clock setting TOYOTA RAV4 2021 Owners Manual (in English)
[x] Cancel search | Manufacturer: TOYOTA, Model Year: 2021, Model line: RAV4, Model: TOYOTA RAV4 2021Pages: 748, PDF Size: 30.79 MB
Page 381 of 748

3815-1. Basic function
5
Audio
Press the “MENU” button to display the “Menu” screen.
Displays the clock. Select to display the clock settings screen.
( P.419)
Select to display the audio control screen. ( P.424)
Select to display the hands-free operation screen. ( P.471)
• When an Apple CarPlay connection is established, select to display the
Phone application screen.
*1
Select to display the Toyota Apps screen.*1, 2 ( P.510)
When an Apple CarPlay/Android Auto connection is established
and this button displays “Apple CarPlay”/“Android Auto”, select to
display the home screen of Apple CarPlay/Android Auto.
*1
( P.411)
Select to display the fuel consumption screen. ( P.99)
Select to display the “Setup” screen. ( P.384)
Select to adjust the contrast, brightness, etc. of the display.
( P.392)
*1: This function is not made available in some countries or areas .
*2: When an Apple CarPlay/Android Auto connection is established, this
function will be unavailable.
Menu screen
Menu screen operation
A
B
C
D
E
F
G
H
Page 418 of 748

4185-5. Other settings
5-5.Other settings
1Press the “MENU” button.
2 Select “Setup”.
If the general settings screen
is not displayed, select “Gen-
eral”.
3 Select the desired items to
be set.
“Clock”
Select to change the time zone and
select “On” or “Off” for daylight sav-
ing time, automatic adjustment of the clock, etc. (
P.419)
“Language”
Select to change the language. The
language setting of Apple Car-
Play/Android Auto can only be
changed on the connected device.
“Customize Home Screen”
Select to change the display infor-
mation/area on the home screen
and the home screen layout.
( P.388)
“Projection Settings”*1
Select to set automatic Apple Car-
Play/Android Auto connection
establishment on/off. ( P.420)
“Beep”
Select to turn the beep sound
on/off.
“Theme Setting”
Select to change the screen theme
setting.
“Units of Measurement”
Select to change the unit of mea-
sure for distance/fuel consumption.
“Keyboard Layout”
Select to change the keyboard lay-
out.
“Delete Keyboard History”
Select to delete the keyboard his-
tory.
“Memorize Keyboard History”
Select to set the memorize key-
board history on/off.
“Animation”
Select to turn the animations on/off.
“Driver Setting”
General settings
Settings are available for
clock, operation sounds,
etc.
Displaying the general
settings screen
General settings screen
Page 419 of 748

4195-5. Other settings
5
Audio
Select to change the driver set-
tings. ( P.420)
“Delete Personal Data”
Select to delete personal data.
( P.421)
“Software Update”
Select to update software versions.
For details, contact your Toyota
dealer.
“Software Update Setting”*2
Select to set software update set-
ting. ( P.421)
“Gracenote Database
Update”
Select to update Gracenote® data-
base versions. For details, contact
your Toyota dealer.
“Software Information”
Select to display the software infor-
mation. Notices related to third
party software used in this product
are enlisted. (This includes instruc-
tions for obtaining such software,
where applicable.)
“SW Sensitivity Level”
Select to change the capacitive
touch screen button sensitivity to 1
(low), 2 (medium), or 3 (high).
*1: This function is not made avail- able in some countries or areas.
*2: Vehicles equipped with DCM
1 Display the general settings
screen. ( P.418)
2 Select “Clock”. 3
Select the desired items to
be set.
Select to change the time
zone. ( P.419)
Select to set daylight saving
time on/off.
Select to set automatic
adjustment of the clock by
GPS on/off.
When set to off, the clock can
be manually adjusted.
( P.419)
Select to set the 24 hour time
format on/off.
When set to off, the clock is
displayed in 12 hour time for-
mat.
1 Select “Time Zone”.
2 Select the desired time zone.
When “Auto Adjust by GPS” is
turned off, the clock can be
manually adjusted.
1 Select “Auto Adjust by GPS”
to set to off.
Clock settings
Setting the time zone
Manual clock setting
A
B
C
D
Page 420 of 748

