TOYOTA RAV4 2001 Owners Manual

'01 Rav4_U (L/O 0008)
772001 RAV4 (OM42483U)
CAUTION
Do not extend the plate at the end of
the sun visor when the visor is in the
position 1. It can cover the anti±glare
inside rear view mirror and obstruct
the rear view.
ÐVanity mirrors
To use the vanity mirrors, swing down
the sun visor and open the cover.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
782001 RAV4 (OM42483U)
ProCarManuals.com

'01 Rav4_U (L/O 0008)
792001 RAV4 (OM42483U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers81 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights83 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wipers and washer84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defoggers85 . . . . . . . . . . . .
SECTION 1± 4
ProCarManuals.com

'01 Rav4_U (L/O 0008)
802001 RAV4 (OM42483U)
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1ÐParking, tail, license plate,
side marker and instrument panel lights
Position 2ÐHeadlights and all of the
above
Light reminder buzzer
A buzzer will remind you to turn the lights
off when the driver 's door is opened if you
remove the key with the headlight switch
on.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system
(on some models)
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the ªOFFº position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
to full intensity for driving at night.
High±Low beamsÐFor high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to ªOFFº.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
812001 RAV4 (OM42483U)
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the ªONº position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See ªReplacing light
bulbsº on page 236 in Section 7±3.
Emergency flashers
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
822001 RAV4 (OM42483U)
Instrument panel light control
To adjust the brightness of the instru-
ment panel lights, turn the knob.
Front fog lights
To turn on the front fog lights, twist
the band of the headlight and turn sig-
nal switch lever. They will come on
only when the headlights are on low
beam.
Interior lights
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
ªONºÐKeeps the light on all the time.
ªOFFºÐTurns the light off.
ªDOORºÐTurns the light on when any of
the side doors and back door are opened.
The light goes off when all the side doors
and back door are closed.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
832001 RAV4 (OM42483U)
ILLUMINATED ENTRY SYSTEM
(with power door lock system)
With the switch in ªDOORº position, the
light comes on when any of the side
doors and back door are opened. After all
the side doors and back door are closed,
the light remains on for about 15 seconds
and then fades out.
However, in the following cases, the light
fades out immediately:

All the side doors and back door are
closed when the ignition key is in
ªACCº or ªONº position.

All the side doors and back door are
locked when the light is still on.
When all the side doors and back door
are unlocked simultaneously with a key or
wireless remote control transmitter, the in-
terior light comes on for about 15 seconds
and then fades out, even if the door is
not opened.
INTERIOR LIGHT CUT OFF OPERATION
To prevent the battery being discharged,
the light will automatically turn off when
the ignition switch is in the ªLOCKº posi-
tion and the door is left opened with the
switch at ªDOORº position for 20 minutes
or more.
Personal lights
With moon roof
Without moon roof
To turn on the personal light, push the
switch. To turn the light off, push the
switch once again.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
842001 RAV4 (OM42483U)
Windshield wipers and washer
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ªONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
For a single sweep of the windshield,
push the lever up and release it.
To squirt washer fluid, pull the lever
toward you.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.For instructions on adding washer fluid,
see ªAdding washer fluidº on page 235 in
Section 7±3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Rear window wiper and washer
To turn on the rear window wiper, twist
the lever knob upward.
The key must be in the ªONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Normal
To squirt washer fluid on the rear window,
twist the knob upward or downward as far
as it will go (position 3 or 4). The knob
automatically returns from these positions
after you release it.
For instructions on adding washer fluid,
see ªAdding washer fluidº on page 235 in
Section 7±3.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
852001 RAV4 (OM42483U)
NOTICE
Do not operate the rear wiper if the
rear window is dry. It may scratch the
glass.
To defog or defrost the rear window,
push the switch.
The key must be in the ªONº position.
The thin heater wires on the inside of the
rear window will quickly clear the window
surface. An indicator light will illuminate to
indicate the defogger is operating.
On some models, the heater panels in the
outside rear view mirrors will also quickly
clear the surfaces.
Push the switch once again to turn the
defoggers off.
The system will automatically shut off af-
ter the defoggers have operated about 15
minutes.
CAUTION
Since the mirror surfaces can get hot,
keep your hands off them when the
defogger switch is on.
Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the battery to discharge, especially during
stop±and±go driving. The defoggers are
not designed for drying rain water or for
melting snow.
If the outside rear view mirrors are heavi-
ly coated with ice, use a spray de±icer
before operating the switch.
NOTICE
When cleaning the inside of the rear
window, be careful not to scratch or
damage the heater wires or connec-
tors.
Rear window and outside
rear view mirror defoggers
ProCarManuals.com

'01 Rav4_U (L/O 0008)
862001 RAV4 (OM42483U)
