MA003±50
MA±4
± MAINTENANCEUNDER HOOD
51 Author: Date:
2005 SEQUOIA (RM1146U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTES

Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.

Every service item in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.

Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the FULL and LOW lines on the see±through reservoir.
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(2UZ±FE engine: See page CO±14)
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL
Check that the electrolyte level of all battery cells is between the upper and lower level lines on the case.
6. BRAKE AND CLUTCH FLUID LEVELS
Check that the brake and clutch fluid levels are near the upper level line on the see±through reservoirs.
7. ENGINE DRIVE BELTS
Check all drive belts for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL
(a) Check the level on the dipstick.
(b) The level should be in the HOT or COLD range depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
(a) Park the vehicle on a level surface.
(b) With the engine idling and the parking brake applied, shift the selector into all positions from the P to
L, and then shift into the P position.
(c) Pull out the dipstick and wipe off the fluid with a clean rag. Re±insert the dipstick and check that the
fluid level is in the HOT range.
(d) Do this check with the fluid at normal driving temperature (70 ± 80°C, 158 ± 176°F).
HINT:
Wait until the engine cools down (approx. 30 min.) before checking the fluid level after extended driving at
high speeds, in hot weather, in heavy traffic or pulling a trailer.
11. EXHAUST SYSTEM
(a) Visually inspect for cracks, holes or loose supports.
(b) If any change in the sound of the exhaust or smell of the exhaust fumes is noticed, find the cause and
correct.

MA004±18
P08488
Back Front
± MAINTENANCEENGINE
MA±5
52 Author: Date:
2005 SEQUOIA (RM1146U)
ENGINE
INSPECTION
HINT:
Perform the following procedures when the engine is cold.
1. REPLACE TIMING BELT
(See page EM±13)
2. INSPECT DRIVE BELT
(See page CH±1)
3. REPLACE SPARK PLUGS
(See page IG±1)
4. INSPECT AIR FILTER
(a) Visually check that the air cleaner element is not exces-
sively dirty, damaged or oily.
HINT:
Oiliness may indicate a stuck PCV valve.
If necessary, replace the air cleaner element.
(b) Clean the element with compressed air.
First blow from back side thoroughly, then blow off the
front side of the element.
5. REPLACE AIR FILTER
Replace the used air cleaner element with a new one.
6. REPLACE ENGINE OIL AND OIL FILTER
(See page LU±2)
7. REPLACE ENGINE COOLANT
(See page CO±2)
8. INSPECT CHARCOAL CANISTER
(See page EC±9)
9. REPLACE GASKET IN FUEL TANK CAP
(See page SF±33)
10. INSPECT FUEL LINES, CONNECTIONS, FUEL TANK
VAPOR VENT SYSTEM HOSES AND FUEL TANK
BAND
Visually inspect the fuel lines for cracks, leakage loose connec-
tions, deformation or tank band looseness.
11. INSPECT EXHAUST PIPES AND MOUNTINGS
Visually inspect the pipes, hangers and connections for severe
corrosion, leaks or damage.
12. INSPECT VALVE CLEARANCE
(See page EM±4)

MA0055
MA014±06
MA±6
± MAINTENANCEBRAKE
53 Author: Date:
2005 SEQUOIA (RM1146U)
BRAKE
INSPECTION
1. INSPECT BRAKE LINE PIPES AND BOOTS
HINT:
Inspect in a well±lighted area. Inspect the entire circumference
and length of the brake hoses using a mirror as required. Turn
the front wheels fully right or left before inspecting the front
brake.
(a) Check all brake lines and hoses for:

Damage

Wear

Deformation

Cracks

Corrosion

Leaks

Bends

Twists
(b) Check all clamps for tightness and connections for leak-
age.
(c) Check that the hoses and lines are clear of sharp edges,
moving parts and the exhaust system.
(d) Check that the lines installed in grommets pass through
the center of the grommets.
2. INSPECT FRONT AND REAR BRAKE PADS AND
DISCS
(Front pads: See page BR±25)
(Rear pads: See page BR±34)
HINT:
If a squealing or scraping noise occurs from the brake during
driving, check the pad wear indicator.
If there are traces of the indicator contacting the disc rotor, the
disc pad should be replaced.

B07270
MA04O±03
B07272
Drive Shaft Boots
B07271
Dust Cover
Z04824
A/T
OK if coolOK if hot
Add if coolAdd if hot
± MAINTENANCECHASSIS
MA±7
54 Author: Date:
2005 SEQUOIA (RM1146U)
CHASSIS
INSPECTION
1. INSPECT STEERING LINKAGE
(a) Check the steering wheel free play (See page SR±9).
(b) Check the steering linkage for looseness or damage.
Check that:

Tie rod ends do not have excessive play.

Dust seals are not damaged.

