TOYOTA RAV4 2019 Accessories, Audio & Navigation (in English)

1013-4. Setup
3
Navigation system
1Select “Phone #”.
2 Enter the phone number and
select “OK”.
1 Select “Icon”.
2 Select the desired icon.
 “Page 1”/“Page 2”: Select to
change pages.
“With Sound”: Select the desired
icons with sound
■When “With Sound” is
selected
A sound for some favorites list
entries can be set. When the
vehicle approaches the location
of the favorites list entry, the
selected sound will be heard.
1 Select “With Sound”.
2 Select the desired sound
icon.
: Select to play the sound.
●When “Bell (with Direction)” is
selected, select an arrow to adjust
the direction and select “OK”.
●The bell sounds only when the
vehicle approaches this point in
the direction th at has been set.
1Select “Delete”.
2 Select the desired item to be
deleted.
“Sort/Delete All”: Select to sort
(date, name, icon) or delete all
favorite list entries.
3Select “Yes” when the confir-
mation screen appears.
Areas to be avoided because of
traffic jams, construction work or
other reasons can be registered
as “Areas to Avoid”.
1 Display the navigation set-
tings screen. ( P.98)
2 Select “Areas to Avoid”.
3 Select the desired item.
Select to register areas to
avoid. ( P.102)
Select to edit areas to avoid.
( P.102)
Select to delete areas to
avoid. ( P.103)
Changing phone number
Changing the icon
Deleting favorites list
entries
Setting up areas to avoid
A
B
C

1023-4. Setup
1Select “New”.
2 Select the desired item to
search for the location.
( P. 8 0 )
3 Select either or to
change the size of the area to
be avoided and select “OK”.
4 Select “OK” when the area to
avoid screen appears.
●If a destination is entered in the
area to avoid or th e route calcula-
tion cannot be made without run-
ning through the a rea to avoid, a
route passing through the area to
be avoided may be shown.
●Up to 10 locations can be regis-
tered as points/areas to avoid.
The name, location and/or area
size of a registered area can be
edited.
1 Select “Edit”.
2 Select the desired area. 3
Select the desired item to be
edited.
Select to edit the name of the
area to avoid. ( P.102)
Select to set display of the
area to avoid name on/off.
Select to edit area location.
( P.102)
Select to edit area size.
( P.102)
Select to set the area to
avoid function on/off.
4 Select “OK”.
1 Select “Name”.
2 Enter a name and select
“OK”.
1 Select “Location”.
2 Scroll the map to the desired
point ( P.72) and select
“OK”.
1 Select “Size”.
Registering areas to avoid
Editing areas to avoid
Changing the name
Changing the location
Changing the area size
A
B
C
D
E

1033-4. Setup
3
Navigation system
2Select either or to
change the size of the area to
be avoided and select “OK”.
1 Select “Delete”.
2 Select the desired area to be
deleted.
3 Select “Yes” when the confir-
mation screen appears.
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Detailed Navi. Set-
tings”.
5 Select the desired items to
be set.
Deleting areas to avoidDetailed navigation
settings
Settings are available for
pop-up information, favor-
ite POI categories, low fuel
warning, etc.
Displaying the detailed
navigation settings
screen

1043-4. Setup
“Low Fuel Warning Pop-up”
Select to set display of low fuel
warning on/off. ( P.105)
 “Unverified Roads Guidance
Warning”
Select to set unverified roads guid-
ance warning on/off.
“Guidance on Unverified
Roads”
Select to set IPD road (roads that
are not completely digitized in our
database) guidance on/off.
“Guidance with Street Names”
Select to set the voice guidance for
the next street name on/off.
“Favorite POI Categories”
Select to set favorite POI catego-
ries that are used for POI selection
to display on the map screen.
(  P.105)
 “Calibration”
Select to adjust the current position
mark manually or to adjust miscal-
culation of the di stance caused by
tire replacement. ( P.105)
 “Adaptive Route”
Select to enable/d isable adaptive
routes. When enabled, the naviga-
tion system will provide frequently
used routes.
 “Reset Adaptive Route”
Select to erase adaptive route data.
“Automatic Destination List
Info”
Select to set automatic destination
list information on/off. When set to
on, the estimated time of arrival to
the registered ho me and preset
destinations from the current posi-
tion will be displayed.
 “Intersection Zoom Map”
Select to set display of a guidance
screen on/off.
“Automatic Zoom”
Select to set automatic zoom func-
tion on/off. When it is enabled, as
the vehicle approaches a guidance
point, the map will change to a
detailed map automatically.
 “State Border Guidance”
Select to set cross-border guidance
on/off.
“Map Color Customization”
Select to set the map display color.
“Map Animation”
Select to set map animation on/off.
“Dynamic Route”*1
Select to enable/disable routes
sourced from the Toyota Entune
center. ( P.90)
 “Predictive Efficient Drive”*1, 2
Select to set predictive efficient
drive on/off. ( P.106)
 “Restore the default settings”
Select to reset all setup items.
*1: This function is not made avail-
able in some countries or areas.
*2: Vehicles with hybrid system
Detailed navigation set-
tings screen

