TOYOTA SEQUOIA 2001 Service Repair Manual

BO4RC±02
BO±140
± BODYREAR NO.1 SEAT (Separate Type)
3693 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (see page BO±136).

BO4SH±01
H16778
Rear Seat Shoulder Belt Cover
Rear Seat Shoulder
Belt GuideHeadrest
Armrest
Seatback Pad
Rear Seat
Protector No. 1 Reclining Cover
Seat Cushion Cover
Seat Cushion Pad
Seat Cushion FrameSeatback Frame
Rear Seatback
Protector
Seatback Cover
Hinge
Cover
RH Rear Seat Lock
LH Rear Seat Lock
43 (430, 32)
Hinge Cover
No. 1 Fold Seat
Lock Control CableFold Seat
Stopper Band
Seat Cushion
Under Cover Rear Seat
Cushion Cover LH
Cushion Seat Leg Cover
Rear Seat Cushion Hinge Rear Seat Stay Rear Seat
Cushion HingeRear No. 1 Seat
Inner Belt
Seat Adjuster
Control Cable
Hinge
Cover
Hinge Cover
Rear Seat
Outer Belt
Rear No. 1 Seat Inner Adjuster
Seat Inner
Bracket
Rear Seat
Cushion Cover RH
37 (380, 27)
37 (380, 27)N´m (kgf´cm, ft´lbf) : Specified torque

Non±reusable part
Reclining Adjuster
Release Handle No. 1 Reclining Cover
Rear No. 1
Seat Outer
Adjuster
42 (430, 31)
43 (440, 32)
42 (430, 31)
43 (440, 32)
42 (430, 31)
42 (430, 31)

Hog Ring

Hog Ring
± BODYREAR NO.1 SEAT (Split Type LH)
BO±141
3694 Author: Date:
2005 SEQUOIA (RM1146U)
REAR NO.1 SEAT (Split Type LH)
COMPONENTS

BO4SI±01
BO±142
± BODYREAR NO.1 SEAT (Split Type LH)
3695 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
REMOVE REAR NO.1 SEAT
(a) Fold the seatback down.
(b) Unlock the seat lock, and swing the whole seat up and forward.
(c) Using a screwdriver, remove the seat leg covers.
HINT:
Tape the screwdriver tip before use.
(d) Remove the 4 bolts and rear No.1 seat.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)

BO4SJ±01
H05304
H05321
± BODYREAR NO.1 SEAT (Split Type LH)
BO±143
3696 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:

A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).

Tape the screwdriver tip before using it to remove the
parts.
1. REMOVE HEADREST
2. REMOVE RECLINING ADJUSTER RELEASE HANDLE
3. REMOVE NO. 1 RECLINING COVERS
(a) Zip the seat cushion cover open.
(b) Remove the 2 screws and 2 No. 1 reclining covers.
4. REMOVE SEAT CUSHION UNDER COVER
(a) Remove the 2 screws and 2 seat cushion under covers.
(b) Remove the 10 screws and seat cushion under cover
sub±assembly.

H16762
H05324
H05730
H16763
BO±144
± BODYREAR NO.1 SEAT (Split Type LH)
3697 Author: Date:
2005 SEQUOIA (RM1146U)
5. REMOVE NO. 1 FOLD SEAT LOCK CONTROL CABLE
Remove the clamp and No. 1 fold seat lock control cable as
shown in the illustration.
6. REMOVE SEATBACK ASSEMBLY
(a) Remove the 3 screws and seat belt reclining detecting
part.
HINT:
At the time of reassembly, please refer to the following items.

Tighten the 2 screws on the seatback side.

Fold down the seatback forward and raise it up to the first
lock position.

Turn A to the rear side of the seat cushion for initial posi-
tioning.

Check visually that the reference holes are penetrated.

Tighten the screws on the cushion side of seat belt reclin-
ing detecting part.
(b) Remove the reclining connecting wire of LH side edge.

