± BODYFRONT SEAT (Manual Adjuster Type)
3683 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:

The procedures listed below are for the LH side.

A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).
1. Driver 's seat:
INSTALL SEAT POSITION SENSOR
(SEE PAGE RS±108)
2. INSTALL RH AND LH SEAT CUSHION LOWER
SHIELDS
3. INSTALL RH AND LH LOWER RECLINING ADJUSTER
INSIDE COVERS
(a) Install the LH lower reclining adjuster inside cover with the
screw.
(b) Perform the same procedure on the other side.
4. INSTALL RH AND LH UPPER RECLINING ADJUSTER
INSIDE COVERS
(a) Install the LH upper reclining adjuster inside cover with
the screw.
(b) Perform the same procedure on the other side.
5. INSTALL SEAT CUSHION COVER
Install the seat cushion cover to the seat cushion pad with the
hog rings.
HINT:
When installing the hog rings, take as much care as possible to
prevent wrinkles.
6. INSTALL SEAT CUSHION COVER AND PAD
(a) Install the seat cushion cover with seat cushion pad, and
latch the seat cushion cover hooks.

H24336
H24335
H24319
H24339Hog Ring
H24338Hog Ring
± BODYFRONT SEAT (Manual Adjuster Type)
BO±131
3684 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Install the hog rings to the seat cushion cover.
(c) Install the clip.
(d) Perform the same procedure on the other side.
7. INSTALL SEATBACK COVER
(a) Install the seatback cover to the seatback pad.
(b) Install the 2 headrest supports.
(c) Turn up the seatback cover and install the hog rings.
8. INSTALL SEATBACK COVER AND PAD
(a) Install the seatback cover and pad to the seat frame as-
sembly.
(b) Install the hog rings to the seat frame assembly.
(c) Install the hog rings to the seat frame assembly.

H24861
H24337
H24316
H24334ClawsClip BO±132
± BODYFRONT SEAT (Manual Adjuster Type)
3685 Author: Date:
2005 SEQUOIA (RM1146U)
(d) w/ Side airbag:
Connect the seatback cover bracket to the seat frame as-
sembly with the nut.
Torque: 5.5 N´m (56 kgf´cm, 49 in.´lbf)
(e) Close the fastener.
(f) Install the hog rings to the seat frame assembly.
9. INSTALL ARMREST ASSEMBLY
(a) Install the spacer to the armrest assembly.
(b) Install the armrest assembly, armrest lock plate and arm-
rest spacer with the bolt.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
HINT:
Install the armrest lock plate as shown in the illustration.
(c) Install the armrest cap.
10. INSTALL FRONT SEAT INNER BELT.
(a) Install the front seat inner belt with the nut.
Torque: 42 N´m (430 kgf´cm, 32 ft´lbf)
(b) Connect the connectors and wire harness clamps.
11. INSTALL SEAT CUSHION INNER SHIELD
Install the seat cushion inner shield with the screw.

H24333
H24331ClawsClip
± BODYFRONT SEAT (Manual Adjuster Type)
BO±133
3686 Author: Date:
2005 SEQUOIA (RM1146U)
12. INSTALL VERTICAL ADJUSTER HANDLE
(a) Install the vertical adjuster handle with the 2 screws.
(b) Install the vertical adjuster handle cap.
13. INSTALL RECLINING ADJUSTER RELEASE HANDLE
14. INSTALL SEAT CUSHION OUTER SHIELD
Install the seat cushion outer shield with the screw.
15. INSTALL HEADREST

BO4SF±01
BO±134
± BODYFRONT SEAT (Manual Adjuster Type)
3687 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
HINT:
The procedures listed below are for the LH side.
1. INSTALL FRONT SEAT
(a) Mount the front seat to the vehicle.
NOTICE:
Be careful not to damage the vehicle body.
(b) w/ Side airbag:
Connect the airbag connector.
(c) Connect the connectors.
(d) Slide the front seat to the rearmost position.
(e) Tighten the bolts on the front side temporarily, starting from the bolt on the inner side.
(f) Tighten them completely.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
(g) Slide the front seat to the foremost position.
(h) Tighten the bolts on the rear side temporarily, starting from the bolt on the inner side.
(i) Tighten them completely.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
2. INSTALL SEAT TRACK COVERS
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. Passenger 's seat:
PERFORM PASSENGER OCCUPANT CLASSIFICATION SYSTEM ZERO POINT CALIBRATION
(See page DI±1128)
5. PERFORM INITIALIZATION (See page IN±20)
Some systems need initialization when disconnecting the cable from the negative battery terminal.

