± INTRODUCTIONFOR ALL OF VEHICLES
IN±11
11 Author: Date:
2005 SEQUOIA (RM1146U)
(c) SPIRAL CABLE (in Combination Switch)
The steering wheel must be fitted correctly to the steering
column with the spiral cable at the neutral position, other-
wise cable disconnection and other troubles may result.
Refer to D I ± 111 8 concerning correct steering wheel
installation.

B06331
Example:
CorrectWrong
Z13950
Example: IN±12
± INTRODUCTIONFOR ALL OF VEHICLES
12 Author: Date:
2005 SEQUOIA (RM1146U)
(d) STEERING WHEEL PAD (with Airbag)
(1) When removing the steering wheel pad or handling
a new steering wheel pad, it should be placed with
the pad top surface facing up.
Storing the pad with its metallic surface upward may
lead to a serious accident if the airbag inflates for
some reason. In addition do not store a steering
wheel pad on top of another one.
(2) Never measure the resistance of the airbag squib.
(This may cause the airbag to deploy, which is very
dangerous.)
(3) Grease should not be applied to the steering wheel
pad and the pad should not be cleaned with any
kind of detergents.
(4) Store the steering wheel pad where the ambient
temperature remains below 93°C (200°F), without
high humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) under the
steering column near the combination switch con-
nector before starting work.
(6) When disposing of a vehicle or the steering wheel
pad alone, the airbag should be deployed using an
SST before disposal (See page RS±23).
Carry out the operation in a safe place away from
electrical noise.

B12629
Example:
Correct Wrong
Z13951
Example:
± INTRODUCTIONFOR ALL OF VEHICLES
IN±13
13 Author: Date:
2005 SEQUOIA (RM1146U)
(e) FRONT PASSENGER AIRBAG ASSEMBLY
(1) Always store a removed or new front passenger air-
bag assembly with the airbag deployment side fac-
ing up.
Storing the airbag assembly with the airbag deploy-
ment side facing down could cause a serious acci-
dent if the airbag deploys.
(2) Never measure the resistance of the airbag squib
(This may cause the airbag to deploy, which is very
dangerous.).
(3) Grease should not be applied to the front passen-
ger airbag assembly and the airbag door should not
be cleaned with any kind of detergents.
(4) Store the airbag assembly where the ambient tem-
perature remains below 93°C (200°F), without high
humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) installed on
assembly before starting work.
(6) When disposing of a vehicle or the airbag assembly
alone, the airbag should be deployed using an SST
before disposal (See page RS±36).
Perform the operation in a safe place away from
electrical noise.

B02129
Example:Correct Wrong
B01546
Example: IN±14
± INTRODUCTIONFOR ALL OF VEHICLES
14 Author: Date:
2005 SEQUOIA (RM1146U)
(f) SIDE AIRBAG ASSEMBLY
(1) Always store a removed or new side airbag assem-
bly with the airbag deployment side facing up.
Storing the airbag assembly with the airbag deploy-
ment side facing down could cause a serious acci-
dent if the airbag inflates.
(2) Never measure the resistance of the airbag squib
(This may cause the airbag to deploy, which is very
dangerous.).
(3) Grease should not be attached to the side airbag
assembly and the surface should not be cleaned
with any kind of detergents.
(4) Store the airbag assembly where the ambient tem-
perature remains below 93°C (200°F), without high
humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) under the
seat before starting work.
(6) When disposing of a vehicle or the side airbag as-
sembly alone, the airbag should be deployed using
an SST before disposal (See page RS±50 or
RS±65).
Perform the operation in a safe place away from
electrical noise.

