TOYOTA RAV4 2001 Owners Manual

'01 Rav4_U (L/O 0008)
372001 RAV4 (OM42483U)
3. To unlock the seat, hold the upper
back of the seat with your hand and
pull the lock release strap up. Swing
the whole seat down and set the
rear legs to the hooks on the floor.
Make sure the rear legs are securely
set to the hooks by trying to pull up
the rear part of the seat.4. Pull the seatback release strap and
swing the seatback up.
CAUTION
When returning seats to their original
position:

Make sure the seat belts are not
twisted or caught under the seat
and are arranged in their proper
position and are ready to use.

Make sure the seat is securely
locked by pushing forward and rear-
ward on the top of the seatback or
by trying to pull up the edge of the
bottom cushion. Failure to do so
will prevent seat belt from operat-
ing properly.
When removing or reinstalling the
seat, observe the following to prevent
personal injury:

Do not fold or remove the seat
while the vehicle is moving.

Be careful not to get your hands or
feet pinched in the seat.

Be careful not to hit the removed
seat against a person or drop it on
yourself.

After folding or installing the seat,
push it forward and backward to
make sure it is locked in position.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
382001 RAV4 (OM42483U)
To prevent personal injury in a colli-
sion or sudden stop:

Do not sit on or place anything on
the folded seatback while driving.

Do not leave the removed seat
loose in the vehicle.

Do not try to sit on or place any-
thing on the removed seat.

When reinstalling the seat, be care-
ful not to hit the seat against you
or inside of the vehicle.

Install each seat in the same posi-
tion from which it was removed.
Failure to do so will prevent rear
seat occupants from using seat
belts properly.For flattening seatbacks, do the follow-
ing:
1. Hold the center of the lever and pull
it up. Then slide the rear seat fully
backward and pull it forward slightly
till it locks.2. Remove the head restraint. Hold the
center of the lever and pull it up.
Then slide the seat further forward
than the front±most lock position.
Flattening seatbacks
(front seat only)
ProCarManuals.com

'01 Rav4_U (L/O 0008)
392001 RAV4 (OM42483U)
3. Pull the seatback angle adjusting le-
ver to unlock and push down the
seatback.
When returning the seatback upright, be
careful not to make yourself hit by the
seatback which will bound with consid-
erable spring force.
After returning the seat to its original
position, be certain to replace the head
restraint.
CAUTION

Do not allow passengers to ride on
the flattened seat while driving; use
the seat in the normal position.

After putting back the seat, try
pushing the seat and seatback for-
ward and rearward to make sure it
is secured in place. Be certain to
replace head restraint.
Head restraints
For your safety and comfort, adjust the
head restraint before driving.
To raise: Pull it up.
To lower: Push it down while pressing the
lock release button.
The head restraint is most effective when
it is close to your head. Therefore, using
a cushion on the seatback is not recom-
mended.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
402001 RAV4 (OM42483U)
CAUTION

Adjust the center of the head re-
straint so that it is closest to the
top of your ears.

After adjusting the head restraint,
make sure it is locked in position.

Do not drive with the head re-
straints removed.
Toyota strongly urges that the driver and
passengers in the vehicle be properly re-
strained at all times with the seat belts
provided. Failure to do so could increase
the chance of injury and/or the severity of
injury in accidents.
Child. Use a child restraint system ap-
propriate for the child until the child be-
comes large enough to properly wear the
vehicle's seat belts. See ªChild restraintº
on page 57 for details.
If a child is too large for a child restraint
system, the child should sit in the rear
seat and must be restrained using the
vehicle's seat belt. According to accident
statistics, the child is safer when properly
restrained in the rear seat than in the
front seat.
If a child must sit in the front seat, the
seat belts should be worn properly. If an
accident occurs and seat belts are not
worn properly, the force of the rapid infla-
tion of the airbag may cause death or
serious injury to the child.Do not allow the child to stand up or
kneel on either rear or front seats. An
unrestrained child could suffer serious in-
jury or death during emergency braking or
a collision. Also, do not let the child sit
on your lap. It does not provide sufficient
restraint.
Pregnant woman. Toyota recommends the
use of a seat belt. Ask your doctor for
specific recommendations. The lap belt
should be worn securely and as low as
possible over the hips and not on the
waist.
Injured person. Toyota recommends the
use of a seat belt. Depending on the inju-
ry, first check with your doctor for specific
recommendations.
Seat beltsÐ
ÐSeat belt precautions
ProCarManuals.com

'01 Rav4_U (L/O 0008)
412001 RAV4 (OM42483U)
CAUTION
Persons should ride in their seats
properly wearing their seat belts
whenever the vehicle is moving.
Otherwise, they are much more likely
to suffer serious bodily injury or
death in the event of sudden braking
or a collision.
When using the seat belts, observe
the following:

Use the belt for only one person at
a time. Do not use a single belt for
two or more peopleÐeven children.

Avoid reclining the seatbacks too
much. The seat belts provide maxi-
mum protection when the seatbacks
are in the upright position. (Refer
to the seat adjustment instructions.)

Be careful not to damage the belt
webbing or hardware. Take care that
they do not get caught or pinched
in the seat or side doors.

Inspect the belt system periodically.
Check for cuts, fraying, and loose
parts. Damaged parts should be re-
placed. Do not disassemble or
modify the system.

