DID9T±01
± DIAGNOSTICSAUDIO SYSTEM
DI±1979
2173 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
TermsMeaning
Physical addressThree±digit code (shown in hexadecimal) which is given to each component com-
prising the AVC±LAN.
Corresponding to the function, individual symbols are specified.
Logical addressTwo±digit code (shown in hexadecimal) which is given to each function comprising
the inner system of the AVC±LAN.
HINT:
Titles for each unit are stated in the following order: parts name (physical address) and [Name indicated on
the DTC display]
1. Radio receiver assy (physical address: 190) [AUDIO H/U]
(a) Logical address: 01 (Communication control)
DTCNameDiagnosisVerificationSee page
D6
*1Absence of Master
Component in which this code is recorded was
disconnected from system or master component
with ignition switch in ACC or ON.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
D8
*2
*5No Response to Connection
CheckComponent shown by sub code is or was discon-
nected from system after engine start.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±

DI±1980
± DIAGNOSTICSAUDIO SYSTEM
2174 Author: Date:
2005 SEQUOIA (RM1146U)D9
*1
Last Mode Error
Audio or visual component operated before en-
gine stop is or was disconnected with ignition
switch in ACC or ON.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DA
*5No Response to ON/OFF
Instruction
No response is identified when changing mode
(audio and visual mode change).
Sound and picture does not change by button op-
eration.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±

± DIAGNOSTICSAUDIO SYSTEM
DI±1981
2175 Author: Date:
2005 SEQUOIA (RM1146U)DB
*1
Mode Status ErrorDual alarm is detected.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DC
*3Transmission Error
Transmission to component shown by auxiliary
code has been failed.
(Detecting this DTC does not necessarily mean
actual failure.)
1. Power source circuit (Rear seat
audio controller). *6
2. Power source circuit (Multi±dis-
play controller sub±assy) *7
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
6. Replace stereo component am-
plifier assy.
7. Replace rear seat audio control-
ler. *6
8. Replace multi±display controller
sub±assy. *7DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DD
*4Master Reset (Momentary Inter-
ruption)After the engine was started, master component
was disconnected from system.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±

DI±1982
± DIAGNOSTICSAUDIO SYSTEM
2176 Author: Date:
2005 SEQUOIA (RM1146U)DE
*4
Slave Reset (Momentary Inter-
ruption)After the engine was started, component shown
by sub code was disconnected from system.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DF
*4Master Error
Due to defective cognition of component with a
display, master function is switched to audio
equipment.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
HINT:

*1: This code may be recorded depending on the battery condition or engine start voltage even if no
failure is detected.

*2: If the power connector is disconnected after the engine starts, this code is recorded after 180 se-
conds.

*3: This code may be stored if the ignition key is turned to the START position again with the engine
running.

*4: This code may be stored if the ignition key is held in the START position for 1 minute or more before
returning to the ON position.

*5: If the device is reported as not existing during verification, check the power source circuit and AVC±
LAN circuit for the device.

*6: w/ Rear seat audio system only.

*7: w/ Rear seat entertainment system only.

± DIAGNOSTICSAUDIO SYSTEM
DI±1983
2177 Author: Date:
2005 SEQUOIA (RM1146U)
Logical address: 01 (Communication control) continued
DTCNameDiagnosisVerificationSee page
E0
*1Registration Completion
Instruction ErrorºRegistration Completion Instructionº command
from master cannot be received.Since this DTC is provided for engi-
neering purposes, it may be de-
tected when no actual failure exists.
±
E2ON/OFF Instruction Parameter
ErrorError occurs in ON/OFF controlling command
from master component.Replace radio receiver assy.±
E3
*1Registration Request Transmis-
sion
Registration Request command is output from
component shown by sub code.
Receiving Connection Check Instruction, Regis-
tration Request command is output from sub±
master component.
Since this DTC is provided for engi-
neering purposes, it may be de-
tected when no actual failure exists.
±
E4
*1Multiple Frame AbortMultiple frame transmission is aborted.
Since this DTC is provided for engi-
neering purposes, it may be de-
tected when no actual failure exists.
±
HINT:

