sensor TOYOTA PRIUS PRIME 2017 2.G Quick Reference Guide

26
PRIUS PRIME_QG_OM47B04U_(U)
3. Basic operation
Carry the electronic key to enable these functions.
■Front door handlesGrip the driver’s door handle
to unlock the door. Holding
the driver’s door handle for
approximately 2 seconds
unlocks all the doors.
Some models, grip the front
passenger’s door handle to
unlock all the doors
*.
Make sure to touch the sensor on the back of the handle.
The doors cannot be unlocked for 3 seconds after the doors are locked.
*: The door unlock settings can be changed. (Refer to “OWNER’SMANUAL”.)
Touch the lock sensor (the indentation on the surface of the front
door handle) to lock the doors.
Check that the door is securely locked.
■
Back door
Locks all the doors
Check that the door is securely
locked.
Unlocks all the doors
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
How to operate unlocking and locking the doors
1
2
1
2

PRIUS PRIME_QG_OM47B04U_(U)
333. Basic operation
3
Basic operation
■Rain-sensing windshield wipers
Ty p e AOff
Rain-sensing opera-
tion
Low speed operation
High speed operation
Temporary operation
Ty p e BOff
Rain-sensing operation
Low speed operation
High speed operation
Temporary operation
When “AUTO” is selected, the wipers will operate automatically when
the sensor detects falling rain. The system automatically adjusts wiper
timing in accordance with rain volume and vehicle speed.
1
2
3
4
5
1
2
3
4
5

34
PRIUS PRIME_QG_OM47B04U_(U)
3. Basic operation
The sensor sensitivity can be adjusted when “AUTO” is selected.Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
The wipers will automatically
operate a couple of times after
the washer squirts.
6
7
8
