This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed to
record data related to vehicle dynamics and safety systems for a short period
of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fas-tened;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a nontrivial crash situa-
tion occurs; no data are recorded by the EDR under normal driving conditions
and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
Event data recorder

12
RAV4_OM_OM42A78U_(U)
●Disclosure of the EDR data
Toyota will not disclose the data recorded in an EDR to a third party except
when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Toyota in a lawsuit
However, if necessary, Toyota may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota dealer
before you scrap your vehicle.
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
Scrapping of your Toyota
Perchlorate Material

RAV4_OM_OM42A78U_(U)
13
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■ General precaution regard ing children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof, or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.

14
RAV4_OM_OM42A78U_(U)
Reading this manual
CAUTION:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to
or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps
in numerical order.
Indicates the action (push-
ing, turning, etc.) used to
operate switches and other
devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not do
this”, or “Do not let this hap-
pen”.
123

15
RAV4_OM_OM42A78U_(U)
How to search
■Searching by name• Alphabetical index .......P. 717
■Searching by installation
position• Pictorial index ................P. 16
■Searching by symptom or
sound• What to do if...
(Troubleshooting) ........P. 712
■Searching by title• Table of contents .............P. 2

16Pictorial index
RAV4_OM_OM42A78U_(U)
Pictorial index
■Exterior
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 119
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 100, 113
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . P. 155
Locking/unlocking by using the mechanical key
* . . . . . . . . . . P. 646
Warning lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 615
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 124
Opening from inside the cabin . . . . . . . . . . . . . . . . . . . . . . . . . P. 124
Opening from outside. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 100, 113
Warning lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 615
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
Driving position memory
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 142
Defogging the mirrors
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 316
1
2
3

17Pictorial index
RAV4_OM_OM42A78U_(U)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 229
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 287
To prevent freezing (windshield wiper de-icer)
*. . . . . . . . . . . . P. 318
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 662
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 551
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 669
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 287
Checking/rotation/tire pressure warning system
*. . . . . . . . P. 551
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 627
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 533
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 533
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 663
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 653
Camera
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 259
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 217
Parking lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Fog lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Turn signal lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
4
5
6
7
8
Light bulbs of the exterior lights for driving
(Replacing method: P. 584, Watts: P. 670)
*: If equipped
9
10
11
12
13
14
15
16
17

18Pictorial index
RAV4_OM_OM42A78U_(U)
■Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 197, 200
Starting the engine/changing the modes . . . . . . . . . . . . . P. 197, 201
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . P. 601
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . P. 643
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 603
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . P. 645
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 85
Reading the meters/adjusting the instrument panel light . . . . . . P. 85
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 80
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 611
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 87
Parking brake lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 2881
2
3
4
5

19Pictorial index
RAV4_OM_OM42A78U_(U)Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Headlights/parking lights/tail lights/daytime running lights . . . . P. 217
Fog lights
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . P. 229
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 229
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 550
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 615
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 533
Manual air conditioning system
*1 . . . . . . . . . . . . . . . . . . . . P. 300
Automatic air conditioning system
*1 . . . . . . . . . . . . . . . . . P. 306
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 300, 306
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 316
Audio system
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 319
Entune Audio
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 319, 387
Entune Audio Plus/Entune Premium Audio
with Navigation
*1, 2
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 504
Power back door main switch
*1. . . . . . . . . . . . . . . . . . . . . . P. 126
Fuel filler door opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 239
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
6
7
8
9
10
11
12
13

20Pictorial index
RAV4_OM_OM42A78U_(U)
■Switches
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . P. 153
Instrument panel light control dial . . . . . . . . . . . . . . . . . . . . . P. 86
VSC OFF switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 273
BSM (Blind Spot Monitor) main switch
*1 . . . . . . . . . . . . . . P. 277
All-wheel drive lock switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . P. 270
Power back door switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . P. 124
Driving position memory switches
*1. . . . . . . . . . . . . . . . . . P. 142
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 155
Door lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 120
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 155
Tire pressure warning reset switch
*1 . . . . . . . . . . . . . . . . . P. 554
1
2
3
4
5
6
7
8
9
10
11