H11622H12060B08604
Example:
CorrectWrong Clear Plastic Bag
R06952H12059B08605
Example:
± INTRODUCTIONFOR ALL OF VEHICLES
IN±15
15 Author: Date:
2005 SEQUOIA (RM1146U)
(g) CURTAIN SHIELD AIRBAG ASSEMBLY
(1) Always store a removed or new curtain shield air-
bag assembly in a clear plastic bag, and keep it in
a safe place.
NOTICE:
Protection bag is not reused.
CAUTION:
Never disassemble the curtain shield airbag assembly
(2) Never measure the resistance of the airbag squib
(This may cause the airbag to deploy, which is very
dangerous.).
(3) Grease should not be attached to the curtain shield
airbag assembly and the surface should not be
cleaned with any kind of detergents.
(4) Store the airbag assembly where the ambient tem-
perature remains below 93°C (200°F), without high
humidity and away from electrical noise.
(5) When using electric welding, first disconnect the air-
bag connector (yellow color and 2 pins) into the
instrument panel before starting work.
(6) When disposing of a vehicle or the curtain shield air-
bag assembly alone, the airbag should be deployed
using an SST before disposal (See page RS±73).
Perform the operation in a safe place away from
electrical noise.

B02121
Example: IN±16
± INTRODUCTIONFOR ALL OF VEHICLES
16 Author: Date:
2005 SEQUOIA (RM1146U)
(h) SEAT BELT PRETENSIONER
(1) Never measure the resistance of the seat belt pre-
tensioner (This may cause the seat belt pretension-
er activation which is very dangerous.).
(2) Never disassemble the seat belt pretensioner.
(3) Never install the seat belt pretensioner in another
vehicle.
(4) Store the seat belt pretensioner where the ambient
temperature remains below 80°C (176°F) and
away from electrical noise without high humidity.
(5) When using electric welding, first disconnect the
connector (yellow color and 2 pins) before starting
work.
(6) When disposing of a vehicle or the seat belt preten-
sioner alone, the seat belt pretensioner should be
activated before disposal (See page BO±166). Per-
form the operation in a safe place away from electri-
cal noise.
(7) The seat belt pretensioner is hot after activation, so
let it cool down sufficiently before the disposal.
However never apply water to the seat belt preten-
sioner.

F09750
DLC3
Ts
CG
± INTRODUCTIONFOR ALL OF VEHICLES
IN±17
17 Author: Date:
2005 SEQUOIA (RM1146U)
(i) AIRBAG SENSOR ASSEMBLY
(1) Never reuse the airbag sensor assembly involved
in a collision when the SRS has deployed.
(2) The connectors to the airbag sensor assembly
should be connected or disconnected with the sen-
sor mounted on the floor. If the connectors are con-
nected or disconnected while the airbag sensor as-
sembly is not mounted to the floor, it could cause
undesired ignition of the supplemental restraint sys-
tem.
(3) Work must be started after 90 seconds from the
time the ignition switch is turned to the ºLOCKº posi-
tion and the negative (±) terminal cable is discon-
nected from the battery, even if only loosening the
set bolts of the airbag sensor assembly.
(j) WIRE HARNESS AND CONNECTOR
The SRS wire harness is integrated with the cowl wire har-
ness assembly and floor wire harness assembly. All the
connectors for the system are also a standard yellow col-
or. If the SRS wire harness becomes disconnected or the
connector becomes broken due to an accident, etc., re-
pair or replace it.
2. FOR VEHICLES EQUIPPED WITH VEHICLE SKID
CONTROL (VSC) SYSTEM
NOTICE:

Even if TRAC is initially OFF, it automatically be-
comes ON when the vehicle speed becomes about 30
km/h (19 mh) or more. Therefore, please drive in the
test mode to avoid dangerous situations caused by
the TRAC control.

VSC/ABS may be failed when the vehicle is driven on
the two±wheel chassis dynamo. Therefore, after driv-
ing on the chassis dynamo, please clear DTC before
normal driving. Please refer to the page DI±899 for the
method of clearing DTC.

Fasten the vehicle with the lock chain.
(a) Confirm VSC system is OFF.
(1) Turn the ignition switch OFF.
(2) Using SST, connect terminals Ts and CG of DLC3.
SST 09843±18040
(3) Start the engine.