1053-4. Setup
3
Navigation system
When the fuel level is low, a
warning message will pop up on
the screen.
1Display the detailed naviga-
tion settings screen.
( P.103)
2 Select “Low Fuel Warning
Pop-up”.
3 Select “On” or “Off”.
A nearby gas station can be
selected as a destination when
the fuel level is low.
1 Select “Yes” when the low
fuel warning appears.
2 Select the desired nearby
gas station.
3 Select “Enter” to set as a
destination.
“Info”: Select to display gas station
information. ( P. 7 6 )
Up to 6 POI icons, which are
used for selecting POIs on the
map screen, can be selected as
favorites.
1 Display the detailed naviga-
tion settings screen.
( P.103)
2 Select “Favorite POI Catego-
ries”. 3
Select the desired category
to be changed.
“Default”: Select to set the default
categories.
4 Select the desired POI cate-
gory.
“List All Categories”: Select to dis-
play all POI categories.
5Select the desired POI icon.
6 Select “OK”.
The current position mark can
be adjusted manually. Miscalcu-
lation of the distance caused by
tire replacement can also be
adjusted.
1 Display the detailed naviga-
tion settings screen.
( P.103)
2 Select “Calibration”.
3 Select the desired item.
 For additional information on
the accuracy of a current
position: P. 1 1 2
Low fuel warning
Searching gas station in low
fuel warning
Favorite POI categories
(Select POI icons)
Current position/Tire
change calibration

1063-4. Setup
When driving, the current posi-
tion mark will be automatically
corrected by GPS signals. If
GPS reception is poor due to
location, the current position
mark can be adjusted manually.
1Select “Position/Direction”.
2 Scroll the map to the desired
point ( P.71) and select
“OK”.
3 Select an arrow to adjust the
direction of the current posi-
tion mark and select “OK”.
The tire change calibration func-
tion will be used when replacing
the tires. This function will adjust
miscalculation caused by the
circumference difference
between the old and new tires.
1 Select “Tire Change”.
 The message appears and
the quick distance calibration
starts automatically.
●If this procedure is not performed
when the tires are replaced, the
current position mark may be
incorrectly displayed.
*1: Vehicles with hybrid system
*2: This function does not operate outside the cont
iguous United
States (Example: Alaska and
Hawaii).
The system automatically stores
and registers support points
where the driver always deceler-
ates or stops based on pedal
operation and the vehicle speed
of the driver.
The registered points are shown
on the map as icons for use
as predictive deceleration sup-
port points.
After releasing the accelerator
pedal, the engine brake (regen-
eration brake) amount
increases. (regeneration boost
control)
As a result, the battery charge
amount can be increased when
decelerating or stopping the
vehicle contributing to improved
actual fuel economy.
 The predictive efficient drive
function can be turned on/off.
( P.103)
The system reads the road and
traffic conditions ahead to opti-
mally control the charging and
discharging of the hybrid battery
according to the actual driving
situation. As a result, actual fuel
Position/Direction calibra-
tion
Tire change calibration
Predictive efficient drive
*1,
2
Predictive deceleration sup-
port
Predictive SOC control

1073-4. Setup
3
Navigation system
economy can be improved.
The capacity of the hybrid bat-
tery is limited. When it is fully
charged, regeneration cannot
occur, and when the battery is
depleted, it may be forcibly
charged by the engine. The sys-
tem predicts these situations to
adjust the battery charge level in
advance, effectively utilizing the
battery.
●The system operates when start-
ing route guidance and the posi-
tion of the vehicle is along the
guided route. (The system does
not operate in parking lots, etc.)
●When multiple destinations are
set, the system will continue to
operate to the last destination.
*: This function is not made avail-
able in some countries or areas.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Traffic”.
4 Select the desired items to
be set.
Traffic settings*
Traffic information such as
traffic congestion or traffic
incident warnings can be
made available.
Displaying the traffic set-
tings screen
Screen for traffic settings