4205-5. Other settings
2Adjust the clock manually.
Select “+” to set the time for-
ward one hour and “-” to set
the time back one hour.
Select “+” to set the time for-
ward one minute and “-” to
set the time back one minute.
Select to round to the nearest
hour.
e.g.
1:00 to 1:29 1:00
1:30 to 1:59 2:00
*: This function is not made avail-
able in some countries or areas.
1 Display the general settings
screen. ( P.418)
2 Select “Projection Settings”.
3 Select the desired items to
be set. Select to turn Apple CarPlay
connection establishment
on/off.
Select to turn Android Auto
connection establishment
on/off.
●When the settings are changed
with a device connected to the
system via USB, disconnect the
device and connect it again to
enable the settings.
The driver settings feature will
allow the system to link some
preferences (such as audio pre-
sets, screen theme, language,
etc.) to a paired Bluetooth
®
phone.
1 Display the general settings
screen. ( P.418)
2 Select “Driver Setting”.
3 Select “Enable This Feature”.
1 Select “Manually Select
Linked Settings”.
Projection settings
*
A
B
C
' U L Y H U V H W W L Q J V
0 D Q X D O O \ V H O H F W O L Q N H G V H W
W L Q J V
A
B
Page 516 of 748

5166-1. Using the air conditioning system and defogger
6-1.Using the air conditioning system and defogger
*: If equipped
Fan speed control switch
Temperature control switch
On/off switch
Windshield defogger switch
Rear window defogger and outside rear view mirror defoggers
*
switch
Airflow mode control switch
Outside/recirculated air mode switch
“A/C” switch
“MAX A/C” switch
*: If equipped
■Adjusting the temperature
setting
To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).
If “A/C” switch is not pressed, the
system will blow a mbient tempera-
ture air or heated air.
■Fan speed setting
To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).
Pressing the on/off switch turns off
the fan.
When the fan is off, pressing the
on/off switch or turning the fan
speed control switch will turn on the
Manual air condi tioning system*
Air conditioning controls
A
B
C
D
E
F
G
H
I
Page 522 of 748

5226-1. Using the air conditioning system and defogger
Automatic mode switch
Left-hand side temperature control knob
Right-hand side temperature control knob
“SYNC” switch
“OFF” switch
Windshield defogger switch
Rear window defogger and outside rear view mirror defoggers
switch
Eco air conditioning mode switch
Fan speed decrease switch
Fan speed increase switch
Airflow mode control switch
Outside/recirculated air mode switch
S-FLOW mode switch
“A/C” switch
■Adjusting the temperature
setting
Turn driver’s side temperature control dial clockwise to
increases the temperature and
turn the dial counterclockwise to
Automatic air co
nditioning system
Air outlets and fan speed are automatically adjusted accord-
ing to the temperature setting.
Air conditioning controls
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Page 736 of 748

736Alphabetical Index
Warning messages .............. 249
Language (multi-information dis- play) ................................. 96, 701
LATCH anchors ........................ 59
Lever Auxiliary catch lever ............. 579
Hood lock release lever........ 579
Shift lever ............................. 201
Turn signal lever................... 204
Wiper lever ................... 218, 221
License plate lights Light switch .......................... 211
Replacing light bulbs ............ 619
Light bulbs Replacing ............................. 619
Wattage ................................ 682
Lights Automatic High Beam system........................................... 214
Fog light switch .................... 217
Front interior lights ............... 532
Headlight switch ................... 211
Interior lights......................... 532
Personal lights...................... 533
Rear interior light .................. 533
Replacing light bulbs ............ 619
Turn signal lever................... 204
Vanity lights .......................... 544
Wattage ................................ 682
Linking multi-information display and the system ..................... 393
Lock steering column ............ 197
LTA (Lane Tracing Assist) ..... 240 Operation ............................. 240
Warning messages .............. 249
Luggage compartment light................................ 118, 121Wattage ................................ 682
Luggage cover........ ................ 541
M
Maintenance Do-it-yourself maintenance ..577
General maintenance ...........573
Maintenance data .................676
Maintenance requirements ...572
Malfunction indicator lamp ....639
Manual air conditioning system ...............................................516Air conditioning filter .............608
Menu icons ................................90
Menu screen............................381 Menu screen operation.........381
Meter Clock ................................82, 85
Indicators ................................76
Instrument panel light control.............................84, 88
Meter control switches............90
Meters ..............................82, 85
Multi-information display.........89
Settings ..........................94, 701
Units ...............................96, 701
Warning lights.......................638
Warning messages .........98, 649
Meter control switches.............90
Microphone ........... ..................474
Mirrors Digital Rear-view Mirror ........147
Inside rear view mirror ..........145
Outside rear view mirror defog-gers ............................517, 524
Outside rear view mirrors .....156
Vanity mirrors ..... ..................544
Mobile Assistant .....................469 Connectable devices and avail-able functions .....................469
Mobile Assistant operation ...469
Moon roof Door lock linked moon roof oper-ation....................................161
Jam protection function ........161
Operation..............................161
Warning message . ...............162
