engine coolant TOYOTA RAV4 2022 Owner's Manual

6649-1. Specifications
*: The coolant capacity is the quantity of reference.If replacement is necessary, contact y our Toyota dealer.
Cooling system
Capacity*
Without engine oil
cooler7.3 qt. (6.9 L, 6.1 Imp. qt.)
With engine oil
cooler7.4 qt. (7.0 L, 6.2 Imp. qt.)
Coolant type
Use either of the following:
“Toyota Super Long Life Coolant”
 Similar high-quality ethylene gly-
col-based non-silicate, non-amine,
non-nitrite, and non-borate cool-
ant with long-life hybrid organic
acid technology
Do not use plain water alone.
Ignition system (spark plug)
MakeDENSO FC16HR-Q8
Gap0.031 in. (0.8 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark pl ug gap.
Electrical system (battery)
Specific voltage reading at
68°F (20°C):
12.3 V or higher
(Turn the engine switch to OFF and turn
on the high beam headlights for 30 sec-
onds.)
If the voltage is lower than the standard
value, charge the battery.
Charging ratesQuick charge15 A max.
Slow charge5 A max.

6789-1. Specifications
■Temperature A, B, C
The temperature grades are A
(the highest), B, and C, repre-
senting the tire’s resistance to
the generation of heat and its
ability to dissipate heat when
tested under controlled condi-
tions on a specified indoor labo-
ratory test wheel.
Sustained high temperature can
cause the material of the tire to
degenerate and reduce tire life, and
excessive temperature can lead to
sudden tire failure.
Grade C corresponds to a level of performance which all passenger
car tires must meet under the Fed-
eral Motor Vehicle Safety Standard
No. 109.
Grades B and A represent higher
levels of performance on the labo-
ratory test wheel than the minimum
required by law.
Warning: The temperature grades
of a tire assume tha
t it is properly
inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can cause
heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked
for three hours or more, or has not been driven
more than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a
tire may be inflated, shown on the sidewall of
the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of transmis-
sion, power steering, power brakes, power
windows, power seats, radio and heater, to the
extent that these items are available as factory-
installed equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including th e maximum capacity of
fuel, oil and coolant, and if so equipped, air con-
ditioning and additional weight optional engine

Alphabetical Index717
88
BSM (Blind Spot Monitor) ...... 259 Blind Spot Monitor function .. 263
Rear Cross Traffic Alert function........................................... 266
C
Care Aluminum wheels ................. 556
Exterior ................................. 556
Interior .................................. 559
Seat belts ............................. 559
Cargo capacity ............... 173, 176
Cargo hooks ........................... 531
Chains ..................................... 364
Child-protectors ..................... 112
Child restraint s ystem ............. 52
Fixed with a LATCH system ... 61
Fixed with a seat belt ............. 56
Front passenger occupant clas- sification system ................... 45
Points to remember ................ 52
Riding with children ................ 51
Types of child restraint system installation met hod ............... 54
Using an anchor bracket ........ 63
Child safety ............................... 51 Airbag precautions ................. 40
Back door precautions ......... 113
Battery precautions ...... 577, 653
Child restraint system............. 54
Heated steering wheel and seat
heater precautions ............. 521
How your child should wear the seat belt................................ 32
Moon roof precau tions ......... 159
Panoramic moon roof precau- tions.................................... 163
Power window lock switch.... 157
Power window precautions .. 156
Rear door child-protectors.... 112
Seat belt extender precautions .............................................32
Seat belt precautions..............31
Seat heater precautions .......521
Cleaning ..........................556, 559 Aluminum wheels .................556
Exterior .................................556
Interior ..................................559
Radar sensor ........................223
Seat belts .............................559
Clock ....................................84, 88
Coat hooks ..............................545
Condenser ............. ..................575
Connected Service s ...............493
Console box ............................528
Consumption screen ................99
Convenience Services (Sugges- tion function)...........................98
Coolant Checking ..............................574
Preparing and checking before winter ..................................362
Warning light ........................623
Cooling system .......................574 Engine overheating ..............654
Cruise control (Dynamic radar cruise control with full-speed
range).....................................248
Cup holders.............................528
Current fuel consumption........99
Current fuel economy ..............91
Curtain shield airbags ..............35
Customizable featu res ...........684
D
Daytime running light system208
Replacing light bulbs ............604
DCM .................494, 496, 497, 500
Deck board ..............................531
Defogger Outside rear view mirrors ...509, 516
Rear window.................509, 516

Alphabetical Index719
Operation ............................. 161
Emergency, in case of If a warning buzzer sounds .. 622
If a warning light turns on ..... 622
If a warning message is dis-played................................. 633
If the electronic key does not operate properly ................. 648
If the engin e will not start ..... 646
If the vehicle battery is dis- charged .............................. 650
If the vehicle is submerged or water on the road is rising .. 613
If you have a flat tire ............. 637
If you lose your keys ............ 648
If you think something is wrong ........................................... 620
If your vehicle becomes stuck ........................................... 656
If your vehicle has to be stopped in an emergency................. 612
If your vehicle needs to be towed ........................................... 615
If your vehicle overheats ...... 654
Emergency flashers ............... 612
Engine ACC.............................. 191, 195
Compartment ....................... 572
Engine switch ............... 191, 192
Fuel pump shut off system ... 621
Hood..................................... 569
How to start the engine 191, 192
Identification number ............ 662
If the engin e will not start ..... 646
If your vehicle has to be stopped in an emergency................. 612
Ignition switch (Engine switch) ................................... 191, 192
Overheating.......................... 654
Tachometer ...................... 82, 85
Engine coolant Capacity ............................... 664 Checking ..............................574
Preparing and checking before
winter ..................................362
Warning light ........................623
Engine coolant temperature gauge .................................82, 85
Engine immobilizer system .....71
Engine oil Capacity ...............................662
Checking ..............................572
Preparing and checking before winter ..................................362
Warning light ........................623
Engine switch .................191, 192 Auto power off fun ction.........195
Changing the engine switch modes.................................195
Changing the engine switch positions .............................191
If your vehicle has to be stopped in an emergency .................612
Enhanced Vehicle Stability Con- trol (Enhanced VSC ) .............356
Enhanced VSC (Enhanced Vehi- cle Stability Control).............356
Entering letters and numbers/list screen operation...................381Entering letters and numbers381
List screen ............................382
EPS (Electric Po wer Steering)
Function................................356
Warning light ........................624
Establishing an Android Auto connection .......... ..................404
Establishing an Apple CarPlay connection .......... ..................403
Event data recorder (EDR) .......10
F
Flat tire.....................................637 Tire pressure warning system...........................................582