B04770
IN±18
± INTRODUCTIONFOR ALL OF VEHICLES
18 Author: Date:
2005 SEQUOIA (RM1146U)
(4) Check that the VSC TRAC warning light blinks.
(5) After the measurement, remove the SST and re-
start the engine. At this time, make sure that the
VSC TRAC warning light is off.
(b) Notice in VSC operation.
(1) Removal and reinstallation of VSC±related compo-
nents may cause misadjustment of them. Do not re-
move or reinstall them unless necessary.
(2) When conducting VSC±related operations, do not
fail to make sure that the preparation and the finish-
ing of the operation are all performed in accordance
with the direction in this text.
3. FOR VEHICLES EQUIPPED WITH A CATALYTIC CONVERTER
CAUTION:
If a large amount of unburned gasoline flows into the converter, it may overheat and create a fire haz-
ard. To prevent this, observe the following precautions and explain them to your customer.
(a) Use only unleaded gasoline.
(b) Avoid prolonged idling.
Avoid running the engine at idle speed for more than 20 minutes.
(c) Avoid spark jump test.
(1) Perform spark jump test only when absolutely necessary. Perform this test as rapidly as possible.
(2) While testing, never race the engine.
(d) Avoid prolonged engine compression measurement.
Engine compression tests must be done as rapidly as possible.
(e) Do not run engine when fuel tank is nearly empty.
This may cause the engine to misfire and create an extra load on the converter.
(f) Avoid coasting with ignition turned off.
(g) Do not dispose of used catalyst along with parts contaminated with gasoline or oil.
4. IF VEHICLE IS EQUIPPED WITH MOBILE COMMUNICATION SYSTEM
For vehicles with mobile communication systems such as two±way radios and cellular telephones, observe
the following precautions.
(1) Install the antenna as far as possible away from the ECU and sensors of the vehicle's electronic
system.
(2) Install the antenna feeder at least 20 cm (7.87 in.) away from the ECU and sensors of the ve-
hicle's electronic systems. For details about ECU and sensor locations, refer to the section on
the applicable component.
(3) Do not wind the antenna feeder together with the other wiring as much as possible, also avoid
running the antenna feeder parallel with other wire harness.
(4) Check that the antenna and feeder are correctly adjusted.
(5) Do not install powerful mobile communication system.

± INTRODUCTIONFOR ALL OF VEHICLES
IN±19
19 Author: Date:
2005 SEQUOIA (RM1146U)
5. FOR USING OBD II SCAN TOOL OR TOYOTA HAND±HELD TESTER
CAUTION:
Observe the following for safety reasons:

Before using the OBD II scan tool or TOYOTA hand±held tester, the OBD II scan tool's instruc-
tion book or TOYOTA hand±held tester's operator manual should be read thoroughly.

Be sure to route all cables securely when driving with the OBD II scan tool or TOYOTA hand±
held tester connected to the vehicle. (i.e. Keep cables away from feet, pedals, steering wheel
and shift lever.)

Two persons are required when test driving with the OBD II scan tool or TOYOTA hand±held
tester, one person to drive the vehicle and one person to operate the OBD II scan tool or TOYO-
TA hand±held tester.

IN0KK±01
IN±20
± INTRODUCTIONFOR ALL OF VEHICLES
20 Author: Date:
2005 SEQUOIA (RM1146U)
INITIALIZATION
NOTICE:
When disconnecting the battery terminal, initialize the following systems after the terminal is recon-
nected.
System NameSee Step No.
Back Door Power Window Control SystemStep 1
INITIALIZE BACK DOOR POWER WINDOW CONTROL SYSTEM
NOTICE:
Resetting the power window regulator motor (initializing the pulse sensor) is necessary if: 1) the bat-
tery terminal cable is disconnected; 2) the back door ECU, wire harness, power window regulator
switch, power window regulator assembly and power window regulator motor are replaced or re-
moved/installed; or 3) the P/W fuse is replaced or removed. If resetting is not performed, the master
switch assembly will not be able to operate the AUTO operation function, jam protection function and
remote operation function.
(a) Turn the ignition switch ON.
(b) Open the power window halfway by pressing the power window switch.
(c) Fully pull up on the switch until the power window is fully closed and continue to hold the switch for
at least 1 second.
(d) Check that the AUTO UP/DOWN function operates normally.
If the AUTO UP/DOWN function operates normally, reset operations are complete. If abnormal, follow the
steps (e) to (g) below.
(e) Disconnect the negative battery terminal cable for 10 seconds.
(f) Connect the battery terminal cable.
(g) Perform the steps (a) to (d) again.