Boot clamps are not loose.
2. INSPECT SRS AIRBAG (See page RS±3)
3. INSPECT STEERING GEAR HOUSING OIL
Check the steering gear housing for oil leaks.
If leakage is found, check the cause and repair.
4. 4WD:
INSPECT DRIVE SHAFT BOOTS
Inspect the drive shaft boots for clamp looseness, grease leak-
age or damage.
5. INSPECT BALL JOINTS AND DUST COVERS
(a) Inspect the ball joints for excessive looseness.
(b) Inspect the dust cover for damage.
6. 2WD:
CHECK OIL LEVEL IN AUTOMATIC TRANSMISSION
AND DIFFERENTIAL
(a) Automatic transmission:
Check that the fluid level is in the ºHOTº range at the nor-
mal operating temperature (70 ± 80°C or 158 ± 176°F)
and add as necessary.
NOTICE:
Do not overfill.
Transmission fluid (A/T): See page
DI±524

B07273
Filler Plug
Differential
Z04824
A/T
OK if coolOK if hot
Add if coolAdd if hot
P23117
Filler Plug
Transfer
B07968
Differential
Front
RearFiller Plug
Filler Plug MA±8
± MAINTENANCECHASSIS
55 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Differential:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it reaches the bottom of the filler hole.
Differential oil: See page SA±129
7. 4WD:
CHECK OIL LEVEL IN AUTOMATIC TRANSMISSION,
TRANSFER AND DIFFERENTIAL
(a) Automatic transmission:
Check that the fluid level is in the ºHOTº range at the nor-
mal operating temperature (70 ± 80°C or 158 ± 176°F)
and add as necessary.
NOTICE:
Do not overfill.
Transmission fluid (A/T): See page DI±524
(b) Transfer:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it reaches the bottom of the filler hole.
Transfer oil: See page TR±4
(c) Differential:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it reaches the bottom of the filler hole.
Front differential oil: See page SA±38
Rear differential oil: See page SA±129

P23118Drain Plug Transfer
B07969
Differential
Front
RearDrain plug
Drain plug
B07952Drain Plug
MA0099
OK if coolOK if hot
Add if coolAdd if hot
± MAINTENANCECHASSIS
MA±9
56 Author: Date:
2005 SEQUOIA (RM1146U)
8. REPLACE TRANSFER AND DIFFERENTIAL OIL
(a) Transfer:
Remove the transfer cover.
(b) Remove the drain plug and drain the oil.
(c) Reinstall the drain plug securely.
(d) Add new oil until it reaches the bottom of the filler hole.
Transfer oil: See page TR±4
Front differential oil: See page SA-38
Rear differential oil: See page SA±129
9. REPLACE AUTOMATIC TRANSMISSION FLUID
(a) Remove the drain plug and drain the fluid.
(b) Reinstall the drain plug securely.
(c) With the engine OFF, add new fluid through the dipstick
tube.
Transmission fluid (A/T): See page DI±524
(d) Start the engine and shift the selector into all positions
from ºPº through ºLº and then shift into ºPº.
(e) With the engine idling, check the fluid level.
Add fluid up to the ºCOOLº level on the dipstick.
(f) Check that the fluid level is in the ºHOTº range at the nor-
mal operating temperature (70 ± 80°C or 158 ± 176°F)
and add as necessary.
NOTICE:
Do not overfill.
10. RECOAT FRONT WHEEL BEARINGS AND THRUST
BUSH
(a) Recoat the front wheel bearing with grease (See page
SA±28).

B13807
A: Propeller Shaft Spiders
B: Propeller Shaft Sliding YokesAB
A
A
MA0568
MA±10
± MAINTENANCECHASSIS
57 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Recoat the drive shaft thrust bush with grease (See page
SA±34).
11. 4WD:
LUBRICATE PROPELLER SHAFT AND TIGHTEN
BOLTS
(a) Lubricate the propeller shaft, referring to the lubrication
chart. Before pumping in grease, wipe off any mud and
dust on the grease fitting.
Grease grade:
Propeller shaft (Except Double±cardan joint)
Lithium base chassis grease NLGI No.2
(b) Tighten the bolts for propeller shaft.
(2WD: See page PR±5)
(4WD: See page PR±9)
12. ROTATE TIRE (See page SA±3)
13. TIGHTEN BOLTS AND NUTS ON CHASSIS AND BODY
(a) Tighten the following parts:

Seat mounting bolts
Torque:
37 N´m (375 kgf´cm, 27 ft´lbf)

B02100
± MAINTENANCECHASSIS
MA±11
58 Author: Date:
2005 SEQUOIA (RM1146U)

Leaf spring U±bolt mounting nuts
Torque: 133 N´m (1,350 kgf´cm, 98 ft´lbf )
(b) Under Severe Conditions:
In addition to the above maintenance items, check for
loose or missing bolts and nuts on the following.

Steering system

Drive train

Suspension system

Fuel tank mounts

Engine mounts, etc.
14. FINAL INSPECTION
(a) Check operation of body parts:

Hood:

Auxiliary catch operates properly

Hood locks securely when closed

Doors:

Door locks operate properly

Doors close properly

Seats:

Seat adjusts easily and locks securely in any
positions

Seat backs lock securely at any angle

Fold±down seat backs lock securely
(b) Road test:

Engine and chassis parts do not have abnormal
noises.

Vehicle does not wander or pull to one side.

Brakes work properly and do not drag.
(c) Be sure to deliver a clean vehicle and especially check:

Steering wheel

Shift lever knob

All switch knobs

Door handles

Seats

PP1D4±02
± PREPARATIONMAINTENANCE
PP±1
59 Author: Date:
2005 SEQUOIA (RM1146U)
MAINTENANCE
EQUIPMENT
MirrorBrake hose

PP1D5±02
PP±2
± PREPARATIONMAINTENANCE
60 Author: Date:
2005 SEQUOIA (RM1146U)
LUBRICANT
ItemCapacityClassification
Brake fluid±SAE J1703 or FMVSS No.116 DOT3
