance requirements ................... 407
General maintenance........ 410
Emission inspection and maintenance (I/M)
programs......................... 413
7-3. D o-it-yourself
m aintenance
Do-it-yourself service precautions ..................... 414
Hood ................................. 417
Positioning a floor jack ...... 419
Engine compartment ......... 420
12-volt battery ................... 429
Tires .................................. 433
Tire inflation pressure ....... 442
Wheels .............................. 445
Air conditioning filter.......... 447
Wireless remote control/ electronic key battery ...... 449
Checking and replacing fuses ................ 452
Light bulbs......................... 456

398
PRIUS c_U
7-1. Maintenance and care
●Working from top to bottom, liberally apply water to the vehicl e
body, wheel wells and underside of the vehicle to remove any di rt
and dust.
● Wash the vehicle body using a sponge or soft cloth, such as a
chamois.
● For hard-to-remove marks, use car wash soap and rinse thoroughl y
with water.
● Wipe away any water.
● Wax the vehicle when the wate rproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the v ehicle
body is cool.
■ Automatic car washes
●Fold the mirrors before washing the vehicle. Start washing from the front of
the vehicle. Make sure to extend the mirrors before driving.
● Brushes used in automatic car washes may scratch the vehicle su rface and
harm your vehicle's paint.
● In certain automatic car washes, the rear spoiler may interfere with machine
operation. This may prevent t he vehicle from being cleaned prop erly or
result in damage to the rear spoiler.
■ High pressure car washes
●Do not allow the nozzles of the car wash to come within close p roximity of
the windows.
● Before using the car wash, check that the fuel filler door on y our vehicle is
closed properly.
■ When using a car wash (vehicles with a smart key system)
If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock repeatedly. In that case, f ollow the fol-
lowing correction procedures to wash the vehicle:
● Place the electronic key in a location 6 ft. (2 m) or more away from the vehi-
cle. (Take care to ensure that the key is not stolen.)
● Set the electronic key to battery-saving mode to disable the sm art key sys-
tem. ( P. 140)
Cleaning and protecting the vehicle exterior
Perform the following to protect the vehicle and maintain it in
prime condition:

3997-1. Maintenance and care
7
Maintenance and care
PRIUS c_U■
Aluminum wheels (if equipped)
●Remove any dirt immediately by using a neutral detergent.
● Wash detergent off with water immediately after use.
● To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-
ing or parking in hot weather
■ Bumpers
Do not scrub with abrasive cleaners.
WARNING
■When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.
■ When cleaning the windshield
Installation area of front sensor on windshield:  P. 227
■ Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe unti l it has
cooled sufficiently, as touching a hot exhaust pipe can cause b urns.
NOTICE
■To prevent paint deterioration an d corrosion on the body and compo-
nents (aluminum wheels etc.)
● Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are presen t on the
paint surface
• After driving in an area contaminated with soot, oily smoke, mine dust, iron powder or chemical substances
• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the pai nt surface
● If the paint is chipped or scratched, have it repaired immediat ely.
● To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.

4007-1. Maintenance and care
PRIUS c_U
NOTICE
■Cleaning the exterior lights
● Wash carefully. Do not use organic substances or scrub with a h ard brush.
This may damage the surfaces of the lights.
● Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.
■ When using a high pressure car wash
● When washing the vehicle, do not spray the camera or its surrou nding
area directly with a high pressure washer. Shock applied from high pres-
sure water may cause the device to not operate normally.
● Do not bring the nozzle tip close to boots (rubber or resin man ufactured
cover), connectors or the following parts. The parts may be dam aged if
they come into contact with high-pressure water.
■ Roof molding (if equipped)
Do not hold or pull a roof molding when climbing onto the vehicle or shaking
the vehicle as the roof molding may become disengaged and water may
leak into the vehicle.
• Traction related parts
• Steering parts • Suspension parts
• Brake parts