1083-4. Setup
Select to set specific routes
(such as frequently used
routes) on which you wish to
receive traffic information.
(P.108)
Select to set the avoid traffic
function auto/manual.
( P.110)
Select to set the usage of
traffic information for the esti-
mated arrival time on/off.
Select to set the display of an
arrow of free flowing traffic
on/off.
Select to set to on/off
whether to consider the pre-
dictive traffic information
( P.78) with estimated
arrival time and detoured
route search.
Select to set traffic incident
voice warning on/off.
Select to reset all setup
items.
Specific routes (such as fre-
quently used routes) on which
you wish to receive traffic infor- mation can be registered as “My
Traffic Routes”. A route is set by
defining a start point and end
point, and can be adjusted by
setting up to 2 preferred roads.
1
Display the traffic settings
screen. ( P.107)
2 Select “My Traffic Routes”.
3 Select the desired item.
Select to register personal
traffic routes. ( P.108)
Select to edit personal traffic
routes. ( P.109)
Select to delete personal traf-
fic routes. ( P.109)
1 Select “New”.
2 Select “Name”.
3 Enter the name and select
“OK”.
4 Select “Start”.
5 Select the desired item to
search for the location.
( P.80)
6 Select “End”.
My traffic routesA
B
C
D
E
F
G
5HJLVWHULQJSHUVRQDOWUDIILF
URXWHV
A
B
C

1093-4. Setup
3
Navigation system
7Select the desired item to
search for the location.
( P. 8 0 )
8 Select “OK”.
9 Confirm the route overview
displayed.
Select the desired route from
3 possible routes. ( P. 8 8 )
Select to modify the route.
The routes can be adjusted
by setting preferred roads.
( P.109)
10 Select “OK”.
●Up to 5 routes can be registered.
1Select “Edit”.
2 Select the desired traffic
route. 3
Select the desired item to be
edited.
Select to edit the name of the
personal traffic route.
( P.108)
Select to edit start location.
( P.108)
Select to edit end location.
( P.108)
Select to see and modify the
entire route. ( P.109)
4 Select “OK”.
5 Follow the steps in “Register-
ing personal traffic routes”
from step 9. (  P.108)
1 Select “Delete”.
2 Select the desired traffic
route to be deleted and
select “Delete”.
3 Select “Yes” when the confir-
mation screen appears.
“My Traffic Routes” can be
adjusted by setting up to 2 pre-
Editing personal traffic
routes
A
B
'HOHWLQJSHUVRQDOWUDIILF
URXWHV
6HWWLQJSUHIHUUHGUR\
DGV
A
B
C
D

1103-4. Setup
ferred roads.
1Select “Set Preferred
Roads”.
2 Select the desired item.
Select to add preferred
roads. ( P.110)
Select to modify preferred
roads. ( P.110)
Select to delete preferred
roads. ( P.110)
■Adding preferred roads
1 Select “Add”.
2 Scroll the map to the desired
point ( P.71) and select
“OK”.
3 Select “OK” to use this road.
“Next”: Select to change road.
Available only when 1 pre-
ferred road is set
4 Select “Add Here” for the
desired location. 
If a preferred road is already
set, a second preferred road
can be added anywhere
between the start point, the
end point and the existing
preferred road.
■Modifying preferred roads
1 Select “Modify”.
2 Select the desired preferred
road to be modified if 2 pre-
ferred roads have been set.
3 Scroll the map to the desired
point ( P.71) and select
“OK”.
4 Select “OK” to use this road.
“Next”: Select to change road.
■Deleting preferred roads
1 Select “Delete”.
2 Select the desired preferred
road to be deleted if 2 pre-
ferred roads have been set.
“Delete All”: Select to delete all pre-
ferred roads on the list.
3Select “Yes” when the confir-
mation screen appears.
1 Display the traffic settings
screen. ( P.107)
2 Select “Avoid Traffic”.
A
B
C
Avoid traffic