Keep the belts clean and dry. If
they need cleaning, use a mild soap
solution or lukewarm water. Never
use bleach, dye, or abrasive clean-
ersÐthey may severely weaken the
belts. (See ªCleaning the interiorº
on page 205 in Section 5.)

Replace the belt assembly (includ-
ing bolts) if it has been used in a
severe impact. The entire assembly
should be replaced even if damage
is not obvious.
ÐFront and rear seat belts
Adjust the seat as needed and sit up
straight and well back in the seat. To
fasten your belt, pull it out of the re-
tractor and insert the tab into the
buckle.
You will hear a click when the tab locks
into the buckle.
The seat belt length automatically adjusts
to your size and the seat position.
The retractor will lock the belt during a
sudden stop or on impact. It also may
lock if you lean forward too quickly. A
slow, easy motion will allow the belt to
extend, and you can move around freely.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
422001 RAV4 (OM42483U)
If the seat belt cannot be pulled out of the
retractor, firmly pull the belt and release
it. You will then be able to smoothly pull
the belt out of the retractor.
When a passenger 's shoulder belt is com-
pletely extended and is then retracted
even slightly, the belt is locked in that
position and cannot be extended. This fea-
ture is used to hold the child restraint
system securely. (For details, see ªChild
restraintº on page 57 in this section.) To
free the belt again, fully retract the belt
and then pull the belt out once more.
CAUTION

After inserting the tab, make sure
the tab and buckle are locked and
that the belt is not twisted.

Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.

If the seat belt does not function
normally, immediately contact your
Toyota dealer. Do not use the seat
until the seat belt is fixed. It cannot
protect an adult occupant or your
child from injury.
Seat belts with an adjustable shoulder
anchorÐ
Adjust the shoulder anchor position to
your size.
To raise: Slide the anchor up.
To lower: Push in the lock release button
and slide the anchor down.
After adjustment, make sure the anchor is
locked in position.
CAUTION
Always make sure the shoulder belt
is positioned across the center of
your shoulder. The belt should be
kept away from your neck, but not
falling off your shoulder. Failure to
do so could reduce the amount of
protection in an accident and cause
serious injuries in a collision.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
432001 RAV4 (OM42483U)
Ta k e u p
slack
To o h i g h
Keep as low on
hips as possible
Adjust the position of the lap and
shoulder belts.
Position the lap belt as low as possible
on your hipsÐnot on your waist, then ad-
just it to a snug fit by pulling the shoulder
portion upward through the latch plate.
CAUTION

High±positioned lap belts and
loose±fitting belts both could cause
serious injuries due to sliding un-
der the lap belt during a collision
or other unintended result. Keep
the lap belt positioned as low on
hips as possible.

For your safety, do not place the
shoulder belt under your arm.
To release the belt, press the buckle±re-
lease button and allow the belt to re-
tract.
If the belt does not retract smoothly, pull
it out and check for kinks or twists. Then
make sure it remains untwisted as it re-
tracts.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
442001 RAV4 (OM42483U)
SEAT BELT FOR REAR CENTER SEAT
The rear center seat belt is a 3±point type
restraint with 2 buckles. Both seat belt
buckles must be correctly located and se-
curely latched for proper operation.
Make sure that buckle 1 (with light gray
buckle±release button) is securely latched
for ready use of the center seat belt.Two buckles and tabs for rear center
seat belt
The 2 buckles for the rear center seat
belt are distinguished with colors of the
buckle release button. Also the 2 tabs
have different shape for its end so that
the belt is not buckled in the wrong place.
Buckle 1 (with light gray buckle±re-
lease button)ÐProperly matches with
concave end tab
Buckle 2 (with red buckle±release but-
ton)ÐProperly matches with round end
tab
CAUTION
Make sure the both buckles are cor-
rectly located and securely latched.
Failure to properly match the buckle
and tab may cause severe injury in
case of an accident or a collision.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
452001 RAV4 (OM42483U)
To release the concave end tab, insert the
key into the hole on buckle 1 (with light
gray buckle±release button) and allow the
belt to retract.CAUTION
Do not use the rear center seat belt
with either buckle released. Fastening
only the shoulder belt or lap belt may
cause severe personal injury in case
of sudden braking or a collision.
STOWING THE REAR CENTER SEAT
BELT
1. To stow the rear center seat belt,
pull the seat belt out of its cover a
little and insert the concave end tab
into the higher slot of the cover.
ÐStowing the rear center
seat belt
ProCarManuals.com

'01 Rav4_U (L/O 0008)
462001 RAV4 (OM42483U)
2. Insert the round end tab into the
cover. You will hear a click when the
tabs are locked in the seat belt cov-
er. Make sure the tabs are securely
locked in the cover.
Seat belt must be stowed before you fold
the seatback. (See ªÐFolding up rear
seatsº on page 32 or ªÐRemoving rear
seatsº on page 35 in this section.)
NOTICE
Stow the rear center seat belt except
when you are wearing it.
PULLING OUT THE REAR CENTER SEAT
BELT
To use the rear center seat belt, pull
the belt out a little and then pull the
tabs out from the cover.
ÐSeat belt extender
If your seat belt cannot be fastened se-
curely because it is not long enough, a
personalized seat belt extender is avail-
able from your Toyota dealer free of
charge.
Please contact your local Toyota dealer so
that the dealer can order the proper re-
quired length for the extender. Bring the
heaviest coat you expect to wear for prop-
er measurement and selection of length.
Additional ordering information is available
at your Toyota dealer.
ProCarManuals.com