*1: This code may be recorded depending on the battery condition or engine start voltage even if no
failure is detected.
(b) Logical address: 61 (Cassette switch)
DTCNameDiagnosisVerificationSee page
40Mechanical Error of MediaMalfunction due to mechanical failure is identified.
Either that, or cassette tape is cut or entangled.1. Inspect cassette tape.
2. Replace radio receiver assy.±
±
(c) Logical address: 62 (CD player)
DTCNameDiagnosisVerificationSee page
42No Disc ReadoutDisc cannot be read.1. Inspect CD.
2. Replace radio receiver assy.±
±
44CD player ErrorError is detected in CD player.Replace radio receiver assy.±
47Detection of high temperatureHigh temperature is detected in CD player.
With ignition switch off, leave ve-
hicle in cool shaded place for a
while and recheck. After deleting
the DTC memory, if same code de-
tected, replace radio receiver assy.
±
48Detection of excess currentOver current is present in CD player.Replace radio receiver assy.±
(d) Logical address: 63 (In±dash CD changer)
DTCNameDiagnosisVerificationSee page
42No Disc ReadoutDisc cannot be read.1. Inspect CD.
2. Replace radio receiver assy.±
±
44CD player ErrorError is detected in CDDH.Replace radio receiver assy.±
47Detection of high temperatureHigh temperature is detected in CDCH.
With ignition switch off, leave ve-
hicle in cool shaded place for a
while and recheck. After deleting
the DTC memory, if same code de-
tected, replace radio receiver assy.
±
48Detection of excess currentOver current is present in CDCH.Replace radio receiver assy.±

DI±1984
± DIAGNOSTICSAUDIO SYSTEM
2178 Author: Date:
2005 SEQUOIA (RM1146U)
2. Stereo component amplifier assy (physical address: 440) [DSP±AMP]
Logical address: 01 (Communication control)
DTCNameDiagnosisVerificationSee page
D6
*1Absence of Master
Component in which this code is recorded was
disconnected from system with ignition in ACC or
ON. Either that, or radio receiver assy was dis-
connected when this code was recorded.
1. Power source circuit (Radio re-
ceiver assy).
2. Power source circuit (Stereo
component amplifier assy).
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *5
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *6
6. Replace radio receiver assy.
7. Replace stereo component am-
plifier assy.DI±1990
DI±1993
DI±2023
DI±2061
DI±2139
±
±
D7Communication Check Error
Component in which this code is recorded is or
was disconnected from system after engine start.
Either that, or radio receiver assy was discon-
nected when this code was recorded.
1. Power source circuit (Radio re-
ceiver assy).
2. Power source circuit (Stereo
component amplifier assy).
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *5
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *6
6. Replace radio receiver assy.
7. Replace stereo component am-
plifier assy.DI±1990
DI±1993
DI±2023
DI±2061
DI±2139
±
±
DC
*2Transmission Error
Transmission to component shown by auxiliary
code failed.
(Detecting this DTC does not necessarily mean
actual failure.)If same auxiliary code is recorded in
other components, check harness
for power supply and communica-
tion system of all components
shown by code.
±
DD
*3Master Reset (Momentary Inter-
ruption)After engine was started, radio receiver assy was
disconnected from system.
1. Power source circuit (Radio re-
ceiver assy).
2. Power source circuit (Stereo
component amplifier assy).
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *5
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *6
6. Replace radio receiver assy.
7. Replace stereo component am-
plifier assy.DI±1990
DI±1993
DI±2023
DI±2061
DI±2139
±
±

