TOYOTA RAV4 1997 Repair Manual

59
On the luggage compartment floor
a. Using the illustration as a guide, run your fingers across the luggage compart-
ment floor itself to locate the position of the bolts underneath. b. Remove the bolt.
c. Insert a 10 mm (0.4 in.) spacer and tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5-24.7 N
Vm (1.68-2.52 kgr-
V m, 12.2-18.2 ft Vlbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra- tion.
If your child restraint system does not pro-
vide any of the necessary parts, ask your
Toyota dealer. (See -Child restraint sys- temº.)
If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent entry of exhaust emissions, water
or dirt.
To change the steering wheel angle,
hold the steering wheel, push down
the lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
CAUTION!
Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,try moving it up and down to make sure it is locked in position.
Adjust the mirror so you can just see
the side of your vehicle in the mirror. Be careful when judging the size or dis- tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
Tilt steering wheel Outside rear view mirrorsÐ

59
On the luggage compartment floor
a. Using the illustration as a guide, run your fingers across the luggage compart-
ment floor itself to locate the position of the bolts underneath. b. Remove the bolt.
c. Insert a 10 mm (0.4 in.) spacer and tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5-24.7 N
Vm (1.68-2.52 kgr-
V m, 12.2-18.2 ft Vlbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra- tion.
If your child restraint system does not pro-
vide any of the necessary parts, ask your
Toyota dealer. (See -Child restraint sys- temº.)
If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent entry of exhaust emissions, water
or dirt.
To change the steering wheel angle,
hold the steering wheel, push down
the lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
CAUTION!
Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,try moving it up and down to make sure it is locked in position.
Adjust the mirror so you can just see
the side of your vehicle in the mirror. Be careful when judging the size or dis- tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
Tilt steering wheel Outside rear view mirrorsÐ

60
CAUTION!
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting inpersonal injuries.
To adjust a mirror, use the switches.
1. Master switchÐTo select the mirror to be adjusted Place the switch at Lº (left) or Rº (right)
2. Control switchÐTo move the mirror push the switch in the desired direc-tion.
If the engine is not running, the key must be in the ACCº position.
If ice should jam the mirror, do not operate the control or scrape the
mirror face. Use a spray de-icer to free the mirror.
NOTICE
ÐPower rear view mirror control

61
The rear view mirrors can be folded
backward for parking in restricted areas.
To fold the rear view mirror, push back- ward.
CAUTION!
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror. Daylight drivingÐLever at position 1
The reflection in the mirror has greater
clarity at this position. Night drivingÐLever at position 2 Remember that by reducing glare you
also lose some rear view clarity.
Anti-glare
inside rear view
mirror
ÐFolding rear view mirrors

Part 1Headlights and turn signals
63
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-4
Lights, Wipers and Defogger
Headlights and turn signals
Emergency flashers
Instrument panel light control
Interior light
Personal lights
Windshield wipers and washer
Rear window wiper and washer
Rear window defogger
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob. Position 1ÐParking, tail, license plate,
side marker and instrument panel lights Position 2ÐHeadlights and all of the above
If you remove the key with the headlights
left on, a buzzer reminds you to turn the
lights off
when you open the driver's door.
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when theengine is not running.
Daytime running light system (Canada only)
The headlights turn on when the parking brake is released with the engine started,
even with the light switch in the OFFº position. They will not go off until the igni-
tion switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
position 1.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the position 2 to turn
to full intensity for driving at night.

64
High-Low beamsÐFor high beams,
turn the headlights on and push the lever away from you (position 1). Pull the lever
toward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will tell
you that the high beams are on.
Flashing the high beam headlights
(position 3) ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights with knob turned to OFFº.TURN SIGNAL
To signal a turn, push the headlight/
turn signal lever up or down to posi-
tion 1. The key must be in the ONº position. The lever automatically returns after you make a turn, but you may have to return it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position 2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal bulb
is burned out. See Replacing light bulbsº
in chapter 7-3.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn other drivers if your vehicle must be
stopped where it might be a traf fic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat- ing. Emergency flashers

65
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when the engine is not running.
To adjust the brightness of the instru-
ment panel lights, turn the knob.To turn on the interior light, slide the switch.
The interior light has the following posi- tion:
ONºÐKeeps the light on all the time.
OFFºÐTurns the light off.DOORºÐ
2-door models: Turns the light on when the back door is opened. The light goes
off when the back door is closed.
4-door models: Turns the light on when either rear door or back door is opened.
The light goes off when both rear doors
and back door are closed.
Instrument panel light control
Interior light

66
To turn on the personal light, push the
switch. To turn the light off, slightly
push the switch on the opposite side.
The personal light switch has the following positions:
ONºÐKeeps the light on all the time.
DOORºÐTurns the light on when either
front door is opened. The light goes off
when both front doors are closed.The personal lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
The center switch has the following posi- tions: DOORºÐTurn both lights on when either
front door is opened. The light goes off
when both front doors are closed.
OFFºÐThe lights are off unless you op- erate either outer switch.To turn on the windshield wipers, move the lever to the desired setting. The key must be in the ONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
To squirt washer fluid, pull the lever to-
ward you and release it.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
Personal lights (without moon roof)
Windshield wipers and washer
Personal light (with moon roof)

67
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
In freezing weather, warm the windshield with the defroster before using the wash-
er. This will help prevent the washer fluid
from freezing on your windshield, which can block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the
glass.
To turn on the rear window wiper, twist
the lever knob upward. The key must be in the ONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Normal
To squirt washer fluid on the rear window, twist the knob upward or downward as far
as it will go (position 3 or 4). The knob au-
tomatically returns from these potions af-
ter you release it.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
NOTICE
Do not operate the wipers if the windshield is dry. It may sc ratch the
glass.
Rear window wiper and washer

68
To defog or defrost the rear window,
push the switch. The key must be in the ONº position.
The thin heater wires on the inside of the rear window will quickly clear the surface. An indicator light will illuminate to indicatethe defogger is operating. Push the switch once again to turn the de-
fogger off.
Make sure you turn the defogger off when
the window is clear. Leaving the defogger
on for a long time could cause the battery
to discharge, especially during stop-and-
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE
To prevent the battery from being
discharged, turn the switch on
when the engine is running.
When cleaning the inside of the
rear window, be careful not to
scratch or damage the heaterwires.
Rear window defogger
