3315-1. Using the air conditioning system and defogger
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
■Button lock function
During the “SYNC” mode is on, the rear air conditioning system buttons will
be automatically locked. ( P. 322)
appears on the display when the buttons are locked.
To unlock the buttons, choose the “SYNC” mode is off.
NOTICE
■ To prevent battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
engine is stopped.

3325-1. Using the air conditioning system and defogger
SEQUOIA_OM_USA_OM0C013U_19MY
Seat heaters/seat ventilators
: If equipped
The seat heaters warm the seats and the seat ventilators main-
tain good airflow by blowing air through the seats.
WARNING
●Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physical ly chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
● Observe the following precautions to prevent the minor burns or overheat-
ing
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the sea t and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent battery discharge, do not use the functions when the engine is
off.

3335-1. Using the air conditioning system and defogger
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY■
Front seats
Vehicles without ventilator
On
The indicator light comes on.
Adjusts the seat temperature
The further you move the dial
upward, the warmer the seat
becomes.
Off
Move the dial fully downward.
The indicator light turns off.
Vehicles with ventilator
Off
Set the dial to 0. The indicator
turns off.
Heats the seats
The indicator comes on. The
higher the number, the warmer
the seats become.
Blows air from the seats
The indicator comes on. The
higher the number, the stronger
the airflow becomes.
Seat heaters/ventilators

3345-1. Using the air conditioning system and defogger
SEQUOIA_OM_USA_OM0C013U_19MY■
Rear seat (vehicles with rear console box)
High heating temperature
The indicator (yellow) comes
on.
Press lightly on the opposite
side to turn off.
Low heating temperature
The indicator (green) comes
on.
Press lightly on the opposite
side to turn off.
■The seat heaters/seat ventilators can be used when
The engine switch is in the “ON” position.

3355-2. Using the interior lights
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
Interior lights list
Outer foot lights (if equipped)
Interior light ( P. 338)
Personal/interior lights ( P. 3 3 7 )
Engine switch light
Footwell lights
Door courtesy lights
Auxiliary lighting

3365-2. Using the interior lights
SEQUOIA_OM_USA_OM0C013U_19MY
On
The personal/interior lights cannot
be individually turned off.
Door position
The personal/interior lights come
on when a door is opened. They
turn off when the doors are closed.
Off
The personal/interior lights and
interior light can be individually
turned on or off.
Personal/interior light main switch

3375-2. Using the interior lights
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY■
Front
Turns the lights on/off
■Center
Turns the lights on/off
■Rear
Turns the lights on/off
Personal/interior lights
Ty p e AType B

3385-2. Using the interior lights
SEQUOIA_OM_USA_OM0C013U_19MY
Door position on
The interior light comes on when a
back door is opened. It turns off
when the door is closed.
Off
On
■Illuminated entry system
The lights automatically turn on/off according to the engine sw itch position,
whether the doors are locked/unlocked, and whether the doors ar e open/
closed.
■ To prevent the battery from being discharged
If the lights remain on when the door is not fully closed and the personal/inte-
rior light main switch is in door position, the lights will go off automatically
after 20 minutes.
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be c hanged.
(Customizable features: P. 516)
Interior light
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than necessary when the engin e is not
running.

3395-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
List of storage features
Overhead console ( P. 344)
Glove boxes ( P. 340)
Auxiliary boxes ( P. 350)
Bottle holders ( P. 349)
Cup holders ( P. 345)
Rear console box
(if equipped) ( P. 342) Front console box (
P. 340)
• Card holder
• Map holder
• Pen holder
• Tissue pocket
Map holder ( P. 342)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into c ontact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may r elease
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, k eep the
lids closed. In the event of sudden braking or sudden swerving, an acci-
dent may occur due to an occupant being struck by an open lid o r the
items stored inside.

3405-3. Using the storage features
SEQUOIA_OM_USA_OM0C013U_19MY
Lower glove box: The glove box light turns on when the tail lig hts are on.
Lift the lid while pulling up the
knob to release the lock.
Glove boxes
Upper glove boxLower glove box
Open (push button) Unloc k with the master key
Lock with the master key
Open (pull the lever)
Front console box
