AUX TOYOTA SEQUOIA 2009 2.G Navigation Manual

AUDIO/VIDEO SYSTEM
188
XS00309
1Function menu display screen
To control the radio, CD changer or
DVD player, touch the touch−screen
buttons. For details, see page 192.
2“TUNE·FILE” knob
Turn this knob to move the station
band and files up or down. For de-
tails, see pages 195 and 213.
3“FM 1·2” button
Push this button to choose an FM sta-
tion. For details, see pages 191 and
195.
4“AM·SAT” button
Push this button to choose an AM or
SAT station. For details, see pages
191, 195 and 199.
5“DISC·AUX” button
Push this button to turn the CD
changer, DVD player and AUX on.
For details, see pages 191, 194, 208
and 219.
6“SCAN” button
Push this button to scan radio sta-
tions. For details, see pages 196,
210, 215, 221 and 224.
7“AUDIO” button
Push this button to display the audio
control screen. For details, see page
190.
8“LOAD·/CLOSE” button
Push this button to display the
“LOAD·EJECT” screen or close the
display. For details, see page 205.
9“SEEK/TRACK” button
Push either side of this button to seek
up or down for a station, or to access
a desired track, file or chapter. For
details, see pages 196, 209, 213, 220
and 223.
10“PWR·VOL” knob
Push this knob to turn the audio sys-
tem on and off, and turn it to adjust the
volume. For details, see page 190.
Quick reference

AUDIO/VIDEO SYSTEM
191
XS00311
Push “AM·SAT”, “FM1·2” or
“DISC·AUX” button to turn on the
desired mode. The selected mode
turns on immediately.
Push these buttons if you want to switch
from one mode to another.
If the disc is not set, the CD changer does
not turn on.
You can turn off the CD changer by eject-
ing all the discs. If the audio system was
previously off, then the entire audio system
will be turned off when you eject all the
discs. If the other function was previously
playing, it will come on again.
6U5001F
6U5002F
6U5014F
6U5003F

AUDIO/VIDEO SYSTEM
194
(f) Your CD changer
When you insert a disc, touch “LOAD” and
gently push the disc in with the label side
up. This CD changer can store up to four
discs. The changer will play from track 1
through to the end of the disc. Then it will
play from track 1 of the next disc.
The changer is intended for use with 12 cm
(4.7 in.) discs only.
XS00312
NOTICE
Do not stack up two discs for inser-
tion, or it will cause damage to the
changer. Insert only one disc into
slot at a time.
Never try to disassemble or oil any
part of the changer. Do not insert
anything other than a disc into the
slot.
(g) Your DVD player
(with rear seat entertainment system)
The sound of the rear seat entertainment
system can be enjoyed by pushing the
“DISC·AUX” button.
(h) AUX adapter
The sound of portable audio players
connected to the AUX adapter can be
enjoyed. Push the “DISC·AUX” button to
switch to AUX mode. For details, refer to
the “Owner’s Manual”.

AUDIO/VIDEO SYSTEM
208
XS00317
(c) Playing a disc
Push the “DISC·AUX” button if the
discs are already loaded in the changer.
“CD CHANGER” appears on the screen.
The discs set in the changer are played
continuously, starting with the last disc you
inserted. The disc number of the disc cur-
rently being played, the track number and
the time from the beginning of the program
appear on the screen.
When play of one disc ends, the first track
of the following disc starts. When play of
the final disc ends, play of the first disc
starts again.
The changer will skip any empty disc trays.
Vehicles with rear entertainment system
—
If the DVD player is turned on, push the
“DISC·AUX” button again to switch to the
CD changer.
If the rear seat entertainment system is on,
pushing the “DISC·AUX” button switches
the sound of the front audio system and
that of the rear seat entertainment system.
6U5061F
(d) Selecting a desired disc
Touch the desired disc number on the
screen.
The selected disc number is highlighted.
The changer will start playing the selected
disc from the first track.