BO4R8±02
H24385
Headrest
Headrest
Support
Seatback CoverSeatback Pad
Seatback Frame
Seat Cushion
Cover
Seat Cushion Pad
Seat Cushion
Frame
Fold Seat
Stopper Band LH Rear Seat Lock
Seat Cushion
Under cover RH Rear Seat
Reclining Adjuster
Cushion Rear No. 1 Seat
Inner Belt
No. 1 Rear Seat
Reclining Cover
RHReclining Adjuster
Release Handle
LH Rear Seat
Reclining Adjuster
No. 1 Rear Seat
Reclining Cover LH
43 (440, 32)
Reclining
Connecting Pipe
42 (430, 31)
37 (380, 27)
37 (380, 27)
N´m (kgf´cm, ft´lbf) : Specified torque
43 (440, 32)
43 (440, 32)
43 (440, 32)
Seat Leg Cover LH Seat Leg
Cover RH
Hog Ring

Non±reusable part

Hog Ring
Fold Seat Lock Control Cable No. 1
Rear Seat Cushion
Hinge RH
Rear Seat Cushion
Hinge LH
43 (440, 32)
64 (653, 47)
RH Rear Seat Lock
± BODYREAR NO.1 SEAT (Separate Type)
BO±135
3688 Author: Date:
2005 SEQUOIA (RM1146U)
REAR NO.1 SEAT (Separate Type)
COMPONENTS
HINT:
The procedures listed below are for the RH side.

H23455
BO4R9±02
BO±136
± BODYREAR NO.1 SEAT (Separate Type)
3689 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
HINT:
The procedures listed below are for the RH side.
1. FOLD REAR SEAT RH
(a) Lower the headrest to the lowest position.
(b) Pull the seatback angle adjusting lever and fold the seat-
back down.
(c) Unlock the seat legs by pulling up one of the levers on the
seat legs, and swing the seat up and forward.
2. REMOVE REAR SEAT RH
(a) Using a screwdriver, remove the 2 seat leg covers.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 4 bolts and rear No.1 seat.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)

BO4SG±01
H17260
H23459
Hook
± BODYREAR NO.1 SEAT (Separate Type)
BO±137
3690 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
CAUTION:
Wear safety gloves, because the sharp edges and surfaces
of the seat frame may cause injury to the hands.
HINT:

The procedures listed below are for the RH side.

A bolt without a torque specification is shown in the stan-
dard bolt chart (see page SS±2).

Tape the screwdriver tip before using it to remove the
parts.
1. REMOVE HEADREST
2. REMOVE RECLINING ADJUSTER RELEASE HANDLE
3. REMOVE NO. 1 REAR SEAT RECLINING COVER
(a) Remove the screw and No. 1 rear seat reclining cover.
(b) Perform the same procedure on the other side.
4. REMOVE SEATBACK ASSEMBLY
(a) Tilt the seat forward.
(b) As shown in the illustration, disengage the hook and open
the seatback cover.
(c) Remove the 4 bolts and the seatback assembly.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
5. REMOVE SEATBACK COVER
(a) Remove the headrest supports.
(b) Disengage the hooks, and remove the seatback frame
from the seatback cover with pad.
(c) Remove the seatback cover from the seatback pad.
HINT:
At the time of reassembly, take as much care as possible to
minimize wrinkles when installing hog rings.

H17261
Hexagon
Bolt
H23461
BO±138
± BODYREAR NO.1 SEAT (Separate Type)
3691 Author: Date:
2005 SEQUOIA (RM1146U)
6. REMOVE REAR SEAT CUSHION UNDER COVER
(a) Using a 5 mm hexagon wrench, remove the bolt and
cushion.
(b) Remove the 6 screws and rear seat cushion under cover.
(c) Remove the screw and fold seat stopper band.
7. REMOVE FOLD SEAT LOCK CONTROL CABLE NO. 1
Using a screwdriver, remove the fold seat lock control cable No.
1.
HINT:
Tape the screwdriver tip before use.
8. REMOVE LH REAR SEAT RECLINING ADJUSTER
AND LH REAR SEAT LOCK
(a) Unfasten the bolt, then remove the rear No. 1 seat inner
belt.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(b) Remove the 2 nuts and LH rear seat reclining adjuster.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
(c) Remove the bolt and LH rear seat lock.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
9. REMOVE RECLINING CONNECTING PIPE
10. REMOVE RH REAR SEAT RECLINING ADJUSTER
Remove the 2 nuts and RH rear seat reclining adjuster.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
11. REMOVE SEAT CUSHION COVER
(a) Remove the seat cushion cover with pad from the seat
cushion frame.
(b) Remove the seat cushion cover from the seat cushion
pad.
HINT:
At the time of reassembly, take as much care as possible to
minimize wrinkles when installing hog rings.
12. REMOVE REAR SEAT CUSHION HINGE LH
(a) Using a screwdriver, remove the E±ring.
(b) Remove the pin, bushings, spring, collar and rear seat
cushion hinge.
(c) Remove the rear seat cushion hinge on the other side us-
ing the same procedures (a) and (b) described above.
13. REMOVE RH REAR SEAT LOCK
Remove the 2 bolts and RH rear seat lock.
Torque: 64 N´m (653 kgf´cm, 47 ft´lbf)

BO4RB±02
± BODYREAR NO.1 SEAT (Separate Type)
BO±139
3692 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (see page BO±137).