± DIAGNOSTICSAUDIO SYSTEM
DI±1985
2179 Author: Date:
2005 SEQUOIA (RM1146U)
Logical address: 01 (Communication control) continued
DTCNameDiagnosisVerificationSee page
DF
*4Master Error
Due to defective condition of component with a
display, master function is switched to audio
equipment.
Error occurs in communication between sub±
master (audio) and master component.
1. Power source circuit (Radio re-
ceiver assy).
2. Power source circuit (Stereo
component amplifier assy).
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *5
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *6
6. Replace radio receiver assy.
7. Replace stereo component am-
plifier assy.DI±1990
DI±1993
DI±2023
DI±2061
DI±2139
±
±
E0
*1Registration Completion
Instruction ErrorºRegistration Completion Instructionº command
from master cannot be received.Since this DTC is provided for engi-
neering purposes, it may be de-
tected when no actual failure exists.
±
E1
*1Audio processor ON errorWhile source equipment is operating, AMP output
stops.
1. Power source circuit (Radio re-
ceiver assy).
2. Power source circuit (Stereo
component amplifier assy).
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *5
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *6
6. Replace radio receiver assy.
7. Replace stereo component am-
plifier assy.DI±1990
DI±1993
DI±2023
DI±2061
DI±2139
±
±
E2ON/OFF Instruction Parameter
ErrorError occurs in ON/OFF controlling command
from radio receiver assy.Replace radio receiver assy.±
E3
*1Registration Request Transmis-
sionRegistration Request command is output from
slave component.Since this DTC is provided for engi-
neering purposes, it may be de-
tected when no actual failure exists.
±
HINT:

*1: This code may be recorded depending on the battery condition or engine start voltage even if no
failure is detected.

*2: This code may be stored if the ignition key is turned to the START position again with the engine
running.

*3: This code may be stored if the ignition key is held in the START position for one minute or more
before returning to the ON position.

*4: If the device is reported as not existing during verification, check the power source circuit and AVC±
LAN circuit for the device.

*5: w/ Rear seat audio system only.

*6: w/ Rear seat entertainment system only.

DI±1986
± DIAGNOSTICSAUDIO SYSTEM
2180 Author: Date:
2005 SEQUOIA (RM1146U)
3. Multi±display controller sub±assy (Physical address: 1F6) [RSE ECU, MAIN]
(a) Logical address: 01 (Communication control)
DTCNameDiagnosisVerificationSee page
21ROM ErrorAbnormal condition of ROM is detected.Replace multi±display controller
sub±assy.±
22ROM ErrorAbnormal condition of RAM is detected.Replace multi±display controller
sub±assy.±
D1
*1
Registered component discon-
nected
AVC±LAN transmitting abnor-
malitiesComponent shown by sub±code is or was discon-
nected from system with ignition switch in ACC or
ON.
Communication with component shown by sub±
code is not ensured when engine is started.
1. Power source circuit (Multi±dis-
play controller sub±assy).
2. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
3. Replace Multi±display controller
sub±assy.DI±2110
DI±2139
±
D7
*2No response to connection
checkComponent shown by sub±code is or was discon-
nected from system after engine started.
1. Power source circuit (Multi±dis-
play controller sub±assy).
2. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
3. Replace Multi±display controller
sub±assy.DI±2110
DI±2139
±
D7
*2AVC±LAN Communication
Check Error
Component in which this code is recorded is or
was disconnected from system after engine start.
Or, when recording this code, multi±display con-
troller was disconnected.
1. Power source circuit (Radio re-
ceiver assy).
2. Power source circuit (Multi±dis-
play controller sub±assy).
3. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
4. Replace Multi±display controller
sub±assy.DI±1990
DI±2110
DI±2139
±
D6
*1Absence of Master
Component in which this code is recorded has
been disconnected from system with ignition in
ACC or ON. Or, when this code was recorded,
multi±display controller was disconnected.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
3. Replace Multi±display controller
sub±assy.DI±1990
DI±2139
±
D7
*2Connection Check Error
Component in which this code is recorded has
been disconnected from system after engine start.
Or, when this code was recorded, multi±display
controller was disconnected.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
3. Replace Multi±display controller
sub±assy.DI±1990
DI±2139
±
DC
*3Transmission Error
Transmission to component shown by sub±code
has been failed.
(This code does not necessarily mean actual fail-
ure.)If same sub±code is recorded in
other component(s), check harness
for power supply and communica-
tion system of all components
shown by code.
±
DD
*4Master Reset (Momentary Inter-
ruption)Component that is to be master has been discon-
nected after engine start.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
3. Replace Multi±display controller
sub±assy.DI±1990
DI±2139
±

± DIAGNOSTICSAUDIO SYSTEM
DI±1987
2181 Author: Date:
2005 SEQUOIA (RM1146U)E0
*1
Registration Completion
Instruction ErrorºRegistration Completion Instructionº command
from master cannot be received.Since this DTC is provided for engi-
neering, it may be detected when no
actual failure exists.
±
E3
*1Registration Request Transmis-
sion

Registration Request command is output from
slave component.