AUDIO/VIDEO SYSTEM
219
XS00317
(c) Playing a disc
Push the “DISC·AUX” button if a disc is
already loaded in the player.
“DVD” appears on the screen. (If the CD
changer is turned on, push the “DISC” but-
ton again to switch to the DVD player.)
6U5033F
(d) Operating an audio CD
PLAYING AN AUDIO CD
CD text only — The disc title and track title
will appear on the screen when pushing
the “DISC·AUX” button.
Push the “AUDIO” button to display
this screen.

INDEX
270
Numbers/Symbols
? button
30,42,88,89
. . . . . . . . . . . . . . . . . .
3 Routes selection 65
. . . . . . . . . . . . . . . . . .
A
Adaptive volume control 152
. . . . . . . . . . .
Adding a memo 126
. . . . . . . . . . . . . . . . . . .
Adding destinations 74
. . . . . . . . . . . . . . . .
Address button 42,47
. . . . . . . . . . . . . . . . . .
Alphabet key 26
. . . . . . . . . . . . . . . . . . . . . . .
AM·SAT button 188,191,195,200 . . . . . . . .
Angle mark 230
. . . . . . . . . . . . . . . . . . . . . . .
Area to avoid 103
. . . . . . . . . . . . . . . . . . . . . .
Arrow screen 35,70
. . . . . . . . . . . . . . . . . . . .
ASL 192
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls 240 . . . . . . .
Audio/video system operating hints 241
. . . . . . . . . . . . . . . . . . . . . . . . . . .
AUDIO button 188,190
. . . . . . . . . . . . . . . . .
Audio input 194
. . . . . . . . . . . . . . . . . . . . . . .
Audio language 231
. . . . . . . . . . . . . . . . . . .
Auto answer 154
. . . . . . . . . . . . . . . . . . . . . .
Auto Voice Guidance 89,115
. . . . . . . . . . .
Automatic sound levelizer 192
. . . . . . . . . .
Automatic transition 182
. . . . . . . . . . . . . . .
Automatic volume settings for high speed 152
. . . . . . . . . . . . . . . . . . . . . .
AUX adapter 194
. . . . . . . . . . . . . . . . . . . . . .
B
BASS 192
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Beep setting 184
. . . . . . . . . . . . . . . . . . . . . .
Bluetooth
129
. . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth information 171
. . . . . . . . . . . . .
Brightness 179
. . . . . . . . . . . . . . . . . . . . . . . .
Building information 38
. . . . . . . . . . . . . . . .
C
Calendar with memo 124
. . . . . . . . . . . . . . .
Calibration 89,117
. . . . . . . . . . . . . . . . . . . . .
Call back 139
. . . . . . . . . . . . . . . . . . . . . . . . .
Call by dial 137
. . . . . . . . . . . . . . . . . . . . . . . .
Call by dialed numbers 138
. . . . . . . . . . . . .
Call by phone book 137
. . . . . . . . . . . . . . . .
Call by POI 143
. . . . . . . . . . . . . . . . . . . . . . .
Call by received calls 139
. . . . . . . . . . . . . .
Call by speed dial 140
. . . . . . . . . . . . . . . . .
Call by voice recognition 140
. . . . . . . . . . .
Call on the Bluetooth
 phone 137 . . . . . . .
Categories 54 . . . . . . . . . . . . . . . . . . . . . . . . . CAUTION screen 24
. . . . . . . . . . . . . . . . . . .
CD changer operation 205 . . . . . . . . . . . . .
Cellular phone 129 . . . . . . . . . . . . . . . . . . . .
Change “Area Size” 107 . . . . . . . . . . . . . . .
Change “Icon” 97 . . . . . . . . . . . . . . . . . . . . . .
Change “Location” 100,106 . . . . . . . . . . . .
Change “Name” 99,105 . . . . . . . . . . . . . . . .
Change “Phone #” 101 . . . . . . . . . . . . . . . . .
Change “Quick Access” 98 . . . . . . . . . . . . .
Change button 42,44 . . . . . . . . . . . . . . . . . .
Change the route 64 . . . . . . . . . . . . . . . . . . .
Change the settings of the
Bluetooth
 phone 146
. . . . . . . . . . . . . . . .
Changing a “Device name” 172
. . . . . . . . .
Changing the angle 230
. . . . . . . . . . . . . . . .
Changing the audio language 230 . . . . . .
Changing the Bluetooth

