± BODYREAR NO.1 SEAT (Split Type RH)
3703 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
REMOVE REAR NO.1 SEAT
(a) Fold the seatback down.
(b) Unlock the seat lock, and swing the whole seat up and forward.
(c) Using a screwdriver, remove the seat leg covers.
HINT:
Tape the screwdriver tip before use.
(d) Remove the 4 bolts and rear No.1 seat.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)

BO4SO±01
H17260
H17261
± BODYREAR NO.1 SEAT (Split Type RH)
BO±151
3704 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:

A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).

Tape the screwdriver tip before using it to remove the
parts.
1. REMOVE HEADREST
2. REMOVE RECLINING ADJUSTER RELEASE HANDLE
3. REMOVE NO. 1 REAR SEAT RECLINING COVER
(a) Remove the screw and No. 1 rear seat reclining cover.
(b) Employ the same manner described above to the other
side.
4. REMOVE SEATBACK ASSEMBLY
Remove the 4 bolts and seatback assembly.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
5. REMOVE SEATBACK COVER
(a) Remove the headrest supports.
(b) Remove the seatback frame from the seatback cover with
pad.
(c) Remove the seatback cover from the seatback pad.
6. REMOVE REAR SEAT CUSHION UNDER COVER
(a) Remove the screw and cushion.
(b) Remove the 7 screws and rear seat cushion under cover.
(c) Remove the screw and fold seat stopper band.

H17262
BO±152
± BODYREAR NO.1 SEAT (Split Type RH)
3705 Author: Date:
2005 SEQUOIA (RM1146U)
7. REMOVE LH REAR SEAT RECLINING ADJUSTER
AND REAR SEAT LOCK
(a) Unfasten the bolt, then remove the rear No. 1 seat inner
belt.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(b) Remove the bolt, 2 nut and LH rear seat reclining adjuster
with rear seat lock.
Torque:
bolt: 43 N´m (440 kgf´cm, 32 ft´lbf)
nut: 43 N´m (440 kgf´cm, 32 ft´lbf)
(c) Using a screwdriver, remove the E±ring, then remove the
LH rear seat reclining adjuster from the rear seat lock.
8. REMOVE RECLINING CONNECTING PIPE
9. REMOVE RH REAR SEAT RECLINING ADJUSTER
Remove the 2 nuts and RH rear seat reclining adjuster.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
10. REMOVE SEAT CUSHION COVER
(a) Remove the seat cushion cover with pad from the seat
cushion frame.
(b) Remove the seat cushion cover from the seat cushion
pad.
11. REMOVE REAR SEAT CUSHION HINGE
(a) Using a screwdriver, remove the E±ring.
(b) Remove the pin, bushings, spring, collar and rear seat
cushion hinge.
(c) Employ the same manner described above to the other
side.

BO4SP±01
± BODYREAR NO.1 SEAT (Split Type RH)
BO±153
3706 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
INSPECT RECLINING LOCK POSITION SLIPPING OFF
When reclining the seat, inspect that the RH and LH rear seat reclining adjusters are released at the same
time.
HINT:
When the reclining lock position slips off, disassemble the seat to adjust the position.

BO4SQ±01
BO±154
± BODYREAR NO.1 SEAT (Split Type RH)
3707 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO±151).

BO4SR±01
± BODYREAR NO.1 SEAT (Split Type RH)
BO±155
3708 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BO±150).

BO47L±04
H24392
Headrest
Headrest
Support
Seatback CoverSeatback Pad
Seatback Frame
Seat Cushion Cover
Seat Cushion Pad
Seat Cushion Frame
Rear No. 2 Seat Inner Belt
Seat AdjusterReclining Connecting Pipe
Reclining Adjuster
Release Handle Reclining Pedal Cover No. 2 Rear Seat
Reclining Cover No. 2 Seat Reclining
Adjuster
Hog Ring
Rear Seat Cushion
Under Cover
Seat Track Handle No. 2 Seat Leg Cover No. 2 Seat Leg Cover
Hog Ring No. 2 Rear Seat
Reclining Cover
N´m (kgf´cm, ft´lbf) : Specified torque

Non±reusable part
19 (195, 14)
43 (440, 32)
43 (440, 32)
43 (440, 32)
19 (195, 14)
42 (430, 31)
43 (440, 32)
Headrest
Support
Headrest
BO±156
± BODYREAR NO.2 SEAT
3709 Author: Date:
2005 SEQUOIA (RM1146U)
REAR NO.2 SEAT
COMPONENTS
HINT:
The procedures listed below are for the LH side.

BO47M±02
H16771
± BODYREAR NO.2 SEAT
BO±157
3710 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:

The procedures listed below are for the LH side.

A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).
1. REMOVE HEADRESTS
2. REMOVE RECLINING ADJUSTER RELEASE HANDLE
3. REMOVE RECLINING PEDAL COVER
4. REMOVE NO. 2 REAR SEAT RECLINING COVER
(a) Remove the screw.
(b) Remove the No. 2 rear seat reclining cover as shown in
the illustration.
(c) Employ the same manner described above to the other
side.
5. REMOVE SEATBACK ASSEMBLY
Remove the 4 bolts and seatback assembly.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
6. REMOVE SEATBACK COVER
(a) Remove the seatback cover with pad from the seatback
frame.
(b) Remove the seatback cover from the seatback pad.
7. REMOVE NO. 2 SEAT RECLINING ADJUSTER
Remove the 4 nuts, 2 No. 2 seat reclining adjusters and reclin-
ing connecting pipe.
8. REMOVE NO. 2 SEAT LEG COVERS
9. REMOVE RECLINING REMOVE CONTROL LEVER
10. REMOVE SEAT TRACK HANDLE
11. REMOVE REAR SEAT CUSHION UNDER COVER
12. REMOVE SEAT CUSHION ASSEMBLY
Remove the 4 screws and seat cushion assembly
Torque: 19 N´m (195 kgf´cm, 14 ft´lbf)
13. REMOVE SEAT CUSHION COVER
(a) Remove the rear No. 2 seat inner belt.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(b) Remove the seat cushion cover with pad from the seat
cushion frame.
(c) Remove the seat cushion cover from the seat cushion
pad.

BO47N±01
BO±158
± BODYREAR NO.2 SEAT
3711 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO±157).

BO47O±02
H16779
Adjustable AnchorCenter Pillar Garnish
Assist Grip
No. 2 Assist Grip Plug
Rear Door Opening
Trim Weatherstrip
Front Door
Opening Trim
WeatherstripRear Door Scuff Plate
Front Seat
Outer Belt Lower Center
Pillar Garnish
Front Door
Scuff Plate
Front Seat
Inner Belt
Front Seat
Inner Belt
Power seat adjuster type:
42 (430, 31)
42 (430, 31)
42 (430, 31)
42 (430, 31)
42 (430, 31)
42 (430, 31)
42 (430, 31)
42 (430, 31)
N´m (kgf´cm, ft´lbf) : Specified torque
42 (430, 31)
± BODYSEAT BELT
BO±159
3712 Author: Date:
2005 SEQUOIA (RM1146U)
SEAT BELT
COMPONENTS