H05326
H05331
H16764
± BODYREAR NO.1 SEAT (Split Type LH)
BO±145
3698 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Remove the reclining connecting wire of RH side edge.
(d) Remove the 4 bolts and seatback assembly.
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
7. REMOVE ARMREST
8. REMOVE SEATBACK FRAME
(a) Using a screwdriver, remove the rear seat shoulder belt
cover.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 4 headrest supports
(c) Disengage the hooks, remove the seatback frame.
9. REMOVE SEAT ADJUSTER CONTROL CABLE
Remove the 2 clamps and seat adjuster control cable.

H16765
H16766
H07940
BO±146
± BODYREAR NO.1 SEAT (Split Type LH)
3699 Author: Date:
2005 SEQUOIA (RM1146U)
10. REMOVE REAR SEAT OUTER BELT
(a) Remove the 2 bolts and rear seat shoulder belt guide.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
HINT:
At the time of reassembly, please refer to the following item.
Install the shoulder belt guide to the seatback frame with a sit
the guide facing to the rear side of the vehicle.
(b) Remove the nut, 3 clamps and rear seat outer belt.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
11. REMOVE SEATBACK COVER
Remove the hog rings and seatback cover.
HINT:
At the time of reassembly, please refer to the following item.
When instaling hog rings, take care to prevent wrinkles as little
as possible.
12. REMOVE SEAT CUSHION FRAME
Remove the hog rings and seat cushion frame.
HINT:
At the time of reassembly, please refer to the following item.
When instaling hog rings, take care to prevent wrinkles as little
as possible.
13. REMOVE REAR NO. 1 SEAT ADJUSTER
(a) Remove the 2 bolts and rear No. 1 seat outer adjuster.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
(b) Remove the 2 bolts and rear No. 1 seat inner adjuster.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
(c) Remove the 4 screws and 2 hinges covers from the rear
No. 1 seat outer and inner adjusters.
(d) Remove the 2 screws and 2 reclining inner covers from
the rear No. 1 seat outer and inner adjuster.
14. REMOVE REAR SEAT STAY
Remove the 2 bolts and rear seat stay.
15. REMOVE REAR SEAT CUSHION HINGE
(a) Using a screwdriver, remove the spring nut and E±rings.
(b) Remove the 2 hinge pins, 2 cushion spacers, 2 cushion
support springs and 2 rear seat cushion hinges.
16. REMOVE LH REAR SEAT LOCK
Unfasten the bolt, then remove the inner belt and LH rear seat
lock.
17. REMOVE RH REAR SEAT LOCK
(a) Remove the screw and rear seat lock cover.
(b) Remove the bolt, seat belt anchor and inner belt.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(c) Remove the RH rear seat lock.

BO4SK±01
± BODYREAR NO.1 SEAT (Split Type LH)
BO±147
3700 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO±143).

BO4SL±01
BO±148
± BODYREAR NO.1 SEAT (Split Type LH)
3701 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BO±142).

BO4SM±01
H16770
Headrest
Headrest
Support
Seatback CoverSeatback Pad
Seatback Frame
Seat Cushion
Cover
Seat Cushion Pad
Seat Cushion
Frame
Fold Seat
Stopper Band Rear Seat
Lock
Seat Cushion
Under cover RH Rear Seat
Reclining Adjuster
Cushion Seat Leg CoverRear No. 1 Seat
Inner Belt
No. 1 Rear Seat
Reclining CoverReclining Adjuster
Release Handle
LH Rear Seat
Reclining Adjuster
No. 1 Rear Seat
Reclining Cover
43 (440, 32)
Reclining
Connecting Pipe
42 (430, 31)
37 (380, 27)
37 (380, 27)
N´m (kgf´cm, ft´lbf) : Specified torque
43 (440, 32)
43 (440, 32)
43 (440, 32)
± BODYREAR NO.1 SEAT (Split Type RH)
BO±149
3702 Author: Date:
2005 SEQUOIA (RM1146U)
REAR NO.1 SEAT (Split Type RH)
COMPONENTS