settings 172 . . . . . . . . . . . . . . . . . . . . . . . .
Changing the map DVD −ROM 267 . . . . . .
Changing the security code 167 . . . . . . . .
Changing the subtitle language 229 . . . . .
Chapter 239 . . . . . . . . . . . . . . . . . . . . . . . . . .
City center 55 . . . . . . . . . . . . . . . . . . . . . . . . .
City name 52 . . . . . . . . . . . . . . . . . . . . . . . . . .
City to search 49,52 . . . . . . . . . . . . . . . . . . .
Color 179 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Command list 178 . . . . . . . . . . . . . . . . . . . . .
Compass mode 37 . . . . . . . . . . . . . . . . . . . .
Compass mode screen 35 . . . . . . . . . . . . .
Connecting a Bluetooth
 phone 135 . . . . .
Contrast 179 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coordinates button 42,62 . . . . . . . . . . . . . .
Current position as the search
point 55 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current position display 30 . . . . . . . . . . . . .
Current position/tire change
calibration 117 . . . . . . . . . . . . . . . . . . . . . .
Cursor position as a destination 32 . . . . .
Cursor position as a memory
point 32 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D
Daylight saving time 111
. . . . . . . . . . . . . . .
Dealer setting 122
. . . . . . . . . . . . . . . . . . . . .
Default 89,108
. . . . . . . . . . . . . . . . . . . . . . . .
Delete personal data 183
. . . . . . . . . . . . . .
Deleting “Quick Access” 99
. . . . . . . . . . . .
Deleting a Bluetooth
 phone 174 . . . . . . . .
Deleting a group name 165 . . . . . . . . . . . . .
Deleting all of the speed dial 148 . . . . . . .
Deleting all the group name 165 . . . . . . . .
Deleting all the phone data 162 . . . . . . . . .
Deleting all the speed tone 151 . . . . . . . . .
Deleting area to avoid 107 . . . . . . . . . . . . .