Registration Request command is output from
sub±master component.Since this DTC is provided for engi-
neering, it may be detected when no
actual failure exists.
±
DF
*4Master Error
Due to defective condition of component with a
display, master function is switched to audio
equipment.
Error occurs in communication between sub±
master (audio) and master component.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy).
3. Replace Multi±display controller
sub±assy.DI±1990
DI±2139
±
E4
*1Multiple Frame AbortMultiple frame transmission is aborted.
Since this DTC is provided for engi-
neering purpose, it may be detected
when no actual failure exists.
±
HINT:

*1: Even if no failure is detected, this code may be stored depending on the battery condition or voltage
for starting an engine.

*2: This code is stored when 180 sec. has passed after the power supply connector is pulled out after
engine start.

*3: This code may be stored when the engine key is turned back to the ON position and then turned
again to the START position in 1 minute after engine start.

*4: This code may be stored when the engine key is turned back to the ON position and then turned
again to the START position after engine start.
Rear seat audio controller (Physical address: 1F4) [RSA]
(a) Logical address: 01 (Communication control)
DTCNameDiagnosisVerificationSee page
D6
*1Absence of Master
Component in which this code is recorded has
been disconnected from system with ignition in
ACC or ON. Or, when this code was recorded,
RSA panel was disconnected.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
D7
*2Connection Check Error
Component in which this code is recorded has
been disconnected from system after engine start.
Or, when this code was recorded, RSA panel was
disconnected.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
DC
*3Transmission Error
Transmission to component shown by sub±code
has been failed.
(This code does not necessarily mean actual fail-
ure.)If same sub±code is recorded in
other component(s), check harness
for power supply and communica-
tion system of all components
shown by code.
±
DD
*4Master Reset (Momentary Inter-
ruption)Component that is to be master has been discon-
nected after engine start.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±

DI±1988
± DIAGNOSTICSAUDIO SYSTEM
2182 Author: Date:
2005 SEQUOIA (RM1146U)E0
*1
Registration Completion
Instruction ErrorºRegistration Completion Instructionº command
from master cannot be received.Since this DTC is provided for engi-
neering, it may be detected when no
actual failure exists.
±
E3
*1Registration Request Transmis-
sion

Registration Request command is output from
slave component.

Registration Request command is output from
sub±master component.Since this DTC is provided for engi-
neering, it may be detected when no
actual failure exists.
±
DF
*4Master Error
Due to defective condition of component with a
display, master function is switched to audio
equipment.
Error occurs in communication between sub±
master (audio) and master component.1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
E4
*1Multiple Frame AbortMultiple frame transmission is aborted.
Since this DTC is provided for engi-
neering purpose, it may be detected
when no actual failure exists.
±
D8
*2No Response To Connection
CheckComponent shown by sub±code is or had been
disconnected from system after engine start.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
D9
*1Last Mode Error
Component operated (sound and/or image was
provided) before engine stop is or was discon-
nected with ignition switch in ACC or ON.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
DANo Response to ON/OFF
Instruction
No response is identified when changing mode
(audio and visual mode change).
Detected when sound and picture does not
change by button operation
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
DB
*1Mode Status ErrorDual alarm is detected.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
DC
*4Transmission Error
Transmission to component shown by sub±code
has been failed.
(This code does not necessarily mean actual fail-
ure.)If same sub±code is recorded in
other component(s), check harness
for power supply and communica-
tion system of all components
shown by code.
±
DE
*3Slave Reset (Momentary Inter-
ruption)After engine start, slave component has been dis-
connected.
1. Power source circuit (Radio re-
ceiver assy).
2. AVC±LAN (Radio receiver assy
± Rear seat audio controller).
3. Replace Rear seat audio control-
ler.DI±1990
DI±2061
±
HINT:

*1: Even if no failure is detected, this code may be stored depending on the battery condition or voltage
for starting the engine.