Alphabetical Index729
Driving precautions .............. 296
Estimated course line display mode .................................. 299
Parking assist gui de line display
mode .................................. 300
Screen display...................... 297
Things you should know....... 306
Toyota parking assist monitor precautions......................... 302
Using the system.................. 298
Toyota Safety Sen se 2.0 ........ 222
Automatic High Beam .......... 210
Dynamic radar cruise control with full-speed range .......... 248
LTA (Lane Tracing Assist).... 235
PCS (Pre-Collision System) . 227
RSA (Road Sign Assist) ....... 245
TRAC (Traction Control) ........ 356
Traction Control (TRAC) ........ 356
Trailer sway control ............... 356
Trailer towing .......................... 177
Transmission Automatic transmission ........ 197
Driving mode select switch... 347
S mode ................................. 199
Trip meters .......................... 82, 85
Troubleshooting In other situations ................. 492
When making/receiving a call........................................... 490
When registering/connecting a cellular phone ..................... 489
When using the Bluetooth
® mes-
sage function ...................... 491
When using the hands-free sys-
tem with a Bluetooth
® device
........................................... 489
When using the phonebook . 490
Turn signal lights Replacing light bulbs ............ 604
Turn signal lever................... 200
Wattage ................................ 670
U
USB charging ports ................538
USB memory ...........................428
USB port ..................................418
Utility vehicle pre cautions .....365
V
Vanity lights
Vanity lights ..........................536
Vanity mirrors .........................536
Vehicle button (Setup screen) ...............................................376
Vehicle data recordings .............9
Vehicle identification number661
Vehicle Stability Control (VSC) ...............................................355
Ventilators (seat ventilators) .521
Voice button (Setup screen) ..376
Voice command system.........454 Voice command system opera-tion......................................455
VSC (Vehicle Stab ility Control)
...............................................355
W
Warning buzzers Approach warning ................255
Brake hold ............................627
Brake Override System ........627
Brake system ........................622
Downshifting .........................200
Drive-Start Control ................627
Electric power steering .........624
High coolant temperature .....623
Intuitive parking assist OFF indi- cator ...................................625
Intuitive parking assist ..........270
Low engine oil pressure .......623
LTA (Lane Tracing Assist) ..235, 625

730Alphabetical Index
LTA indicator ........................ 625
Open door ............................ 111
Open hood ........................... 111
Open window ....................... 156
PKSB OFF indicator ............. 626
Pre-collision warning ............ 227
RCTA (Rear Cross Traffic Alert) ........................................... 260
RCTA OFF indicator............. 626
Seat belt reminder ................ 629
Vehicle sway warning........... 239
Warning lights ABS ...................................... 624
Brake hold operated indicator........................................... 627
Brake Override System ........ 627
Brake system ....................... 622
Charging system .................. 622
Drive-Start Control ............... 627
Electric power steering ......... 624
Engine .................................. 623
High coolant temperature ..... 623
Inappropriate pedal operation ........................................... 627
Intuitive parking assist OFF indi- cator ................................... 625
Low engine oil pressure ....... 623
Low fuel level ....................... 628
LTA indicator ........................ 625
Malfunction indicator lamp ... 623
Parking brake indicator ........ 628
PCS warning light................. 624
PKSB (Parking Support Brake) ........................................... 626
PKSB OFF indicato r ............. 626
RCTA OFF indicator............. 626
Seat belt reminder light ........ 629
Slip indicator......................... 627
SRS ...................................... 623
Stop & Start cancel indicator 625
Tire pressure ........................ 628
Warning messages ................ 633 Washer
Checking ..............................578
Low washer fluid warning mes-sage............................578, 633
Preparing and checking before winter ..................................362
Switch ...........................214, 217
Washing and waxing ..............556
Weight Cargo capacity .............173, 176
Load limits ............................176
Weight ..................................660
Wheels .....................................590 Replacing wheels .................590
Size ......................................667
Wi-Fi
®.......................................398
Connecting a device to the in- vehicle access point ...........398
Operating hints .....................401
Wi-Fi
® button (Setup screen) 376
Wi-Fi
® Hotspot ........................398
Window glasses Power windows ....................155
Window lock switch ...............157
Windows Power windows ....................155
Rear window defogger .509, 516
Washer .........................214, 217
Windshield defog ger ......509, 516
Windshield wipers Intermittent windshield wipers...........................................214
Position.........................214, 217
Rain-sensing windshield wipers ...........................................214
Replacing the wiper insert ....594
Winter driving tips ..................362
Wiper insert .............................594
Wireless charger.....................539
Wireless remote control.........104 Battery-saving function .........128
Locking/Unlocking ................104