INDEX
271
Deleting destinations75
. . . . . . . . . . . . . . .
Deleting home 103
. . . . . . . . . . . . . . . . . . . .
Deleting memory points 101
. . . . . . . . . . . .
Deleting previous points 108
. . . . . . . . . . .
Deleting set destinations 75
. . . . . . . . . . . .
Deleting the log data 166
. . . . . . . . . . . . . . .
Deleting the phone data 161
. . . . . . . . . . . .
Deleting the speed dial individually 147
. . . . . . . . . . . . . . . . . . . . .
Deleting the speed tone individually 150
. . . . . . . . . . . . . . . . . . . . .
DEST button 10,42,43
. . . . . . . . . . . . . . . . .
Destination information 34
. . . . . . . . . . . . .
Destination screen 42,43
. . . . . . . . . . . . . .
Destination search 43
. . . . . . . . . . . . . . . . .
Destination search by “Address” 47 . . . . .
Destination search by “Coordinates” 62
. . . . . . . . . . . . . . . . . . . .
Destination search by “Emergency” 58
. . . . . . . . . . . . . . . . . . . . .
Destination search by
“Freeway Ent./Exit” 61
. . . . . . . . . . . . . . .
Destination search by “Intersection” 60
. . . . . . . . . . . . . . . . . . . .
Destination search by “Map” 59 . . . . . . . .
Destination search by “Memory” 58 . . . . .
Destination search by “Phone #” 62 . . . . .
Destination search by “POI Category” 54
. . . . . . . . . . . . . . . . . . .
Destination search by
“POI Name” 51
. . . . . . . . . . . . . . . . . . . . . .
Destination search by “Previous” 59 . . . .
Destination search by Home 46 . . . . . . . .
Destination search by Quick access 46
. . . . . . . . . . . . . . . . . . . . . . . . . .
Detour setting 77
. . . . . . . . . . . . . . . . . . . . . .
Dialing by name 141
. . . . . . . . . . . . . . . . . . .
Dialing by phone number 142
. . . . . . . . . . .
Disc slot 205,267
. . . . . . . . . . . . . . . . . . . . . .
DISC·AUX button 188,191,194,208,219
. . . . . . . . . . . . . . .
DISP button 10,179
. . . . . . . . . . . . . . . . . . . .
Display Building Shapes 89,113 . . . . . . . .
Display of building shape 113
. . . . . . . . . .
Display phone status 154
. . . . . . . . . . . . . .
Display POI Icons 80,89,112
. . . . . . . . . . .
Displaying DVD controls 227
. . . . . . . . . . .
Displaying the title and name 202 . . . . . . .
Displaying video CD controls 236 . . . . . . .
Distance 89,109
. . . . . . . . . . . . . . . . . . . . . . .
Distance and time to
destination 10,73
. . . . . . . . . . . . . . . . . . .
Distance unit 89,109
. . . . . . . . . . . . . . . . . . .
Dual map 36
. . . . . . . . . . . . . . . . . . . . . . . . . .
Dual map screen 35
. . . . . . . . . . . . . . . . . . .
DVD controls 227
. . . . . . . . . . . . . . . . . . . . . . DVD language
231
. . . . . . . . . . . . . . . . . . . .
DVD player and DVD video disc information 238
. . . . . . . . . . . . . . . . . . . . .
DVD player operation 217
. . . . . . . . . . . . . .
DVD video disc glossary 239
. . . . . . . . . . .
DVD video discs 238
. . . . . . . . . . . . . . . . . . .
E
Edit “Dealer” or “Contact” 123
. . . . . . . . . .
Edit “Location” 123
. . . . . . . . . . . . . . . . . . . .
Edit “Phone #” 124
. . . . . . . . . . . . . . . . . . . . .
Editing a group name 164
. . . . . . . . . . . . . .
Editing a memo 127
. . . . . . . . . . . . . . . . . . .
Editing area to avoid 104
. . . . . . . . . . . . . . .
Editing memory points 96
. . . . . . . . . . . . . .
Editing the name 157
. . . . . . . . . . . . . . . . . .
Editing the phone data 160
. . . . . . . . . . . . .
Editing the phone number 158
. . . . . . . . . .
Editing the speed tone 149
. . . . . . . . . . . . .
Eject button 206,218,267
. . . . . . . . . . . . . . .
Emergency button 42,58
. . . . . . . . . . . . . . .
Enter a Bluetooth
 phone 134
. . . . . . . . . .
Enter subtitle language code 232 . . . . . . .
Estimated arrival time 73
. . . . . . . . . . . . . .
Estimated travel time 73,89,109 . . . . . . . .
F
FILE button 213
. . . . . . . . . . . . . . . . . . . . . . .
FM button 188,191,195
. . . . . . . . . . . . . . . . .
FOLDER LIST button 212
. . . . . . . . . . . . . .
Foot print map 38
. . . . . . . . . . . . . . . . . . . . .
Foot print map button 10,38
. . . . . . . . . . . .
Freeway Ent./Exit button 42,61
. . . . . . . . .
Freeway information screen 35,68 . . . . . .
Function menu display screen 188 . . . . . .
Function help 30
. . . . . . . . . . . . . . . . . . . . . .
G
GPS 256
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GPS mark 10,256
. . . . . . . . . . . . . . . . . . . . .
Guidance screen for the freeway 35,69
. . . . . . . . . . . . . . . . . . . . . .
Guiding the route 17
. . . . . . . . . . . . . . . . . . .
H
Hands −free system 129 . . . . . . . . . . . . . . . .
Heading −up 10,39 . . . . . . . . . . . . . . . . . . . . .
Heading −up symbol 39 . . . . . . . . . . . . . . . .
Help 30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
